Danfoss BasicPlus2 WT-T User manual

Installation Guide
BasicPlus2WT-T
Room thermostat

VICUL202 Danfoss Heating Solutions
2
Installation Guide BasicPlus2WT-T Room Thermostat
GB
1. Installation Steps
1. Installation must be done by an authorised
electrician.
2. The room thermostat should be installed at approx.
1.5 m above oor and where the eects of sunlight,
draught or other heat sources (eg. TV’s) are avoided,
see g. 1.
3. First of all, carefully remove the cover and dial knob,
see g. 2.
4. Connect the wire before mounting the back plate to
the wallbox using the enclosed screws. Then mount
the cover to the back plate, see g. 3.
2. Wiring
See g. 4 for dimensions and g. 5 for wiring diagram.
WT-T is often used with a Danfoss TWA actuator.
Depending on the conditions of power location and
actuator type (NC or NO), the wiring between room
thermostat and actuator is dierent.
Follow the illustrations to complete the wiring.
1. When power supply location is close to room
thermostat:
• Connect to actuator TWA 230 V NC type, see g. 6.
• Connect to actuator TWA 230 V NO type, see g. 7.
2. When power supply location is close to actuator:
• Connect to actuator TWA 230 V NC type, see g. 8.
• Connect to actuator TWA 230 V NO type, see g. 9.

Danfoss Heating Solutions VICUL202
3
Installation Guide BasicPlus2WT-T Room Thermostat
GB
3. Notes
1. Correct wiring is essential; using instrument to con-
rm L and N before wiring is recommended.
2. Don’t remove too much of the insulation cover from
the wire to avoid short circuit caused by the naked
wire touching the metal 86 size mounting wall box.
3. Don’t let the screw press or touch the wire when
using screws to x room thermostat in wall box. A
short-circuit risk exists if the wire insulation cover is
damaged by the screw, and if the naked wire con-
nects with the screw.
4. If walls must be painted, mount the room thermo-
stat after painting, to avoid dust or paint material
penetrating the room thermostat and thus damag-
ing the PCB.
5. The max. load of relay is 3 A (resistive) or 1 A (induc-
tive, such as pump or motor). The relay will be dam-
aged if the load exceeds the limit.
6. Don’t cover the thermostat, for instance by hanging
towels directly in front of it.
7. The room thermostat should be connected to the
corresponding loop actuator in individual room
temperature control.

VICUL202 Danfoss Heating Solutions
4
Installation Guide BasicPlus2WT-T Room Thermostat
GB
4. Technical Specications
Feature Description
Approval CE Marking, EN60730
Ambient temperature -10 - 60° C
IP Class 30
Max. load, inductive <1 A
Max. load, resistive <3 A
Power consumption 7 W
Power supply 230 Vac ±10%, 50/60 Hz
Room temp. set range 5 - 30° C
Shell material ABS + PC

Danfoss Heating Solutions VICUL202
5
Installation Guide BasicPlus2WT-T illustrations
Fig. 1
1.5 m
Fig. 2
Fig. 3

VICUL202 Danfoss Heating Solutions
6
Installation Guide BasicPlus2WT-T illustrations
Fig. 4
Fig. 5
N
L
NO
NC
230 V
~
Fig. 6
NC NO L N
N
230 V
~
L
TWA
230V
NC
WT-T

Danfoss Heating Solutions VICUL202
7
Installation Guide BasicPlus2WT-T illustrations
Fig. 7
NC NO L N
N
230 V
~
L
TWA
230V
NO
WT-T
Fig. 8
NC NO L N
N
230
V ~
L
TWA
230V
NC
WT-T
Fig. 9
NC NO L N
N
230
V ~
L
TWA
230V
NO
WT-T
