Danfoss PLUS+1 DM1 00 Series Manual

Technical Information
PLUS+1® Mobile Machine Displays
DM1x00 Series
www.danfoss.com

Revision history Table of revisions
Date Changed Rev
October 2021 Minor typographical edits and statistical correction 0204
August 2021 Updated Machine wiring guidelings and LCD features 0203
December 2020 Corrected Pin Assignment tables 0202
December 2019 Under Pin assignments C1-C9, corrected tables for C5,C6, C7, and C8; and under DM1x00
Series Displays description, Dual core 1.2 GHz i.MX6 replaced with Dual core 800 MHz i.MX6
0201
October 2019 First edition 0101
Technical Information
PLUS+1 DM1x00 Series Displays
2 | ©Danfoss | October 2021 BC313277849405en-000204

DM1x00 literature references
Technical Information (TI)............................................................................................................................................................. 4
Data Sheet (DS)................................................................................................................................................................................. 4
PLUS+1®GUIDE User Manual....................................................................................................................................................... 4
Latest version of technical literature.........................................................................................................................................4
User liability and safety statements
OEM responsibility...........................................................................................................................................................................5
Safety statements.............................................................................................................................................................................5
Display operation guidelines..................................................................................................................................................5
Machine wiring guidelines...................................................................................................................................................... 7
Machine welding guidelines...................................................................................................................................................7
Overview DM1x00 Series Displays description..........................................................................................................................................8
Features..........................................................................................................................................................................................8
PLUS+1®GUIDE..................................................................................................................................................................................8
LCD features.......................................................................................................................................................................................9
Ordering information Model variants.................................................................................................................................................................................10
Model code.......................................................................................................................................................................................10
Model code key...............................................................................................................................................................................10
Related products............................................................................................................................................................................11
Input/output types and specifications
Specifications...................................................................................................................................................................................12
Input types........................................................................................................................................................................................12
Digital/analog..................................................................................................................................................................................13
Multifunction inputs.....................................................................................................................................................................13
CAN shield and analog input.....................................................................................................................................................16
Digital output..................................................................................................................................................................................16
CAN communication.....................................................................................................................................................................16
USB communication..................................................................................................................................................................... 17
RS232 communication.................................................................................................................................................................17
Sensor output..................................................................................................................................................................................17
Video power.....................................................................................................................................................................................17
Officially validated digital camera formats...........................................................................................................................17
Officially validated analog camera formats..........................................................................................................................18
Ethernet.............................................................................................................................................................................................18
Audio outputs................................................................................................................................................................................. 18
Wifi / Bluetooth...............................................................................................................................................................................19
Product ratings DM1x00 environmental testing criteria.................................................................................................................................20
Supply voltage/maximum current ratings........................................................................................................................... 20
Ingress Protection (IP) rating .................................................................................................................................................... 21
Installation DM1x00 Series Displays dimensions.......................................................................................................................................22
Button options................................................................................................................................................................................22
Pin assignments C1—C9............................................................................................................................................................. 23
Standard Mount..............................................................................................................................................................................25
Mounting panels cutouts............................................................................................................................................................26
RAM mount...................................................................................................................................................................................... 26
Fastening...........................................................................................................................................................................................26
Visibility and viewing radius...................................................................................................................................................... 27
Display faulty application recovery.........................................................................................................................................27
Cleaning............................................................................................................................................................................................ 27
Technical Information
PLUS+1 DM1x00 Series Displays
Contents
©Danfoss | October 2021 BC313277849405en-000204 | 3

Reference literature
Literature title Literature type Literature number
DM1x00 Series PLUS+1®Mobile Machine Displays Technical Information BC313277849405
DM1x00 Series PLUS+1®Mobile Machine Displays Data Sheet AI304864913574
PLUS+1®GUIDE Software User Manual AQ152886483724
Technical Information (TI)
A TI is comprehensive information for engineering and service personnel to reference.
Data Sheet (DS)
A DS is summarized information and parameters that are unique to a specific model.
PLUS+1®GUIDE User Manual
The Operation Manual (OM) details information regarding the PLUS+1®GUIDE tool used in building PLUS
+1®applications. This OM covers the following broad topics:
•How to use the PLUS+1®GUIDE graphical application development tool to create machine
applications
•How to configure module input and output parameters
•How to download PLUS+1®GUIDE applications to target PLUS+1®hardware modules
•How to upload and download tuning parameters
•How to use the PLUS+1®Service Tool
Latest version of technical literature
Comprehensive technical literature is online at www.danfoss.com
Technical Information
PLUS+1 DM1x00 Series Displays
DM1x00 literature references
4 | ©Danfoss | October 2021 BC313277849405en-000204

OEM responsibility
The OEM of a machine or vehicle in which Danfoss products are installed has the full responsibility for all
consequences that might occur. Danfoss has no responsibility for any consequences, direct or indirect,
caused by failures or malfunctions.
•Danfoss has no responsibility for any accidents caused by incorrectly mounted or maintained
equipment.
•Danfoss does not assume any responsibility for Danfoss products being incorrectly applied or the
system being programmed in a manner that jeopardizes safety.
•All safety critical systems shall include an emergency stop to switch off the main supply voltage for
the outputs of the electronic control system. All safety critical components shall be installed in such a
way that the main supply voltage can be switched off at any time. The emergency stop must be easily
accessible to the operator.
Safety statements
W
Warning
Unintended movement of the machine or mechanism may cause injury to the technician or bystanders.
Improperly protected power input lines against over current conditions may cause damage to the
hardware. Properly protect all power input lines against over-current conditions. To protect against
unintended movement, secure the machine.
W
Warning
At high ambient temperatures the metal housing can become hotter than 70℃. Please use caution when
touching the metal housing of the display
C
Caution
Unused pins on mating connectors may cause intermittent product performance or premature failure. Be
sure to plug all pins on mating connectors.
Display operation guidelines
•Disconnect your machine's battery power before connecting power and signal cables to the display.
•Before doing any electrical welding on your machine, disconnect all power and signal cables
connected to the display.
•Do not exceed the display power supply voltage ratings. Using higher voltages may damage the
display and can create a fire or electrical shock hazard.
•Do not use or store the display where flammable gases or chemicals are present. Using or storing the
display where flammable gases or chemicals are present may cause an explosion.
•Software configures the keypad buttons on the display. Do not use these buttons to implement
critical safety features. Use separate mechanical switches to implement critical safety features such as
emergency stops.
•Design systems that use the display so that a communication error or failure between the display and
other units cannot cause a malfunction that might injure people or damage material.
•The protective glass over the display screen will break if hit with a hard or heavy object. Install the
display to reduce the possibility of it being hit by hard or heavy objects.
•Storing or operating a display in an environment that exceeds the display specified temperature or
humidity rating may damage the display.
Technical Information
PLUS+1 DM1x00 Series Displays
User liability and safety statements
©Danfoss | October 2021 BC313277849405en-000204 | 5

•Always clean the display with a soft, damp cloth. Use a mild dishwashing detergent as needed. To
avoid scratching and discoloring the display, do not use abrasive pads, scouring powders, or solvents
such as alcohol, benzene, or paint thinner.
•Keep ambient light sensor area clean and uncovered for best operation.
•Danfoss graphical displays are not user serviceable. Return the display to the factory in case of failure.
Technical Information
PLUS+1 DM1x00 Series Displays
User liability and safety statements
6 | ©Danfoss | October 2021 BC313277849405en-000204

Machine wiring guidelines
•Protect wires from mechanical abuse, run wires in flexible metal or plastic conduits.
•Use 85˚ C (185˚ F) wire with abrasion resistant insulation and 105˚ C (221˚ F) wire should be
considered near hot surfaces.
•Use a wire size that is appropriate for the module connector.
•Separate high current wires such as solenoids, lights, alternators or fuel pumps from sensor and other
noise-sensitive input wires.
•Run wires along the inside of, or close to, metal machine surfaces where possible, this simulates a
shield which will minimize the effects of EMI/RFI radiation.
•Do not run wires near sharp metal corners, consider running wires through a grommet when
rounding a corner.
•Do not run wires near hot machine members.
•Provide strain relief for all wires.
•Avoid running wires near moving or vibrating components.
•Avoid long, unsupported wire spans.
•Ground electronic modules to a dedicated conductor of sufficient size that is connected to the
battery (-).
•Power the sensors and valve drive circuits by their dedicated wired power sources and ground
returns.
•Twist sensor lines about one turn every 10 cm (4 in).
•Use wire harness anchors that will allow wires to float with respect to the machine rather than rigid
anchors.
Machine welding guidelines
W
Warning
High voltage from power and signal cables may cause fire or electrical shock, and cause an explosion if
flammable gasses or chemicals are present.
Disconnect all power and signal cables connected to the electronic component before performing any
electrical welding on a machine.
The following is recommended when welding on a machine equipped with electronic components:
•Turn the engine off.
•Remove electronic components from the machine before any arc welding.
•Disconnect the negative battery cable from the battery.
•Do not use electrical components to ground the welder.
•Clamp the ground cable for the welder to the component that will be welded as close as possible to
the weld.
Technical Information
PLUS+1 DM1x00 Series Displays
User liability and safety statements
©Danfoss | October 2021 BC313277849405en-000204 | 7

DM1x00 Series Displays description
The Danfoss DM1x00 display series bring modern appearance and performance to mobile machine
markets with two display platforms, expanding the PLUS+1®family.
The DM1x00 series was developed for best operator viewability with its high brightness, optical bonding,
anti-glare, anti-reflection, oleophobic coating and wide viewing angles. It is equipped with an
outstanding dual core 800 MHz i.MX6 processor and 4GB flash memory delivering high performance.
Ruggedized for mobile machine markets, it is built to withstand harsh operating environments with its
IP66 and IP67 rating and the water-resistant screen allowing for multi-touch while wearing gloves.
The integrated file viewer and media player provides view of documents and media files on the run using
the audio line out to connect to the vehicle speaker system.
To meet specific needs, the DM1x00 includes two different screen sizes (10.1” and 12.1”) with optional
multi-touch and two button pad configurations with programmable back-lights and tactile feedback.
WiFi and Bluetooth®provide wireless channels for servicing the machine remotely.
Features
•4 CAN ports
•RS232 and USB 2.0 high-speed
•Ethernet
•Bluetooth®and WiFi, GNSS (optional)
•4 Camera inputs (Up to 2 displayed at one time)
•Audio line out
•Sensor supply out
•Optional keypad with either 8 buttons on each side (16 total) or 8 buttons plus navigation panel (16
total)
•Backlit buttons
•Touch screen (optional)
•Optical signal (2 RGB LEDs)
•Integrated ambient light sensor for automatically adjusting brightness to lighting conditions
•Ignition input
•Wake up over input
•Dual core 800 MHz i.MX6
‒4 GB Flash memory
•Media player and File viewer (PDF, JPG, MP3, MP4)
•PLUS+1®GUIDE programmable
•Real Time Clock (RTC)
•Rugged IP66 and IP67 rating
•2 Integrated DEUTSCH connectors
•Fast Start-up Time (less than 5 seconds)
•RAM®or Bracket (optional) mount (portrait or landscape)
•Integrated accelerometer for auto-adjusting between screen orientations
•32 MB App Log
PLUS+1®GUIDE
PLUS+1®GUIDE (Graphical User Integrated Development Environment) is a complete toolbox that
generates downloadable applications for all programmable PLUS+1®Compliant products.
A screen editor allows easy development of applications by programmers without formal software
development training. The expertise from a software engineer is not needed to find your way around in
PLUS+1®GUIDE.
Technical Information
PLUS+1 DM1x00 Series Displays
Overview
8 | ©Danfoss | October 2021 BC313277849405en-000204

C
Caution
Unwanted system failure may occur.
Refer to PLUS+1®GUIDE Software User Manual, AQ152886483724 for best programming practices.
https://www.danfoss.com/en/products/software/dps/plus1-software/plus1-guide/#tab-overview
LCD features
DM1000 LCD 10.1" screen
Description Value. Unit Notes
Screen Size 10.1 Inch
Resolution 1280 x 800 Pixels
Brightness 900 cd/m2 Value includes cover glass
Contrast Ratio 500:1
Viewing Angle ± 85 Degree vertical and horizontal
Color Depth 24 Bits 8 bits per color
DM1200 LCD 12.1" screen
Description. Value. Unit. Notes.
Screen Size 12.1 Inch
Resolution 1280 x 800 Pixels
Brightness 900 cd/m2 Value includes cover glass
Contrast Ratio 500:1
Viewing Angle ± 85 Degree vertical and horizontal
Color Depth 24 Bits 8 bits per color
Technical Information
PLUS+1 DM1x00 Series Displays
Overview
©Danfoss | October 2021 BC313277849405en-000204 | 9

Model variants
Part number Order code Description
11223953 DM1000-0-0-0-0 10.1", Non-Touch, No Buttons
11223954 DM1000-0-1-0-0 10.1", Non-Touch, No Buttons, WIFI/BT/GNSS
11223955 DM1000T-0-0-0-0 10.1", Touch, No Buttons
11223957 DM1000T-0-1-0-0 10.1", Touch, No Buttons, WIFI/BT/GNSS
11223958 DM1000-0-0-1-0 10.1", Non-Touch, 2x8 Buttons
11223956 DM1000-0-0-2-0 10.1", Non-Touch, 1x8 + Navigation Buttons
11223959 DM1000-0-1-1-0 10.1", Non-Touch, 2x8 Buttons, WIFI/BT/GNSS
11223960 DM1000-0-1-2-0 10.1", Non-Touch, 1x8 + Navigation Buttons, WIFI/BT/GNSS
11223961 DM1000T-0-0-1-0 10.1", Touch, 2x8 Buttons
11223965 DM1000T-0-0-2-0 10.1", Touch, 1x8 + Navigation Buttons
11223962 DM1000T-0-1-1-0 10.1", Touch, 2x8 Buttons, WIFI/BT/GNSS
11223966 DM1000T-0-1-2-0 10.1", Touch, 1x8 + Navigation Buttons, WIFI/BT/GNSS
11223963 DM1200T-0-0-0-0 12.1", Touch, No Buttons
11223964 DM1200T-0-1-0-0 12.1", Touch, No Buttons, WIFI/BT/GNSS
Mounting kits are not included. Please see Related Product section for ordering info.
Model code
A B C D E
DM1x00
Model code key
A—Model name Description
DM1000 10.1" Non-Touch
DM1000T 10.1" Touch
DM1200T 12.1" Touch
B—Not configured Description
0 NC
C—WIFI/BT/GNSS Description
0 Without WIFI/BT/GNSS
1 With WIFI/BT/GNSS
D—Buttons Description
0 No Buttons
1 2x8 Buttons
2 1x8 + Navigation Buttons
E—Not configured Description
0 NC
Technical Information
PLUS+1 DM1x00 Series Displays
Ordering information
10 | ©Danfoss | October 2021 BC313277849405en-000204

Related products
Connector kit
10100944 DEUTSCH 12-pin Connector Kit (DTM06-12SA)
Cable kits
11231512 Cable, M12 4-Pin to USB Device A code
11130713 Cable, M12 8-Pin to Lead Wires A code
11130712 Cable, M12 5-Pin to Lead Wires A code
Panel mounting kits
11224242 Panel mounting kit for 10" Display unit with no buttons
11224243 Panel mounting kit for 10" Display unit with buttons
11224244 Panel mounting kit for 12" Display unit
Software
11179523
(Annual renewal with 11179524 to keep the software
updates)
PLUS+1®GUIDE Professional Software (includes 1 year of
software updates, a single user license, Service and
Diagnostic Tool and Screen Editor)
Connection tools
10100744 DEUTSCH Extraction tool size 20 red
10100745 DEUTSCH solid contacts terminal crimp tool
Technical Information
PLUS+1 DM1x00 Series Displays
Ordering information
©Danfoss | October 2021 BC313277849405en-000204 | 11

Specifications
Characteristics/certifications
Processor 800 MHz i.MX6
RAM 512 MB
FRAM 32 kB
Supply voltage 9 to 36 VDC
Connector DEUTSCH DTM06-12SA and DTM06-12SB
Size 10.1" and 12.1"
Aspect ratio 16:10 wide view
Resolution 1280x800, IPS
Brightness 900 cd/m2
Contrast ratio 500:1
Viewing angle ±85° vertical and horizontal
Color depth 24 bit
IP rating IP66 and IP67 front and back
Operating temperature -30°C to +70°C [-22°F to +158°F]
Storage temperature -40°C to +85°C [-40°F to +185°F]
Weight DM1000: 2.106 kg [4 lb 10 oz]
DM1000 (w/ buttons): 2.528 kg [5 lb 9 oz]
DM1200: 2.722 kg [6 lb]
Vibration/Shock IEC 60068-2-64 (3.17g) /2-27 (50g)
EMI/RFI rating ISO 13766
Humidity IEC 60068-2-78, 60068-2-30
Transients ISO 7637/1, 2, 3
DM1000 DM1200
FCC Certified Certified
CE/RED Certified
UKCA Certified
EAC Certified
Giteki Certified
RCM Pending
E1-Mark Pending
Input types
Each PLUS+1®Module input pin supports one of the above functional types. For pins with multiple
functions, input configurations are user programmable using PLUS+1®GUIDE templates.
When using inputs in digital mode, it is advised to use the software selectable pull-up or pull-down
resistors.
Technical Information
PLUS+1 DM1x00 Series Displays
Input/output types and specifications
12 | ©Danfoss | October 2021 BC313277849405en-000204

Digital/analog
Middle range
Description Unit Minimum Typical Maximum Comment
Minimum discernible
voltage V — —0.03 —
Minimum discernible
voltage V 5.69 5.78 5.88 —
Resolution mV — 1.4 — —
Worst case offset and gain
error V — — ±0.14 VMeasure = 5.78 V
Non-linearity mV — — ±8.5 —
Input impedance kΩ 232 233 234 No pull up or pull down
Input impedance (5V/GND) kΩ 13.9 14.1 14.3 Pull up or pull down
Input impedance (2.5V) kΩ 7.1 7.3 7.4 Pull up and pull down
High range
Description Unit Minimum Typical Maximum Comment
Minimum discernible
voltage V — —0.16 —
Maximum discernible
voltage V 37.9 38.8 39.7 —
Resolution mV — 9.5 — —
Worst case offset and gain
error V — — 0.95 VMeasure = 38.8 V
Non-linearity mV — — ±56.8 —
Input impedance kΩ 109.1 109.3 109.5 No pull up or pull down
(Vin < 5.7 V)
Input impedance (5V/GND) kΩ 13.0 13.2 13.4 Pull up or pull down (Vin <
5.7 V)
Pull up and pull down input
impedance (2.5V) kΩ 6.9 7.0 7.1 Pull up and pull down (Vin < 5.7 V)
Multifunction inputs
Low range analog
Description Unit Minimum Typical Maximum Comment
Minimum discernible
voltage mV — — 13 —
Maximum discernible
voltage mV 379 404 430 —
Resolution mV — 0.1 — —
Worst case offset and gain
error mV — — ±0.6 VMeasure = 404 mV
Non-linearity mV — — ±26 —
Input impedance kΩ 232 233 234 No pull up or pull down
Input impedance (5V/GND) kΩ 13.9 14.1 14.3 Pull up or pull down
Input impedance (2.5V) kΩ 7.1 7.3 7.4 Pull up and pull down
Technical Information
PLUS+1 DM1x00 Series Displays
Input/output types and specifications
©Danfoss | October 2021 BC313277849405en-000204 | 13

Middle range analog
Description Unit Minimum Typical Maximum Comment
Minimum discernible
voltage V — — 0.03 —
Maximum discernible
voltage V 5.69 5.78 5.88 —
Resolution mV — 1.4 — —
Worst case offset and gain
error V — — ±0.14 VMeasure = 5.78 V
Non-linearity mV — — ±8.5 —
Input impedance kΩ 232 233 234 No pull up or pull down
Input impedance (5V/GND) kΩ 13.9 14.1 14.3 Pull up or pull down
Input impedance (2.5V) kΩ 7.1 7.3 7.4 Pull up and pull down
High range analog
Description Unit Minimum Typical Maximum Comment
Minimum discernible
voltage V — — 0.16 —
Maximum discernible
voltage V 37.9 38.8 39.7 —
Resolution mV — 9.5 — —
Worst case offset and gain
error V — — ±0.95 VMeasure = 38.8 V
Non-linearity mV — — ±56.8 —
Input impedance kΩ 109.1 109.3 109.5 No pull up or pull down
(Vin < 5.7 V)
Input impedance (5V/GND) kΩ 13.0 13.2 13.4 Pull up or pull down (Vin <
5.7 V)
Input impedance (2.5V) kΩ 6.9 7.0 7.1 Pull up and pull down (Vin
< 5.7 V)
Low range frequency (PPU)
Description Unit Minimum Typical Maximum Comment
Range Hz 0 — 10000 In steps of 1 Hz
Rising voltage threshold mV — — 314
Falling voltage threshold mV 55 — —
Input impedance kΩ 232 233 234 No pull up or pull down
Input impedance (5V/GND) kΩ 13.9 14.1 14.3 Pull up or pull down
Input impedance (2.5V) kΩ 7.1 7.3 7.4 Pull up and pull down
Middle range frequency (PPU)
Description Unit Minimum Typical Maximum Comment
Range Hz 0 — 10000 In steps of 1 Hz
Range (phase and quad) Hz 0 — 5000 In steps of 1 Hz
Rising voltage threshold V — — 4.25 Voltage required for
frequency input
Falling voltage threshold V 0.97 — — Voltage required for
frequency input
Input impedance kΩ 232 233 234 No pull up or pull down
Technical Information
PLUS+1 DM1x00 Series Displays
Input/output types and specifications
14 | ©Danfoss | October 2021 BC313277849405en-000204

Middle range frequency (PPU) (continued)
Description Unit Minimum Typical Maximum Comment
Input impedance (5V/GND) kΩ 13.9 14.1 14.3 Pull up or pull down
Input impedance (2.5V) kΩ 7.1 7.3 7.4 Pull up and pull down
Resistance input
Description Unit Minimum Typical Maximum Comment
Range Ω 6 — 10000 In steps of 1 Ω
Measurement error % — — 7.1 @100Ω
— — 2.1 @1kΩ
— — 5.4 @10kΩ
Input impedance Ω 1320 1320 1330 No pull up or pull down
Current input (4-20 mA)
Description Unit Minimum Typical Maximum Comment
Minimum discernible
current mA — — 0.12 —
Maximum discernible
current mA 28.2 28.9 29.7 —
Resolution µA — 7 — —
Worst case offset and gain
error µA — — ±743 IMeasure = 28.9 mA
Non-linearity µA — — ±42 —
Input impedance Ω 197 200 202 No pull up or pull down
Technical Information
PLUS+1 DM1x00 Series Displays
Input/output types and specifications
©Danfoss | October 2021 BC313277849405en-000204 | 15

CAN shield and analog input
CAN Shield
Description Unit Minimum Typical Maximum Comment
Input impedance — — 0.68µF+1Ω — —
Analog input
Description Unit Minimum Typical Maximum Comment
Minimum discernible
voltage V — — 0.03 —
Maximum discernible
voltage V 5.64 5.78 5.92 —
Resolution mV — 1.4 — —
Worst case offset and gain
error V — — ±0.14 VMeasure = 5.78 V
Non-linearity mV — — ±8.5 —
Input impedance kΩ 230 233 236
Digital output
Low side digital output
Description Unit Minimum Typical Maximum Comment
Voltage V 0 — Vin Iout = 500mA
Current mA 0 — 500 —
CAN communication
Description Unit Minimum Typical Maximum Comment
Available Baud rates kbps 50 With 120 Ω termination.
The default baud rate is 250
kbps.
100
125
250
500
1000
Maximum input voltage
range V -27 — 40 CAN+ and CAN-
Software updates using CG150 are supported via CAN0 and CAN1 channels.
Technical Information
PLUS+1 DM1x00 Series Displays
Input/output types and specifications
16 | ©Danfoss | October 2021 BC313277849405en-000204

USB communication
Description Unit Minimum Typical Maximum Comment
Available Baud rates Mbps 12 — 480 —
Maximum input voltage V -0.3 — 7.3 D+, D-, and VBUS
USB current limitation mA 250
RS232 communication
Description Unit Minimum Typical Maximum Comment
Available Baud rates bps — 9600 —
11400
19200
28800
38400
57600
115200
Maximum input voltage V -25 — 25 Rx
-13.2 — 13.2 Tx
Sensor output
Description Unit Minimum Typical Maximum Comment
Sensor Output Voltage (5V) V 4.85 5 5.15
Sensor Output Voltage (8V) V 7.75 8 8.25
Sensor Output Current (5V) mA 250
Sensor Output Current (8V) mA 150
Video power
Description Unit Minimum Typical Maximum Comment
Output Voltage (12V) V 12
Output Voltage (24V) V 24
Output Current (12V) mA 750
Output Current (24V) mA 375
Officially validated digital camera formats
IP Transport Protocol RTSP, RTP
Video Stream Format H264, MJPEG
Technical Information
PLUS+1 DM1x00 Series Displays
Input/output types and specifications
©Danfoss | October 2021 BC313277849405en-000204 | 17

Officially validated analog camera formats
Format Lines Fields FSC (MHz)
NTSC-M 525 60 3.579545
NTSC-Japan 525 60 3.579545
PAL-B, G, N 625 50 4.433619
PAL-D 625 50 4.433619
PAL-H 625 50 4.433619
PAL-I 625 50 4.433619
PAL-M 525 60 3.575612
PAL-CN 625 50 3.582056
SECAM 625 50 4.406 / 4.25
PAL-60 525 60 4.433619
NTSC (4.43) 525 60 4.433619
Ethernet
Symbol Description Unit Minimum Typical Maximum Comment
Baud Available baud rates bps 10 M Automatic polarity
detection and
correction; Auto-
negotiation
100 M
Vin Max input voltage range V -25 25 Receiver input
Audio outputs
Symbol Description Unit Minimum Typical Maximum Comment
HP Out Output Power mW 62.5 @1kHz
Right and left channel included - Stereo output
Technical Information
PLUS+1 DM1x00 Series Displays
Input/output types and specifications
18 | ©Danfoss | October 2021 BC313277849405en-000204

Wifi / Bluetooth
Available WiFi frequencies
2.412 to 2.462 GHz
11 Channels 5.180 to 5.240 GHz 7 Channels (U-NII-1)
Frequency Frequency
Channel Center
(MHz) Min (MHz) Max (MHz) Channel Center (MHz) Min (MHz) Max (MHz)
1 2412 2401 2423 36 5180 5170 5190
2 2417 2406 2428 38 5190 5170 5210
3 2422 2411 2433 40 5200 5190 5210
4 2427 2416 2438 42 5210 5170 5250
5 2432 2421 2443 44 5220 5210 5230
6 2437 2426 2448 46 5230 5210 5250
7 2442 2431 2453 48 5240 5230 5250
8 2447 2436 2458
9 2452 2441 2463
10 2457 2446 2468
11 2462 2451 2473
Note for the EU region: 5GHz U-NII-1 band is restricted to in-cab applications only
Description Unit Minimum Typical Maximum Comment
Transmit Power (802.11b) dBm 10.5
Transmit Power (802.11g/n) dBm 11
Transmit Power (802.11a/n) dBm 13
Technical Information
PLUS+1 DM1x00 Series Displays
Input/output types and specifications
©Danfoss | October 2021 BC313277849405en-000204 | 19

DM1x00 environmental testing criteria
Climate environment
Description Applicable standard Comment
Storage temperature IEC 60068-2-1, test Ab, IEC 60068-2-2 test
Bb
Operating temperature IEC 60068-2-1, test Ab, IEC 60068-2-2 test
Bd
Thermal and humidity cycle IEC 60068-2-38 (partial)
Degree of protection IEC 60529
Chemical environment
Description Applicable standard Comment
Chemical resistance ISO 16750-5
Mechanical environment
Description Applicable standard Comment
Vibration IEC 60068-2-64 test Fh 3.17g
Bump IEC 60068-2-27 test Eb
Shock IEC 60068-2-27 test Ea 50g
Free fall IEC 60068-2-31 test Ed
Electrical/electromagnetic
Description Applicable standard Comment
EMC emissions ISO 13766 Electromagnetic compatibility for
earth moving machinery.
EMC immunity ISO 13766 Electromagnetic compatibility for
earth moving machinery.
ESD EN61000-4-2
Electrical transients ISO 7637-2, ISO 7637-3
Short circuit protection Danfoss test Inputs and outputs survive
continuous short circuit. Normal
function resumes when short is
removed.
Reversed polarity protection Danfoss test Survives reverse polarity at supply
voltage for at least five minutes.
Supply voltage/maximum current ratings
DM1x00 displays are designed to operate with a nominal 9 to 36 Vdc power supply with reverse polarity
protection.
Supply voltage/maximum current ratings
Description Unit Minimum Typical Maximum Comment
Operating temperature °C -30 — +70
Storage temperature °C -40 — +85
Technical Information
PLUS+1 DM1x00 Series Displays
Product ratings
20 | ©Danfoss | October 2021 BC313277849405en-000204
