DAPAudio DS-MP-150 User manual

DS-MP-150
ORDERCODE D1230

Congratulations!
You have bought a great, innovative product from DAP Audio.
The DAP Audio DS-MP-150 brings excitement to any venue. Whether you want simple plug-&-play action
or a sophisticated show, this product provides the effect you need.
You can rely on DAP Audio, for more excellent audio products.
We design and manufacture professional audio equipment for the entertainment industry.
New products are being launched regularly. We work hard to keep you, our customer, satisfied.
For more information: [e-mail]
You can get some of the best quality, best priced products on the market from DAP Audio.
So next time, turn to DAP Audio for more great audio equipment.
Always get the best -- with DAP Audio !
Thank you!

1
2
2
2
3
4
4
5
5
6
7
8
8
8
8
9
9
10
11
11
11
11
11
11
11
11
11
12
12
12
12
12
12
13
13
14
14
17
18
19
20
20
20
Dap Audio
Dap Audio DS-MP-150™ Product Guide
Warning.................................................................................…...……………..…………..………………….………....…
Unpacking Instructions………………………………………………………………………………………………...…..
Safety-instructions………………………………………………………………………………………………………..…
Operating Determinations.…………………………………………………………………………………………….....
Return Procedure....................................................................................................................................................
Claims.......................................................................................................................................................................
Description....................................................................................................................................................................
Overview..................................................................................................................................................................
Deck.........................................................................................................................................................................
Mixer.........................................................................................................................................................................
Frontside...................................................................................................................................................................
Backside...................................................................................................................................................................
Installation....................................................................................................................................................................
Set Up and Operation.................................................................................................................................................
Names and functions..................................................................................................................................................
Deck functions........................................................................................................................................................
Mixer functions........................................................................................................................................................
Front functions........................................................................................................................................................
Back functions........................................................................................................................................................
Operations...................................................................................................................................................................
Selecting tracks using the folder select encoder..............................................................................................
Selecting folders.....................................................................................................................................................
Starting playback...................................................................................................................................................
Stop playback........................................................................................................................................................
Pausing....................................................................................................................................................................
Setting a cue point................................................................................................................................................
Setting a hot cue point in pause mode..............................................................................................................
Setting a hot cue point in play mode.................................................................................................................
Deleting a (hot) cue point....................................................................................................................................
Cueing.....................................................................................................................................................................
Frame search..........................................................................................................................................................
Scanning (fast forward/fast backward).................................................................................................................
Changing the pitch of the song...........................................................................................................................
Loop play................................................................................................................................................................
Software Installation....................................................................................................................................................
Running the setup program..................................................................................................................................
Running the Virtual DJ-software for the first time ....................................................................................................
Interface Zones.......................................................................................................................................................
Browser Panels.......................................................................................................................................................
Maintenance...............................................................................................................................................................
Troubleshooting...........................................................................................................................................................
Product Specifications...............................................................................................................................................

2
WARNING
Unpacking Instructions
Immediately upon receiving this product, carefully unpack the carton and check the contents to ensure
that all parts are present, and have been received in good condition. Notify the dealer immediately and
retain packing material for inspection if any parts appear damaged from shipping or the carton itself
shows signs of mishandling. Save the carton and all packing materials. In the event that a fixture must be
returned to the factory, it is important that the fixture be returned in the original factory box and packing.
Your shipment includes:
• DAP DS-MP-150
• USB cable
• CD with Virtual DJ software
• User manual
WARNING
SAFETY INSTRUCTIONS
Every person involved with the installation, operation and maintenance of this system has to:
-be qualified
-follow the instructions of this manual
Before you initial start-up, please make sure that there is no damage caused by transportation. Should
there be any, consult your dealer and do not use the system.
To maintain perfect condition and to ensure a safe operation, it is absolutely necessary for the user to
follow the safety instructions and warning notes written in this manual.
Please consider that damages caused by manual modifications to the system are not subject to
warranty.
This system contains no user-serviceable parts. Refer servicing to qualified technicians only.
IMPORTANT:
The manufacturer will not accept liability for any resulting damages caused by the non-
observance of this manual or any unauthorized modification to the system.
Never remove warning or informative labels from the unit.
Never leave any cables lying around.
Do not connect this system to a dimmerpack.
Do not switch the system on and off in short intervals, as this would reduce the system’s life.
CAUTION!
Keep this system away from rain and moisture!
CAUTION! Be careful with your operations.
With a dangerous voltage you can suffer
a dangerous electric shock when touching the wires!
FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL CAREFULLY
BEFORE YOUR INITIAL START-UP!

3
Do not open the device and do not modify the device.
Do not drive the inputs with a signal level bigger, than required to drive the equipment to full
output.
Only use system indoor, avoid contact with water or other liquids.
Avoid flames and do not put close to flammable liquids or gases.
Make sure you don’t use the wrong kind of cables or defective cables.
When using a power adaptor, make sure that the available voltage is not higher than stated on
the rear panel.
Please turn off the power switch, when changing the power adaptor or signal cable.
Extreme frequency boosts in connection with a high input signal level may lead to overdriving
your equipment. Should this occur, it is necessary to reduce the input signal level by using the gain
control.
To emphasize a frequency range, you don’t necessarily have to move its respective control
upward; try lowering surrounding frequency ranges instead. This way, you avoid causing the next
piece of equipment in your sound path to overdrive. You also preserve valuable dynamic reserve
(“headroom”)
Avoid ground loops! Always be sure to connect the power amps and the mixing console to the
same electrical circuit to ensure the same phase!
If system is dropped or struck, disconnect the power supply or USB cable immediately. Have a
qualified engineer inspect for safety before operating.
If the system has been exposed to drastic temperature fluctuation (e.g. after transportation), do
not switch it on immediately. The arising condensation water might damage your system. Leave
the system switched off until it has reached room temperature.
If your Dap Audio device fails to work properly, discontinue use immediately. Pack the unit
securely (preferably in the original packing material), and return it to your Dap Audio dealer for
service.
Repairs, servicing and electric connection must be carried out by a qualified technician.
For replacement use fuses of same type and rating only.
OPERATING DETERMINATIONS
This system is not designed for permanent operation. Consistent operation breaks will ensure that the
system will serve you for a long time without defects.
If this system is operated in any other way, than the one described in this manual, the product may suffer
damages and the warranty becomes void.
Any other operation may lead to dangers like short-circuit, burns, electric shock, etc.
You endanger your own safety and the safety of others!
Improper installation can cause serious damage to people and property !

4
Return Procedure
Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued.
Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned
without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility.
Call Highlite 0031-455667723 or mail [e-mail] and request an RMA prior to shipping the fixture.
Be prepared to provide the model number, serial number and a brief description of the cause for the
return. Be sure to properly pack fixture, any shipping damage resulting from inadequate packaging is the
customer’s responsibility. Highlite reserves the right to use its own discretion to repair or replace
product(s). As a suggestion, proper UPS packing or double-boxing is always a safe method to use.
Note: If you are given an RMA number, please include the following information on a piece of paper
inside the box:
1) Your name
2) Your address
3) Your phone number
4) A brief description of the symptoms
Claims
The client has the obligation to check the delivered goods immediately upon delivery for any short-
comings and/or visible defects, or perform this check after our announcement that the goods are at their
disposal. Damage incurred in shipping is the responsibility of the shipper; therefore the damage must be
reported to the carrier upon receipt of merchandise.
It is the customer's responsibility to notify and submit claims with the shipper in the event that a fixture is
damaged due to shipping. Transportation damage has to be reported to us within one day after receipt
of the delivery.
Any return shipment has to be made post-paid at all times. Return shipments must be accompanied with
a letter defining the reason for return shipment. Non-prepaid return shipments will be refused, unless
otherwise agreed in writing.
Complaints against us must be made known in writing or by fax within 10 working days after receipt of the
invoice. After this period complaints will not be handled anymore.
Complaints will only then be considered if the client has so far complied with all parts of the agreement,
regardless of the agreement of which the obligation is resulting.

5
Description of the device
Features
The DS-MP-150 is a true midi controller to control your PC like a common audio device.
Just connect the DS-MP-150 with USB to your computer or laptop and you will be able to fully control your
music-files.
Delivery is complete with the award winning Virtual DJ software which is user friendly and quick to learn.
Mixing has never been easier as with the DS-MP-150.
• Touch Jog Wheel
• USB interface
• 3 selectable Jog Modes (Pitch, Search, Scratch)
• Adjustable cross-fader
• Plug & Play functionality
• Including Virtual DJ (Basic) software
Overview
Top
Fig. 1
1. Deck 1
2. Mixer
3. Deck 2

6
Deck
Fig. 2
1) Sync Button 16) Pitch Fader
2) Sampler Selector 17) Bend - Button
3) Sampler Play Button 18) Bend + Button
4) Loop Adjustment 1/8 Button 19) Sensor
5) Search Button 20) BPM Button
6) Scratch Button 21) Shuttle Wheel
7) Hot Cue Buttons 22)PFL Button
8) Cue Button 23) Effects On Button
9) Pause Button 24) Effect Selector Button
10) Play Button 25) Loop In Button
11) Master Volume Control 26) Parameter 1 Control
12) Master Tempo Button 27) Loop Out Button
13) Pitch Button 28) Parameter 2 Control
14)Sampler Volume Control 29) Sample Display
15) Loop Adjustment 16 Button

7
Mixer
Fig. 3
30)Enter/ Folder Select Encoder 39) Folder Out Button
31)Load A Button 40) Load B Button
32)Channel A Gain Control 41)Channel B Gain Control
33)Channel A High Control 42)Channel B High Control
34)Channel A Mid Control 43) Channel B Mid Control
35)Channel A Low Control 44) Channel B Low Control
36)Power LED 45) VU-Meter
37)Channel A Fader 46)Channel B Fader
38) Crossfader

8
Frontside
Fig. 4
47)Crossfader Slope Control
Backside
Fig. 5
48)DC In 5V 1000mA
49)Power Switch
50) USB Connector
Installation
Remove all packing materials from the DS-MP-150. Check that all foam and plastic padding is removed.
Connect all cables.
Always disconnect from electric mains power supply before cleaning or servicing.
Damages caused by non-observance are not subject to warranty.
Set Up and Operation
Before plugging the unit in, always make sure that the power supply matches the product specification
voltage. The power supply is printed on the back of the device.
You can power the DS-MP-150 either by the USB connector or by an optional DC5V/1A adaptor in case
your computer’s USB interface is not able to provide sufficient power.
Connections
1. Turn off the Power (49) switch.
2. Connect the DS-MP-150 to your computer with a USB cable.
3. If the unit is powered by USB, set the Power (49) switch in USB position, if you use an external power
adaptor, set the Power (49) switch in adaptor position. In order to turn the DS-MP-150 on.
CAUTION: Be sure that the power is off, when connecting the cables.
