Defender Security DFR-5MP-XVR4 User manual

1
5MP HYBRID DVR
MODELS: DFR-5MP-XVR4 & DFR-5MP-XVR8

2
IMPORTANT SAFETY INFORMATION
Please read these instructions carefully before use and retain for future reference.
• When using electrical appliances basic safety precautions should always be
followed.
• Check that the voltage indicated on the rating plate corresponds with that of the
local network before connecting the PSU to the mains power supply.
• Do not expose the unit to rain or moisture or liquids of any sort, as doing so may
result in damage. Although the cameras attached may be outdoors this DVR is
only intended to be used indoors.
• Do not install near heat sources such as radiators, ovens, or other devices that
produce heat.
• Install in a well ventilated space to allow good heat dissipation.
• Never block the cooling vents.
• The DVR can be installed at on a horizontal surface or wall mounted.
• Avoid installing in areas with high vibration or impacts as these may damage the
internal hard drives.
• If the unit is not in use for a long period of time, switch the power off and unplug
the power supply.
• Before cleaning, switch off the power and unplug the power supply.
PRODUCT OVERVIEW
FEATURES
• Four or eight video BNC socket input channels (depending on the model).
• Four audio input channels and one audio output via RCA sockets.
• HDMI and VGA video outputs.
• SATA hard disk interface supporting 2.5” or 3.5” drives up to 8TB.
WALL MOUNTING
• Ensure the mounting surface can support the weight of the unit and that there are
no concealed pipes or wiring.
• Referring to the keyhole slots on the base on the unit, drill two holes horizontally
195mm apart and insert suitable wall plugs if required.
• Screw in two suitable screws leaving the heads approximately 2-3mm proud of the
surface.
• Attach the DVR onto these screws making sure the unit has engaged securely.
3.Hard disk installation
5.Local Basic Operation
4.2 8 Channels D /DB / C / CB series XVR rear panel interface
32 Channels L series XVR rear panel interface description
5.1 Boot up
3
4
1.Statement
4.1 XVR rear panel interface description
4.Rear panel interface description
RJ45 Ethernet interface
Video input or video
interface
V-IN for video input
V-OUT for video output
USB interface for mouse
and U disk
HD: High definition
video output interface
RS485 interface for
PTZ camera access
Alarm interface
Power switch
interface
DC 12V power
interface
AC 110V-240V power
connector
115V/230V power
switch.
Switch to 230V when
220V power input,
and switch to 115V
when 110V power
input.
VGA: Video output
interface
eSATA interface
2
Audio input or output
interface.
A-IN for audio input
A-OUT for audio output
（1）Unscrew the back panel screws and take off the cover.
（2）Remove the hard disk rack.
（3）Install the hard disk to the rack from top to bottom.
（4）Fix the hard disk by screws.
（5）Install the rack and fix it.
（6）Connect the hard disk power cable and data cable.
（7）Install the cover and fix it by screws.
3.3 Hard disk installation guide for XVR L series
1
XVR
Quick Start Guide
Please read the Quick Start Guide carefully before using the product and
keep it.
Related tools and documents of products, please download from
www.herospeed.net.
This manual is applicable for XVR PGH/PG/C/CB/DB/D/L type housing .
This manual may contain some contents that are technically inaccurate
or inconsistent with product functions and operations or wrongly
printed. The contents of this manual will be updated according to the
enhancement of products without prior notice. If this description of
product in the manual does not match with the actual object, please
prevail in kind.
2.Safety Instructions
This equipment should be installed in well-ventilated environment.
When installing, please keep proper space with the ground. It is good
for machine heat dissipation that keeping proper space with the
ground when install. Keep the equipment away from heat source and
high temperature environment.
The device should be installed horizontally, to avoid the installation in
a strong vibration position.
This device is not waterproof. To avoid fire or other hazards caused by
short-circuit, shall prevent the device from getting wet.
Please use the hard disk recommended by the manufacturer
(generally recommend monitor level hard disk of Seagate and
Western Digital) to meet the requirements of long time reading and
writing of big data. Please buy from form channels to ensure the
quality of hard disk.
This product can not withstand heavy loads. Do not place heavy
objects or multi-layer overlays on this product.
XVR installation and construction must meet the specifications, may
refer to the relevant national or local standards.
NOTE:
1. Please use the XVR dedicated SATA hard disk recommended by the
device manufacturer. Make sure the power is off before installation.
2. The following pictures and installation diagrams for reference only,
subject to the available products.
3.1 Hard disk installation guide for XVR PG / PGH series
（1）Unscrew the screws and
remove upper cover.
（3）Connect one end of the
hard disk power cable and
data cable to the
motherboard and the other
end to the hard disk.
（4）Install the cover and fix it
by screws.
（2）Align the hard disk screw
holes to the chassis backplane, and
then tighten lock the screws.
3.2 Hard disk installation guide for XVR C / CB / DB / D
series
（1）Unscrew the screws on the
back and sides of the chassis and
remove the cover.
（3） Align the hard disk screw
holes to the chassis backplane,
and then tighten lock the screws.
（4）Install the cover and fix it by
screws.
（2）Connect one end of the hard
disk power cable and data cable to
the motherboard and the other
end to the hard disk.
5.2 Boot Wizard
You can perform basic configuration on the device through the
Power-on Wizard.
Step 1: The device automatically enters the Boot Wizard page after it is
powered on. Click "Next", enter the administrator password, select the
language, click "Login", "Modify", modify the login password, and click
"Save" to enter the boot wizard "General" page.
Step 2: After configuring the basic settings such as language, record
mode, video standard, and device time, click “Next” to set related
parameters for other interfaces.
Make sure the input voltage matches the XVR consumption. Connect
the device to the monitor and to the power adapter (if available). Plug
in the power, switch on the power button (if available), then the device
boot up.
NOTE:
1. It is recommended that you refer to international standards for power
supply input with stable voltage values and low ripple interference.
2. Some devices do not have power button and will boot up directly
when plug into an electric power supply.
NOTE:
XVR rear panel interface is similar with above picture, but the product
appearance, including interfaces and layout, for reference only, please
prevail in kind.

3
HARD DRIVE INSTALLATION (BB MODELS ONLY)
• Disconnect the power supply.
• Remove the screw in the top centre of the rear panel and the screw on each side
of the unit and remove the top casing.
• With reference to the four keyhole slots in the base of the unit, partly insert a
suitable screw into the relevant threaded mounting points on the hard drive.
• Connect the power and data cables to the hard drive then locate the mounting
screws into the keyhole slots, slide sideways then from underneath, tighten them
to x the drive into place.
• Route the cables neatly ensuring all the connectors are fully pushed home.
• Ret the top casing and replace the three screws.
Note: only use hard drives recommended by the manufacturer for continuous DVR
usage.
• Connect the cameras to the video input sockets.
• Connect a monitor to either the VGA/HDMI output sockets as required.
• Connect the mouse to a USB socket.
• Connect the power supply to the DC socket and plug into a mains socket and turn
the power on. The red LED on the front panel will light.
• The DVR will display the boot screen followed by the log on window.
• Default username is ‘admin’ and password is ‘12345’.
• After successful log on you can set the general conguration of the unit including
modifying the username and password, language, video standard and the time.
• Click ‘Next’ to set further parameters as follows:
Note: If you have previously congured all parameters the set up wizard can be
bypassed on future booting by un-ticking the option box on the boot screen. You
can also turn off the boot wizard in Settings/General.
Drive Mountings
LOGGING ON
5.3 Network Settings
5.4 Channel Configuration
6.1 Login
6.WEB Operation
6
5.5 IP Channel Configuration
5.6 Recording Settings
8.Disclaimer
8
7.Mobile App Operation
7
5.7 Instant playback
5
1. As a result of the following reasons, if the product interrupts or
terminates the service for any of the following reasons, the company
shall not be liable for personal injury or property damage to you or a
third party. Failure to install or use properly as required; for the sake of
national or public interest; force majeure; your own or third-party
reasons (including but not limited to the use of third-party products,
software or components, etc.
2. The company has not expressed or implied that this product is
applicable to special purpose.This product may not be used in medical
/ safety equipment or other applications where there is a breakdown of
the product that could result in life-threatening or personal injury, as
well as hazardous or non-humanitarian hazards such as weapons of
mass destruction, biological and chemical weapons, nuclear explosions
or any unsafe use of nuclear energy use. Any loss or liability arising out
of the above use will be at your own risk.
3. This product, when properly installed and used, can detect
unauthorized intrusion during a particular delight but can not avoid
accidents or personal injury or property damage. In your daily life, you
should be vigilant and strengthen your safety awareness.
4. The Company is not responsible for any indirect, incidental, special
punitive damages, claims, loss of property or loss of any data or
documents. To the maximum extent permitted by law, the liability for
compensation of company is not exceed than the amount you paid for
this product.
The following exemptions or limitations of liability, please pay
special attention to:
XVR LAN login(the PC and the device are in the same router)
Step 1: Make sure the XVR and PC are in same network segment. If not,
the network segment of PC need to be set up to the same segment with
XVR, such as "192.168.1.99".
Step 2: Open IE browser, select Tools > Internet Options > Security >
Custom Level > ActiveX controls and plug-ins, all options are enabled.
Step 3: Open "Search Tool", double-click the target device from the
search result to enter the login interface, or open the IE browser to enter
the XVR address: such as “http://192.168.1.88/ “(If the http port of the XVR
is changed to 89, enter "http:// 192.168.1.88:89/”) to enter the login
interface.
Step 4: Enter the device user name (default is “admin”), password (default
is “12345”), and click “Login”.
In the preview interface, click the play button at the bottom. For the first
time connecting, you have to download and install the plugin before
previewing.
NOTE:
The Web-side can also perform the operations such as system, network,
storage, playback, download, upgrade, maintenance, and factory reset
on the Web.
6.2 Preview
Step 1: Choose "Menu> Playback" or right click on the preview interface
and select "Playback" to enter the Playback interface.
Step 2: Choose "Date > Channel > More". Double click to search for the
file, and the interface will start playing the file. Or select the "time >
channel", left mouse click on the time progress bar below the playback
interface to play the video.
Choose "Menu> Shut Down", click "Shut Down".
5.8 Playback
5.9 Shut down
Step 1: When the mouse clicks anywhere in the current channel screen,
the control bar will automatically pop up below the channel.
Step2: Click ” ” to enter the instant playback interface, can play the first
5 minutes of the current channel video.
NOTE:
1. If you do not need to set the device, you can click "Cancel" to exit the
boot wizard interface. You can also turn off the boot wizard in " Menu >
Configuration> General ".
2. You should reset the device administrator password (the system default
username is "admin" and the password is "12345") when booting for the
first time. To ensure the security of the device, please save the admin login
password and modify it regularly.
Step 1: Choose “Menu> Configuration> Channel Config”.
Step 2: Select the signal access type of each channel as required.
Step 3: Click “Apply>Confirm”, the device restarts and the modified
Channel configuration takes effect.
Network parameters must be properly configured before operating the
device over the network.
Procedure: Choose “Menu > Configuration > Network”. The system displays
the IP/Port interface. Modify the IP address of the device according to the
actual network plan. (The default IP address of the XVR is 192.168.1.88.).
NOTE:
1. Single channel select signal access mode to follow certain rules, the
interface will be automatically reflected in the optional options.
2. The actual access signal should be checked with the signal mode. If a
channel selected "HD" mode, you can access the
TVI / CVBS / AHD / CVI
signal; when switching signals cause abnormal display, you can reconnect
the video cable; if a channel is selected "IP" mode, is the IP channel , Can
access IP equipment.
3. In the preview interface, when the HD (
TVI / CVBS / AHD / CVI ) channel
has no image source, the channel displays “HD VIDEO”; when there is no
signal source in the IP channel, the channel displays “NO CONFIG”. When
there is no image source, the channel displays “NO VIDEO”.
Before accessing and configuring the IP channel, make sure that the XVR
network connection is correct and valid.
Step 1: Choose "Menu> Camera> Add Camera" to enter the Add Camera
interface.
Step 2: Add IPC by automatically or manually.
Automatically add, click "Auto add" button.
Manually add a device, click "Add", the Device Search interface
automatically searches for "Onvif" or "Private" protocol (if our company IPC
recommends selecting "Private"), select the IP device to be added, and
click "Add", select add channel, click "Save" to complete the addition.
NOTE:
The device opens all channels by default for 24 hours record.
Step 1: Choose "Menu> Record > Schedule" to enter the Schedule
interface.
Step 2: Select the channel and recording type according to the actual
needs. Hold down the left mouse button and drag the mouse in the time
period diagram or click “ ” to set the recording schedule.
Step 1: Download and Install
Use the Android or iOS phone to scan the corresponding QR code or
search "BitVision" from the application store to download and install
the BitVision App.
Android App QR iOS App QR
Step 2: Account login
Run BitVision App, click " " in the sliding sidebar, enter the account
name and password, and click “Login” (Note: no account is required to
register first).
Step 3: Add device
After login, click "Device manage" , " " and " Add device" ,
select "SN Add", enter the device user name, password and verification
code after scan the QR code (the verification code printed on the
label), click "Submit" to set device name and group, click "Finish" and
the addition is successful.
Step 4: Live preview
Select "Real time" and " " to enter the device list in the main
interface, select the device channel to be previewed in the group, you
will see the live video after click " Done ".
5
5.3 Network Settings
5.4 Channel Configuration
6.1 Login
6.WEB Operation
6
5.5 IP Channel Configuration
5.6 Recording Settings
8.Disclaimer
8
7.Mobile App Operation
7
5.7 Instant playback
5
1. As a result of the following reasons, if the product interrupts or
terminates the service for any of the following reasons, the company
shall not be liable for personal injury or property damage to you or a
third party. Failure to install or use properly as required; for the sake of
national or public interest; force majeure; your own or third-party
reasons (including but not limited to the use of third-party products,
software or components, etc.
2. The company has not expressed or implied that this product is
applicable to special purpose.This product may not be used in medical
/ safety equipment or other applications where there is a breakdown of
the product that could result in life-threatening or personal injury, as
well as hazardous or non-humanitarian hazards such as weapons of
mass destruction, biological and chemical weapons, nuclear explosions
or any unsafe use of nuclear energy use. Any loss or liability arising out
of the above use will be at your own risk.
3. This product, when properly installed and used, can detect
unauthorized intrusion during a particular delight but can not avoid
accidents or personal injury or property damage. In your daily life, you
should be vigilant and strengthen your safety awareness.
4. The Company is not responsible for any indirect, incidental, special
punitive damages, claims, loss of property or loss of any data or
documents. To the maximum extent permitted by law, the liability for
compensation of company is not exceed than the amount you paid for
this product.
The following exemptions or limitations of liability, please pay
special attention to:
XVR LAN login(the PC and the device are in the same router)
Step 1: Make sure the XVR and PC are in same network segment. If not,
the network segment of PC need to be set up to the same segment with
XVR, such as "192.168.1.99".
Step 2: Open IE browser, select Tools > Internet Options > Security >
Custom Level > ActiveX controls and plug-ins, all options are enabled.
Step 3: Open "Search Tool", double-click the target device from the
search result to enter the login interface, or open the IE browser to enter
the XVR address: such as “http://192.168.1.88/ “(If the http port of the XVR
is changed to 89, enter "http:// 192.168.1.88:89/”) to enter the login
interface.
Step 4: Enter the device user name (default is “admin”), password (default
is “12345”), and click “Login”.
In the preview interface, click the play button at the bottom. For the first
time connecting, you have to download and install the plugin before
previewing.
NOTE:
The Web-side can also perform the operations such as system, network,
storage, playback, download, upgrade, maintenance, and factory reset
on the Web.
6.2 Preview
Step 1: Choose "Menu> Playback" or right click on the preview interface
and select "Playback" to enter the Playback interface.
Step 2: Choose "Date > Channel > More". Double click to search for the
file, and the interface will start playing the file. Or select the "time >
channel", left mouse click on the time progress bar below the playback
interface to play the video.
Choose "Menu> Shut Down", click "Shut Down".
5.8 Playback
5.9 Shut down
Step 1: When the mouse clicks anywhere in the current channel screen,
the control bar will automatically pop up below the channel.
Step2: Click ” ” to enter the instant playback interface, can play the first
5 minutes of the current channel video.
NOTE:
1. If you do not need to set the device, you can click "Cancel" to exit the
boot wizard interface. You can also turn off the boot wizard in " Menu >
Configuration> General ".
2. You should reset the device administrator password (the system default
username is "admin" and the password is "12345") when booting for the
first time. To ensure the security of the device, please save the admin login
password and modify it regularly.
Step 1: Choose “Menu> Configuration> Channel Config”.
Step 2: Select the signal access type of each channel as required.
Step 3: Click “Apply>Confirm”, the device restarts and the modified
Channel configuration takes effect.
Network parameters must be properly configured before operating the
device over the network.
Procedure: Choose “Menu > Configuration > Network”. The system displays
the IP/Port interface. Modify the IP address of the device according to the
actual network plan. (The default IP address of the XVR is 192.168.1.88.).
NOTE:
1. Single channel select signal access mode to follow certain rules, the
interface will be automatically reflected in the optional options.
2. The actual access signal should be checked with the signal mode. If a
channel selected "HD" mode, you can access the
TVI / CVBS / AHD / CVI
signal; when switching signals cause abnormal display, you can reconnect
the video cable; if a channel is selected "IP" mode, is the IP channel , Can
access IP equipment.
3. In the preview interface, when the HD ( TVI / CVBS / AHD / CVI ) channel
has no image source, the channel displays “HD VIDEO”; when there is no
signal source in the IP channel, the channel displays “NO CONFIG”. When
there is no image source, the channel displays “NO VIDEO”.
Before accessing and configuring the IP channel, make sure that the XVR
network connection is correct and valid.
Step 1: Choose "Menu> Camera> Add Camera" to enter the Add Camera
interface.
Step 2: Add IPC by automatically or manually.
Automatically add, click "Auto add" button.
Manually add a device, click "Add", the Device Search interface
automatically searches for "Onvif" or "Private" protocol (if our company IPC
recommends selecting "Private"), select the IP device to be added, and
click "Add", select add channel, click "Save" to complete the addition.
NOTE:
The device opens all channels by default for 24 hours record.
Step 1: Choose "Menu> Record > Schedule" to enter the Schedule
interface.
Step 2: Select the channel and recording type according to the actual
needs. Hold down the left mouse button and drag the mouse in the time
period diagram or click “ ” to set the recording schedule.
Step 1: Download and Install
Use the Android or iOS phone to scan the corresponding QR code or
search "BitVision" from the application store to download and install
the BitVision App.
Android App QR iOS App QR
Step 2: Account login
Run BitVision App, click " " in the sliding sidebar, enter the account
name and password, and click “Login” (Note: no account is required to
register first).
Step 3: Add device
After login, click "Device manage" , " " and " Add device" ,
select "SN Add", enter the device user name, password and verification
code after scan the QR code (the verification code printed on the
label), click "Submit" to set device name and group, click "Finish" and
the addition is successful.
Step 4: Live preview
Select "Real time" and " " to enter the device list in the main
interface, select the device channel to be previewed in the group, you
will see the live video after click " Done ".
5

4
Network Settings
• Ensure the DVR is correctly connected to the local network via the RJ45 Ethernet
socket. The network parameters must be correctly set before operating the device
over the network.
• The interface displays the IP/Port settings where it is possible to modify the
address and port as required. Default is 168.192.1.88
Channel Conguration
• Select the signal type for each input channel connected.
• In HD mode you can access TVI/CVBS/AHD/CVI signals and IP allows access to
IP equipment.
• Click Apply/Conrm to store the setting and the device will reboot to use the
modied conguration.
• In the preview interface if there is no signal on an HD channel the display shows
‘HD Video’ and on an IP channel it states ‘No Cong’.
Note: If there is no input device on a channel the display shows ‘NO VIDEO’.
IP Channel Conguration
• Ensure the network conguration is correct and valid.
• Select Camera/Add Camera then select either ‘Auto Add’ or to manually search for
a device click on ‘Add’ and choose ‘Onvif’ or ‘Private’.
• Select the IP address to be added and click ‘Add’ then select the channel then
‘Save’ to conrm.
5.3 Network Settings
5.4 Channel Configuration
6.1 Login
6.WEB Operation
6
5.5 IP Channel Configuration
5.6 Recording Settings
8.Disclaimer
8
7.Mobile App Operation
7
5.7 Instant playback
5
1. As a result of the following reasons, if the product interrupts or
terminates the service for any of the following reasons, the company
shall not be liable for personal injury or property damage to you or a
third party. Failure to install or use properly as required; for the sake of
national or public interest; force majeure; your own or third-party
reasons (including but not limited to the use of third-party products,
software or components, etc.
2. The company has not expressed or implied that this product is
applicable to special purpose.This product may not be used in medical
/ safety equipment or other applications where there is a breakdown of
the product that could result in life-threatening or personal injury, as
well as hazardous or non-humanitarian hazards such as weapons of
mass destruction, biological and chemical weapons, nuclear explosions
or any unsafe use of nuclear energy use. Any loss or liability arising out
of the above use will be at your own risk.
3. This product, when properly installed and used, can detect
unauthorized intrusion during a particular delight but can not avoid
accidents or personal injury or property damage. In your daily life, you
should be vigilant and strengthen your safety awareness.
4. The Company is not responsible for any indirect, incidental, special
punitive damages, claims, loss of property or loss of any data or
documents. To the maximum extent permitted by law, the liability for
compensation of company is not exceed than the amount you paid for
this product.
The following exemptions or limitations of liability, please pay
special attention to:
XVR LAN login(the PC and the device are in the same router)
Step 1: Make sure the XVR and PC are in same network segment. If not,
the network segment of PC need to be set up to the same segment with
XVR, such as "192.168.1.99".
Step 2: Open IE browser, select Tools > Internet Options > Security >
Custom Level > ActiveX controls and plug-ins, all options are enabled.
Step 3: Open "Search Tool", double-click the target device from the
search result to enter the login interface, or open the IE browser to enter
the XVR address: such as “http://192.168.1.88/ “(If the http port of the XVR
is changed to 89, enter "http:// 192.168.1.88:89/”) to enter the login
interface.
Step 4: Enter the device user name (default is “admin”), password (default
is “12345”), and click “Login”.
In the preview interface, click the play button at the bottom. For the first
time connecting, you have to download and install the plugin before
previewing.
NOTE:
The Web-side can also perform the operations such as system, network,
storage, playback, download, upgrade, maintenance, and factory reset
on the Web.
6.2 Preview
Step 1: Choose "Menu> Playback" or right click on the preview interface
and select "Playback" to enter the Playback interface.
Step 2: Choose "Date > Channel > More". Double click to search for the
file, and the interface will start playing the file. Or select the "time >
channel", left mouse click on the time progress bar below the playback
interface to play the video.
Choose "Menu> Shut Down", click "Shut Down".
5.8 Playback
5.9 Shut down
Step 1: When the mouse clicks anywhere in the current channel screen,
the control bar will automatically pop up below the channel.
Step2: Click ” ” to enter the instant playback interface, can play the first
5 minutes of the current channel video.
NOTE:
1. If you do not need to set the device, you can click "Cancel" to exit the
boot wizard interface. You can also turn off the boot wizard in " Menu >
Configuration> General ".
2. You should reset the device administrator password (the system default
username is "admin" and the password is "12345") when booting for the
first time. To ensure the security of the device, please save the admin login
password and modify it regularly.
Step 1: Choose “Menu> Configuration> Channel Config”.
Step 2: Select the signal access type of each channel as required.
Step 3: Click “Apply>Confirm”, the device restarts and the modified
Channel configuration takes effect.
Network parameters must be properly configured before operating the
device over the network.
Procedure: Choose “Menu > Configuration > Network”. The system displays
the IP/Port interface. Modify the IP address of the device according to the
actual network plan. (The default IP address of the XVR is 192.168.1.88.).
NOTE:
1. Single channel select signal access mode to follow certain rules, the
interface will be automatically reflected in the optional options.
2. The actual access signal should be checked with the signal mode. If a
channel selected "HD" mode, you can access the
TVI / CVBS / AHD / CVI
signal; when switching signals cause abnormal display, you can reconnect
the video cable; if a channel is selected "IP" mode, is the IP channel , Can
access IP equipment.
3. In the preview interface, when the HD (
TVI / CVBS / AHD / CVI ) channel
has no image source, the channel displays “HD VIDEO”; when there is no
signal source in the IP channel, the channel displays “NO CONFIG”. When
there is no image source, the channel displays “NO VIDEO”.
Before accessing and configuring the IP channel, make sure that the XVR
network connection is correct and valid.
Step 1: Choose "Menu> Camera> Add Camera" to enter the Add Camera
interface.
Step 2: Add IPC by automatically or manually.
Automatically add, click "Auto add" button.
Manually add a device, click "Add", the Device Search interface
automatically searches for "Onvif" or "Private" protocol (if our company IPC
recommends selecting "Private"), select the IP device to be added, and
click "Add", select add channel, click "Save" to complete the addition.
NOTE:
The device opens all channels by default for 24 hours record.
Step 1: Choose "Menu> Record > Schedule" to enter the Schedule
interface.
Step 2: Select the channel and recording type according to the actual
needs. Hold down the left mouse button and drag the mouse in the time
period diagram or click “ ” to set the recording schedule.
Step 1: Download and Install
Use the Android or iOS phone to scan the corresponding QR code or
search "BitVision" from the application store to download and install
the BitVision App.
Android App QR iOS App QR
Step 2: Account login
Run BitVision App, click " " in the sliding sidebar, enter the account
name and password, and click “Login” (Note: no account is required to
register first).
Step 3: Add device
After login, click "Device manage" , " " and " Add device" ,
select "SN Add", enter the device user name, password and verification
code after scan the QR code (the verification code printed on the
label), click "Submit" to set device name and group, click "Finish" and
the addition is successful.
Step 4: Live preview
Select "Real time" and " " to enter the device list in the main
interface, select the device channel to be previewed in the group, you
will see the live video after click " Done ".
5
CONFIGURATION

5
WEB OPERATION
• To perform viewing and setting changes via a PC, the computer must be on the
same local network as the DVR and on the same network segment.
• Ensure Active-X and plug-ins are enabled in your browser settings (you may need
to download and install the OCX plug-in).
• In your browser go to URL http://192.168.1.88/ to download and install the OCX
plug-in.
• Once installed refresh your browser window and choose your language setting
then log on. If you changed the default admin and password previously, use these
or otherwise use the default ‘admin/12345’ to log on.
• After logging on successfully you can enter the preview mode and select the
channel to view.
• Other system settings can be changed from the web interface such as network,
storage, playback, upgrade and factory reset.
5.3 Network Settings
5.4 Channel Configuration
6.1 Login
6.WEB Operation
6
5.5 IP Channel Configuration
5.6 Recording Settings
8.Disclaimer
8
7.Mobile App Operation
7
5.7 Instant playback
5
1. As a result of the following reasons, if the product interrupts or
terminates the service for any of the following reasons, the company
shall not be liable for personal injury or property damage to you or a
third party. Failure to install or use properly as required; for the sake of
national or public interest; force majeure; your own or third-party
reasons (including but not limited to the use of third-party products,
software or components, etc.
2. The company has not expressed or implied that this product is
applicable to special purpose.This product may not be used in medical
/ safety equipment or other applications where there is a breakdown of
the product that could result in life-threatening or personal injury, as
well as hazardous or non-humanitarian hazards such as weapons of
mass destruction, biological and chemical weapons, nuclear explosions
or any unsafe use of nuclear energy use. Any loss or liability arising out
of the above use will be at your own risk.
3. This product, when properly installed and used, can detect
unauthorized intrusion during a particular delight but can not avoid
accidents or personal injury or property damage. In your daily life, you
should be vigilant and strengthen your safety awareness.
4. The Company is not responsible for any indirect, incidental, special
punitive damages, claims, loss of property or loss of any data or
documents. To the maximum extent permitted by law, the liability for
compensation of company is not exceed than the amount you paid for
this product.
The following exemptions or limitations of liability, please pay
special attention to:
XVR LAN login(the PC and the device are in the same router)
Step 1: Make sure the XVR and PC are in same network segment. If not,
the network segment of PC need to be set up to the same segment with
XVR, such as "192.168.1.99".
Step 2: Open IE browser, select Tools > Internet Options > Security >
Custom Level > ActiveX controls and plug-ins, all options are enabled.
Step 3: Open "Search Tool", double-click the target device from the
search result to enter the login interface, or open the IE browser to enter
the XVR address: such as “http://192.168.1.88/ “(If the http port of the XVR
is changed to 89, enter "http:// 192.168.1.88:89/”) to enter the login
interface.
Step 4: Enter the device user name (default is “admin”), password (default
is “12345”), and click “Login”.
In the preview interface, click the play button at the bottom. For the first
time connecting, you have to download and install the plugin before
previewing.
NOTE:
The Web-side can also perform the operations such as system, network,
storage, playback, download, upgrade, maintenance, and factory reset
on the Web.
6.2 Preview
Step 1: Choose "Menu> Playback" or right click on the preview interface
and select "Playback" to enter the Playback interface.
Step 2: Choose "Date > Channel > More". Double click to search for the
file, and the interface will start playing the file. Or select the "time >
channel", left mouse click on the time progress bar below the playback
interface to play the video.
Choose "Menu> Shut Down", click "Shut Down".
5.8 Playback
5.9 Shut down
Step 1: When the mouse clicks anywhere in the current channel screen,
the control bar will automatically pop up below the channel.
Step2: Click ” ” to enter the instant playback interface, can play the first
5 minutes of the current channel video.
NOTE:
1. If you do not need to set the device, you can click "Cancel" to exit the
boot wizard interface. You can also turn off the boot wizard in " Menu >
Configuration> General ".
2. You should reset the device administrator password (the system default
username is "admin" and the password is "12345") when booting for the
first time. To ensure the security of the device, please save the admin login
password and modify it regularly.
Step 1: Choose “Menu> Configuration> Channel Config”.
Step 2: Select the signal access type of each channel as required.
Step 3: Click “Apply>Confirm”, the device restarts and the modified
Channel configuration takes effect.
Network parameters must be properly configured before operating the
device over the network.
Procedure: Choose “Menu > Configuration > Network”. The system displays
the IP/Port interface. Modify the IP address of the device according to the
actual network plan. (The default IP address of the XVR is 192.168.1.88.).
NOTE:
1. Single channel select signal access mode to follow certain rules, the
interface will be automatically reflected in the optional options.
2. The actual access signal should be checked with the signal mode. If a
channel selected "HD" mode, you can access the
TVI / CVBS / AHD / CVI
signal; when switching signals cause abnormal display, you can reconnect
the video cable; if a channel is selected "IP" mode, is the IP channel , Can
access IP equipment.
3. In the preview interface, when the HD ( TVI / CVBS / AHD / CVI ) channel
has no image source, the channel displays “HD VIDEO”; when there is no
signal source in the IP channel, the channel displays “NO CONFIG”. When
there is no image source, the channel displays “NO VIDEO”.
Before accessing and configuring the IP channel, make sure that the XVR
network connection is correct and valid.
Step 1: Choose "Menu> Camera> Add Camera" to enter the Add Camera
interface.
Step 2: Add IPC by automatically or manually.
Automatically add, click "Auto add" button.
Manually add a device, click "Add", the Device Search interface
automatically searches for "Onvif" or "Private" protocol (if our company IPC
recommends selecting "Private"), select the IP device to be added, and
click "Add", select add channel, click "Save" to complete the addition.
NOTE:
The device opens all channels by default for 24 hours record.
Step 1: Choose "Menu> Record > Schedule" to enter the Schedule
interface.
Step 2: Select the channel and recording type according to the actual
needs. Hold down the left mouse button and drag the mouse in the time
period diagram or click “ ” to set the recording schedule.
Step 1: Download and Install
Use the Android or iOS phone to scan the corresponding QR code or
search "BitVision" from the application store to download and install
the BitVision App.
Android App QR iOS App QR
Step 2: Account login
Run BitVision App, click " " in the sliding sidebar, enter the account
name and password, and click “Login” (Note: no account is required to
register first).
Step 3: Add device
After login, click "Device manage" , " " and " Add device" ,
select "SN Add", enter the device user name, password and verification
code after scan the QR code (the verification code printed on the
label), click "Submit" to set device name and group, click "Finish" and
the addition is successful.
Step 4: Live preview
Select "Real time" and " " to enter the device list in the main
interface, select the device channel to be previewed in the group, you
will see the live video after click " Done ".
5
5.3 Network Settings
5.4 Channel Configuration
6.1 Login
6.WEB Operation
6
5.5 IP Channel Configuration
5.6 Recording Settings
8.Disclaimer
8
7.Mobile App Operation
7
5.7 Instant playback
5
1. As a result of the following reasons, if the product interrupts or
terminates the service for any of the following reasons, the company
shall not be liable for personal injury or property damage to you or a
third party. Failure to install or use properly as required; for the sake of
national or public interest; force majeure; your own or third-party
reasons (including but not limited to the use of third-party products,
software or components, etc.
2. The company has not expressed or implied that this product is
applicable to special purpose.This product may not be used in medical
/ safety equipment or other applications where there is a breakdown of
the product that could result in life-threatening or personal injury, as
well as hazardous or non-humanitarian hazards such as weapons of
mass destruction, biological and chemical weapons, nuclear explosions
or any unsafe use of nuclear energy use. Any loss or liability arising out
of the above use will be at your own risk.
3. This product, when properly installed and used, can detect
unauthorized intrusion during a particular delight but can not avoid
accidents or personal injury or property damage. In your daily life, you
should be vigilant and strengthen your safety awareness.
4. The Company is not responsible for any indirect, incidental, special
punitive damages, claims, loss of property or loss of any data or
documents. To the maximum extent permitted by law, the liability for
compensation of company is not exceed than the amount you paid for
this product.
The following exemptions or limitations of liability, please pay
special attention to:
XVR LAN login(the PC and the device are in the same router)
Step 1: Make sure the XVR and PC are in same network segment. If not,
the network segment of PC need to be set up to the same segment with
XVR, such as "192.168.1.99".
Step 2: Open IE browser, select Tools > Internet Options > Security >
Custom Level > ActiveX controls and plug-ins, all options are enabled.
Step 3: Open "Search Tool", double-click the target device from the
search result to enter the login interface, or open the IE browser to enter
the XVR address: such as “http://192.168.1.88/ “(If the http port of the XVR
is changed to 89, enter "http:// 192.168.1.88:89/”) to enter the login
interface.
Step 4: Enter the device user name (default is “admin”), password (default
is “12345”), and click “Login”.
In the preview interface, click the play button at the bottom. For the first
time connecting, you have to download and install the plugin before
previewing.
NOTE:
The Web-side can also perform the operations such as system, network,
storage, playback, download, upgrade, maintenance, and factory reset
on the Web.
6.2 Preview
Step 1: Choose "Menu> Playback" or right click on the preview interface
and select "Playback" to enter the Playback interface.
Step 2: Choose "Date > Channel > More". Double click to search for the
file, and the interface will start playing the file. Or select the "time >
channel", left mouse click on the time progress bar below the playback
interface to play the video.
Choose "Menu> Shut Down", click "Shut Down".
5.8 Playback
5.9 Shut down
Step 1: When the mouse clicks anywhere in the current channel screen,
the control bar will automatically pop up below the channel.
Step2: Click ” ” to enter the instant playback interface, can play the first
5 minutes of the current channel video.
NOTE:
1. If you do not need to set the device, you can click "Cancel" to exit the
boot wizard interface. You can also turn off the boot wizard in " Menu >
Configuration> General ".
2. You should reset the device administrator password (the system default
username is "admin" and the password is "12345") when booting for the
first time. To ensure the security of the device, please save the admin login
password and modify it regularly.
Step 1: Choose “Menu> Configuration> Channel Config”.
Step 2: Select the signal access type of each channel as required.
Step 3: Click “Apply>Confirm”, the device restarts and the modified
Channel configuration takes effect.
Network parameters must be properly configured before operating the
device over the network.
Procedure: Choose “Menu > Configuration > Network”. The system displays
the IP/Port interface. Modify the IP address of the device according to the
actual network plan. (The default IP address of the XVR is 192.168.1.88.).
NOTE:
1. Single channel select signal access mode to follow certain rules, the
interface will be automatically reflected in the optional options.
2. The actual access signal should be checked with the signal mode. If a
channel selected "HD" mode, you can access the
TVI / CVBS / AHD / CVI
signal; when switching signals cause abnormal display, you can reconnect
the video cable; if a channel is selected "IP" mode, is the IP channel , Can
access IP equipment.
3. In the preview interface, when the HD (
TVI / CVBS / AHD / CVI ) channel
has no image source, the channel displays “HD VIDEO”; when there is no
signal source in the IP channel, the channel displays “NO CONFIG”. When
there is no image source, the channel displays “NO VIDEO”.
Before accessing and configuring the IP channel, make sure that the XVR
network connection is correct and valid.
Step 1: Choose "Menu> Camera> Add Camera" to enter the Add Camera
interface.
Step 2: Add IPC by automatically or manually.
Automatically add, click "Auto add" button.
Manually add a device, click "Add", the Device Search interface
automatically searches for "Onvif" or "Private" protocol (if our company IPC
recommends selecting "Private"), select the IP device to be added, and
click "Add", select add channel, click "Save" to complete the addition.
NOTE:
The device opens all channels by default for 24 hours record.
Step 1: Choose "Menu> Record > Schedule" to enter the Schedule
interface.
Step 2: Select the channel and recording type according to the actual
needs. Hold down the left mouse button and drag the mouse in the time
period diagram or click “ ” to set the recording schedule.
Step 1: Download and Install
Use the Android or iOS phone to scan the corresponding QR code or
search "BitVision" from the application store to download and install
the BitVision App.
Android App QR iOS App QR
Step 2: Account login
Run BitVision App, click " " in the sliding sidebar, enter the account
name and password, and click “Login” (Note: no account is required to
register first).
Step 3: Add device
After login, click "Device manage" , " " and " Add device" ,
select "SN Add", enter the device user name, password and verification
code after scan the QR code (the verification code printed on the
label), click "Submit" to set device name and group, click "Finish" and
the addition is successful.
Step 4: Live preview
Select "Real time" and " " to enter the device list in the main
interface, select the device channel to be previewed in the group, you
will see the live video after click " Done ".
5
Recording Schedule
• By default all channels are set to record for 24hrs (continuous).
• To change to a selective schedule choose ‘Record/Schedule’ to enter the record
timer.
• Select the channel and recording type as required then click and drag the pointer
in the time period or click ‘
5.3 Network Settings
5.4 Channel Configuration
6.1 Login
6.WEB Operation
6
5.5 IP Channel Configuration
5.6 Recording Settings
8.Disclaimer
8
7.Mobile App Operation
7
5.7 Instant playback
5
1. As a result of the following reasons, if the product interrupts or
terminates the service for any of the following reasons, the company
shall not be liable for personal injury or property damage to you or a
third party. Failure to install or use properly as required; for the sake of
national or public interest; force majeure; your own or third-party
reasons (including but not limited to the use of third-party products,
software or components, etc.
2. The company has not expressed or implied that this product is
applicable to special purpose.This product may not be used in medical
/ safety equipment or other applications where there is a breakdown of
the product that could result in life-threatening or personal injury, as
well as hazardous or non-humanitarian hazards such as weapons of
mass destruction, biological and chemical weapons, nuclear explosions
or any unsafe use of nuclear energy use. Any loss or liability arising out
of the above use will be at your own risk.
3. This product, when properly installed and used, can detect
unauthorized intrusion during a particular delight but can not avoid
accidents or personal injury or property damage. In your daily life, you
should be vigilant and strengthen your safety awareness.
4. The Company is not responsible for any indirect, incidental, special
punitive damages, claims, loss of property or loss of any data or
documents. To the maximum extent permitted by law, the liability for
compensation of company is not exceed than the amount you paid for
this product.
The following exemptions or limitations of liability, please pay
special attention to:
XVR LAN login(the PC and the device are in the same router)
Step 1: Make sure the XVR and PC are in same network segment. If not,
the network segment of PC need to be set up to the same segment with
XVR, such as "192.168.1.99".
Step 2: Open IE browser, select Tools > Internet Options > Security >
Custom Level > ActiveX controls and plug-ins, all options are enabled.
Step 3: Open "Search Tool", double-click the target device from the
search result to enter the login interface, or open the IE browser to enter
the XVR address: such as “http://192.168.1.88/ “(If the http port of the XVR
is changed to 89, enter "http:// 192.168.1.88:89/”) to enter the login
interface.
Step 4: Enter the device user name (default is “admin”), password (default
is “12345”), and click “Login”.
In the preview interface, click the play button at the bottom. For the first
time connecting, you have to download and install the plugin before
previewing.
NOTE:
The Web-side can also perform the operations such as system, network,
storage, playback, download, upgrade, maintenance, and factory reset
on the Web.
6.2 Preview
Step 1: Choose "Menu> Playback" or right click on the preview interface
and select "Playback" to enter the Playback interface.
Step 2: Choose "Date > Channel > More". Double click to search for the
file, and the interface will start playing the file. Or select the "time >
channel", left mouse click on the time progress bar below the playback
interface to play the video.
Choose "Menu> Shut Down", click "Shut Down".
5.8 Playback
5.9 Shut down
Step 1: When the mouse clicks anywhere in the current channel screen,
the control bar will automatically pop up below the channel.
Step2: Click ” ” to enter the instant playback interface, can play the first
5 minutes of the current channel video.
NOTE:
1. If you do not need to set the device, you can click "Cancel" to exit the
boot wizard interface. You can also turn off the boot wizard in " Menu >
Configuration> General ".
2. You should reset the device administrator password (the system default
username is "admin" and the password is "12345") when booting for the
first time. To ensure the security of the device, please save the admin login
password and modify it regularly.
Step 1: Choose “Menu> Configuration> Channel Config”.
Step 2: Select the signal access type of each channel as required.
Step 3: Click “Apply>Confirm”, the device restarts and the modified
Channel configuration takes effect.
Network parameters must be properly configured before operating the
device over the network.
Procedure: Choose “Menu > Configuration > Network”. The system displays
the IP/Port interface. Modify the IP address of the device according to the
actual network plan. (The default IP address of the XVR is 192.168.1.88.).
NOTE:
1. Single channel select signal access mode to follow certain rules, the
interface will be automatically reflected in the optional options.
2. The actual access signal should be checked with the signal mode. If a
channel selected "HD" mode, you can access the
TVI / CVBS / AHD / CVI
signal; when switching signals cause abnormal display, you can reconnect
the video cable; if a channel is selected "IP" mode, is the IP channel , Can
access IP equipment.
3. In the preview interface, when the HD ( TVI / CVBS / AHD / CVI ) channel
has no image source, the channel displays “HD VIDEO”; when there is no
signal source in the IP channel, the channel displays “NO CONFIG”. When
there is no image source, the channel displays “NO VIDEO”.
Before accessing and configuring the IP channel, make sure that the XVR
network connection is correct and valid.
Step 1: Choose "Menu> Camera> Add Camera" to enter the Add Camera
interface.
Step 2: Add IPC by automatically or manually.
Automatically add, click "Auto add" button.
Manually add a device, click "Add", the Device Search interface
automatically searches for "Onvif" or "Private" protocol (if our company IPC
recommends selecting "Private"), select the IP device to be added, and
click "Add", select add channel, click "Save" to complete the addition.
NOTE:
The device opens all channels by default for 24 hours record.
Step 1: Choose "Menu> Record > Schedule" to enter the Schedule
interface.
Step 2: Select the channel and recording type according to the actual
needs. Hold down the left mouse button and drag the mouse in the time
period diagram or click “ ” to set the recording schedule.
Step 1: Download and Install
Use the Android or iOS phone to scan the corresponding QR code or
search "BitVision" from the application store to download and install
the BitVision App.
Android App QR iOS App QR
Step 2: Account login
Run BitVision App, click " " in the sliding sidebar, enter the account
name and password, and click “Login” (Note: no account is required to
register first).
Step 3: Add device
After login, click "Device manage" , " " and " Add device" ,
select "SN Add", enter the device user name, password and verification
code after scan the QR code (the verification code printed on the
label), click "Submit" to set device name and group, click "Finish" and
the addition is successful.
Step 4: Live preview
Select "Real time" and " " to enter the device list in the main
interface, select the device channel to be previewed in the group, you
will see the live video after click " Done ".
5
‘ to set the desired parameters.
Instant Playback
• By clicking on any channel display the video playback control will be shown below
the window.
Playback
• Choose ‘Playback’ or right click on the preview interface and select ‘Playback’.
• Select Date/Channel/More then double click to search for the le.
• Alternatively select ‘Time/Channel’ then click on the progress bar to play the video.
Shutdown
• From the menu choose ‘Shut Down’ and the pop up window will appear from
where you can log out reboot or shut the system down.

6
CLEANING AND MAINTENANCE
• When cleaning, use a soft dry cloth to remove any dust that may have
accumulated.
• Use a damp cloth and a small amount of liquid detergent if necessary.
• Do not use any chemicals, abrasives or solvents that could damage the unit.
MOBILE APP OPERATION
• Search the app store for “BitVision” or scan the QR codes below and download
and install the app:
• Run the app and swipe right to reveal the sidebar.
• Select the Log in option and register a new account.
• Enter the Captcha as directed which will be sent to the email address you give
then log in.
• Select ‘Device Manage’ then ‘+’ followed by ‘Add Device’.
• Select ‘SN Add’ and Scan the QR code on the label on the bottom of the device
• Enter your user name and password and then when prompted enter your chosen
device name and group.
• Select ‘Submit’ to store the settings then select ‘Finish’ to access the functions.
Live Preview
• From the sidebar options select ‘Real Time’ then ‘+’ to enter the device list and
select the channel to be viewed then choose ‘Preview’ to show the live feed for
that channel.
Playback History
• Select ‘History Playback’ from the sidebar then ‘
5.3 Network Settings
5.4 Channel Configuration
6.1 Login
6.WEB Operation
6
5.5 IP Channel Configuration
5.6 Recording Settings
8.Disclaimer
8
7.Mobile App Operation
7
5.7 Instant playback
5
1. As a result of the following reasons, if the product interrupts or
terminates the service for any of the following reasons, the company
shall not be liable for personal injury or property damage to you or a
third party. Failure to install or use properly as required; for the sake of
national or public interest; force majeure; your own or third-party
reasons (including but not limited to the use of third-party products,
software or components, etc.
2. The company has not expressed or implied that this product is
applicable to special purpose.This product may not be used in medical
/ safety equipment or other applications where there is a breakdown of
the product that could result in life-threatening or personal injury, as
well as hazardous or non-humanitarian hazards such as weapons of
mass destruction, biological and chemical weapons, nuclear explosions
or any unsafe use of nuclear energy use. Any loss or liability arising out
of the above use will be at your own risk.
3. This product, when properly installed and used, can detect
unauthorized intrusion during a particular delight but can not avoid
accidents or personal injury or property damage. In your daily life, you
should be vigilant and strengthen your safety awareness.
4. The Company is not responsible for any indirect, incidental, special
punitive damages, claims, loss of property or loss of any data or
documents. To the maximum extent permitted by law, the liability for
compensation of company is not exceed than the amount you paid for
this product.
The following exemptions or limitations of liability, please pay
special attention to:
XVR LAN login(the PC and the device are in the same router)
Step 1: Make sure the XVR and PC are in same network segment. If not,
the network segment of PC need to be set up to the same segment with
XVR, such as "192.168.1.99".
Step 2: Open IE browser, select Tools > Internet Options > Security >
Custom Level > ActiveX controls and plug-ins, all options are enabled.
Step 3: Open "Search Tool", double-click the target device from the
search result to enter the login interface, or open the IE browser to enter
the XVR address: such as “http://192.168.1.88/ “(If the http port of the XVR
is changed to 89, enter "http:// 192.168.1.88:89/”) to enter the login
interface.
Step 4: Enter the device user name (default is “admin”), password (default
is “12345”), and click “Login”.
In the preview interface, click the play button at the bottom. For the first
time connecting, you have to download and install the plugin before
previewing.
NOTE:
The Web-side can also perform the operations such as system, network,
storage, playback, download, upgrade, maintenance, and factory reset
on the Web.
6.2 Preview
Step 1: Choose "Menu> Playback" or right click on the preview interface
and select "Playback" to enter the Playback interface.
Step 2: Choose "Date > Channel > More". Double click to search for the
file, and the interface will start playing the file. Or select the "time >
channel", left mouse click on the time progress bar below the playback
interface to play the video.
Choose "Menu> Shut Down", click "Shut Down".
5.8 Playback
5.9 Shut down
Step 1: When the mouse clicks anywhere in the current channel screen,
the control bar will automatically pop up below the channel.
Step2: Click ” ” to enter the instant playback interface, can play the first
5 minutes of the current channel video.
NOTE:
1. If you do not need to set the device, you can click "Cancel" to exit the
boot wizard interface. You can also turn off the boot wizard in " Menu >
Configuration> General ".
2. You should reset the device administrator password (the system default
username is "admin" and the password is "12345") when booting for the
first time. To ensure the security of the device, please save the admin login
password and modify it regularly.
Step 1: Choose “Menu> Configuration> Channel Config”.
Step 2: Select the signal access type of each channel as required.
Step 3: Click “Apply>Confirm”, the device restarts and the modified
Channel configuration takes effect.
Network parameters must be properly configured before operating the
device over the network.
Procedure: Choose “Menu > Configuration > Network”. The system displays
the IP/Port interface. Modify the IP address of the device according to the
actual network plan. (The default IP address of the XVR is 192.168.1.88.).
NOTE:
1. Single channel select signal access mode to follow certain rules, the
interface will be automatically reflected in the optional options.
2. The actual access signal should be checked with the signal mode. If a
channel selected "HD" mode, you can access the
TVI / CVBS / AHD / CVI
signal; when switching signals cause abnormal display, you can reconnect
the video cable; if a channel is selected "IP" mode, is the IP channel , Can
access IP equipment.
3. In the preview interface, when the HD (
TVI / CVBS / AHD / CVI ) channel
has no image source, the channel displays “HD VIDEO”; when there is no
signal source in the IP channel, the channel displays “NO CONFIG”. When
there is no image source, the channel displays “NO VIDEO”.
Before accessing and configuring the IP channel, make sure that the XVR
network connection is correct and valid.
Step 1: Choose "Menu> Camera> Add Camera" to enter the Add Camera
interface.
Step 2: Add IPC by automatically or manually.
Automatically add, click "Auto add" button.
Manually add a device, click "Add", the Device Search interface
automatically searches for "Onvif" or "Private" protocol (if our company IPC
recommends selecting "Private"), select the IP device to be added, and
click "Add", select add channel, click "Save" to complete the addition.
NOTE:
The device opens all channels by default for 24 hours record.
Step 1: Choose "Menu> Record > Schedule" to enter the Schedule
interface.
Step 2: Select the channel and recording type according to the actual
needs. Hold down the left mouse button and drag the mouse in the time
period diagram or click “ ” to set the recording schedule.
Step 1: Download and Install
Use the Android or iOS phone to scan the corresponding QR code or
search "BitVision" from the application store to download and install
the BitVision App.
Android App QR iOS App QR
Step 2: Account login
Run BitVision App, click " " in the sliding sidebar, enter the account
name and password, and click “Login” (Note: no account is required to
register first).
Step 3: Add device
After login, click "Device manage" , " " and " Add device" ,
select "SN Add", enter the device user name, password and verification
code after scan the QR code (the verification code printed on the
label), click "Submit" to set device name and group, click "Finish" and
the addition is successful.
Step 4: Live preview
Select "Real time" and " " to enter the device list in the main
interface, select the device channel to be previewed in the group, you
will see the live video after click " Done ".
5
’ to see the device list and
select the channel then select ‘Done’.
5.3 Network Settings
5.4 Channel Configuration
6.1 Login
6.WEB Operation
6
5.5 IP Channel Configuration
5.6 Recording Settings
8.Disclaimer
8
7.Mobile App Operation
7
5.7 Instant playback
5
1. As a result of the following reasons, if the product interrupts or
terminates the service for any of the following reasons, the company
shall not be liable for personal injury or property damage to you or a
third party. Failure to install or use properly as required; for the sake of
national or public interest; force majeure; your own or third-party
reasons (including but not limited to the use of third-party products,
software or components, etc.
2. The company has not expressed or implied that this product is
applicable to special purpose.This product may not be used in medical
/ safety equipment or other applications where there is a breakdown of
the product that could result in life-threatening or personal injury, as
well as hazardous or non-humanitarian hazards such as weapons of
mass destruction, biological and chemical weapons, nuclear explosions
or any unsafe use of nuclear energy use. Any loss or liability arising out
of the above use will be at your own risk.
3. This product, when properly installed and used, can detect
unauthorized intrusion during a particular delight but can not avoid
accidents or personal injury or property damage. In your daily life, you
should be vigilant and strengthen your safety awareness.
4. The Company is not responsible for any indirect, incidental, special
punitive damages, claims, loss of property or loss of any data or
documents. To the maximum extent permitted by law, the liability for
compensation of company is not exceed than the amount you paid for
this product.
The following exemptions or limitations of liability, please pay
special attention to:
XVR LAN login(the PC and the device are in the same router)
Step 1: Make sure the XVR and PC are in same network segment. If not,
the network segment of PC need to be set up to the same segment with
XVR, such as "192.168.1.99".
Step 2: Open IE browser, select Tools > Internet Options > Security >
Custom Level > ActiveX controls and plug-ins, all options are enabled.
Step 3: Open "Search Tool", double-click the target device from the
search result to enter the login interface, or open the IE browser to enter
the XVR address: such as “http://192.168.1.88/ “(If the http port of the XVR
is changed to 89, enter "http:// 192.168.1.88:89/”) to enter the login
interface.
Step 4: Enter the device user name (default is “admin”), password (default
is “12345”), and click “Login”.
In the preview interface, click the play button at the bottom. For the first
time connecting, you have to download and install the plugin before
previewing.
NOTE:
The Web-side can also perform the operations such as system, network,
storage, playback, download, upgrade, maintenance, and factory reset
on the Web.
6.2 Preview
Step 1: Choose "Menu> Playback" or right click on the preview interface
and select "Playback" to enter the Playback interface.
Step 2: Choose "Date > Channel > More". Double click to search for the
file, and the interface will start playing the file. Or select the "time >
channel", left mouse click on the time progress bar below the playback
interface to play the video.
Choose "Menu> Shut Down", click "Shut Down".
5.8 Playback
5.9 Shut down
Step 1: When the mouse clicks anywhere in the current channel screen,
the control bar will automatically pop up below the channel.
Step2: Click ” ” to enter the instant playback interface, can play the first
5 minutes of the current channel video.
NOTE:
1. If you do not need to set the device, you can click "Cancel" to exit the
boot wizard interface. You can also turn off the boot wizard in " Menu >
Configuration> General ".
2. You should reset the device administrator password (the system default
username is "admin" and the password is "12345") when booting for the
first time. To ensure the security of the device, please save the admin login
password and modify it regularly.
Step 1: Choose “Menu> Configuration> Channel Config”.
Step 2: Select the signal access type of each channel as required.
Step 3: Click “Apply>Confirm”, the device restarts and the modified
Channel configuration takes effect.
Network parameters must be properly configured before operating the
device over the network.
Procedure: Choose “Menu > Configuration > Network”. The system displays
the IP/Port interface. Modify the IP address of the device according to the
actual network plan. (The default IP address of the XVR is 192.168.1.88.).
NOTE:
1. Single channel select signal access mode to follow certain rules, the
interface will be automatically reflected in the optional options.
2. The actual access signal should be checked with the signal mode. If a
channel selected "HD" mode, you can access the
TVI / CVBS / AHD / CVI
signal; when switching signals cause abnormal display, you can reconnect
the video cable; if a channel is selected "IP" mode, is the IP channel , Can
access IP equipment.
3. In the preview interface, when the HD (
TVI / CVBS / AHD / CVI ) channel
has no image source, the channel displays “HD VIDEO”; when there is no
signal source in the IP channel, the channel displays “NO CONFIG”. When
there is no image source, the channel displays “NO VIDEO”.
Before accessing and configuring the IP channel, make sure that the XVR
network connection is correct and valid.
Step 1: Choose "Menu> Camera> Add Camera" to enter the Add Camera
interface.
Step 2: Add IPC by automatically or manually.
Automatically add, click "Auto add" button.
Manually add a device, click "Add", the Device Search interface
automatically searches for "Onvif" or "Private" protocol (if our company IPC
recommends selecting "Private"), select the IP device to be added, and
click "Add", select add channel, click "Save" to complete the addition.
NOTE:
The device opens all channels by default for 24 hours record.
Step 1: Choose "Menu> Record > Schedule" to enter the Schedule
interface.
Step 2: Select the channel and recording type according to the actual
needs. Hold down the left mouse button and drag the mouse in the time
period diagram or click “ ” to set the recording schedule.
Step 1: Download and Install
Use the Android or iOS phone to scan the corresponding QR code or
search "BitVision" from the application store to download and install
the BitVision App.
Android App QR iOS App QR
Step 2: Account login
Run BitVision App, click " " in the sliding sidebar, enter the account
name and password, and click “Login” (Note: no account is required to
register first).
Step 3: Add device
After login, click "Device manage" , " " and " Add device" ,
select "SN Add", enter the device user name, password and verification
code after scan the QR code (the verification code printed on the
label), click "Submit" to set device name and group, click "Finish" and
the addition is successful.
Step 4: Live preview
Select "Real time" and " " to enter the device list in the main
interface, select the device channel to be previewed in the group, you
will see the live video after click " Done ".
5

7
SPECIFICATION
Model DFR-5MP-XVR4 DFR-5MP-XVR8
Processor/Codec HISilicon HI3520DV400
Op Sys Embedded Linux
Video Input
Normal Mode: Analogue:
4×(AHD/TVI/CVI:8M; TVI/AHD: 5M;
AHD/TVI/CVI: 4M; AHD/TVI: 3M; AHD/
TVI/CVI: 1080P/720P; Analogue: 960H)
8×(AHD/TVI/CVI:8M; TVI/AHD: 5M; AHD/
TVI/CVI: 4M; AHD/TVI: 3M; AHD/TVI/CVI:
1080P/720P; Analogue: 960H)
Lite Mode: Analogue: 4×(AHD/TVI/CVI: 1080P/720P;
Analogue: 960H)
8×(AHD/TVI/CVI: 1080P/720P;
Analogue: 960H)
Analogue+Network: 2×Analogue(1080P) +7×network
(MAX 5MP)
6×Analogue (1080P) +3×network
(Max 8MP), 4×Analogue (1080P)
+5×network (Max 8MP), 2×Analogue
(1080P) +7×network (Max 8MP)
Network: 12×5MP/4MP/3MP/1080P/960P/720P
(Total incoming bandwidth=48M)
16×8MP/5MP/4MP/3MP/1080P/960P/720P
(Total incoming bandwidth=80M)
Input: 4CH BNC 8CH BNC
Signal Type; Analogue/AHD/CVI/TVI 2.0/TVI 3.0/Network
Output: 1 HD, 1 VGA
Audio Input: 4 Channel, RCA
Audio Output: 1 Channel, RCA
Motion Detection: 4 Channel (max 16 Channel in pure network mode)
Trigger Events: Email, Screen tips, Buzzer, Push notications (motion detection)
Email Alarm: Send image to the designated e-mail
Interface/ Protocol: RS485 / Pelco-D, Pelco-P
Baud Rate/Address: 110~921600/0~255
Display
VGA Resolution: 1920×1080P/60Hz, 1280×1024/60Hz, 1280×720/60Hz,1024×768/60Hz
HD Output Normal Mode: 2560×1440/30Hz, 1920×1080P/60Hz
1280×1024/60Hz
1280×720/60Hz,1024×768/60Hz
3840×2160/30Hz, 2560×1440/30Hz
1920×1080P/60Hz, 1280×1024/60Hz
1280×720/60Hz,1024×768/60Hz
Lite Mode: 3840×2160/30Hz, 2560×1440/30Hz, 1920×1080P/60Hz, 1280×1024/60Hz
1280×720/60Hz, 1024×768/60Hz
Display Split: 16 Channel/9 Channel/4 Channel/1Channel
Privacy Masking: 3 Rectangular Zones (Each camera)
OSD: Camera title, Time, Video loss, Alarm, Motion detection, Recording
Recording
Video Compression: H.265/H.265+/H.264/H.264+
Audio Compression: G.711u
Resolution: 5MP(2592×1944),8MP_LITE(1920×2160),5MP_HALF(1296×1944),4MP(2560×1440),4
MP_HALF(1280×1440),3MP(2048×1536),1080P(1920×1080),720P(1280×720),
960H(960×576)
Record Rate Normal Mode
Analogue:
PAL:8MP_LITE(1920×2160 4×8fps), 5MP(2592×1944 4×6fps), 5MP_HALF(1296×1944
4×10fps),4MP(2560×1440 4×8fps),4MP_HALF(1280×1440 4×15fps),3MP(2048×1536
4×9fps),1080P(1920×1080 4×15fps),720P(1280×720 4×25fps), 960H(960×576 4×25fps)
Lite Mode Analogue: Half 1080P(960x1080 4×25fps),720P(1280×720 4×25fps), 960H(960×576 4×25fps)
Pure IP (H.265): PAL: 5MP@12x25fps,
3MP@12×25fps,1080P@12×25fps,
960P@12×25fps, 720P@12×25fps,
D1@12×25fps
PAL:4k@8x25fps, 5MP@12x25fps,
4MP@16x25fps, 3MP@16x25fps,
1080P@16x25fps, 960P@16x25fps,
720P@16x25fps, D1@16x25fps
Record Mode: Manual\Timer\Motion Detection

8
INFORMATION ON WASTE DISPOSAL FOR CONSUMERS OF ELECTRICAL &
ELECTRONIC EQUIPMENT.
When this product has reached the end of its life it must be treated as Waste Electrical & Electronic Equipment
(WEEE). Any WEEE marked products must not be mixed with general household waste, but kept separate for
the treatment, recovery and recycling of the materials used. Contact your local authority for details of recycling
schemes in your area.
Made in China. PR2 9PP Man Rev 1.1
Playback & Backup
Decode Capability:
2CH 1080P@30fps 4CH 1080P@30fps
Sync Playback Pure Analogue: 4CH 5MP@6fps, 4CH 8MP Lite@8fps,
4CH 4MP@8fps, 4CH 3MP@9fps,
4CH 1080p@15fps, 4CH 1080N@25fps
8CH 5MP@6fps, 4CH 8MP Lite@8fps, 8CH
4MP@8fps, 8CH 3MP@9fps,
8CH 1080P@15fps, 8CH 1080N@25fps
Mix Mode: 1CH 5MP@30fps, 1CH 4MP@30fps,
1CH 3MP@30fps, 2CH 1080P@30fps,
3CH 1080p@15fps
4CH 5MP@6fps, 4CH 4MP@8fps,
4CH 3MP@9fps, 4CH 1080P@15fps,
1CH 8MP 30fps, 2CH 5MP 30fps,
2CH 4MP @30fps, 2CH 3MP@30fps
Pure IPC: 1CH 5MP@30fps, 1CH 4MP@30fps,
1CH 3MP@30fps, 4CH 1080P@30fps,
4CH 960P@30fps, 4CH 720P@30fps
1CH 4K@30fps, 2CH 5MP@30fps,
3CH 4MP@30fps, 4CH 3MP@30fps,
4CH 1080P@30fps, 4CH 960P@30fps,
4CH 720P@30fps
Remote Playback: 4 Channel/1Channel
Search Mode: ALL, Channel, Manual, Time, Date, Motion Detection
Playback Functions: Play, Pause, Stop, Fast play, Rewind, Digital Zoom, Full screen
Smart Phone Playback: 4 Channel
Backup Mode: USB Device(with format FAT 32) / Network/FTP
Network
Interface:
1 RJ45 10M/100M Adaptive Ethernet Interface
Network Functions TCP/IP, HTTP, UPnP, DNS, NTP, SMTP, PPPoE, DHCP, FTP, DDNS, RTP, RTSP, RTCP
DDNS: Dyndns, changeip, no-ip, Oray, A-PRESS, MYQSEE, SKDDNS, SMART-EYES, ZEBEYE
Web Browser: IE8-11, Google Chrome (lower than Ver44), Firefox (lower than Ver53)
CMS Software Support: Windows 7 / Windows 8 / Windows 10
Extra Stream: CIF(1~25fps) CIF(1~30fps)
Smart Phone: iPhone, iPad, Android, Android pad
Hard Disk Drive Interface: Type1 SATA Interface
Capacity: 1 SATA Hard Disk (2.5”/3.5” SATA, Up to 8TB)
UTC Control: Yes
USB Interface: 2 USB 2.0 Interfaces
Power consumption: DC 12V @ 6W (Without Hard Disk)
Working Environment: -10~55o/10~90%
Dimension (W × D × H) 260 x 215 x 43(mm)
Weight: 2kg (Without HDD)
