Danfoss AK-PI 100 User manual

Instructions
Woodley Protocol interface
AK-PI 100
RI8MK102 3-2008
-20°< tamb < 55°C
-0°F < tamb < 130°F
0 - 95% RH, non condensing
IP10 / VBG4
UL: E166834
AK-PI 100 installation:
See manual: RS8FB
Princip
Max. 199 addresses

2 Instructions RI8MK102 © Danfoss 3/2008 AK-PI 100 Woodley Protocol interface
DE-BD
Quick setup
The Product contains electrical components And may not be disposed together with domestic waste. Equipment must be separate collected with Electrical and Elec- tronic waste. According to Local and currently valid legislation.
The 24 V must not be
shared by other
controllers or units
The 24 V input must not
have earth connection
Supply voltage:
Transformer
Class II
e.g. 012 ( from 11 to 199)
1. Address = 000 (Factory setting)
2. Connect service tool
3. Configuration (IP and MDM/WTP). See manual.
4. Disconnect service tool
5. Set address on AK-PI 100
6. Connect to Woodley 4 way TPI card. (WTP) or to
Woodley MDM-PI (MDM)
7. Connect to AK-SC 255
8. AK-SC 255 configuration
a) Ethernet
b) I/O Network
c) Rescan
d) PI 100/ 200
e) Mark PI-address
f) Rescan
g) Configuration /Refrigeration / Add controls / Setup
Further information !
AK-PI 100 manual / AK-SC 255 manual
