Danpex PMC100-1 User manual

Media Converter (PMC) module
User’s Manual
PMC100-1 / PMC100-2
Version: 1.0
Date: 11/25/2008

CONTENTS
1Overview
2
1.1 What You Should Get..........................................................................2
1.2 External Architecture..........................................................................3
1.3 Size & Weight ....................................................................................3
1.4 Connectors and Switches ..................................................................4
1.5 Product Configuration ........................................................................5
2Introduction 6
3Unique Features 7
4Application Case Examples 8
4.1 Remote Transmission Solution (PMC100-1).................................... ..8
4.2 Upgrade Analog Camera to IP Camera (PMC 100-2) .........................8
5Integrating Other Products with PMC 10
6 Q&A 11
Appendix 12

Rev.En 1.0
2
PMC Modules
User’s Manual
1 Overview
1.1 What You Should Get
Please check the module before using it.
PMC100-1(Twist Pair)/ PMC100-2 (Coaxial cable)
Module--------------------------------------x 1
Power Adapter (DC 5V 2A) -----------x 1
Device Mounting-------------------------x 2
Φ2.9’ screw -------------------------------x 4
Φ4.8’ screw -------------------------------x 2
Terminal Block ---------------------------x 1
User manual ------------------------------x1
PMC100-1
PMC100-2

Rev.En 1.0
3
PMC Modules
User’s Manual
1.2 External Architecture
PMC100-1/ PMC100-2
Front panel
Right side panel
Back panel
1.3 Size & Weight
PMC100-1/ PMC100-2
Dimension: 126 (W) x 95 (D) x 30(H) (mm)
Weight: Approx 311± 2g
Material: metal
Term Cable
Power
jack LAN Port
(RJ-45) Phone
Port RJ11/
DIP switch LED
Fan (Exhaust)
Ground

Rev.En 1.0
4
PMC Modules
User’s Manual
1.4 Connectors and Switches
(1) Power Input
PMC100-1/ PMC100-2 single 5V - 1A adapter
CAUTION! Be sure to follow the specified power requirement to avoid damaging the
equipment.
(2) Dip Switch Settings DIP
Switch # Function ON Position OFF Position
1 Master/Slave CPE CO
2 Transmission Fast Mode Interleave mode
3 Rate Limit No Limit Limited
4 SNR 6 dB 9 dB
> DIP 1：CO, CPE switch
CO: PMC module acts as Central Office (CO) side.
CPE: PMC module acts as Customer Premises Equipment (APE) side.
> DIP2: Impulse noise protection
Interleave mode: Provides communication protection for up to 250ms impulse noise with latency
of less than 6 ms.
Fast mode: Direct data transmission with latency of less than 1ms.
> DIP 3: Rate limit control
Limited: Line rate limited to 50/20 Mbps.
No limit: Provides up to 100Mbps/60Mbps line rate in short line.
> DIP 4: General protection
9dB: Better channel noise protection with SNR of up to 9 dB.
6dB: Original channel noise protection with SNR of 6 dB SNR.
(3) LED Indicators
> LAN Port (RJ-45) bottom right LED status
LED Status Function
Off Off-Line
Blinking Transmitting data
Lights On Idle
> LAN Port (RJ-45) bottom left LED status

Rev.En 1.0
5
PMC Modules
User’s Manual
LED Status Bandwidth Speed
Off Full-Duplex 100Mbps
Lights On Half-Duplex 10Mbps
> Front Panel LED status
LED Position OFF Blinking Lights On
Top (PW) Power Off Don’t care Power On
Middle
(CPE/CO) CO Mode Don’t care CPE mode
Bottom (LINK) Don’t care Training
(handshaking)
Slave & Master
successfully
connected
1.5 Product Configuration
Model
Number Power Supply Interface Special Feature Ideal Locations of Application
PMC100-1 RJ-11 / 2-Wire
Terminal Block
Vast distances / High
bandwidth
applications
Long span of bridges /
roads
/ remotes areas
PMC100-2
Max. 4.2W
5V DC
BNC Upgrades analog
camera to IP camera
Airport / neighborhood
/ factory / museum

Rev.En 1.0
6
PMC Modules
User’s Manual
2 Introduction
The PMC (Media Converter, hereinafter called PMC100-1/ PMC100-2) modules which include
models that utilize new built-in IP camera device or are capable of upgrading analog camera into
IP camera, are ideal devices for centralized surveillance and control. Furthermore, its
installation cost is cut to minimum due to reduced installation man-hour and cable/wiring
requirements. Through splitter, the PMC modules can be connected to the security network
through existing coaxial cables or telephone wirings. PMC modules are also capable of
extending its surveillance capability to about 1.5 kilometer from control center through a single
Ethernet port (RJ-45) and an RJ-11or wire terminal block port.
PMC modules are plug-n-play as they do not require software. For long range connections, the
modules offer up to 100/60 Mbps transition bandwidth for the distance of within 300 meters and
25/5 Mbps for 1.6 kilometers using existing telephone line at ultra-high performance. Being a
plug-n-play device, it provides minimum installation time as well as minimum expense by
allowing video streaming and data sharing with existing telephone twisted-pair or coaxial cable
without interference.
With its ultra-high performance, the PMC modules are capable of transmitting high definition
images; such as High Definition Television (HDTV). This makes the device most suitable for
hotel/motel rooms TV network application. PMC modules also support Ethernet Bridge and
switching functions and are compatible with optical fiber device.
In suppressing radio interference in tunnel or elevator, as well as in long distance surveillance in
farmlands or of bridges across bays, the PMC modules are capable of meeting these challenges
as long as telephone line or cable networks already exist in these locations. Furthermore, the
modules are also equipped with RS485 interfaces for Emergency/Security Control application.
Lastly, PMC modules feature the Remote Power Feeding (RPF) capability that enables the
device to transmit and provide power over telephone lines. This is an ideal option for applying
surveillance network in remote areas where power source is not available.

Rev.En 1.0
7
PMC Modules
User’s Manual
3 Unique Features
¾No new wiring network required: Uses existing phone lines /coaxial cables
¾Fast Upgrade: Upgrade analog camera to IP camera.
¾Long distance transmission: Up to 100/60 Mbps transition bandwidth within 300m without
interference.
¾Support multi-cameras at the same time: Support Twenty-five cameras at the same time
within 200m in sufficient bandwidth.
¾Easy to Install: Plug-n-play device, no software installation required
¾Auto-detect & adapts itself with environment: Can readjust itself to adapt with complicated
wiring environment, such as elevator or tunnel.
¾Cost saving: Saves material and labor cost due no new wiring required. Hence no wiring
installation man-hour required.

Rev.En 1.0
8
PMC Modules
User’s Manual
4 Application Case Examples
4.1 Remote Transmission Solution (PMC100-1)
9Video transmission distance up to 1500m
9Transmit bandwidth: 100Mbps , live video
9long distance transmission without adding extra Hub/Switch
4.2 Upgrade Analog Camera to IP Camera (PMC100-2)
> Objective:
Upgrade analog camera to IP camera with PMC100-2 module using existing coaxial cable line.
> Location:
ELAN Microelectronics Corp building -1st Floor
> Network Architecture:
Figure2. Example PMC100-2 Network Architecture
Hub
Twist pair
PMC100-1 PMC100-1
Remote Control

Rev.En 1.0
9
PMC Modules
User’s Manual
This case shows user installing a new surveillance IP camera using the existing coaxial cable
which is connected and used by an analog camera. Therefore, no fresh wiring is involved and
cost down is achieved
As user wants to add a new IP camera in addition to the existed analog camera, it is therefore
necessary to use a coaxial splitter device. Furthermore, user must add a modulator device
between analog cameras and coaxial splitter, and add a demodulator device between coaxial
splitter and surveillance center device. If user wants to add more new IP cameras, it only needs
to install a switch hub device between IP cameras and PMC100-2.
> Theory:
IP camera delivers image data through RJ-45 line. Analog camera delivers image data through
coaxial cable line. We use modulator/demodulator devices to separate a high frequency or low
frequency from the same frequency band.

Rev.En 1.0
10
PMC Modules
User’s Manual
5 Integrating Other Products with PMC

Rev.En 1.0
11
PMC Modules
User’s Manual
6 Q&A
Q1. How to select CO side and CPE side mode PMC?
A1. Referring to the figure below, the PMC B module (nearest to IP camera) is the CO side and
PMC A module (nearest to control center) is the CPE side for valid operation bandwidth.
Q2. How to identify fast and interleaved mode?
A2. Fast mode guarantees a minimum end to end latency of less than 1 ms. Interleaved mode
provides protection from any impulse noise with duration of less than 250 μs. Interleaved mode
has a maximum end to end latency of 10 ms. Interleaved mode is the default mode.
Q3. How to select target data rate and target SNR margin?
A3. User can select fixed SNR margin (9 dB) or fixed target data rate. When fixed SNR margin
is selected, the systems will maintain the SNR margin at 9 dB across all usable loop length.
When fixed target data rate is selected, the system will lock the data rate at 50Mbps/30Mbps
whenever the calculated SNR margin is higher than 9 dB. This provides the best system
stability and is the default mode.
Q4. Why PMC modules cannot link each other after training?
A4. 1) A pair of PMC modules should consist of a CO side mode module and a CPE
side mode module. They cannot be of the same mode modules.
2) RJ-11 jack and connector may have loose contact.
3) The distance between 2 PMC modules should not exceed 1.5Km.
RJ45
RJ11 (2km)
PMC A PMC B
RJ45

Rev.En 1.0
12
PMC Modules
User’s Manual
Appendix
PMC100-1 / PMC100-2 Specifications
Model Name PMC100-1 PMC100-2
Dimension 126(W)*95(D)*30(H)(mm) 126(W)*95(D)*30(H)(mm)
Weight 311± 5g 311± 5g
LED Indicators
Green-PW for power
Green-CPE/CO
Green-Link for data link
Power Consumption Max. 4.2W 5V 2A DC Max. 4.2W 5V 2A DC
Ethernet 10/100 10/100
I/O Terminal block for phone line /
RJ-45 BNC 75 ohm connector / RJ-45
Transmission rate and
distance 94Mbps/200m 94Mbps/200m
Features Long Distance
2.High BW 1.Analogue cam Upgrade
Application Road/Bridge Airport/society/
Community/museum
