Davcor Smartlock Digital ComboGard Pro 39E User manual

www.smartlockdigital.com
1.
Enter “Zero” six times
DUAL CODE
2.
Enter your existing six (6) digit code once
Two combinations required to open
3.
Enter your NEW six (6) digit code two times
TI
ME DELAY
4.
If a mistake is made wait thirty (30) seconds and repeat steps 1-3
Delay period 1-99 minutes
5.
test lock operation several times before closing the door
Open period 1-19 minutes
39E ComboGard Pro
4300M swingbolt/ 6040M squarebolt/ 6034 springbolt instructions
Operating Guide_
Factory default code is open on ‘1’ (see keypad only setup instructionsbefore operating lock)
Opening the Lock
1. Enter valid six (6) digit combination. The lock will emit a double beep if
valid code has been entered.
2. Within 3.5 seconds of entering the valid code the lock can be opened-
either turn the keypad or handle (depending on how the lock has been
installed. Please ask your installer for further details)
3. Pull door open.
INVALID CODE ENTRY – Triple beep after six (6) digits are entered
VALID CODE ENTRY- double beep after six (6) digits are entered
Opening the Lock with Time delay (feature must be pre-enabled)
1. Enter valid six (6) digit combination. Delay period starts. LED flashes
RED at one (1) second intervals
2. At end of delay period open period starts. LED flashes RED at ½ second
intervals. During open period enter valid code to open
1. If valid code entered during delay, delay restarts
2. If invalid code entered during delay, delay aborts
3. If invalid code entered during open period, open period continues
Dual Combination Operation (feature must be pre-enabled)
1. Second user must be added in setup stage of lock and dual mode
turned on. Second user cannot then be disabled or removed.
2. If time delay is active, one valid code will start the delay period. Both
codes must then be entered to open the lock during the open period
3. To open, enter both codes, one after the other
Time Delay Override Operation (feature must be pre-enabled)
1. User 9 must be added in setup stage of lock and TDO mode turned
on, User 9 cannot then be disabled or removed
2. Entry of override code during Delay period will open the lock
3. Entry of override code at any time will immediately open the lock
Silent Signal Alarm (feature must be pre-enabled, duress interface required)
1. Enter code as normal but enter the last digit one number HIGHER or
LOWER
EXAMPLE: code = 123456. Duress code is 123455 or 123457
The lock will open without any indication duress has been sent.
Changing your code
Always perform operation with the door open
If lock is enabled for dual code each code must be changed
independently
STANDARD
FEATURES
WRONG TRY
PENALTY
Four (4) consecutive invalid codes initiates
five minute delay period.
LOW BATTERY WARNING
Repeated audio and visual signal (LED
flashing and repeated beeping) during
opening indicates battery low.
AUDIO AND VISUAL SIGNAL
Double signal (LED flashes and unit beeps)
indicates entry is valid or accepted.
Triple signal indicates invalid or not
accepted.
PROGRAMMABLE FEATURES
ACTIVE
MANAGER CODE
Add/remove second user
Enable/disable second user
USER CODE
Open lock
Change Code
TIME DELAY OVERRIDE
VALID CODE ENTRY- double beep after valid six (6) digits are entered
INVALID CODE ENTRY – Triple beep after six (6) digits are entered and
old code is still valid
SILENT SIGNAL ALARM
Duress signal if last number of code (s) is
entered using one number higher or one
number lower
DISABLE LOCK
Input signal disables opening of lock by
valid code
Smartlock Digital – a division of Davcor Pty Ltd ABN 95 003 562 598 PH [phone] Fax [phone] email [e-mail]

www.smartlockdigital.com
Wrong try penalty
Entry of 4 consecutive invalid codes starts a 5 minute
delay period. LED flashes red at ten (10) second
intervals
At the end of the delay period, two more consecutive
invalid codes will restart an additional 5 minute delay
period
Entry will not respond to a single keystroke during the delay
period
Battery low warning
Repeated beeping during an opening indicates that the
battery is low and needs immediate replacement. LA
GARD recommends the replacement of batteries at
least once annually.
MANAGER PROGRAMMING
Add user (feature must be pre-enabled)
Always perform operation with the door open
1. Enter manager code and HOLD DOWN LAST DIGIT of
Changing the Battery
3000 AND 3715 KEYPADS Slide the housing
up,
carefully pull away
from mounting
surface to expose
battery
compartment.
CAUTION! Hold
onto battery
terminal to avoid
pulling wires out of
housing.
To replace, carefully
position the keypad
over the mounting
screws and slide the
keypad housing
down. Ensure that
there are no wires or
cables trapped
between the input
code until the lock signals with 2 sets of double beeps
2. Press 1. lock signals twice
3. Enter user code twice.The lock signals twice after
each valid entry
4. if a mistake is made wait thirty (30) seconds and
repeat steps 1-3
VALID CODE ENTRY- double beep after valid six (6)
digits are entered
INVALID CODE ENTRY – Triple beep after six (6)
digits are entered and old code is still valid
Disable user (manager feature only)
1. Enter manager code and HOLD DOWN LAST DIGIT of
code until the lock signals with 2 sets of double beeps
2. PRESS 2. Lock signals once.
3. User is temporarily disabled.
pad and the safe door. Pinched cables can result in a short circuit.
3750 KEYPADS
Remove black plastic battery
compartment cover (located at the
bottom of the keypad) by gently pulling
down on its handle. Allow the battery and
its attached leads to drop down and out
of the battery compartment. If it does not
drop, gently pull at the battery until it
drops out.
When battery is changed gently push the
battery and the leads completely up into
the battery compartment. Install the
battery cover by placing one side of the
cover in position first and then gently
pressing the other side in place.
3035 KEYPADS
Reinstate user (manager feature only)
1. Enter manager code and HOLD DOWN LAST DIGIT of
code until the lock signals with 2 sets of double beeps
2. Press 1. lock signals once
3. User is reinstated
VALID CODE ENTRY- double beep after valid six (6)
digits are entered
INVALID CODE ENTRY – Triple beep after six (6)
digits are entered and old code is still valid
Remove user (manager feature only)
1. Enter manager code and HOLD DOWN LAST DIGIT of
code until the lock signals with 2 sets of double beeps
2. Press 3. lock signals once
User is permanently deleted. Another code can be added if
required via the add user function
VALID CODE ENTRY- double beep after valid six (6)
digits are entered
INVALID CODE ENTRY – Triple beep after six (6)
digits are entered and old code is still valid
If the battery is completely depleted,
place a 9v battery on the ‘snake eyes’ on
the outside of the keypad, hold the
battery there for
the entire time
while you enter the
code and open the
lock.
There is a battery
box located on the
inside of the safe/cabinet which houses the
battery. Please refer to your cabinet
manufacturer for the exact location. The lid
of the battery box can be lifted and the new battery is placed
inside. Exercise caution with cables, and be careful not to get wires
caught in the battery box when replacing the lid, pinched cables
can result in a short circuit.
CHANGING THE BATTERY- Remove 9-Volt Alkaline battery and
replace with new one. The connector is easily removed by
unsnapping it from the two terminals on the top of the battery.
ONLY USE ALKALINE BATTERIES- we strongly
recommend the use of Duracell
