dB Technologies CROMO 8+ User manual

CROMO 8+
CROMO 10+
CROMO 12Club
CROMO 12+
CROMO 15+
2-Way Active Speakers
Series
+

2-Way Active
Speakers
2-Way Active
Speakers
Series
61
The Cromo+ Series offers powered loudspeakers with modern digital technology for first
time users, without having to miss out on professional features and outstanding audio
performance.
The Cromo+ Series features the ultra compact digipack digital power amplifiers, based on
the successful digipro® amp technology for maximum efficiency.
The integrated digital sound processor (DSP) caters for perfect sound calibration of the
individual speaker components. All in all, true professional features, unique in its class
and setting new standards in entry level speaker lines.
The compact multifunctional housing of the Cromo+ speaker line, with asymetrical CD
horns, can be used for many different applications, such as live events, a public address
system for a singer, for monitoring purposes on stage, or for fixed installations in Bars
or lounges.
All Cromo+ models have a microphone input on XLR and jack sockets for maximum
flexibility.
C
r
o
m
o
PACK

CROMO 8+ | CROMO 10+ | CROMO 12Club | CROMO 12+ | CROMO 15+
Professional Active Speakers
Series
CR10+
Club
CR CR12CR
Technical Data
Speaker Type: 2-Way Active Speaker
Acoustical data
Frequency Response [-10dB]: 68 - 20.000 Hz
Frequency Response [+/- 3dB]: 80 - 19.000 Hz
Max SPL: 118 dB
HF: 1 “
Type HF: Compression driver
Directivity: 90/70 x 60 °
Horn: Asymmetrical CD Horn
LF: 8 “
Amplifier
Amp Technology: Digipack™
Amp Class: Class D
Power PRG: 300 Watt
Processor
Controller: DSP 24bit/48kHz
System Presets: Flat, Processed
Limiter: Dual Active Peak, RMS, Thermal
Mechanics
Housing: Polyporpylen PP
Angles Up: Monitor use 43 °
Width: 270 mm (10.8 in)
Height: 435 mm (17.4 in)
Depth: 252 mm (10.08 in)
Weight: 7,8 kg (15.43 lbs)
CROMO 8+
Technical Data
Speaker Type: 2-Way Active Speaker
Acoustical data
Frequency Response [-10dB]: 65 - 20.000 Hz
Frequency Response [+/- 3dB]: 70 - 19.000 Hz
Max SPL: 121 dB
HF: 1 “
Type HF: Compression driver
Directivity: 90/70 x 60 °
Horn: Asymmetrical CD Horn
LF: 10 “
Amplifier
Amp Technology: Digipack™
Amp Class: Class D
Power PRG: 400 Watt
Processor
Controller: DSP 24bit/48kHz
System Presets: Flat, Processed
Limiter: Dual Active Peak, RMS, Thermal
Mechanics
Housing: Polyporpylen PP
Angles Up: Monitor use 43 °
Width: 320 mm (12.8 in)
Height: 508 mm (20.32 in)
Depth: 297 mm (11.88 in)
Weight: 12 kg (26.46 lbs)
CROMO 10+
Technical Data
Speaker Type: 2-Way Active Speaker
Acoustical data
Frequency Response [-10dB]: 55 - 20.000 Hz
Frequency Response [+/- 3dB]: 60 - 19.000 Hz
Max SPL: 124 dB
HF: 1 “
Type HF: Compression driver
Directivity: 90/70 x 60 °
Horn: Asymmetrical CD Horn
LF: 12 “
Amplifier
Amp Technology: Digipack™
Amp Class: Class D
Power PRG: 400 Watt
Processor
Controller: DSP 24bit/48kHz
System Presets: Flat, Processed
Limiter: Dual Active Peak, RMS, Thermal
Mechanics
Housing: Polyporpylen PP
Angles Up: Monitor use 43 °
Width: 402 mm (16.08 in)
Height: 615 mm (24.6 in)
Depth: 356 mm (14.24 in)
Weight: 17,7 kg (39.02 lbs)
CROMO 12Club
62
CR8+ CR8+

CROMO 8+ | CROMO 10+ | CROMO 12Club | CROMO 12+ | CROMO 15+
More power To Your Power Amp
Series
CR12+CR15+ CR CR
Technical Data
Speaker Type: 2-Way Active Speaker
Acoustical data
Frequency Response [-10dB]: 55 - 20.000 Hz
Frequency Response [+/- 3dB]: 60 - 19.000 Hz
Max SPL: 126 dB
HF: 1 “
Type HF: Compression driver
Directivity: 90/70 x 60 °
Horn: Asymmetrical CD Horn
LF: 12 “
Amplifier
Amp Technology: Digipack™
Amp Class: Class D
Power PRG: 600 Watt
Processor
Controller: DSP 24bit/48kHz
System Presets: Flat, Processed
Limiter: Dual Active Peak, RMS, Thermal
Mechanics
Housing: Polyporpylen PP
Angles Up: Monitor use 43 °
Width: 402 mm (16.08 in)
Height: 615 mm (24.6 in)
Depth: 356 mm (14.24 in)
Weight: 18,5 kg (39.68 lbs)
CROMO 12+
Technical Data
Speaker Type: 2-Way Active Speaker
Acoustical data
Frequency Response [-10dB]: 45 - 20.000 Hz
Frequency Response [+/- 3dB]: 50 - 19.000 Hz
Max SPL: 128 dB
HF: 1 “
Type HF: Compression driver
Directivity: 90/70 x 60 °
Horn: Asymmetrical CD Horn
LF: 15 “
Amplifier
Amp Technology: Digipack™
Amp Class: Class D
Power PRG: 600 Watt
Processor
Controller: DSP 24bit/48kHz
System Presets: Flat, Processed
Limiter: Dual Active Peak, RMS, Thermal
Mechanics
Housing: Polyporpylen PP
Angles Up: Monitor use 43 °
Width: 470 mm (18.8 in)
Height: 720 mm (28.8 in)
Depth: 405 mm (16.2 in)
Weight: 22.9 kg (50.49 lbs)
CROMO 15+
Professional Active Speakers
63
