Operator’s Manual
Danfoss FT1555-BM230
Bench Mount Hose Capping System

Danfoss FT1555-BM230 Bench Mount Hose Capping System Operator’s Manual
2 | © Danfoss FT1555-BM230 Bench Mount Hose Capping System Operator’s Manual | 2023.04.
AQ453954047097en-010101
Table of Contents
Intended Use ...................................................................................................................................3
Packaging .........................................................................................................................................3
General ..............................................................................................................................................3
Safety ...............................................................................................................................3
Important Information ................................................................................................................ 3
Description of safety symbols in this manual .....................................................................3
Safety Symbols on the machine .............................................................................................. 4
Safety Precautions .........................................................................................................................4
Residual Risks ..................................................................................................................................4
Description and Operating Procedures ....................................................................5
Product Views (FRONT/ BACK/ SIDE) ......................................................................................5
Features & Benefits ....................................................................................................................... 5
Installation ....................................................................................................................................... 6
Operating procedures ................................................................................................................. 6
Capsule Application Process ..................................................................................................... 7
Specifications ..................................................................................................................................8
Machine Plate ................................................................................................................................. 9
Maintenance .................................................................................................................. 10
Air Filter maintenance ................................................................................................................. 10
Troubleshooting ............................................................................................................11
Repairs .............................................................................................................................11
Advised Spare parts ..................................................................................................................... 11
Modifications .................................................................................................................................. 13
Disposal .............................................................................................................................................13
RoHS ...................................................................................................................................................13

Danfoss FT1555-BM230 Bench Mount Hose Capping System Operator’s Manual
AQ453954047097en-010101 © Danfoss FT1555-BM230 Bench Mount Hose Capping System Operator’s Manual | 2023.04. | 3
Important Information
Before attempting to use the FT1555-BM230, read, understand,
and know all the safety information in this chapter. If you do not
follow all the warnings and procedures in this manual, it could lead
to serious injury to yourself or others. This CapSeal System was
designed with safety in mind and includes features to help prevent
injury and damage. This manual is intended to help you operate
the units in a safe manner. The operator / user is a person who
physically interacts with the unit and/or the unit’s control systems.
In this manual an operator / user includes a person who cleans the
machine. It is your responsibility to operate this system
in accordance with all the safety instructions and procedures in this
manual and with all other safety procedures in your workplace. It
is the user’s responsibility to make sure that the system is correctly
installed, configured, commissioned, operated, serviced, and
maintained so that such actions are only carried out by people
who have been properly trained for those tasks. It is also the user’s
responsibility to make sure that the machine is only used in full
accordance with laws - and regulations, which have the force of law
- in the jurisdiction in which the machine is installed.
Intended Use
The FT1555-BM230 is intended to only shrink CapSeal Capsules
onto a hose or tube fitting. Applications other than intended use
may void warranty.
Packaging
The CapSeal Machine is packed in cardboard for protection during
transportation. Remove all packaging materials before usage.
Dispose or recycle all packaging materials in accordance with the
local regulations.
General
When the machine is delivered, check the equipment for possible
transport damage and that all components are included.
Included Contents:
• CapSeal System FT1555-BM230
• CE manual
• FT1555-SMP (Small Magnetic Puck)
• FT1555-LMP (Large Magnetic Puck)
!
Safety
Description of safety symbols in this manual
Safety and Warning signs are attached to the machine to give safety information.
All Safety/Warning signs are repeated and usually further explained in this manual.
Mandatory: Read User Manual before using this system.
Use eye-protection
Caution! Burning hands or fingers when entering Air Knife
Caution! General warning sign
Caution! Hot surface
Caution! Electrical hazard
!

Danfoss FT1555-BM230 Bench Mount Hose Capping System Operator’s Manual
4 | © Danfoss FT1555-BM230 Bench Mount Hose Capping System Operator’s Manual | 2023.04.
AQ453954047097en-010101
Safety Symbols for the UC-CSS-203V-AK
HOT SURFACE HOT SURFACE
DO NOT PLACE FINGERS
IN AIR KNIFE OPENING
DO NOT PLACE FINGERS
IN AIR KNIFE OPENING
CAUTION
ELECTRICAL HAZARD
Safety Precautions
The following precautions must be followed when using the FT1555-BM230. Failure to follow warnings and fully understand the
operation of the FT1555-BM230 could cause serious injury to the operator or other personnel and may void warranty.
Before starting to use the FT1555-BM230 read the operation instructions and take care of the safety precautions as indicated.
Safety glasses are mandatory when operating the FT1555-BM230
The unit is never to be operated without safety cover(s) and heat guard removed.
Do not use the system until you are sure that the routine checks described have been completed and that the routine preventive
maintenance program is up-to-date. If any part of the system is known (or suspected) to be defective or wrongly adjusted do not
use the system until a repair has been made. Operation of the system with defective or wrongly adjusted components could create
safety hazards. This could lead to serious personal injury.
Do not touch the areas of the machine housing around the Air Knife/ Heat Guard, as these surfaces are hot and can cause burns.
Let the machine housing surfaces cool down before touching external surfaces of the machine.
Do not put your fingers or hand in the opening of the Air Knife, risk of burning fingers or hand.
*Be sure to keep the work area around the FT1555-BM230, clean and dry at all times.
Do not place any objects into the Air Knife other than ends of hose or tube assemblies with a CapSeal Capsule.
Residual Risks
!
Hazardous Situation Avoiding Warning Symbol
The Air Knife will become hot and could cause
burns to the skin
Do NOT touch while machine is in operation or
immediately after use, allow to cool.
Burning fingers at operating temperature
in the Air Knife FT1555-BM230 176˚C 350°F
Do NOT stick fingers into the Air Knife while in use.

Danfoss FT1555-BM230 Bench Mount Hose Capping System Operator’s Manual
AQ453954047097en-010101 © Danfoss FT1555-BM230 Bench Mount Hose Capping System Operator’s Manual | 2023.04. | 5
Product Views (Front / Back / Side)
Description and Operating Procedures
Features & Benefits
• Applies heated air to shrink CapSeal Capsules onto fitting ends
in less than one second
• Designed for CapSeal Capsules from 14mm ID through 80mm
ID
• Works with fitting hex sizes from 10mm through 78mm or any
other shape fitting within the size limitation of the capsule.
• The Air Knife with heat guard has a 110mm center opening
that allows multiple assembly ends to shrink at once with use
of the Magnetic Pucks.
• Magnetic Puck holds the Capsule onto the fitting for a perfect
seal during the shrinking process (Small 40mm / Large 64mm)
• Magnetic Puck pulls the swivel nut forward on 90° and 45°
fittings for easy insertion into the Air Knife for capsule shrinking
• Heating unit is thermocouple protected against overheating.

Danfoss FT1555-BM230 Bench Mount Hose Capping System Operator’s Manual
6 | © Danfoss FT1555-BM230 Bench Mount Hose Capping System Operator’s Manual | 2023.04.
AQ453954047097en-010101
Installation
• Position the machine in a clean, dry, well ventilated area and
away from any combustible materials.
• Keep a clear perimeter of 0.3m (12”) at both sides and 0.6m
(24”) at rear of machine.
• Do not place anything on top of this machine.
• Attach Air Knife/ Heat Guard to heatgun nozzle, using allen
wrench key size (3/16” or 4.5mm)
• Tampering with cord or socket may cause electrical issues and
void warranty.
• Connect the power cord to the correct electrical socket, make
sure the Power On/Off Switch on the CapSeal System is in the
Off position. (L6-15 NEMA twist lock)
Operating Procedures
Check the area around the machine and make sure that
everything is clear, clean and dry before turning the
FT1555-BM230 on.
• Set the Power On/Off switch in the on position. The Power
switch will light up green. From a cold start the machine will
take 8 minutes to reach the optimal sealing temperature.
(Consult Chart Below)
• Place the CapSeal Capsule over the fitting of the hose or tube
assembly. Place small or large puck onto the end fitting to
ensure no space between end fitting and capsule. Be sure
capsule is not extended over the edge of Puck for even heat
distribution
• Slowly insert fitting through the Air Knife with a forward
motion allowing the fitting to pass through the Air Knife. Then
with a backwards motion pull the fitting out of the Air Knife.
• Remove magnetic puck and inspect capsule to confirm that it
is shrunk securely onto the fitting
Do NOT leave the FT1555-BM230 unattended when in use.
!
!
Machine Warm-Up
time from cold start
WARM-UP TIME
(MIN)
SEAL TIME (SEC)
1
3.5
2
2.5
3
2
4
1.5
5
1.25
6
1
7
1
8
0.75
9
0.75
10
075
Capsule Application Process
Place correct size CapSeal Capsule
on the end of hose or tube fitting.
*Reference Size Chart.
Place magnetic puck onto the end of
fitting. Slowly move fitting through the
Air Knife until capsule is completely
shrunk.
Inspect fitting to ensure CapSeal Capsule
has shrunk properly.
Pull Tear Strip to remove CapSeal Capsule
from fitting.
FT1555-BM230

Danfoss FT1555-BM230 Bench Mount Hose Capping System Operator’s Manual
AQ453954047097en-010101 © Danfoss FT1555-BM230 Bench Mount Hose Capping System Operator’s Manual | 2023.04. | 7
CAPSULE SIZES
Inside Diameter
x Length in MM
HEX SIZES
COVERED
in mm
HEX SIZES
COVERED
in inches
STRAIGHT
ELBOW
14X24 10mm to 13mm .39" to 051" x x
16X24 12mm to 15mm .47" to .59" x x
18X24 14mm to 17mm .55" to .67" x x
20X23 15mm to 19mm .59" to .75" x
20X30 15mm to 19mm .59" to .75" x
22X24 18mm to 21mm .71" to .83" x
25X27 18mm to 24mm .71" to .94" x
25X40 18mm to 24mm .71" to .94" x
28X40 22mm to 26mm .87" to 1.14" x
31X33 24mm to 29mm .94" to 1.4" x
31X40 24mm to 29mm .95" to 1.14" x
34X40 27mm to 32mm 1.07" to 1.26" x
38X40 30mm to 36mm 1.19" to 1.42" x x
43X45 32mm to 41mm 1.26" to 1.61" x x
46X50 34mm to 44mm 1.34" to 1.73" x x
52X60 41mm to 50mm 1.62" to 1.97" x x
58X60 49mm to 56mm 1.93" to 2.20" x x
67X60 55mm to 65mm 2.16" to 2.56" x x
80X60 64mm to 78mm 2.52" to 3.07" x x
SIZING
*FITTING
CapSeal Capsule Sizing Chart Capsule Size Selection by Fitting
Specifications
Item Specication
Machine Dimensions (w x d x h)
FT1555-BM230
254 x 584.2 x 279.4 mm
Weight (net)
FT1555-BM230
9.57 Kg / 21.1 lbs
Voltage 230-240 VAC 50/60 Hz
Max Power consumption 3400W
Current 14.78 Amps
Set Temperature Heat Gun
FT1555-BM230
330 °C / 631 °F
Exterior temperature housing
FT1555-BM230
60-80 °C / 140-175 °F
Duty Cycle 100%
Noise Emission <65 dB(A)
Heating element life Approx. 500-800 hrs.
Electrical Connection Requirement 230-240V, 15 Amp, Grounded L6-15 NEMA twist lock

Danfoss FT1555-BM230 Bench Mount Hose Capping System Operator’s Manual
8 | © Danfoss FT1555-BM230 Bench Mount Hose Capping System Operator’s Manual | 2023.04.
AQ453954047097en-010101
Machine Plate
The Machine plate is located on the back side of the machine,
left of the power cord.
Wiring Diagram 230V-AK
FT1555-BM230 Exploded View
1
2
3
4
5
7
8
6
12
13
9 10
11
14
Item Description Part Number Quantity
1 2.0" Air Knife UC2.0-AK 1
2
Hot End Plate UC-HS-G3-HEP 1
3
Base UC-HS-G3-BASE 1
4
Cover UC-HS-G3-COVER 1
5divider
UC-HS-G3 DP 1
6
Heat Gun UC-HG5000E 1
7
Cradle UC-HS-G3-Cradle 1
8
Cold End Plate UC-HS-G3-CEP 1
9
Mag Plate UC-HS-G3-MP 1
10
Buffer Plate UC-HS-G3-BP 1
11
Rocker Switch UC-HS-SWITCH 1
12
Fan Guard and
Filter
UC-19155k22 1
13
Rubber Feet UC-2572k25 1
14
Cord Grip UC-MCG50A450 1
15
CORD UC-70615NP 1
16
insulation UC-9328k41 1
A A
B B
4
4
3
3
2
2
1
1
Exploded View of the
230V Clean Seal
System
DO NOT SCALE DRAWING
UC-CSS-230V-AK exploded view
SHEET 1 OF 1
8/11/22
JTC
UNLESS OTHERWISE SPECIFIED:
SCALE: 1:10
WEIGHT:
REV
DWG. NO.
B
SIZE
TITLE:
NAME
DATE
COMMENTS:
Q.A.
MFG APPR.
ENG APPR.
CHECKED
DRAWN
FINISH
MATERIAL
INTERPRET GEOMETRIC
TOLERANCING PER:
DIMENSIONS ARE IN INCHES
TOLERANCES:
FRACTIONAL
ANGULAR: MACH BEND
TWO PLACE DECIMAL
THREE PLACE DECIMAL
APPLICATION
USED ON
NEXT ASSY
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS
DRAWING IS THE SOLE PROPERTY OF
<INSERT COMPANY NAME HERE>. ANY
REPRODUCTION IN PART OR AS A WHOLE
WITHOUT THE WRITTEN PERMISSION OF
<INSERT COMPANY NAME HERE> IS
PROHIBITED.
FT1555-HH-AK20 Exploded View
1
2
3
4
1
5
6
7
Item Description Part Number quantity
1
Heat Guard
Assemnly
UC-HS-G3-HGA 2
2
Air Knife Back UC-HS-AKB 1
3
Air Knife Adapter UC-HS-G3-240ADP 1
4
Air Knife Front UC-HS-AKF 1
5
Ceramic Spacers UC-HS-G3-SPACER 8
6
Heat Absorbant
Gasket
UC-HS-G3-GSK 8
7
Ultra Low Profile
SHCS
1/4-20 X 1-1/4 Low
Profile SHCS
8
8
locking screw UC-1/4-20X1SHCS 1
9
locking nut UC-1/4-20nut 1
10
A A
B B
4
4
3
3
2
2
1
1
Exploded View
2.0 Air Knife
DO NOT SCALE DRAWING
UC2.0-AK
SHEET 1 OF 1
8/11/22
JTC
UNLESS OTHERWISE SPECIFIED:
SCALE: 1:5
WEIGHT:
REV
DWG. NO.
B
SIZE
TITLE:
NAME
DATE
COMMENTS:
Q.A.
MFG APPR.
ENG APPR.
CHECKED
DRAWN
FINISH
MATERIAL
INTERPRET GEOMETRIC
TOLERANCING PER:
DIMENSIONS ARE IN INCHES
TOLERANCES:
FRACTIONAL
ANGULAR: MACH BEND
TWO PLACE DECIMAL
THREE PLACE DECIMAL
APPLICATION
USED ON
NEXT ASSY
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS
DRAWING IS THE SOLE PROPERTY OF
<INSERT COMPANY NAME HERE>. ANY
REPRODUCTION IN PART OR AS A WHOLE
WITHOUT THE WRITTEN PERMISSION OF
<INSERT COMPANY NAME HERE> IS
PROHIBITED.

Danfoss FT1555-BM230 Bench Mount Hose Capping System Operator’s Manual
AQ453954047097en-010101 © Danfoss FT1555-BM230 Bench Mount Hose Capping System Operator’s Manual | 2023.04. | 9
Disconnect all incoming electrical power to the FT1555-BM230
before you start cleaning or maintaining the system. When
the cleaning or maintenance is complete, you may restore the power
supply.
Air Filter maintenance
Required tools: 5/64 or 2mm Allen wrench, coarse brush or vacuum
cleaner with brush. This maintenance procedure can be executed by
the operator of the machine.
The scheduled cleaning of CapSeal System Air Filters is
vitally important to the correct temperature and function
of the heating element and shrinking process. Without proper
air flow through the system, the heating element can overheat
which will cause internal damage and overheating of the CapSeal
Capsule. The amount of airborne contaminants varies from
location to location. Daily cleaning of the filter and air intake grill
is required when the machine is in use. If you have any questions
or concerns about the cleaning procedures or correct operation of
the unit, please contact us immediately at fpgproductsupport@
danfoss.com or your supplier outside the USA.
1. Turn off the power switch. Disconnect the FT1555-BM230 from the
power source and remove the unit from service.
2. Visually inspect the system for signs of overheating. Examples of
overheating may include discoloration of the stainless-steel cover,
cracked or peeling warning labels, or deformation of the rubber
foot mounts.
3. Remove the black plastic filter retainer on the end plate and
remove the foam filter. Wash the foam filter in warm water with
soap and dry completely.
4. Remove the 4 screws that hold the filter base in place, using a
2mm or 5/64” Allen Wrench (not included)
5. Use a coarse brush (not included) for removing any debris from
the heating elements’air intake grill that could obstruct air flow.
A vacuum cleaner with brush attachment is also acceptable for
cleaning.
6. Reinstall the foam filter and retainer.
7. Return the FT1555-BM230 to service (see page 4)
Maintenance
!
!

Danfoss FT1555-BM230 Bench Mount Hose Capping System Operator’s Manual
10 | © Danfoss FT1555-BM230 Bench Mount Hose Capping System Operator’s Manual | 2023.04.
AQ453954047097en-010101
All electrical components comply with the relevant safety regulations. Repairs to the electrical components should only be performed by a qualified
electrician. Otherwise, the user may run the risk of accidents.
Advised Spare parts
Troubleshooting
Repairs
Part Number Item Description Exploded view #
230V-AK 2.0 AK
UC-HG5000E HG5000E 230V Heat Gun 6
U C-19 55K 2 2 CSS- Plastic Fan Guard with Filter Insert 12
UC-2572K25 CapSeal System Bumper Feet 13
FT1555-SMP Small Puck
FT1555-LMP Large Puck
Problem Cause Solution
Capsule does not fit properly Wrong diameter capsule for application Measure outside diameter of the fitting and use
advised capsule.
Capsule doesn’t shrink Machine is turned off/ Not heated to max
temp.
Turn on machine as described in section 2.4
Reference Time chart on page 7
Capsules melt during shrinking
process
Temperature is too high.
Holding capsule in the AK for more than
5 seconds
Check foam filter and air inlet of the Heat gun.
Clean both filters as described under 3.1.
Check temperature settings. Display on heat
gun should read as follows:
FT1555-BM230 325-330ºC
Unit doesn’t blow air Faulty electrical
Overheating
Check breaker and power supply.
Check filters and clean as described under 3.1

Danfoss FT1555-BM230 Bench Mount Hose Capping System Operator’s Manual
AQ453954047097en-010101 © Danfoss FT1555-BM230 Bench Mount Hose Capping System Operator’s Manual | 2023.04. | 11
CapSeal Capsule Sizing Chart
Modifications
Do not attempt to make any modifications or alterations
to the machine without the prior express agreement of
Danfoss. Unauthorized modifications or alterations to the machine
could lead to serious personal injury.
Please call Danfoss with any questions regarding the safe operation of
the FT1555-BM230.
Disposal
Electrical and electronic equipment, accessories and packaging must be
recycled in an environmentally compatible manner. Ensure compliance
with local legislation, regulations, instructions and precautions
concerning health, safety and environment.
RoHS
All surface treatments and materials contained in the manufacturer’s
products do not contain any of the prohibited substances specified in
Directive 2011/65/EU.
!

12 | © Danfoss FT1555-BM230 Bench Mount Hose Capping System Operator’s Manual | 2023.04. AQ453954047097en-010101
Danfoss can accept no responsibility for possible errors in catalogs, brochures, and other printed material. Danfoss reserves the right to alter
its products without notice. This also applies to products already on order provided that such alterations can be made without subsequent
changes being necessary in specifications already agreed. All trademarks in this material are the property of the respective companies.
Danfoss and the Danfoss logotype are trademarks of Danfoss A/S. All rights reserved.
About Danfoss Power Solutions FC
Danfoss hoses, fittings, and tooling provide the ultimate fluid conveyance solutions
for a variety of equipment and applications around the world. We proudly engineer
to support a sustainable future for tomorrow.
To learn more please visit: http://www.danfoss.com/en/about-danfoss/our-businesses/
power-solutions
Danfoss Power Solutions
14615 Lone Oak Road
Eden Prairie, MN 55344, USA
Phone: [phone]
Danfoss Power Solutions (US) Company
2800 East 13th Street
Ames, IA 50010, USA
Phone: [phone]
Danfoss Power Solutions GmbH & Co.OHG
Krokamp 35
D-2439 Neumünster, Germany
Phone: [phone]
Danfoss Power Solutions ApS
Nordborgveg 81
DK-6430 Nordborg, Denmark
Phone: [phone]
Danfoss Power Solutions Trade (Shanghai) Co. Ltd.
Building #22, No 1000 Jin Hai Rd
Jin Qiao, Pudong New District
Shanghai, China 201206
Phone: [phone]w
