DAXYS Tail Light User manual

LOGO-ICONLOGO-TYPE
(MAIN LOGO)
Colour 1:
Dash Blue
RGB: 0,240,244
HEX: #00F0F4
CMYK: 30,4,4,0
PMS: 311c
Colour 2:
Neutral Black
RGB: 51,51,51
HEX: 333333
CMYK: 15,15,15,90
PMS: Neutral Black C
Daxys Tail Light
Model:
Daxys Tail Light
User Manual

LOGO-ICONLOGO-TYPE
(MAIN LOGO)
Colour 1:
Dash Blue
RGB: 0,240,244
HEX: #00F0F4
CMYK: 30,4,4,0
PMS: 311c
Colour 2:
Neutral Black
RGB: 51,51,51
HEX: 333333
CMYK: 15,15,15,90
PMS: Neutral Black C
Daxys Tail Light
Model:
王婷/宣章珊
对接人：
Take out the light to install on seatpost, thicker side of silicone downwards, adjust
the tightness to be suitable.
PRODUCT INSTALLATION
OPERATING INSTRUCTIONS
Correct installation:
the light should be
parallel to the ground
Specification
Brightness (lm)
15 lm
5 lm
2 lm
2 lm
Modes
Daytime Flash
High Flash
Low Steady
Low Flash
Working Time
≈ 16.8 hrs
≈ 26 hrs
≈ 9 hrs
≈ 56 hrs
Working Modes
Light Source
Max Brightness
Battery
Input
Visible Beam Distance
Visual Angle
Waterproof
Size
Size (including strap)
Weight
Weight (including strap)
COB
15 lm
200 mAh
Micro 5V/0.1A
>1000m
＞300°
IPX4
54.68*15.6*26mm
120.6*54.68*34.05mm
≈17g
≈27.8g
1
2
3
4
Long press the button for 0.75 seconds to turn on/o the light. Short press
the switch button to select lighting modes : 15lm daytime flash - 5lm high
flash - 2lm steady light - 2lm low flash - cycle.
Modes memory function: when you turn the light on, it lights up in the last
lighting mode you used.
Battery indicator: red light flashes to represent 10%-1% of remaining power
which needed to be charged in time; When charging, red light flashes; Red
light is constant on when fully charged.
Charging: 5V/0.1A.
