DATREND Systems vPad-RW User manual

vPad-RW TM
Radiant Warmer Tester
Operating Manual

vPad-RW ™
Radiant Warmer Tester
Operating Manual
© 2015 Datrend Systems Inc.
130-4020 Viking Way
Richmond, BC • CANADA • V6V 2L4
Tel: [phone] (North America Only) or
604.291.7747 • Fax [phone]
e-mail: [e-mail]

This manual is Datrend P/N: 6100-120
Revision Revision History Description Date
A Initial Release 2015-Mar-18
Copyright
Datrend Systems Inc. (“DSI”) agrees to a limited copyright release that allows you to reproduce manuals and other
printed materials for use in service training programs and other technical publications. If you would like other
reproductions or distributions, submit a written request to Datrend Systems Inc.
Unpacking and Inspection
Follow standard receiving practices upon receipt of the instrument. Check the shipping carton for damage. If damage
is found, stop unpacking the instrument. Notify the freight carrier and ask for an agent to be present while the
instrument is unpacked. There are no special unpacking instructions, but be careful not to damage the instrument
when unpacking it. Inspect the instrument for physical damage such as bent or broken parts, dents, or scratches.
Claims
Our routine method of shipment is via common carrier. Upon delivery, if physical damage is found, retain all packing
materials in their original condition and contact the carrier immediately to file a claim. If the instrument is delivered in
good physical condition but does not operate within specifications, or if there are any other problems not caused by
shipping damage, please contact your local sales representative or Datrend Systems immediately.
Standard Terms and Conditions
Refunds & Credits
Please note only serialized products (products labelled with a distinct serial number) and accessories are eligible for
partial refund and/or credit. Non-serialized parts and accessory items (cables, carrying cases, auxiliary modules,
etc.) are not eligible for return or refund. In order to receive a partial refund/credit, the product must not have been
damaged, and must be returned complete (meaning all manuals, cables, accessories, etc.) within 90 days of original
purchase and in “as new” and resalable condition. The Return Procedure must be followed.
Return Procedure
Every product returned for refund/credit must be accompanied by a Return Material Authorization (RMA) number,
obtained from Datrend Customer Service. All items being returned must be sent prepaid (freight, duty, brokerage,
and taxes) to our factory location.
Restocking Charges
Products returned within 30 days of original purchase are subject to a minimum restocking fee of 15%. Products
returned in excess of 30 days after purchase, but prior to 90 days, are subject to a minimum restocking fee of 20%.
Additional charges for damage and/or missing parts and accessories will be applied to all returns. Products which
are not in “as new” and resalable condition, are not eligible for credit return and will be returned to the customer at
their expense.
Certification
This instrument was thoroughly tested and inspected and found to meet DSI’s manufacturing specifications when it
was shipped from the factory. Calibration measurements are traceable to the National Research Council of Canada
(NRC) and/or the National Institute of Standards and Technology (NIST). Devices for which there are no NRC/NIST
calibration standards are measured against in-house performance standards using accepted test procedures.

WARRANTY
Warranty and Product Support
Datrend Systems Inc. ("DSI") warrants this instrument to be free from defects in materials and workmanship under
normal use and service for one (1) year from the date of original purchase. This warranty will be automatically
extended to a maximum of five (5) years from the date of original purchase provided that calibration is performed
on an annual basis by a Datrend Authorized Service Center (refer to Chapter 7 of this manual). During the warranty
period DSI will, at our option, either repair or replace a product at no charge that proves to be defective; provided
you return the product (shipping, duty, brokerage and taxes prepaid) to DSI. Any and all transportation charges
incurred are the responsibility of the purchaser and are not included within this warranty. This warranty extends only
to the original purchaser and does not cover damage from abuse, neglect, accident or misuse or as the result of
service or modification by other than DSI. IN NO EVENT SHALL DATREND SYSTEMS INC. BE LIABLE FOR
CONSEQUENTIAL DAMAGES.
This warranty applies only to Datrend manufactured product and does not include OEM components which are
provided as part of a system. These OEM components include, but are not limited to tablet, netbook, laptop or
desktop computers, and these components shall be covered only by the OEM manufacturer’s limited warranty, and
warranty issues must be handled direct with the manufacturer.
No warranty shall apply when damage is caused by any of the following:
!Misuse or abuse of any form;
!Use of an AC power supply adapter other than the AC adapter specified for the instrument;
!Power failure, surges, or spikes;
!Damage in transit or when moving the instrument;
!Improper power supply such as low voltage, incorrect voltage, defective wiring or inadequate fuses;
!Accident, alteration, abuse or misuse of the instrument;
!Fire, water damage, theft, war, riot, hostility, acts of God, such as hurricanes, floods, etc.
Only serialized products (those items bearing a distinct serial number tag) and their accessory items are covered
under this warranty. PHYSICAL DAMAGE CAUSED BY MISUSE OR PHYSICAL ABUSE IS NOT COVERED
UNDER THE WARRANTY. Items such as cables and non-serialized modules are not covered under this warranty.
This warranty gives you specific legal rights and you may have other rights, which vary from province to province,
state to state, or country to country. This warranty is limited to repairing the instrument to DSI's specifications.
When you return an instrument to DSI for service, repair or calibration, we recommend shipment using the original
shipping foam and container. If the original packing materials are not available, we recommend the following guide
for repackaging:
!Use a double-walled carton of sufficient strength for the weight being shipped.
!Use heavy paper or cardboard to protect all instrument surfaces. Use non-abrasive material around all projecting
parts.
!Use at least four inches of tightly packed, industrial-approved, shock-absorbent material all around the instrument.
DSI will not be responsible for lost shipments or instruments received in damaged condition due to improper
packaging or handling. All warranty claim shipments must be made on a prepaid basis (freight, duty, brokerage, and
taxes). No returns will be accepted without a Return Materials Authorization ("RMA”) number. Please contact
Datrend Systems, 1(604)291-7747 or email customers[email protected] to obtain a Return Materials
Authorization (RMA) number and receive help with shipping/customs documentation.
Re-calibration costs of instruments are not covered under the warranty.

Warranty Disclaimer
Should you elect to have your instrument serviced and/or calibrated by someone other than Datrend Systems,
please be advised that the original warranty covering your product becomes void when the tamper-resistant Quality
Seal is removed or broken without proper factory authorization. We strongly recommend, therefore, that you send
your instrument to Datrend Systems for service and calibration, especially during the original warranty period.
In all cases, breaking the tamper-resistant Quality Seal should be avoided at all cost, as this seal is the key to your
original instrument warranty. In the event that the seal must be broken to gain internal access to the instrument (e.g.,
in the case of a customer-installed firmware upgrade), you must first contact Datrend Systems. You will be required
to provide us with the serial number for your instrument as well as a valid reason for breaking the Quality Seal. You
should break this seal only after you have received factory authorization. Do not break the Quality Seal before you
have contacted us! Following these steps will help ensure that you will retain the original warranty on your instrument
without interruption.
WARNING
Unauthorized user modifications or application beyond the published specifications may result in electrical shock
hazards or improper operation. Datrend Systems will not be responsible for any injuries sustained due to
unauthorized equipment modifications.
DSI DISCLAIMS ALL OTHER WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING ANY WARRANTY OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE OR APPLICATION.
THIS PRODUCT CONTAINS NO USER-SERVICEABLE COMPONENTS.
UNAUTHORIZEDOPENINGOFTHEINSTRUMENTSHALLVOIDTHISAND
ALL OTHER EXPRESSED OR IMPLIED WARRANTIES.
vPad™, vPad-XPORT™, vPad-ES™, vPad-353™, vPad-AS™, vPad-A3™, vPad-NFPA™, vPad-IN™, vPad-RW™
, vPad-Record Manager™, vPad-RM™ , vPad-EQM™, vPad-Check™, vPad-Cal™, and Datrend Docs™ and CMX™
are trademarks of Datrend Systems Inc.
Android™ is trademark of Google Inc.

vPad-RW OPERATING MANUAL
Table of Contents
1Specifications ........................................................ 1
1.1GeneralSpecifications .............................................. 1
1.2DataCollectionSpecifications ........................................ 2
1.3StandardAccessories............................................... 3
1.4OptionalAccessories ............................................... 3
2GeneralInformation ................................................... 5
2.1Overview ......................................................... 5
2.2Features ......................................................... 5
2.3 Controls and Interface Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2.4 Setup ........................................................... 9
2.5PowerOn ....................................................... 13
2.6vPad-RWSoftware................................................ 13
2.7RadiantWarmer .................................................. 14
3TabletSetup ........................................................ 15
4Operation .......................................................... 17
4.1HOMEScreen.................................................... 17
4.2Startup.......................................................... 19
4.3TestSettings..................................................... 20
4.4GlobalSettings ................................................... 20
4.5 Create / Edit / Run Autosequences . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
4.6RunTest ........................................................ 28
5RunningaTest ...................................................... 31
5.1Overview ........................................................ 31
5.2 Ambient Air Flow and Temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
5.3 Manual Temperature Control Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
5.4BabyTemperatureControl .......................................... 36
5.5ProbeTest....................................................... 39
5.6AlarmSoundLevel-Inside.......................................... 44
5.7AlarmSoundLevel-Outside ........................................ 45
5.8SavingTestReports ............................................... 47
6TestReports ........................................................ 49
6.1Overview ........................................................ 49
6.2RecallingRecords................................................. 49
6.3ViewRawData ................................................... 51
6.4ExportingData ................................................... 52
7CalibrationandMaintenance ........................................... 53

vPad-RW OPERATING MANUAL

vPad-RW OPERATING MANUAL
Abbreviations, Definitions and Symbols
The following abbreviations, terms and acronyms are used throughout this manual:
ACTRE Air Control Temperature Regulation Error
AIT Average Incubator Temperature
ATX Average Temperature of Temperature Sensor X, where X = 2 - 5
AV Air Velocity
BSL Background Sound Level
°C degrees Celsius (centigrade)
°F degrees Fahrenheit
Autosequence A series of measurements or test operations that are run
automatically in a predefined order, with or without user involvement.
DUT Device Under Test
GUI Graphical User Interface
IT Incubator Temperature
IIT Independent Incubator Temperature
NSL Noise Sound Level
STC Steady Temperature Condition
STS Skin Temperature Sensor
TC Temperature Control
TEMP Temperature
WT Warm Up Time
CAUTION: Read the instructions for use before operating this device.
Definitions:
Some of the following definitions are paraphrased from the relevant sections and
clauses of IEC 60601-2-21
Mid Point Average
Temperature Section 1, clause 2.10.103: the TEST DEVICE AVERAGE TEMPERATURE of the TEST DEVICE positioned at the mid
point of the EQUIPMENT mattress
Test Device
Average
Temperature
Section 1, clause 2.10.102: the average temperature reading
taken during a STEADY TEMPERATURE CONDITION at
regular intervals at the center of a TEST DEVICE

vPad-RW OPERATING MANUAL
TEST DEVICE Section 1, clause 2.1.102: the A totally matte blackened disc
used as a reproducible receiver of radiant energy during the
testing of the INFANT RADIANT WARMER
Control
Temperature Section 1, clause 2.10.104: temperature set at the temperature control (of the RADIANT WARMER as the desired temperature)
Autosequence A series of measurements or test operations that are run
automatically in a predefined order, with or without user
involvement
Device Under Test
(DUT) The device being tested by vPad-RW (the RADIANT WARMER)
Graphical User
Interface A display system for the test instrument (vPad-RW) which relies on graphics to a large extent to display information. In the case
of vPad-RW, this is an Android Tablet (10") with an Android
type operating system (4.1.1), or equivalent
Infant Radiant
Warmer Section 1, clause 2.2.101: an electrically powered device with a radiant heating source intended to maintain the thermal balance
of an infant PATIENT by direct radiation of energy in the infra-
red region of the electromagnetic spectrum
Steady Temperature
Condition Section 1, clause 2.10.101: the condition reached when the temperature, measured at the center of the TEST DEVICE
positioned on the midpoint of the EQUIPMENT mattress, does
not vary by more than 1
o
C over a period of one hour
Skin Temperature
Sensor Section 1, clause 2.10.101: a sensing device including the link with the EQUIPMENT intended to measure the infant’s SKIN
TEMPERATURE

vPad-RW OPERATING MANUAL
Specifications/Chapter 1 # Page 1
1 Specifications
1.1 General Specifications
Environment:
• 15 °C to 40 °C (59 °F to 104 °F)
• 10% to 90% Relative Humidity
• Indoor Use nly
• Category II
• Pollution Degree 2
Note: Mains supply voltage fluctuations not to exceed +/- 10% of the nominal supply voltage.
User Interface:
vPad-RW is supplied with a 10" (nominal) Android tablet which has the vPad-RW software
application pre-installed and ready to run. In some instances, the hardware for vPad-RW may
have been supplied with vPad-IN. The software is controlled by touching a function button
on the graphical user interface (GUI) or, where applicable, by entering specific data via the on
screen keyboard.
Display (10" Android Tablet :
1920 x 1200 color IPS touch screen LCD

vPad-RW OPERATING MANUAL
Specifications/Chapter 1 # Page 2
1.2 Data Collection Specifications
Temperature:
• Measurement Range: 0 °C - 50 °C
• Accuracy: T1: ± 0.05 °C
• Resolution: 0.01 °C
• Convection: 5 ‘puck’ sensors (T6 - T10) - radiant warmer
• Air Conduction: 5 sensors (alternate ‘post’ T1 - T5) - incubator
1 mattress temperature
• ptional Skin Sensor
‘oven’ with thermal pad
contact:
28 °C to 40 °C in 2 °C increments ± 0.01 °C resolution,
± 0.05 °C Accuracy
Airflow:
• Measurement Range: 0.1 to 1 m/s
• Accuracy: ± 0.1 m/s
at 50% RH ± 15%
Sound Level:
• Measurement Range: 30 dbA to 90 dbA, Type III
• Accuracy: ± 3 dbA
• Resolution: 0.1 dbA
Data Retention:
• Capacity: up to 48 hours per test
• Sample Rate: 1/min or 1/sec, depending on parameter

vPad-RW OPERATING MANUAL
Specifications/Chapter 1 # Page
1. Standard Accessories
AC Adapter (all models) 100-240 VAC 50/60 Hz to 9 VDC: P/N 3000-611
Blade Sets Kit (for P/N 3000-611): P/N 7500-490
(Includes: North America; Europe/Schuko; United Kingdom; China/Australia)
AA Battery, 1.2V 2300mAH: P/N 3310-012
1.4 Optional Accessories
For a complete list of available accessories, visit www.datrend.com or contact Datrend
Customer Service (see Chapter 7 for contact details).

vPad-RW OPERATING MANUAL
Specifications/Chapter 1 # Page 4

vPad-RW OPERATING MANUAL
1Throughout this manual, IEC 60601-2-21 is referred to as the “Standard”
Overview/Chapter 2 # Page 5
2 General Information
2.1 Overview
vPad-RW is a portable datalogging system for temperature, air flow, and sound level;
specifically configured to test infant radiant warmers and, optionally, incubators and transport
incubators to applicable IEC performance standards. The data collection system is designed to
operate for up to 48 hours from a rechargeable 4.8VDC nickel-metal hydride (4 AA cells)
battery, or alternatively, from a 5VDC switchmode AC adapter. The sensors and the data
collection system are placed on the mattress of the radiant warmer, and external to the device
under test (DUT), a user interface based on an Android tablet communicates wirelessly to the
sensor system via Bluetooth, and provides the user with the ability to control the test operation
and display the results without disturbing the test environment.
vPad-RW incorporates all the functionality necessary to meet the requirements of the IEC
standards, related to temperature, airflow and sound level tests. vPad-RW incorporates a
graphical user interface which interfaces wirelessly to 5 temperature sensors, 1 airflow sensor,
and 1 sound level meter. vPad-RW also incorporates a non-volatile memory or "data log" which
is used to save test data, such tests typically being conducted by the user over several hours or
days.
2.2 Features
IEC 60601-2-21
1
is a standard which specifies safety and performance requirements for an
infant radiant warmer. Some of the parameters that lend themselves to testing are temperature,
sound level, and air flow. These parameters are monitored at specific locations within the
radiant warmer and are expected to conform to the values defined by the Standard. vPad-RW
provides a mechanical framework to hold the sensors in the appropriate locations, and provides
the ability to adjust the framework to fit warmers of various sizes.
vPad-RW provides 5 temperature sensors which are positioned according to the Standard, with
one central sensor and one sensor in the center of each of four quadrants on the mattress. The
central sensor is an integral component of the data collection and wireless communication hub

vPad-RW OPERATING MANUAL
Overview/Chapter 2 # Page 6
of the system. In addition to the 5 temperature sensors, vPad-RW provides airflow, and sound
level sensors in separate packages which connect to the central hub. The test protocols are
designed to perform all the temperature tests in one contiguous time block to avoid numerous
long heating and cooling cycles. Tests of airflow, or sound are performed either before or after
the temperature tests so that the sensors can be moved about in the radiant warmer without
disrupting a temperature test.
2. Controls and Interface Connections
Referring to Figure 1 through Figure 6, the following components, controls and interfaces of
the vPad-RW Radiant Warmer Test system are:
Note: the hardware components for vPad-RW are virtually identical to vPad-IN. The
differences are in the setup, and which temperatures to measure. If the user has one of the
systems (hardware), only the software is needed to do the other EQUIPMENT (incubator).
1. Sensor Electronics and Wireless
Hub (the HUB)
Provides the connection point for all sensors used
internally to the incubator or warmer under test.
Also referred to as the DAT unit
2. Temperature Connectors Temperature Probes (T1 - T5) are connected on
the top of the large, black thermal mass (Puck) to
place the thermistor in the correct position above
the mattress. T6 - T10, Temperature Probes are
embedded in the thermal mass (Puck) for use in
radiant warmers.
3. Thermal Mass (the Puck)Thermal mass to mimic the infant body for
convection warming in a radiant warmer. Contains
Magnetic Fasteners (3.b) for attachment of other
sensors
4. Temperature Probe (T1 - T5) Bypasses the thermistor in the Puck and places the
thermistor at the correct position above the
mattress, per the Standard. For use with vPad-IN
5. Mattress Temperature Measures the temperature of the mattress. For use
with vPad-IN
6. Airflow Probe Measures the flow of air, and can be moved as
required. Held in place on the Puck magnetically.

vPad-RW OPERATING MANUAL
Overview/Chapter 2 # Page 7
7. Sound Level Probe Measures sound level. Can be moved within the
device under test (DUT) and can also be connected
to an extension cable for external sound/alarm
level measurements. Held in place on the Puck
magnetically.
8. Humidity Probe Measures Humidity. Can be moved within the
device under test (DUT). Held in place on the
Puck magnetically. Not required for radiant
warmers
9. Hub Connections - Left Side a. T4 Temperature Input
b. T5 Temperature Input
c. Airflow Sensor Input
d. Power Input
e. Power LED
f. Power Switch
10. Hub Connections - Right Side a. T3 Temperature Input
b. T2 Temperature Input
c. Humidity Sensor Input
d. Sound Level Sensor Input
11. Positioning Frame Allows T2/7 - T5/10 Pucks to be positioned with
respect to T1/6 at the center of the mattress
12. Positioning Frame Components a. Longitudinal positioning bar
b. Horizontal positioning bar
c. T bracket
Each of the sensors has an internal magnet on the bottom which will hold it in place on the
Thermal Mass. Each sensor also has a cable with a miniDIN connection to connect to the
HUB.

vPad-RW OPERATING MANUAL
Overview/Chapter 2 # Page 8
Figure 1: Wireless HUB - Right Side View
Figure 2: Wireless HUB - Left Side View
Figure 3:
Sound Level Sensor Figure 4: Air Flow Sensor Figure 5: Humidity Sensor Figure 6: Mattress
Temperature Sensor
