Daytona P200T User manual

optos.com
User Guide
P200T
Optos Panoramic Ophthalmoscope
G102748/11_ENG

G102748/11_ENG
WARNING
Before using this system:
The system should be used by trained professionals. Before using the system, please read
the operating instructions and safety recommendations in this user guide.
Failure to follow the instructions for use and safety recommendations provided in this user
guide can cause injury to the patient, to the operator, or to other persons.
CAUTION
In the United States of America, Federal law restricts this device to sale by or on the order
of a physician.
Page 2 of 60
English
Part Number: G102748/11_ENG
Copyright 2021, Optos plc. All rights reserved.

Legal notice
Copyright 2021, Optos plc. All rights reserved.
Optos Plc. products are protected by patents and patent applications listed at www.optos.com/patents.
The information contained within this document is subject to change without notice. The latest version of this
information can be found at optos.com.
This document should be used in conjunction with the assistance information supplied in each application.
Instructions and service information can be obtained by contacting Optos, see Contact us on page55.
Optos does NOT provide guidelines on making reimbursement claims. Diagnostic tests should be ordered by
the consulting physician and this physician is responsible for appropriate usage, adequate documentation
and accurate coding. It is the responsibility of the physician to comply with reimbursement regulations, and
check with the local insurance carrier for reimbursement information and instructions. Optos does NOT accept
any liability for reimbursement claims made while using this device.
Copyright
This document may only be used for your personal, non-commercial use. This document and all its contents
(including without limitation, all text, formats, graphics and logos) are the property of Optos plc and are
protected from unauthorized copying and dissemination by the Copyright, Designs and Patents Act 1988 (as
amended), by various intellectual property laws and by international conventions.
Trademarks
are
Page 3 of 60
Optos, optomap, Daytona, Optos Daytona, California, Optos California, ResMax, 3D Wrap and
registered trademarks. All rights reserved.
WINDOWS is a Trademark of Microsoft Corporation.
ADOBE and ACROBATREADER are Trademarks of Adobe Systems Incorporated.
All other trademarks are the property of their respective owners.
Part Number: G102748/11_ENG
Release Date: January 2021
0197
Manufacturer
Optos plc
Queensferry House
Carnegie Campus
Enterprise Way
Dunfermline, Fife
KY11 8GR
UK
Part Number: G102748/11_ENG
Copyright 2021, Optos plc. All rights reserved. English

Page 4 of 60
English
Part Number: G102748/11_ENG
Copyright 2021, Optos plc. All rights reserved.

Table of Contents
1 Warnings and cautions 11
1.1 General safety 11
1.2 Laser safety 12
1.3 Electrical safety 14
1.4 Environmental safety 15
1.5 EMC safety 15
1.6 Cleaning guidelines 16
1.7 Device failure 17
1.8 Maintaining information security 17
1.9 Data security 18
1.10 Software on Optos-supplied PCs 19
1.11 Symbol and label information 19
2 Introduction 21
2.1 Device description 21
2.2 Intended use 21
2.3 Intended users 21
2.4 Target environment 22
2.5 Contraindications 22
2.6 System configuration 22
2.6.1 System parts 22
2.6.2 Network specification and characteristics 23
2.6.3 Image modalities 24
2.6.4 System software 24
2.6.4.1 Understanding the review software 24
2.6.5 Accessories and detachable parts 25
3 How to... 27
3.1 Get started 27
3.1.1 Switch on each day 27
3.1.1.1 Switch on the image server 27
3.1.1.2 Switch on the scan head 27
3.1.1.3 Switch on browser-based review clients 28
3.1.2 Switch off at the end of each day 28
3.1.2.1 Shut down the scan head 29
3.1.2.2 Install software updates 29
Page 5 of 60
Part Number: G102748/11_ENG
Copyright 2021, Optos plc. All rights reserved. English

3.1.2.3 Log off the image server each day 29
3.1.2.4 Restart the image server each week 29
3.1.3 Use the system 29
3.1.3.1 Using the touch screen 29
3.1.3.2 Using the touch screen keyboard 30
3.2 Capture images 30
3.2.1 Working with patient details 32
3.2.1.1 Working with Modality Work List (MWL) 32
3.2.1.1.1 How to search using MWL 32
3.2.2 How to prepare for image capture 33
3.2.3 How to align the patient 33
3.2.3.1 Patient coaching 33
3.2.3.2 Align the patient 33
3.2.4 How to capture SLO images 34
3.2.4.1 What to do after the image is captured 35
3.2.5 How to capture eye steered images 35
3.2.6 How to capture stereo images 35
3.3 Review images 35
3.3.1 Starting the review software 36
3.3.1.1 How to start the application 36
3.3.2 Reviewing patient images and scans 36
3.3.3 Exiting the review software 36
3.4 Manage the system 36
3.4.1 Managing user details 36
3.4.1.1 How to create user accounts for use on the scan head 36
3.4.1.2 How to create user accounts on the image server 37
3.4.1.3 How to change users 37
3.4.2 How to change the language on the scan head 37
3.4.3 How to change the language displayed in OptosAdvance 37
3.4.4 Storing and archiving images 37
3.4.5 Managing connections 38
3.4.6 Managing the Modality Work List 38
3.4.7 Quality checks 38
3.4.7.1 Self-tests 38
3.4.7.2 Status indicator 38
Page 6 of 60
English
Part Number: G102748/11_ENG
Copyright 2021, Optos plc. All rights reserved.

3.4.7.3 Software update 38
3.4.8 Maintenance 39
3.4.8.1 Servicing 39
3.4.8.2 Warranty 39
3.4.8.3 Cleaning 40
3.4.8.3.1 General cleaning 40
3.4.8.3.2 Cleaning before each patient 41
3.4.8.3.3 How to change the eye piece 41
3.4.8.3.4 Cleaning the main mirror 42
3.4.8.3.5 Disinfection 43
3.4.8.4 Battery replacement 43
3.4.8.5 Cable management 43
3.4.9 Troubleshooting 44
3.4.9.1 Why can't Ilogin? 45
3.4.9.2 What information do I need when contacting Optos? 45
3.4.9.3 How do I image if the alignment system does not recognize the eye? 45
3.4.9.4 How do I restart the scan head? 46
3.4.9.5 How do I restart the image server? 46
3.4.9.6 What should I do if the PC drive on the image server is full? 46
4 Technical Specification 47
4.1 Safety designation (IEC 60601-1) 47
4.1.1 Scan head 47
4.1.2 Connections 48
4.1.3 Scan head dimensions 49
4.1.4 Review client properties 49
4.1.5 Touch screen properties 49
4.1.6 Table requirements 50
4.1.7 Battery 50
4.1.8 Environmental considerations (ambient) 50
4.2 Laser safety designation (IEC 60825-1) 50
4.2.1 External Laser warning information 51
4.2.2 Internal Laser warning information 51
4.2.3 Laser classification 51
4.3 Electromagnetic compatibility (EMC) 51
4.3.1 Guidance and manufacturer declaration - electromagnetic emissions 51
Page 7 of 60
Part Number: G102748/11_ENG
Copyright 2021, Optos plc. All rights reserved. English

4.3.2 Guidance and manufacturer declaration – electromagnetic immunity 52
4.3.3 Recommended separation distances 53
5 Contact us 55
5.1 Global Headquarters 55
5.2 Regional Offices 55
5.2.1 United States and Canada 55
5.2.2 Australia 56
5.2.3 Denmark 56
5.2.4 France 56
5.2.5 Germany and Austria 56
5.2.6 Norway 56
5.2.7 Spain 57
5.2.8 Sweden 57
5.2.9 Switzerland 57
5.2.10 United Kingdom and other European countries 57
Patient Alignment Guide 59
List of Tables
TABLE 1: Network specification 23
TABLE 2: List of parts 25
TABLE 3: List of touch screen icons 30
TABLE 4: List of status indicator lights 38
TABLE 5: List of problems and solutions 44
TABLE 6: Scan head safety designation details 47
TABLE 7: Scan head dimensions 49
TABLE 8: Review client properties 49
TABLE 9: Touch screen properties 49
TABLE 10: Table size requirements 50
TABLE 11: Environmental ranges 50
TABLE 12: List of electromagnetic emission compliance 51
TABLE 13: List of electromagnetic immunity compliance 52
TABLE 14: List of recommended separation distances 53
List of Figures
Page 8 of 60
English
Part Number: G102748/11_ENG
Copyright 2021, Optos plc. All rights reserved.

FIGURE 1: P200T device connected to network (Daytona shown) 22
FIGURE 2: Network data flow 24
FIGURE 3: Example capture and review workflow 31
FIGURE 4: Sample of the connection label 48
Page 9 of 60
Part Number: G102748/11_ENG
Copyright 2021, Optos plc. All rights reserved. English

Page 10 of 60
English
Part Number: G102748/11_ENG
Copyright 2021, Optos plc. All rights reserved.

Chapter 1 - Warnings and cautions
1 Warnings and cautions
Your system is a medical device and must be operated within the safety parameters and instructions defined
in this User Guide.
If the device appears faulty or has non-functioning components, please contact your Optos representative,
see Contact us on page55.
If you have any questions regarding the correct use of your device, please contact your Optos representative
before attempting to operate the device.
Read the warnings and cautions before using your device.
1.1 General safety
WARNING
Guidance for use on patients with Epilepsy
The device uses flashes of light. Some patients with epilepsy may be sensitive to flashes
of light. Caution should be exercised for patients who have a history of reaction to camera
flashes or strobe lighting.
Equipment modifications
No modification of this equipment is allowed.
Positioning scan head on table
The scan head should be positioned in the middle of the table width. The front of the scan
head should be inline with the front of the table to allow the patient to get into the correct
alignment position.
Suitability of images
The suitability of using an image or print for viewing is determined by the clinician.
CAUTION
Day to day use - operators
The protection provided by the equipment may be impaired if the equipment is used in a
manner NOT specified by Optos.
The use of this device or any other device which uses light for ocular examination should
NOT be prolonged unnecessarily.
Do NOT place any optical elements, with the exception of the patient wearing contact
lenses, between the device and the patient’s eye.
Do NOT use lint cloths, tissues, or other materials that may create dust, on or near the scan
head. Always allow cleaned areas to air-dry.
The device requires low levels of room light to operate efficiently. Take care to avoid
accidents when working under low light conditions.
Only use the fabric cover when the scan head is powered OFF. Remove the fabric cover
before operating the scan head.
You should not schedule archiving tasks if CDs or DVDs are used.
Page 11 of 60
Part Number: G102748/11_ENG
Copyright 2021, Optos plc. All rights reserved. English

Chapter 1 - Warnings and cautions
CAUTION
Day to day use - patients
Patients MUST NOT operate this device.
The patient should not touch the touch screen. The patient should only be in contact with
the face pad and eye piece.
Do NOT capture images when the eye piece is NOT in place.
Do NOT lean on the table.
The face pad may get warm during use.
CAUTION
Measurements
After you have drawn the points on the image, the software can estimate the relative
distance between any two points. The calculated distance is an estimate only and may be
used to indicate a need for further review. The measurements of relative distance,
however, should not be used as an indication of a specific condition or disease. The size
and shape of an image depends on the type of device used to capture it. Images from
different types of device should not be compared.
Measurements in third party viewers may not be accurate.
CAUTION
Installation and maintenance
Your device will be installed by Optos trained personnel. Do NOT operate the device until
they have completed the installation and training.
Your Optos representative will configure the settings when the device is installed. These
settings should NOT be changed in the course of normal operation.
Please consult your Optos representative before changing the settings.
Do NOT remove the scan head covers. Only Optos trained technical personnel are
permitted to service the device.
The scan head weighs 28 kg (62 lbs) maximum. This requires two people to lift or carry the
unit.
Please consult your Optos representative before moving the device.
You should be aware of your contractual obligations before disposing of any equipment.
Only Optos trained personnel are permitted to install and service the device.
Do NOT service the device when imaging a patient.
1.2 Laser safety
WARNING
Danger of laser injury
While no acute optical radiation hazards have been identified for direct or indirect
ophthalmoscopes, some patients may be less tolerant to an exposure of light. This may be
the case for infants, aphakic patients and persons with diseased eyes. Patients who have
had any exposure with the same device or with any other ophthalmic device using a visible
light source within the previous 24 hours may also be less tolerant to a further exam using
light.
Page 12 of 60
English
Part Number: G102748/11_ENG
Copyright 2021, Optos plc. All rights reserved.

Chapter 1 - Warnings and cautions
CAUTION
The Laser Management System maintains a Class 1 accessible emission limit (AEL) at the
eye for normal operation and under foreseeable fault conditions.
While the scan head covers are fitted the risks are minimized. Images may only be
captured when the scanning system is within safe operating conditions. The following
items are monitored by the Laser Radiation Management System:
lInternal power monitoring prevents excess power at the eye.
lAn internal shutter and associated controls prevent early or prolonged laser
exposure.
Using the controls, adjustments or performance of procedures other than those specified
herein may result in hazardous radiation exposure.
All P200T product variants are Class 1 laser devices at the eye, and comply with IEC/EN
60825-1:2007 and 21 CFR1040.10 and 1040.11 except for deviation pursuant to Laser
Notice 50, dated June 24, 2007.
Based on current scientific knowledge, a Class 1 laser device can be considered as safe
by engineering design, and safe under reasonably foreseeable conditions of operation.
The patient may experience some discomfort from exposure to light. It should be noted that
the benefits of an eye exam outweigh any discomfort.
Page 13 of 60
Part Number: G102748/11_ENG
Copyright 2021, Optos plc. All rights reserved. English

Chapter 1 - Warnings and cautions
1.3 Electrical safety
WARNING
Equipment classification
Electrical Shock Protection - Class 1 Equipment
Type B - relates to the allowable maximum leakage current which can flow from the applied
part. The limits for this are defined in IEC/EN 60601.
The applied parts are the face pad and eye piece.
Medical device. Continuous operation.
Do NOT open the scan head covers. There are no user serviceable or replaceable parts
inside.
DoNOT plug the scan head into a power block or powered table. The scan head must be
plugged directly into a wall socket.
Do NOT disconnect or connect the touch screen while the scan head is in use.
To prevent electric shock:
lOnly use cables supplied by Optos.
lCables should NOT be extended or altered.
lMains supply must be earthed.
lThe device may only be serviced by Optos trained personnel.
lCare must be taken never to touch exposed parts of the device while in physical
contact with a patient.
If the mains cable is damaged do not use the system and contact your Optos
representative, see Contact us on page55.
The image server, switch, browser-based review clients and any Viewing PCs or monitors
must be positioned outside the patient environment; more than 1.5 meters (5 ft) from the
scan head.
Do NOT connect any peripherals to the scan head. Only use peripherals supplied with the
device. Independently sourced peripherals may NOT be compatible. Contact your Optos
representative for more information on compatible peripherals, see Contact us on page55.
CAUTION
Ordinary equipment without protection against ingress of water.
You must regularly inspect the equipment. If there is any damage please contact your
Optos representative, see Contact us on page55.
The device is isolated from the mains by the main power cable and IEC connector. In an
emergency, the device should be isolated by unplugging from the mains power supply.
Ensure the mains socket is easily accessible.
Page 14 of 60
English
Part Number: G102748/11_ENG
Copyright 2021, Optos plc. All rights reserved.

Chapter 1 - Warnings and cautions
1.4 Environmental safety
WARNING
Do NOT operate the device:
lIn the presence of explosive or flammable gases, flammable anaesthetic mixtures
or in oxygen rich environments.
lInside the influence of the magnetic field of a magnetic resonance imaging device.
lIn environments that block the scan head air intake vents.
lIn environments that exceed the environmental limits, see Environmental
considerations (ambient) on page50.
1.5 EMC safety
CAUTION
In order to provide reasonable interference protection against radio communication
services, this device has been tested and complies with 47 CFR Part 15, Sub Part B of the
FCC (U.S.A.) rules and EN 60601-1-2 standard requirements at the premises of a typical
user, and the CISPR11 standard emission limits (CISPR11 Group 1 Class B), Guidance
and manufacturer declaration - electromagnetic emissions on page51.
Although compliant with all applicable international EMC standards, the equipment
generates, uses and can radiate radio frequency energy. The equipment may cause radio
frequency interference to other medical and non-medical devices and radio
communications nearby.
There is no guarantee that interference will NOT occur in a particular installation.
If this device is found to cause interference (which may be determined by turning the
equipment ON and OFF), the user or qualified service personnel should attempt to correct
the problem by one or more of the following measures:
lRelocate the affected device or devices
lIncrease the separation between the equipment and the affected device
lConsult the Optos service representative for further suggestions
Page 15 of 60
Part Number: G102748/11_ENG
Copyright 2021, Optos plc. All rights reserved. English

Chapter 1 - Warnings and cautions
CAUTION
Unauthorized changes or modifications will invalidate the warranty of this device.
The manufacturer is NOT responsible for any interference caused by using:
lInterconnect cables NOT supplied by Optos
lUnauthorized changes or modifications to this equipment
Do NOT use devices which intentionally transmit RF signals (cellular phones, transceivers
or radio controlled devices) in the vicinity of this equipment, as it may cause performance
outside the published specifications, see Recommended separation distances on page53.
Adhering to the distance separation recommended will reduce the disturbances recorded at
the image level, but may NOT eliminate all disturbances, see Recommended separation
distances on page53. However, when installed and operated as specified herein the
system will maintain its essential performance by continuing to acquire, display and store
diagnostic quality images safely.
It is recommended that the image server is not used adjacent to or stacked with other
equipment.
The use of accessories and cables other than those specified may result in degraded
electromagnetic compatibility of the system.
1.6 Cleaning guidelines
The device cleaning instructions are detailed in Cleaning on page40. Adhere to the following cautions while
cleaning the device.
CAUTION
Cleaning patient contact parts
In order to prevent any contamination always clean and disinfect parts of the equipment
which will be in contact with the patient, see Cleaning before each patient on page41.
Adequate cleaning and disinfection is necessary to prevent disease transmission.
Thoroughly clean and disinfect the equipment surfaces that contact the patient and all
equipment surfaces likely to become soiled during use.
Do NOT attempt to wash or immerse the patient contact parts (for example, face pad and
eye piece) in water or cleaning fluid.
CAUTION
Cleaning the main mirror
The mirror can be damaged during cleaning. Preventing mirror contamination reduces the
risk of damaging the mirror. It is NOT recommended to routinely clean the main mirror. Only
clean the mirror if dust particles, smudges or spots have accumulated on its surface.
When cleaning the main mirror, do NOT rub the spots too hard, as this may cause damage.
Do NOT touch the edges of the main mirror. The edges of the main mirror are sharp.
Only clean visible areas of the main mirror. Do NOT put your hand or any cleaning material
into parts of the device you cannot see.
Do NOT polish the mirror surfaces; clean only dust particles, smudges or spots.
Do NOT wear jewelry (for example rings, watches or bracelets) while cleaning the mirror
surface as this may damage the mirror.
Dispose of the dirty cloth after each wipe to avoid transferring the dust back on to the
mirror. You will have to use several wipes to clean the mirror.
Page 16 of 60
English
Part Number: G102748/11_ENG
Copyright 2021, Optos plc. All rights reserved.

Chapter 1 - Warnings and cautions
CAUTION
Cleaning materials
Wear powder-free gloves at all times when cleaning the device including the scan head and
main mirror. If the gloves become contaminated they must be replaced immediately.
Do NOT use lint cloths, tissues, or other materials that may create dust, on or near the scan
head. Always allow cleaned areas to air-dry.
Improper cleaning methods or use of inappropriate cleaning and disinfecting agents can
result in the following:
lDamaged equipment
lPoor imaging performance
lIncreased risk of electric shock
Always follow the cleaning and disinfecting agents’ manufacturer’s instructions and
precautions; for storage, method of application, protective gloves, shelf life and disposal to
help assure effective and safe use of the product.
Be careful NOT to damage the scan head covers when cleaning.
Do NOT use harsh detergent, abrasive cleaners or solvents that are NOT recommended by
the manufacturer.
Do NOT expose equipment parts to steam or sterilizers as this will damage the device.
Do NOT allow liquids to get into the equipment.
If you believe cleaning sprays or liquids have got into the equipment, disconnect the power
supply and have the equipment checked by Optos qualified service personnel.
Do NOT let the cleaning wipes come into contact with the inside of the instrument.
Do NOT use the equipment until you have confirmed it is safe to use.
1.7 Device failure
WARNING
In the unlikely event you hear a loud noise from the device, see smoke or smell burning,
stop imaging and isolate the device by unplugging from the mains power supply.
If you suspect the device may be faulty see Troubleshooting on page44.
If the fault still persists, please contact your Optos representative, see Contact us on
page55.
CAUTION
The device is isolated from the mains by the main power cable and IEC connector. In an
emergency, the device should be isolated by unplugging from the mains power supply.
Ensure the mains socket is easily accessible.
1.8 Maintaining information security
WARNING
Do NOT connect this equipment with any other equipment not provided in the accessory kit.
Do NOT use any cables, adapters, or products that are not provided or approved for the
device as this may result in non-compliance.
Page 17 of 60
Part Number: G102748/11_ENG
Copyright 2021, Optos plc. All rights reserved. English

Chapter 1 - Warnings and cautions
WARNING
IT networks used by medical devices
Connection of the P200T device to an IT NETWORK/DATA COUPLING that includes other
equipment could result in previously unidentified RISKS to PATIENTS,OPERATORS or third
parties.
The RESPONSIBLE ORGANIZATION should identify, analyze, evaluate and control these
RISKS.
Subsequent changes to the IT NETWORK/DATA COUPLING could introduce new RISKS and
require additional analysis, and changes to the IT NETWORK/DATA COUPLING.
These include:
lchanges in the IT NETWORK/DATA COUPLING configuration
lconnection of additional items to the IT NETWORK/DATA COUPLING
ldisconnecting items from the IT NETWORK/DATA COUPLING
lupdate of equipment connected to the IT NETWORK/DATA COUPLING
lupgrade of equipment connected to the IT NETWORK/DATA COUPLING
CAUTION
The scan head and image server should be kept in a secure location. You are responsible
for maintaining the security of information stored on the scan head and image server.
You are responsible for the security of user accounts and the maintenance of password
security.
1.9 Data security
CAUTION
Your System Administrator is responsible for backing up the image server. Backups MUST
be verified regularly to avoid patient data loss.
Only allow authorized personnel to access the data. Changes to data may lead to incorrect
diagnosis.
Implement measures to protect personal patient data from misuse.
If a critical error occurs during capture you should review the saved images and scans, and
recapture scans and images if necessary.
Exit OptosAdvance before turning OFF the image server.
You can install critical Windows Updates and antivirus signatures on the Image Server PC
and Viewing PCs by following the instructions displayed during the update.
Page 18 of 60
English
Part Number: G102748/11_ENG
Copyright 2021, Optos plc. All rights reserved.

Chapter 1 - Warnings and cautions
1.10 Software on Optos-supplied PCs
CAUTION
Only install software when supplied and instructed by Optos.
Installing new software
Contact Optos Customer Support if you need to install other software, see Contact us on
page55.
Updating existing software
Your System Administrator should carry out software upgrades using the software and
instructions provided by Optos.
Do NOT accept software updates when you are about to image a patient.
1.11 Symbol and label information
Symbol and label information
Switch - OFF position.
Switch - ON position.
Protective earth terminal.
Danger: high voltage warning.
WARNING
Warnings are directions which, if NOT followed, could cause:
lFatal or serious injury to a user, engineer, patient or any other person.
lDamage to the equipment described in this manual and/or other equipment or goods.
lEnvironmental pollution.
CAUTION
Cautions are directions which, if NOT followed, could cause:
lA hazardous situation for a user, engineer, patient or any other person.
lDamage to the equipment or loss of data.
Interference may occur in the vicinity of equipment marked with this symbol.
Laser device present. This symbol is used internally. Only Optos trained personnel are
permitted to service the device. Under normal use, operators should never see this symbol.
Date of manufacture.
Manufacturer.
Page 19 of 60
Part Number: G102748/11_ENG
Copyright 2021, Optos plc. All rights reserved. English

Chapter 1 - Warnings and cautions
Symbol and label information
Type B - relates to the allowable maximum current leakage which can flow from the applied
part. The limits for this are defined in IEC 60601.
SN
Serial Number.
In accordance with Directive 93/42/EEC.
Consult accompanying documents.
Disposal in compliance with WEEE Directive.
Page 20 of 60
English
Part Number: G102748/11_ENG
Copyright 2021, Optos plc. All rights reserved.
0197
