1 Setting up the machine
1.1 Transport
For safe transport to the setup site, the transport route must be
checked. In all areas, make sure that the width, height and load-
bearing capacity are sufficient. Check the following:
■Entrance and parking options for a truck
■Access inside the building (stairs, doors, passageways)
■Stairwells and elevators
■Floor conditions and surfacing
1.2 Setup site
CAUTION
Building damage due to impermissible load-bearing capacity!
When setting up the machine in residential buildings, the
permissible floor load must be checked by a structural engineer.
■Here, observe the machine weight (see table in the chapter
"Dimensions and weight") and also note that the machine
generates dynamic loads of approx. 500 N with a frequency
from 0 to 5 Hz.
The machine is installed on site on a solid base. The floor of
the installation location must be sufficiently strong, rigid and
smooth. The height of the support feet is adjustable and they
are not screwed to the floor. The machine requires a minimum
all-round clearance to its surroundings to allow access to
components within the casing. See the Technical Data for the
various dimensions.
Also observe the legal regulations on occupational health and
safety and escape routes.
CAUTION
Risks of using cooling lubricants!
Flammable vapours may be generated when using cooling
lubricants.
■Open flames, smoking, eating and drinking are prohibited in
the vicinity of the machine.
■The safety instructions of the manufacturer of the cooling
lubricant and material must be observed!

1Setting up the machine
Room climate
1-2 DATRON AG Setup instructions neo
1.21
1.3 Room climate
NOTE Air should be free of aggressive dusts and gases.
Required room climate:
Temperature 18 - 30 °C
Humidity < 65 % rel.
Make sure the room temperature is sufficient. The ideal room
temperature is 20 - 23 °C. The machine must be completely at
room temperature before commissioning. For perfect operation,
the spindles require a coolant temperature of at least 18 °C, ideal
would be 25 °C.
If there is a risk of frost during storage or transport of the DATRON
machine, the cooling water must be completely drained out of the
machine and the cooling device beforehand.
Venting the set-up location Make sure there is good ventilation in the set-up environment.
When machining materials which release harmful dusts, the dusts
which are formed must be suctioned off. Observe the statutory
regulations.
The following must be observed when the machine is operated
with cooling lubricant:
During continuous machine operation the area around the
machine must be well ventilated or an exhaust system for the
removing the cooling lubricant vapour must be installed. When
installing the room exhaust system, note whether the cooling
lubricant in use is lighter or heavier than air. Install the room
exhaust system at the top or bottom as applicable. The AGW
values (maximum workplace concentration values) of the cooling
lubricant must be below the maximum limit.
In HVAC technology, the following general empirical values are
used for the air exchange numbers (i.e. exchanged air per hour):

Setting up the machine
Screen 1
Setup instructions neo
1.21
DATRON AG 1-3
Location Exchanged air
per hour
Workshops 3 - 6
Workshops where especially high levels of fumes
develop 10 - 18
Laboratories 5 - 15
Garages 3 - 5
CAUTION
Hearing damage dur to noise during machine operation!
At idle the noise level at the machine is < 80 dB(A).
When machining a work piece, the noise level may be > 80 dB(A).
■Wear suitable hearing protection at noise levels above
80 dB(A).
■Hearing protection must be available at lower noise levels.
■Work pieces and sheet material that tend to vibrate during
machining must be clamped flat (e. g. with a vacuum plate).
1.4 Screen
Screen
CAUTION
Possible damage to the screen!
Covering the screen leads to excessive heat development.
■Never cover the screen during operation.
■Keep ventilation slots free.

1Setting up the machine
Screen
1-4 DATRON AG Setup instructions neo
1.21

Connecting the supply media
Voltage supply 2
Setup instructions neo
1.21
DATRON AG 2-1
2 Connecting the supply media
CAUTION
Malfunctions and trip hazards
Open and loose machine connections are trip hazards and may
affect machine functions due to damage.
•Avoid loose and open installations of machine connections.
•Install machine connections in enclosed and fixed paths.
•Position machines to enable optimum use of connection ports
in the machine housing.
Connection options The machine can be connected from below, e.g. through a cable
duct in the floor.
2.1 Voltage supply
The power supply must meet the requirements of EN 60204 to
ensure trouble-free operation of the system.
CAUTION
Interference in domestic environments
The machine may generate electromagnetic interference, which
may affect electrical equipment in domestic environments.
■If necessary, employ interference suppression measures in
accordance with DIN EN 61800-3
Information concerning personal
protection ■If the power supply is fitted with a residual current device (RCD
or FI), the device must conform to type B.
■The machine must be connected to a separate power circuit.
■Other consumers must be separately connected.
■Observe the local legal requirements for connection.
WARNING
Danger of injury and death due to high voltage!
Work on electrical devices requires technical knowledge, otherwise
there is a risk of injury and death by electrocution.
■Electrical work must be performed by qualified electricians.

2Connecting the supply media
Network integration
2-2 DATRON AG Setup instructions neo
1.21
CAUTION
Power circuit interruption
If consumers other than the DATRON machine are connected to
the same power circuit, there is risk of circuit interruption.
■Always connect the DATRON machine to a separate power
circuit protected by an RCD (3x16 A).
■Do not connect any other consumers to the circuit used by the
DATRON machine.
Fig. 2-1: Voltage supply connection 3 x 400 V
Data Voltage 3 x 400 V /16 A
Frequency 50 Hz / 60 Hz
Power consumption with 3.5 kW
2.2 Internet connection
An Internet connection for the control computer integrated in
the machine is absolutely necessary to be able to make use of
remote maintenance. This is the only way DATRON can access the
machine control if support is needed, making immediate analysis
and help possible.
2.3 Network integration
Integration of the DATRON machine into the customer's network
happens at the risk and responsibility of the customer.
If you have any questions about the network integration, consult
an IT specialist who can consider the situation at your site.

Connecting the supply media
Network integration 2
Setup instructions neo
1.21
DATRON AG 2-3
Fig. 2-2: Integration of the DATRON computer in a company
network
1Control computer of the DATRON machine
2USB port at the control computer
3Hardware firewall
4Company network
The establishment of a network connection (internet, in-house data
exchange) must be made without changing the configuration of
the control computer (for instance, integration into a domain).
For network integration, DATRON recommends using a hardware
firewall between the control computer and the company network
(see Fig. 2-2).
Only virus-tested media may be connected to the USB port of the
control computer.
Data exchange Data is exchanged with program administration sing a USB stick.

2Connecting the supply media
Compressed air supply
2-4 DATRON AG Setup instructions neo
1.21
2.4 Notes regarding the control computer
Observe the following points to ensure the process reliability of
the machining system and quick help in the event repairs are
needed:
■The DATRON machine may only be operated with the control
components included in delivery. These are an integral part of
the system.
■Do not install any other applications, and also no virus
scanners on the control components, which are not expressly
approved of by DATRON. Additionally installed applications
can lead to non-reproducible, sporadically occurring errors.
2.5 Compressed air supply
The compressed air must meet the requirements of the spindle
manufacturer (see the original spindle operating instructions).
It must be dry, clean and oil-free. Otherwise, the components
through which the air flows could be damaged (especially the
spindle).
Required air purity
Solid contaminants Class 3 Max. particle size 5 µm
max. Particle content 5 mg/m³
Water content Class 4 Max. pressure dew point +3 °C
Total oil content Class 3 Max. oil content 1 mg/m³
NOTE DATRON urgently recommends that an air treatment system be
connected in front of the system!
Any air treatment system available on the market can be used
which fulfils the above requirements. Our commissioning
personnel is instructed to use a suitable air dryer when there is
moisture in the compressed air. This is available for purchase.
If the machine is operated with insufficiently pure compressed air,
the warranty for the spindle and components through which air
flows is invalid.

Connecting the supply media
Cooling lubricant 2
Setup instructions neo
1.21
DATRON AG 2-5
Data
Fig. 2-3: Compressed air connection 1/2" rapid action hose
coupling
Required pressure 7 to 10 bar
Connection 1/2" rapid action hose coupling (NW 7.2 mm)
max. 300 l/min Machine
Compressed air
consumption approx. 100 l/min Compressed air gun
Compressor Design your compressed air supply so that there is a continuous
supply available to the DATRON machine. Depending on the
type of compressor, the capacity must lie much higher than the
consumption of the machine and the supply buffered via a boiler,
so that the compressor has sufficient cooling-off time available.
Please have the manufacturer help you with the design of the
compressor.
2.6 Cooling lubricant
Select a suitable cooling lubricant depending on the application.
WARNING
In the following cases, ethanol is not permissible as a cooling
lubricant:
■Ethanol must not be used as a cooling lubricant when
machining steel or other metals that generate sparks during
machining. Danger of burns due to spark formation! Use a
different suitable cooling lubricant (e.g. fatty alcohol).
■Ethanol is not permitted as a cooling lubricant when suctioning
chips. Danger of explosion in the vacuum cleaner!

2Connecting the supply media
Cooling lubricant
2-6 DATRON AG Setup instructions neo
1.21
When machining non-ferrous metals, use the following cooling
lubricant for perfect operation and the best machining results:
Ethanol (99%, denatured)
Ethyl alcohol 642
EEC designation 200-578-6 (EINECS)
Ethanol can be purchased tax free without any formalities when
the following denaturants are involved: Methyl ethyl ketone,
shellac, pininic colophonium, toluol or cyclohexane.
Germany Austria
BCD Chemie GmbH
Frankfurt Office
Carl-Benz Strasse 4-6
D-60314 Frankfurt am Main
Tel.: +49 - (0) 69 - 40101 - 0
Fax.: +49 - (0) 69 - 425994
[email protected]
LACTAN
Vertriebsgesellschaft m.b.H. & Co KG
c/o Mr Reibenschuh
Puchstrasse 85
A-8020 Graz
Tel.: +43 - (0) 316 - 23692 - 12
Fax.: +43 - (0) 316 - 323692 - 19
[email protected]
Tab. 2-1: Examples for ethanol suppliers
Impermissible cooling lubricants Do not use any drilling emulsions, cooling lubricants with high
solid content or such which tend to flocculate (milky emulsion).
The DATRON machine is not designed for such cooling lubricants
and potential material damage could result. If this is not observed,
it will invalidate the warranty.
NOTE Export restriction for initial filling of the machine with cooling
lubricant and coolant for spindle cooling unit.
DATRON machines are not filled with cooling lubricant when
exported to countries outside the European Union. In this case, the
customer must procure the suitable cooling lubricant.
Check your order confirmation.
DATRON approves the following products for use without
reservation:
•Coolant for spindle cooling unit: Antifrogen-N with a water
content of 25 % - max. 27 %
•cooling lubricant for workpiece machining ProCut 200,
ProCut 56 and ProCut 56-2
If in doubt, consult DATRON.

Connecting the supply media
Chip suction 2
Setup instructions neo
1.21
DATRON AG 2-7
2.7 Chip suction
Only use suctioning systems which are permitted for the material
to be machined.

2Connecting the supply media
Chip suction
2-8 DATRON AG Setup instructions neo
1.21

Technical data
Dimensions and weight 3
Setup instructions neo
1.21
DATRON AG 3-1
3 Technical data
3.1 Dimensions and weight
CNC base system DATRON neo Dimensions (mm)
Weight approx. 700 kg
Width (with screen)/depth approx. 1300/1290
Height 1880
Width with flaps open approx. 2275
Machine
Depth with flaps open approx. 2310
Free space above the machine at least 400
Distance
Free space right of the machine at least 1000
Installation width without packaging, without terminal 805
Operating terminal width/depth 350/570
Support feet Distance 700/980
Chip tray Extension length right 900
Machining traverse paths Traverse path (X/Y/Z) 520/420/230
Portal access Height 175
Transport dimensions
when packed in wrapping
on the pallet (terminal
mounted)
width/depth/height 980/1480/2160

3Technical data
Dimensions and weight
3-2 DATRON AG Setup instructions neo
1.21
400
2275
2310
348
60
1087
570
1880
1296
980
800
63 157
1290
805
700
109
587
1000
492
52 52
265
Fig. 3-1: Machine dimensions

Safety regulations for operating the machine
Dry machining 4
Setup instructions neo
1.21
DATRON AG 4-1
4 Safety regulations for operating the machine
The following points are an excerpt from the operating
instructions. Please observe the complete operating instructions
when operating the machine.
4.1 Dry machining
In dry machining, the material is machined without the cooling
spray function. The released dusts must be suctioned by a
deduster.
WARNING
Damage to health due to harmful dusts!
When dry machining materials, dusts which are harmful to health
can be released.
■For this, observe the information on the safety data sheet of the
respective material.
■In the case of harmful dusts, you must use a suitable vacuum
cleaner.
CAUTION
Machine damage due to released dusts!
During machining, the dusts that are released have to be suctioned
off by a suitable vacuum cleaner.
■Check the compatibility of the vacuum cleaner and the material
to be machined.

4Safety regulations for operating the machine
Processing with minimum-quantity cooling lubrication system
4-2 DATRON AG Setup instructions neo
1.21
4.2 Processing with minimum-quantity cooling lubrication system
CAUTION
Hazard posed by using cooling lubricants!
When using cooling lubricants which have not been explicitly
recommended by DATRON, observe the manufacturer
specifications with regard to fire and explosion hazards. If in
doubt, consult a safety professional.
■Canisters with cooling lubricants must be labelled.
■Only use the cooling lubricants recommended by DATRON,
since these are optimally suited for the system. Non-
recommended cooling lubricants can lead to poor results and
damage of the machine.
■When using cooling lubricants, make sure there is sufficient
ventilation at the setup site.
■Observe the safety data sheet of the used cooling lubricant.
CAUTION
Danger of blockage in the vacuum cleaner!
Suctioning is not allowed when machining with cooling lubricants.
■Switch the vacuum cleaner off beforehand.
