DAWAD WL-18L User manual

1
INSTRUCTION MANUAL
AIR FRYER TOASTER OVEN
MODEL: WL-18L
CAPACITY: 18 LITRES
120V~/60Hz, 1550W
Read all the sections of this booklet and follow all the instructions carefully.
SAVE THESE INSTRUCTION-
For Household Use Only
If you have any questions to our products, please contact us by E-mail:
[email protected] . Our customer services are always ready to offer you a satisfying solution.

2
IMPORTANT SAFEGUARDS
When using electric appliances, basic safety precautions should
always be followed:
PREPARATIONS BEFORE USING:
1. Read all instructions.
•Purpose of the application:
2. Do not use the appliance for any other purpose than described in
this manual. The use of accessory attachments not recommended
by the appliance manufacturer may cause injuries.
3. Do not use outdoors.
4. For household use only.
5. This appliance is not intended for use by persons (including children
younger than 8) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they have
supervision.
6. Do not use appliance for other than intended use.
•Placement of the application:
7. Do not place the appliance on or near combustible materials such
as a tablecloth or curtain. The accessible surfaces may become hot
during use. Do not place on or near a hot gas or electric burner, or
in a heated oven.
8. Do not place the appliance against a wall or against other
appliances. Leave at least 4 inches of free space on the back and
sides and 4 inches of free space above the appliance. Do not place
anything on top of the appliance.
•Safety check:
9. Check if the voltage indicated on the appliance corresponds to the
local main voltage before you connect the appliance.
10. Check whether the plug, the main cord and the application are
damaged. Do not use the appliance if the plug, the main cord or the
heated oven.

3
appliance itself is damaged. Always make sure that the plug is
inserted properly into a wall outlet.
11. To protect against electric shock, do not immerse cord, plugs, or
appliance in water or other liquid. Do not plug in the appliance or
operate the control panel with wet hands.
•Regarding to children:
12. Close supervision is necessary when any appliance is used near
children. Children should be supervised to ensure that they do not
play with the appliance. Cleaning and user maintenance shall not be
done by children unless they are older than 8 and supervised.
DURING USING:
•Avoid damage of application:
13. Do not let the cord hang over the edge of the table or counter or
touch hot surfaces.
14. Never connect this appliance to an external timer switch or separate
remote-control system in order to avoid a hazardous situation. To
disconnect, turn off the appliance, then remove plug from wall
outlet.
•Avoid injuries of users:
15. Do not let the appliance working unattended. Extreme caution must
be used when moving an appliance containing hot oil or other hot
liquids.
16. Do not touch the hot surfaces; use handle. During air frying, hot
steam is released through the air outlet openings. Keep your hands
and face at a safe distance from the steam and from the air outlet
openings. Also be careful of hot steam and air when you remove
the pan from the appliance.
17. Use extreme caution when removing tray or disposing of hot
grease.
•Placement of items in the application:
18. Oversize foods or metal utensils must not be inserted in a toaster
oven as they may create a fire or risk of electric shock.
19. Extreme caution should be exercised when using containers

4
constructed of anything other than metal or glass.
20. Do not use accessories, which are not recommended, on the oven.
21. Do not place any of the following materials in the oven: paper,
cardboard, plastic, and the like.
22. Do not place anything on the glass door when it is opened.
•Operation of application:
23. Suggest to follow setting of temperature, time and function from
professional recipes.
24. Do not cover crumb tray or any part of the oven with metal foil. This
will cause overheating of the oven.
•Placement of application:
25. A fire may occur if the toaster oven is covered or touching
flammable material, including curtains, draperies, walls, and the
like, when in operation. Do not store any item on top of the
appliance when in operation.
•Emergent situations:
26. Immediately unplug the appliance if you see dark smoke coming out
of the appliance. Wait for the smoke emission to stop before you
remove the pan from the appliance.
AFTER USING:
•Cleaning of application:
27. After using the appliance, avoid contact with the hot metal inside.
Unplug from outlet when not in use and before cleaning. Allow to
cool before cleaning the appliance.
28. Do not clean with metal scouring pads. Pieces can break off the pad
and touch electrical parts, creating a risk of electric shock.
•Damage of application:
29. Do not operate any appliance with a damaged cord or plug, after
the appliance malfunctions, or has been damaged in any manner.
Return appliance to the nearest qualified service facility for
examination, repair, or adjustment.

5
•Storage of application:
30. Do not store any materials, other than manufacturers-recommended
accessories, in this oven when not in use.
•Movement of application:
31. Check the oven is power off before moving the oven.
SAVE THESE INSTRUCTIONS
IMPORTANT SAFEGUARDS
CORD SAFETY
1. A short power-supply cord is provided to reduce risk of becoming
entangled in or tripping over a longer cord.
2. Extension cords may be used if care is exercised in their use.
3. If an extension cord is used:
4. The marked electrical rating of the extension cord should be at least
equal to the electrical rating of the appliance;
5. The longer cord should be arranged so that it will not drape over the
countertop or tabletop where it can be pulled on by children or
tripped over.
ELECTRICAL POLARIZED PLUG
This unit has a polarized plug (one blade
is wider than the other). To reduce the
risk of electric shock, the plug is
intended to be used by inserting it into
the electrical outlet only one way.
If the plug does not fit securely into the
outlet, reverse the plug and re-insert. If it
still does not fit, contact a qualified
electrician for assistance. Do not modify
the plug in any way.
･The marked electrical rating of the extension cord should be at least
equal to the electrical rating of the appliance;
･The longer cord should be arranged so that it will not drape over the
countertop or tabletop where it can be pulled on by children or
tripped over.

6
SPECIFICATIONS:
Model Number：WL-18L
Voltage &: 120V~ 60Hz
Product Dimension: 16” x 15” x 13.5” (L x D x H)
Dimension: 19” x 17” x 16” (L x D x H)
Power:1550W
Capacity: 18L
Net weight: 17.5 lbs
Gross weight: 21 lbs
Accessories：Pan, Grill rack, Fry basket Crumb tray
Up heating tube: 60V~ 350W 60Hz 4pcs,
Down heating tube: 60V~ 400W 60Hz 2pcs
USING YOUR AIR FRYER OVEN
BEFORE USING FOR THE FIRST TIME
1. Remove all packaging stickers,and labels from the unit
2. Wash the Fry Basket, Oven Rack, Baking Pan, and Crumb Tray with
hot water, some dish-washing liquid, and a non- abrasive sponge. Dry
before placing trays into Air Fryer Oven.
3. Place the Crumb Tray in the bottom of the Air Fryer Oven
CAUTION:
1. Do not place the Air Fryer Oven against a wall or against other
appliances. It is important to leave at least 4 inches of free space on
the back and sides, and 4 inches of free space above the Air Fryer
Oven to allow for proper ventilation.
2. Do not put anything on top of the Air Fryer Oven.
3. Water may be leaved on the countertop since water will release from
food during cooking.
Oven.

7
Crumb Tray
KNOW YOUR AIR FRYER OVEN FUNCTION:
Toast timer Thermostat Lamp key
Work light
Function switch
Oven timer 60’min
Baking Pan
Fry Basket
Oven Rack
When using baking pan, please put
it on the oven rack.

8
FUNCTION INTRODUCTION:
Broil:
This function is used to cook beef, chicken, pork, fish and other meats.
Tips for broiling:
• Do not put food exceed the capacity of the container.
• Avoid to use glass dishes.
Toast:
This function is commonly used to toast bread. DAWAD oven allows to select
three modes of toasting, satisfying different preferences of tastes.
Tips for toasting:
• Put the container in the middle of the application.
Bake:
This function is usually used to cook various dishes, including cake, muffin,
cookies and so on.
Tips for baking:
• When cooking frozen food, it is recommended to place the container at the upper part of the
oven.
• When cooking fresh food, it is recommended to put the containers at the lower part of the
oven.
Air Fry:
This function is designed to replace deep fry. It mimics the taste of oil-fried food
using much less oil and in a way with low calorie and low fat, and provides
delicious and healthy food for those who have preference of fried food.
Tips for air frying:
• Distribute some oil evenly on the surface of the food before cooking.
• Some food with large volume requires to flip halfway during cooking.
• Coating, such as breadcrumbs, can be used on the air fried food.

9
WORKING INSTRUCTIONS:
Warm:
• Warm: turn the function knob to warm, turn the thermostat knob to warm,
turn the OVEN TIMER, oven working. (power:800w, down heating tube )
Broil:
• Broil (top browning): turn the function knob to broil ,turn the thermostat
knob to 450 degrees F or less, turn the OVEN TIMER, oven working.
(power:730w, 2pcs up heating tube and motor)
• Convection Broil (even browning): turn the function knob to Convection Broil
,turn the thermostat knob to 450 degrees F or less, turn the OVEN TIMER,
oven working. (power:750w, 2pcs up heating tube and motor)
Toast:
• Toast: turn the function knob to toast, turn the thermostat knob to 450
degrees F, turn the TOAST TIMER, oven working. The knob scale is the time
of cooking 2-4 slices of bread at a time. The increase or decrease of the
number of bread slices needs corresponding increase or decrease time.
(power:1500w, down heating tube and up heating tube and motor)
Bake:
• Bake (top browning): turn the function knob to bake ,turn the thermostat
knob to 450 degrees F or less, turn the OVEN TIMER, oven working.
(power:1530w, down heating tube and motor and up heating tube)
• Convection Bake (even browning): turn the function knob to Convection
Bake, turn the thermostat knob to 450 degrees F or less, turn the OVEN
TIMER, oven working. (power:1550w, down heating tube and motor and up
heating tube)
Air fry:
• Air fry: turn the function knob to air fry ,turn the thermostat knob to 450
degrees F or less, turn the OVEN TIMER, oven working. (power:1450w, up
heating tube and motor)

10

11
•
CLEANING & MAINTENANCE
WARNING: Never immerse cord, plugs, or appliance in water or other liquid.
Do not plug in the appliance or operate the control panel with wet hands.
• Clean the appliance after each use.
• Always unplug the appliance and let it cool down completely beforecleaning.
Never use abrasive cleaner or corrosive products to clean the appliance,as
this may damage the appliance surface and cause rust.
• Clean the exterior with soapy sponge or towel.
• Wet the towel or sponge in soap water,and clean the interior with wet towel or
sponge.Remove all the residue after each use.
• Clean accessories in dishwasher, or hand wash with a nylon scoring pad or
brush in warm, soapy water.
STORAGE
1. Unplug the appliance and let it cool down.
2. Make sure all parts are clean and dry
3. Store the appliance in a clean and dry place.
ENVIRONMENT
Do not throw away the appliance with the normal household waste at the end
of its life, but hand it in at an offcial collection point for recycling. By doing this,
you help to preserve the environment.
GUARANTEE AND SERVICE
If you need service or information or if you have a problem, please contact
us by email [e-mail].

12
TROUBLESHOOTING
Problem
Solution
The Air Fryer Oven does
not perform
Ensure the unit is plugged into a dedicated
power outlet.
Food is not cooked
Use smaller batches for more even cooking
Raise temperature and continue cooking
Food is not fried evenly
Turn over food halfway through cooking
process
Cook similar sized foods together
White smoke is coming
out of the Air Fryer Oven
Clean the Air Fryer Oven and accessories
after each use to remove greasy residue
French Fries are not cooking
evenly
Fry less potatoes at a time
Blanch potatoes with boiling water before frying
Use firm, fresh potatoes cut into sticks
Fries are not crispy
Remove excess water from potatoes
Cut potatoes into more narrow strips
Mist with a little more oil
