Danfoss DEVIreg Smart User manual

www.DEVI.com
Installation Guide
DEVIreg™ Smart
Intelligent Electronic Timer Thermostat or Timer
Switch with Wi-Fi connectivity and App control

DEVIreg™ Smart
Installation Guide2
1 Introduction
DEVIreg™ Smart is an electronic programmable timer
thermostat used for controlling electrical oor heating
elements. The thermostat is designed for xed installation
only and can be used for both direct heating of the entire
room and for comfort heating of the oor. Among others,
the thermostat has the following features:
• A touchscreen display with light.
• An easy-to-follow menu-driven programming and
operation (requires an app).
1 Introduction . . . . . . . . . . . . . . . . . . . . . . 2
2 Technical Specications . . . . . . . . . . . . . . . 4
3 Safety Instructions . . . . . . . . . . . . . . . . . . 6
4 Mounting Instructions . . . . . . . . . . . . . . . . 8
5 Display Symbols . . . . . . . . . . . . . . . . . . . 13
6 Configuring . . . . . . . . . . . . . . . . . . . . . . 19
7 Settings . . . . . . . . . . . . . . . . . . . . . . . . 20
8 Warranty. . . . . . . . . . . . . . . . . . . . . . . . 23
9 Radio Equipment Directive . . . . . . . . . . . . 24
10 Disposal Instruction . . . . . . . . . . . . . . . . 25
Table of Contents

DEVIreg™ Smart
3Installation Guide
• An installation wizard with room/oor type-specic
setup (requires an app).
• Support for multiple frame systems.
• Compatible with several 3rd party NTC sensors.
• Thermostat settings can be specied before instal-
lation and imported to the thermostat using a web-
generated code (For DEVIreg™ Touch), or copied
from a thermostat in a similar installation. This
includes DEVIreg™ Touch thermostats.
• Smart access via app to thermostat settings after
installation, for easy access, setup or remote trou-
bleshooting. Thermostat/timer will continuously be
updated with newest version of software.
• DEVIreg™ Smart can be used as a switch for On/O
systems
Regarding Connectivity:
• 10 smart devices (like Smartphone or Tablet) can be
connected to 1 thermostat/switch.
• 2 smart devices can be in contact with the thermo-
stat/switch at the same time.
DEVIREG™ SMART REQUIRES WORKING Wi-Fi
TO FUNCTION .

DEVIreg™ Smart
Installation Guide4
More information on this product can also be found at:
devismart.com
2 Technical Specications
Operation voltage 220–240 V~, 50/60 Hz
Standby power
consumption
Max. 0,40 W
Relay:
Resistive load
Inductive load
Max. 16 A / 3680 W @ 230 V
Max. 1 A cos φ= 0,3
Sensing units* NTC 6,8 kOhm at 25°C
NTC 10 kOhm at 25°C
NTC 12 kOhm at 25°C
NTC 15 kOhm at 25°C (Default)
NTC 33 kOhm at 25°C
NTC 47 kOhm at 25°C
Sensing values*:
(Default NTC 15 K)
0 °C
20 °C
50 °C
42 kOhm
18 kOhm
6 kOhm
Control* PWM (Pulse Wide Modulation)
Ambient temperature 0°C to 30°C
Frost protection
temperature*
5°C to 9°C (default 5°C)

DEVIreg™ Smart
5Installation Guide
Temperature range* Room temperature: 5°C to 35°C.
Floor temperature: 5°C to 45°C.
Max. oor: 20°C to 35°C (if unrecover-
able seal is broken then up to 45°C).
Min. oor: 10°C to 35°C, only with
combination of room and oor sensor.
Sensor failure monitoring* The thermostat has a built-in
monitoring circuit, which will switch
o the heating if the sensor is
disconnected or short-circuited.
Timer functions 2 periods per day for DEVIweb™.
5 periods per day for DEVIsmart App.
All clock/date/schedule settings are
updated from the cloud.
Set-point resolution of timer is
30minutes.
Cable specication max. 1x4 mm2
Ball pressure test tem-
perature
75°C
Pollution degree 2 (domestic use)
Controller type 1C
Software class A
Storage temperature -20°C to +65°C
IP class 21
Protection class Class II -

DEVIreg™ Smart
Installation Guide6
Dimensions 85 x 85 x 20-24 mm
(in-wall depth: 22 mm)
Weight 127 g
* not relevant for switch function
Electrical safety and Electro-Magnetic Compatibility
for this product is covered by the compliance with the
EN/IECStandard“Automatic electrical controls for house-
hold and similar use”:
• EN/IEC 60730-1 (general)
• EN/IEC 60730-2-7 (timer)
• EN/IEC 60730-2-9 (thermostat)
3 Safety Instructions
Make sure the mains supply to the thermostat/switch is
turned o before installation.
Important: When the thermostat is used to control a
oor heating element in connection with a wooden oor
or similar material, always use a oor sensor and never set
the maximum oor temperature to more than 35°C.
Please also note the following:
• The installation of the thermostat /switch must be done
by an authorized and qualied installer according to
local regulations.

DEVIreg™ Smart
7Installation Guide
• The thermostat /switch must be connected to a power
supply via an all-pole disconnection switch.
• Always connect the thermostat /switch to continuous
power supply.
• Do not expose the thermostat /switch to moisture,
water, dust, and excessive heat.
• This thermostat /switch can be used by children aged
from 8 years and above and persons with reduced
physical, sensory or mental capabilities or lack of expe-
rience and knowledge, if they have been given supervi-
sion or instruction concerning use of the appliance in
a safe way and understand the hazards involved, by a
person responsible for their safety.
• DEVIreg™ Smart can modied to work as a timer on/
o switch by downloading new software with new
functionality.
• Children should be supervised to ensure that they do
not play with the thermostat /switch .
• Switch is designed for permanent operation.
• Not for uorescent lamps and lament lamps.
• Cleaning and user maintenance shall not be made by
children without supervision.
• Updating to timer switch function may take up to
1hour. Same time should be expected if function is to
be rolled back to thermostat functionality.

DEVIreg™ Smart
Installation Guide8
4 Mounting Instructions
Please observe the following placement guidelines:
Place the thermostat at a suitable height on the wall
(typically 80–170 cm). Switch can be placed on free
area on the wall.
The thermostat/switch should not be placed in wet
rooms. Thermostat/switch must be placed outside
zone 2. Place it in an adjacent room and use oor
sensor only. Always place the thermostat/switch
according to local regulation on IP classes.
Do not place the thermostat on the inner side of a
poorly insulated exterior wall.
Always install the thermostat at least 50 cm from
windows and doors, due to draft, when using regulation
in: oor and room mode or room alone mode.
Do not place the thermostat in a way that it will be
exposed to direct sunlight.

DEVIreg™ Smart
9Installation Guide
Note for thermostat: A oor sensor is recommend-
ed in all oor heating applications and mandatory
to thin mats and under wooden oors to reduce the
risk of over-heating the oor.
• Place the oor sensor in a protecting plastic conduit
in the oor construction in an appropriate place,
where the oor is not exposed to sunlight or draft
from door openings.
12
≥
• Equally distant and
>2 cm from the
heating cables on
both sides.
• The conduit should
be ush with the
oor surface, coun-
tersink the conduit
if necessary and
possible.
• Route the conduit to the connection box.
• The bending radius of the conduit must be min 50 mm.

DEVIreg™ Smart
Installation Guide10
Follow the steps below to mount the thermostat/switch:
1. Unpack thermostat/switch.
2.1. Connect the thermostat according to the connection
diagram.
IP21
T30
Mains
220-240V~
50-60 Hz
Maximum
Load 16 (1) A
Sensor
NTC
Danfoss A/S
Nordborgvej 81
6430 Nordborg
Denmark
NLL
L
O
A
DN
L
O
A
D
Standby maximum 0.4 Watt
The screen of the heating
cable must be connected to
the earth conductor of the
power supply cable by using
a separate connector.
Note: Always install the oor sensor in a conduit in
the oor.
IP21
T30
Mains
220-240V~
50-60 Hz
Maximum
Load 16 (1) A
NTC
Danfoss A/S
Nordborgvej 81
6430 Nordborg
Denmark
NLL
L
O
A
DN
L
O
A
D
Standby maximum 0.4 Watt
2.2. Connect the switch ac-
cording to the connection
diagram.
3. Fasten the thermostat/switch rmly to a ush
mounted wall box or an exterior wall box by driving

DEVIreg™ Smart
11Installation Guide
the screws through the holes in each side of the
thermostat/switch.
4. Add the frame before assem-
bling of top part to the snap
locks/bottom part.
5. Click the front part module in
place. Pay attention, in relation
to the female header, in not to
bending the connectors. Press
carefully until the frame is xed
against the rubber gasket.

DEVIreg™ Smart
Installation Guide12
Important: Do NOT press in the center of the display screen.
When mounting and reassembling the thermostat/switch.
Press your ngers under the top of the front part and pull
toward you until it releases from the snap lock:
To ensure that the batteries are fully charged, the ther-
mostat/switch shall be connected to main supply for
minimum 15 hours.
All other settings are stored permanently.

DEVIreg™ Smart
13Installation Guide
5 Display Symbols
Top part main functionalities are to support user interface
through display and hold all the controller logic.
Display main functionalities are to show the current status
of the thermostat/switch and recognize the user actions
from the buttons. Display consists of dierent buttons,
numbers and symbols.
Thermostat Switch
1
4
2
3

DEVIreg™ Smart
Installation Guide14
Nr. Type Description
1 Button/Symbol Control button
2 Button/Symbol Arrow Up button
3 Button/Symbol Arrow Down button
4 Symbol Thermostat function: 3 digit 7 seg-
ment numbers with comma separator
for temperature indication. Timer
switch function: “On”/”O” text.
Symbol indications
Indication Mode/State Description
Blue - blinking Access Point
Mode
Thermostat/switch ready for
set-up
Blue Access Point
Mode
Smart phone connected
directly to thermostat/switch
for set-up
Red - blinking Fault state Displays Error code
Red - slow
pulsing
Active Mode Indicating heating the oor
(Relay on)
Green - constant Active Mode Thermostat/switch active and
connected to Wi-Fi (Relay o)

DEVIreg™ Smart
15Installation Guide
Green – blinking Active Mode
& Access
Point Mode
Thermostat/switch waiting for
conrmation of action
Arrows –
blinking rapidly
when touched
Active Mode Safety lock is on
Interaction directly on thermostat
Function Button Description
Turn
thermostat/
switch on
1. Touch any button
2. Touch control but-
ton (1)
Thermostat/switch
turn on and display
temperature or On/O
states
Turn
thermostat/
switch o
1. Touch any button
2. Touch and hold
control button (1)
Thermostat/switch
display will turn on
Thermostat switch
count down and switch
o
Adjust set-
point
Up (2) Overrule timer and
switch on/temporary
set point
Down (3) Overrule timer and
switch o/temporary
set point

DEVIreg™ Smart
Installation Guide16
Frost protec-
tion
Touch and hold Con-
trol (1) for 1 sec.
Deactivate frost protec-
tion
Safety lock Touch and hold Up (2)
+ Down (3) for 3 sec.
Activate/Deactivate
safety lock
Factory
restore
Touch and hold
Control (1) + Up (2)
for 5 sec.
After that touch
Control (1) again to
conrm
Activates factory
restore state
Away mode Touch and hold
Control (1) for 1 sec. to
deactivate Away mode
Activate/Deactivate
Away/Vacation mode
Error codes
When the error occurs and is resolved, the thermostat, in
some cases, will require a restart to start heating again.

DEVIreg™ Smart
17Installation Guide
Error
type
Nr. Description Solution Need restart
Floor
Sensor
discon-
nected
E1 Connection
to sensor is
lost
Contact
service
The thermostat
requires a restart
to operate again.
Floor
Sensor
short-
circuited
E2 Sensor short-
circuited
Contact
service
The thermostat
requires a restart
to operate again.
Thermo-
stat over-
heated
E3 Thermostat
is overheat-
ed, heating is
turned o
Wait until
thermo-
stat cools
down
The thermostat
requires no
restart, but will
start heating
when the
temperature is
lowered
Unrecov-
erable
error
E4 Room
temperature
sensor value
too high or
too low
Contact
service
The thermostat
requires a restart
to operate again.

DEVIreg™ Smart
Installation Guide18
Communication Error Codes
Communication
error
Nr. Description
Wrong SSID or
password
C1 STA trying to connect to the AP
No IP address C2 STA - connection acquired, no IP
yet, waiting for conguration data.
No internet con-
nection
C3 STA connected and has an IP from
DHCP server.

DEVIreg™ Smart
19Installation Guide
6 Configuring
Download App
Download the DEVIsmart™ app from App Store
or Google Play or at devismart.com.
Find Wi-Fi name and password for the Wi-Fi
network, that you would like to connect your
thermostat/switch to. If in doubt contact net-
work administrator or internet service provider.
Identify your oor sensor type ( in kOhm).
Identify your installed output (in W), from
label on the heating element/equipment.
Power on the thermostat, and it will show
“-“ in the display. Then it is ready to be con-
gured using your iPhone and Android device.
Open the DEVIsmart™ App. Follow instructions and set-
up ow in the App.
DEVIreg™ Smart indication
The DEVIreg™ Smart shows “–” indicating that power is
ON, but still need to be congured.

DEVIreg™ Smart
Installation Guide20
7 Settings
IMPORTANT DURING
THERMOSTAT SET-UP
Select whether only a oor sen-
sor or a combination of room
and oor sensor should be used.
A “room only” option is also
available, but requires that you
have to break the small plastic
seal and the seal in the print
board below, on the back of
the display module, e.g. using
a screwdriver; reset is needed;
it will be possible to set the
