DCS RGSC-305 User manual

1
PRELIMINARY
DCS is a leading manufacturer of premium quality cooking and specialty appliances for both residential and professional use.
We are proud of our reputation for quality and our commitment to customer satisfaction. We have set high standards for
ourselves along with our network of independent Part Distributors and Service Agencies. As an Authorized Part Distributor or
Authorized Service Agency we are counting on you to represent our company in a professional manner. We are here to help
support you should you need assistance. Our technical support center is staffed by experienced technicians eager to help you.
Your questions can be answered by DCS Customer Care Center by phone:[phone],email:suppor[email protected],
orby mail:
This manual contains information necessary for you to troubleshoot a DCS RGSC-305 self cleaning range. If the technical
data you are looking for is not contained in this publication please call our technical support department at 888-396-2665
between the hours of 6:00 a.m.to 4:30 p.m.pacific standard time,Monday thru Friday.
Anytime you need information, or parts you will need a complete model and serial number. The rating plate is located
behind the kickpanel, on the right side of the frame. DCS uses model numbers which describe the type of unit they
represent. “RGSC”designates range,gas,self-cleaning. The number 305 indicates a 30”five burner range.
We haveincludedsectionsoncookingandinstallations. Insomecases a serviceproblem isdirectlyrelated toan improper
installation or not following correct cooking practices. The information contained in these sections should help you in
determining the origin of the condition for which the customer is concerned.
WARNING
If the information in this manual is not followed exactly, a fire or explosion may result causing
property damage,personal injury or death.
WARNING
Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any
other appliance.
FORYOUR SAFETY
If you smell gas:
Donot try to light any appliance.
Donottouch any electrical switch;do not use any phone in your building.
Immediately call your gas supplier from a neighbor’s phone.Follow the gas
supplier’s instructions.
If you cannot reach your gas supplier,call the fire department.
Installation and service must be performed by a qualified installer, service agency or the gas
supplier.
PLEASE RETAINTHIS MANUAL FOR FUTURE REFERENCE.
DCS
Attention: CustomerCare Center
5800SkylabRoad
HuntingtonBeach,CA92647 www.dcsappliances.com
TO OUR VALUED SERVICE PARTNERS
INTRODUCTION

PRELIMINARY
2
TABLE OF CONTENTS
INTRODUCTION..............................................................................................................................................................................................1
SAFETY PRACTICES AND PRECAUTIONS................................................................................................................................3-5
INSTALLATION...........................................................................................................................................................................................6-11
Cabinet Preparation........................................................................................................................................................................6-7
Electrical Connections........................................................................................................................................................................8
Gas Hook-up....................................................................................................................................................................................9-10
Anti-Tip Device Installation............................................................................................................................................................10
Backguard Installation.....................................................................................................................................................................11
Flame Characteristics.......................................................................................................................................................................11
COOKTOP USE.........................................................................................................................................................................................12-13
OVEN USE...................................................................................................................................................................................................14-15
Convection Baking / Broiling.........................................................................................................................................................14
Set Oven For Baking.........................................................................................................................................................................15
Set Oven For Broiling.................................................................................................................................................................16-17
CARE AND MAINTENANCE..................................................................................................................................................................18
SEALED BURNER DISASSEMBLY......................................................................................................................................................19
COMPONENT ACCESS.......................................................................................................................................................................20-30
Oven Door Removal.........................................................................................................................................................................20
Kick Panel Removal...........................................................................................................................................................................20
Baker Igniter..................................................................................................................................................................................20-21
Convection Fan...................................................................................................................................................................................22
Transformer and Relay Assembly Disconnect Power Supply............................................................................................22
Regulator Manifold Assembly.......................................................................................................................................................23
Motorized Latch.................................................................................................................................................................................23
Broiler Assembly/Igniter Removal........................................................................................................................................24-27
Control Panel Removal....................................................................................................................................................................27
Selection Switch.................................................................................................................................................................................27
Burner Re-igniter................................................................................................................................................................................27
Top Burners..........................................................................................................................................................................................27
Top Assembly......................................................................................................................................................................................28
Cooling Fan Motor.............................................................................................................................................................................28
OvenThermostat...............................................................................................................................................................................29
LockThermostat.................................................................................................................................................................................30
CleanThermostat...............................................................................................................................................................................30
TROUBLESHOOTING.................................................................................................................................................................................31
CLEAN RELAY ..........................................................................................................................................................................................32-34
PUSH BUTTON SWITCH ........................................................................................................................................................................35
OVEN & BROILER IGNITER....................................................................................................................................................................36
SERVICE BULLETIN.....................................................................................................................................................................................37
Foot Kit Repair – K-14355...............................................................................................................................................................37
PARTS LIST ................................................................................................................................................................................................38-51
WIRING DIAGRAM / SCHEMATIC..............................................................................................................................................52-53
HOWTO OBTAIN SERVICE....................................................................................................................................................................54
WARRANTY......................................................................................................................................................................................................55

SAFETY PRACTICES & PRECAUTIONS
PRELIMINARY
3
When properly cared for,your new DCS Appliance has
been designed to be a safe,reliable cooking appliance.
When using this restaurant caliber appliance,use it with
extreme care,as this type appliance provides intense
heat and can increase the accident potential.Basic
safety precautions must be followed when using kitchen
appliances,including the following:
ReadthisServiceManualthoroughlybeforeusing
your new appliance. This will help to reduce the
risk of fire,electric shock,or injury to persons.
Beginbyinsuringproperinstallationandservicing.
Follow the installation instructions which came
with this appliance. Be sure to have a qualified
technician to install and ground this appliance
before using.
Have the installer show you where the gas supply
shutoff valve is located so you will know how and
where to turn off the gas to the appliance.
Ifyousmellgas,theinstallerhasnotdoneaproper
jobofcheckingforleaks.You can havea smallleak
and therefore a faint gas smell if the connections
are not completely tight.Finding a gas leak is not
a “do-it-yourself” procedure. Some leaks can only
be found with the burner control in the “ON”
position and for your protection it must be done
by a qualified service technician.
WARNING:
Gasleaks mayoccur inyour systemand
result in a dangerous situation. Gas
leaks may not be detected by smell
alone. Gas suppliers recommend you
purchase and install an UL approved
gas detector. Install and use in
accordance with the manufacturer’s
instructions.
If by some chance a burner goes out and gas
escapes,open a window or a door to let the room
air out.Do not attempt to use the appliance until
the gas has had time to dissipate. Follow the
instructions on page 1,“What to do if You Smell
Gas”.
This appliance has been factory assembled for
natural gas. It should be correctly adjusted by a
qualified service technician or installer for the
type of gas that is used.
Do not repair or replace any part of this appliance
unless it is specifically recommended in this
manual.All other servicing should be referred to a
qualified technician.
Children should not be left alone or unattended
in an area where appliances are in use. They
should never be allowed to turn knobs, push
buttons,sit or stand on any part of an appliance.
Children in walkers, or children crawling can be
attracted to the round oven door handle and may
grab and open the oven door. This can result in
injury from the door being pulled open on a child,
or severe burns if the oven is in use and hot.
WARNING:
Donotstoreitemsofinteresttochildren
above or at the back of any appliance.
Children could be seriously injured if
they should climb onto the appliance to
reach these items.
Never store anything in the oven or on the
cooktop. Flammable materials can catch fire,
plasticitemsmaymeltor igniteandother types of
items could be ruined.
Do not hang articles from any part of the
appliance or place anything against the oven.
Some fabrics are quite flammable and may catch
on fire.
If the appliance is near a window be certain the
curtains do not blow over or near the cooktop
burners;they could catch on fire.
Do not use water on grease fires.Turn all burners
OFF, then smother fire with baking soda or use a
dry chemical or foam-type fire extinguisher.
Neverletclothing,potholders,orother flammable
materialscomeincontact with,ortoocloseto,any
burner or burner grate until it has cooled. Fabric
may ignite and result in personal injury.
Be certain to use only dry pot holders: moist or
damp pot holders on hot surfaces may cause
burns from steam. Do not use a towel or other
bulky cloth in place of pot holders.Do not let pot
holders touch hot burners,or burner grates.
For personal safety, wear proper apparel. Loose
fitting garments or hanging sleeves should never
be worn while using this appliance. Some
synthetic fabrics are highly flammable and should
not be worn while cooking.
Do not use aluminum foil to line any part of the
oven or cooktop.Using a foil liner could result in a
fire hazard, or the obstruction of the flow of
combustion and ventilation air.Foil is an excellent
heat insulator and heat will be trapped
underneath it. This trapped heat can upset the

PRELIMINARY
SAFETY PRACTICES & PRECAUTIONS
4
cooking performance and can damage the finish
of the oven or the cooktop parts.
WARNING:
This appliance is for cooking. Based on
safety considerations, never use the
oven or cooktop to warm or heat a
room. Also, such use can damage the
cooktop or oven parts.
When using the cooktop: Do not touch the
burner grates or the immediate surrounding
area. Areas adjacent to the burners may become
hot enough to cause burns.
When using the oven:Do not touch the interior
surfaces of the oven, the exterior area
immediately surrounding the door or the back
trim. The surfaces directly above the oven door
maybehotiftheovenhasbeenoperatedwiththe
door open, or if something has prevented the
door from sealing.
Never leave the cooktop unattended when
using high flame settings. Boil overs cause
smoking and greasy spill overs may ignite. More
importantly,iftheburnerflamesaresmotheredby
a severe boil over which effects the igniter,
unburned gas will escape into the room. See
page 1.
Only certain types of glass, heat-proof glass-
ceramic,ceramic,earthen ware,or other glazed
utensils are suitable for cooktop use. This type
of utensil may break with sudden temperature
changes. Use only on low or medium flames
settings according to the manufacturer’s
directions.
Do not heat unopened food containers; a build
up of pressure may cause the container to burst.
During cooking, set the burner control so that
the flame heatsonly the bottom ofthe pan and
does not extend beyond the bottom of the pan.
This could heat and/or melt the handles.
Always use utensils that have flat bottoms
large enough to cover the burner. The use of
undersized utensils will expose a portion of the
flame to direct contact and may result in ignition
of clothing.
To minimize burns, ignition of flammable
materials and unintentional spill overs, position
handles of utensils inward so they do not extend
over adjacent work areas, cooking areas, or the
edge of the cooktop.
Hold the handle of the pan to prevent
movement of the utensil when stirring or turning
food.
GREASE IS FLAMMABLE. Let hot grease cool
before attempting to handle it. Avoid letting
grease deposits collect around the cooktop
burners.Clean after each use or boil over.
For proper lighting and performance of the
cooktop burners,keep the burner ports clean. It
may be necessary to clean these when there is a
boil over or when the burner does not light,even
though the electronic igniters click.
Clean the cooktop with caution. Avoid steam
burns; do not use a wet sponge or cloth to clean
thecooktopwhileitishot.Somecleanersproduce
noxious fumes if applied to a hot surface. Follow
directions provided by the cleaner manufacturer.
Be sure all the range and/or cooktop controls are
turned off and the appliance is cool before using
any type of aerosol cleaner on or around the
appliance. The chemical that produces the
spraying action could, in the presence of heat,
ignite or cause metal parts to corrode.
Place oven racks in desired position while the
oven is cool. If a rack must be moved while the
oven is hot,do not let the pot holders contact the
hot interior of the oven.
Use care when opening the oven door. Let hot
air or steam escape before removing or replacing
foods.
Do not rub, damage, move or remove the door
gasket.Itisessentialforagoodsealduringbaking.
Clean the ventilator hood and filters above the
range or cooktop frequently so grease from
cooking vapors does not accumulate on them.
Turn the ventilator OFF in case of fire or when
intentionally “flaming” liquor or other spirits on
the cooktop. The blower, if in operation, could
unsafely spread the flames.
Do not obstruct the flow of combustion or
ventilation air to the appliance.Be sure a fresh air
supply is available.
For safety reasons and to avoid damage to the
appliance never sit, stand, or lean on the oven
door or cooking surface.
Service should only be done by authorized
technicians. Technicians must disconnect the
power supply before servicing this appliance.

PRELIMINARY
5
SAFETY PRACTICES & PRECAUTIONS
CaliforniaProposition65-Warning:Theburningof
gas cooking fuel generates some by-products
which are known by the State of California to
cause cancer or reproductive harm.California law
requires businesses to warn customers of
potential exposure to such substances. To
minimize exposure to these substances, always
operate this unit according to the instructions
contained in this booklet and provide good
ventilation to the room when cooking with gas.

INSTALLATION
6
PRELIMINARY
CABINET PREPARATION
1) The range is a free standing unit. If the unit is to be
placed adjacent to cabinets, the clearances shown in
Fig.1 arerequired. Thesame clearancesapplytoisland
installations .
2) The range can be placed in various positions with
respect to the cabinet front,with the front either flush
or projecting, depending on the countertop depth
(See Fig.2,page 4).
3) The gas and electrical supply should be within the
zones shown in Fig.1 & Fig.3.
4)Themaximum depthof overheadcabinets installedon
either side of the hood is 13".
5) Any openings in the wall behind the range and in the
floor under the range must be sealed.
6) When there is less than a 12" clearance between
combustible material and the back edge of the range,
(above the cooking surface) a DCS Backguard must be
installed (see Fig. 2). When clearance to combustible
materialis over12",a DCSislandtrim maybe used(see
Fig. 2). The range comes equipped with island trim
standard. (Fig. 2) indicate the space required for each
type of backguard.
7) Always keep the appliance area clear and free from
combustible materials, gasoline and other flammable
vapors and liquids.
8)Donotobstructtheflowofcombustionandventilation
air to the unit.
min.30"widehood
CAUTION:
36"min.to
combustible
material,
fromcooking
surface
electrical+gas
supply
35-3/8"max.forlevelcounter,
36-3/4"max.withrange
levelinglegsfullyextended
12"min.tocombustible
material, eachside
cookingsurface
C
D
B
Asdefinedinthe
“NationalFuelGasCode”
(ANSIZ223.1,latestedition).
Thehorizontalsurfacesoftherangetop(cooktop)trimmustnotbebelow
countertoplevel.
A)
B)
C)
D)
E)
F)
7-1/2"
18"min.
3"
13"max.
4-1/2"(gas)
11"(electrical)
A
E
F
Fig.1

PRELIMINARY
7
INSTALLATION
2"Maximum
ProtrusionfromWall
forGasSupply
GasSupply
FlexLinetoRange
ManualShut-Off
Valvemustbe
EasilyAccessible
Fig.3
min.30"widehood
CAUTION:
36"min.to
combustible
material,
fromcooking
surface
electrical+gas
supply
35-3/8"max.forlevelcounter,
36-3/4"max.withrange
levelinglegsfullyextended
12"min.tocombustible
material, eachside
cookingsurface
C
D
B
Asdefinedinthe
“NationalFuelGasCode”
(ANSIZ223.1,latestedition).
Therangeheightisadjustable.Thelevelofthe
rangetopmustbeatthesamelevelorabovethecountertoplevel.
A)
B)
C)
D)
E)
F)
7-1/2"
18"min.
3"
13"max.
4-1/2"(gas)
11"(electrical)
A
E
F
Fig.2

PRELIMINARY
8
INSTALLATION ELECTRICAL / GAS CONNECTIONS
POWER REQUIREMENTS
120VAC,60 Hz.,single phase.
4 Amp.Max.
(Use 15 Amp.Circuit)
Always disconnect electric supply cord from the wall
outlet or service disconnect before servicing this
appliance. Observe all governing codes and ordinances
when grounding, in the absence of which, observe
National Electrical Code ANSI/NFPA No.70-1990.
RECOMMENDED GROUNDING METHOD
This appliance is factory equipped with a power supply
cord with a three-prong grounding plug (with polarized
parallel blades). It must be plugged into a mating
grounding, type receptacle, connected to a correctly
polarized 120 Volt circuit. If the circuit does not have a
grounding type receptacle, it is the responsibility and
obligation of the installer or user to have the existing
receptacle changed to a properly grounded and
polarized receptacle in accordance with all applicable
local codes and ordinances by a qualified electrician. In
theabsenceof local codes andordinancesthe receptacle
replacement shall be in accordance with the National
Electrical Code. THE THIRD GROUND PRONG SHOULD
NOT,UNDER ANYCIRCUMSTANCES,BE CUT ORREMOVED
(See Fig.4).
GAS
Verify the type of gas supplied to the location.The range
is shipped from the factory set up and adjusted for
natural gas.The unit can be readily converted to LP gas.
After LP conversion, burner adjustment may be
necessary.
NATURAL GAS REQUIREMENTS
Connection: 1/2" NPT Minimum 5/8" dia.flex
line.
Pressure: 6" to 14" W.C.
LP GAS REQUIREMENTS
Connection: 1/2" N.P.T. Minimum 5/8" dia.flex
line.
Pressure: Supply pressure must be 11" to 14"
W.C.
A regulator is required at the LP source to
provide a maximum of 14"W.C.to the range
regulator.
Receptacle Box
Cover Plate
Three Prong
Receptacle
Three
Prong
Plug
Fig.4

PRELIMINARY
9
INSTALLATION ELECTRICAL / GAS CONNECTIONS
HOOKUP
A manual valve is installed in an accessible location from
the front for the purpose of shutting off the gas supply.
The supply line must not protrude beyond the back of
the unit. Make sure the gas supply is turned off before
connectingtheappliance. Theflex line forthe gas supply
mustbe metalandbe approvedbyCSA,AGA,CGAORUL.
Only use a metal supply hose, as the heat may cause a
rubber hose to melt and develop leaks. The gas supply
connections should be made by a qualified technician
and in accordance with local codes or ordinances.In the
absence of a local code,the installation must conform to
the National Fuel Gas Code ANSI 223.1-1988, latest
edition.
CAUTION:
Theappliancemustbeisolatedfromthe
building’s gas supply piping system by
closing its individual manual shut-off
valve during any pressure testing of the
gas supply piping system at test
pressures equal to or less than 1/2 psig
(3.5kPa.). The appliance and its
individual shut-off valve must be
disconnected from the gas supply
piping system during any pressure
testing of the system at the test
pressures in excess of 1/2 psig (3.5kPa.).
When checking the manifold gas
pressure, the inlet pressure to the
regulatorshouldbeatleast7.0”W.C.for
natural gas or 12.0”for LP.
When hooking up the gas supply from range rear hard
pipe to wall hard pipe, installation length of flex line
between range/wall hard piping must accommodate the
range being pulled from wall for cleaning or servicing
purpose. Whenrangeispulledfromwall,nostrainshould
occur at range or wall hard pipe connections (See Fig.5 ).
NOTE: Pipe sealer must be used on pipe thread
connections only.
Metal Flex Gas Line
Hard Pipe
1/2" NPT
Manual Shut-Off
Valve must be
Easily Accessible WALL
Hard Pipe
Connection
Fig.5

PRELIMINARY
10
ANTI-TIP DEVICE INSTALLATION INSTRUCTIONS
ANTI-TIP DEVICE INSTALLATION
Allrangesmusthaveananti-tipdevice correctly installed
as per these instructions. If you pull the range out from
the wall for any reason, make sure that the device is
properlyengaged whenyoupushthe rangebackagainst
the wall. If it is not, there is a possible risk of the range
tipping over and causing injury if you or a child stand,sit
or lean on an open door.
INCLUDED PARTS:
Included with this kit are: (4) #10 x 2” wood screws, (1)
Anti-tip bracket,and (1) Installation Instructions.
INSTALLINGTHE KIT:
Instructions are provided for wood and cement floors.
Anyothertypeorconstructionmayrequirespecialinstal-
lation techniques as deemed necessary to provide
adequate fastening of the Anti-tip bracket to the floor
and wall. The use of this bracket does not preclude
tipping of the range when not properly installed.
WOOD CONSTRUCTION:
Placethe bracket againstthebackwall,intotheright rear
corner where the range is to be located. Leave a gap
between the wall (or side of range) and the bracket of
3/4”.Drill (2) 1/8”diameter pilot holes in the center of the
small holes. A nail or awl may be used if a drill is not
available. Fasten the bracket securely to the floor and
wall. See Fig.6.
Concrete or cement construction:
HARDWARE REQUIRED: (2) sleeve anchors, lag bolts, and
washers (not provided).Locate the bracket as described
above. Drill the recommended size holes for the
hardware. Install the sleeve anchors into the holes and
then install the lag bolts through the bracket.The bolts
must be properly tightened as recommended for the
hardware. Fasten the bracket securely to the floor and
wall.
ONCE INSTALLED:
Complete the range installation per the instructions
provided with the product.Check for proper installation
of the Range and Anti-tip device by grasping the back of
the unit and carefully attempt to tilt the range forward.
WARNING
ALL RANGES CAN TIP
INJURY COULD RESULT
INSTALL ANTI-TIP
BRACKET PACKED
INSIDE OVEN
SEE INSTRUCTIONS
Fig.7
Fig.6
(2) Large Holes for
Concrete Installations
(2)Small Holes for
Wood Installations
(2)Wood Screws into
BackWall (All
Installations)
Back
Wall
RIGHT SIDE OF
WALL OR RANGE
3/4”
THE MANUFACTURE WILL NOT PAY
FOR ANY DAMAGE DO TO MISSING OR
IMPROPERLY INSTALLED ANTI-TIP
DEVICE.
