DARTMOOR E-THUNDERBIRD CF COCKPIT ASSEMBLE INSTRUCTION
*This instruction is an attachment to the general bicycle manual.

2
TABLE OF CONTENTS
1. Dropper seat post assembly.
2. Electric cables support.
3. Assemble of EW-EN100 connector
on the dropper seat post cable.
NOTE: Due to the packaging and
transport, the control connector
is placed in a separate box.
Other system components have
been installed in accordance with
the manual and manufacturer’s
recommendations.
TABLE

3
TABLE OF CONTENTS
The first step aer unpacking the bike is the
front wheel assembly. Aer completing the
first step, install the dropper seat post with the
shier in accordance with the manufacturer’s
manual:
See the manufacturer website.
Always use a SHIMANO genuine tool when removing and inserting electric cables.
2.1 Connection of the electric cable
Connect the electric cable to the E-TUBE port.
1. Align the plug of the electric cable with the SHIMANO
original tool. If there is an adjustment tab on the elec-
tric cable plug, align it with the groove on the SHIMA-
NO original tool.
2.2. Disconnection of the electric cable
Remove the electric cable.
1. Put the original Shimano tool into the groove on the
electric cable plug.
2. Disconnect the electric cable from the e-Tube socket.
1. DROPPER SEAT POST ASSEMBLY 2. ELECTRIC CABLES SUPPORT
CAUTION: When connecting and disconnecting the electric cable, do not force the plug to bend it. This can
result in poor connection quality.
CAUTION: Do not repeat the operation of connect-
ing and disconnecting the electric cable too oen.
The connector can be used or deformed, which can
aect on lack of water resistance and good quality
connection.
According to the figure above, use the (A) parts of
the original Shimano tool as a rotating support and
move like a lever, then disconnect it. If the amount
of space for setting up the tool is limited, put the
original Shimano tool up and disconnect the elec-
tric cable.
*
2. Insert the plug of the electric cable into the E-TUBE
slot. Push it straight in until you feel a click.
plug
E-TUBE slot

4
TABLE OF CONTENTS
3. ASSEMBLE OF THE EW-EN100 CONNECTOR ON THE DROPPER SEAT POST CABLE
The EW-EN100 is a connector with simple operation / display functionality.
3.1 Determine the place of the EW-EN100 asseble, then set up the adapter
3.2 Set up the EW-EN100 part, then connect it to the electric cables
The redundance of electric cable should be tucked into the frame. Then secure the electric cable on both sides of
the connector by wrapping the spiral provided in the kit. Cut the wrapper to adjust to the desirable length. The final
eect is shown in the photo on the le.
1. Open the adapter and set the dropper seat post on
the cable.
2. Bend the adapter on the dropper seat post cable.
Adapter
Cable housing
EW-EN100
Adjust the holes on the inside area.
CAUTION: Installation of the EW-EN100
Install the EW-EN100 as shown in the figure below to aviod touching the sides of the frame. Otherwise, it
may be damaged in case of tipping over the bicycle and being squeezed between the frame and the ground.

5
