Datum Storage Ez2 Drawer User manual

C
Figure A
Figure B
Detail C
INST0089REV0TJE8/6/04
Ez2 Drawer Installation Instructions
Step 1: Pay close attention to how Slide
properly functions before disassembling to
aid in reassembling later. Remove Large
Part of Slide that is riveted to Bracket by
engaging Release Lever to allow this part to
slide off.
Release Lever
Step 2: Attach each Bracket with Large Part of Slide to
desired location on cabinet with two #10-24 x 1/2" Type 'F'
Phillips Pan Head Screws as shown in Detail C.
Large Part of
Slide & Bracket
#10-24 x 1/2"
Screw
Bracket
Inside of Cabinet
Page 1
Lock Optional

E
Detail E
Ez2 Drawer Installation Instructions
Step 3: Install Drawer by reassembling parts of Slide.
Page 2
Reassemble Parts of Slide
Note: Before adding additional drawers or
shelves above the drawer just installed, be sure
there is clearance for media being stored.
If you need assembly assistance, please contact Customer Service at
1-866-217-0330 (Monday through Friday 8:00 AM - 5:00 PM E.S.T.)
