Delfield Meridian MHPT1-S User manual

MERIDIAN SERIES® HEATED PASS-THROUGHS
Project __________________________
Item____________________________
Quantity _________________________
CSI Section 11400
MERIDIAN SERIES®
Heated Pass-Throughs
980 S. Isabella Road
Mt. Pleasant, MI 48858
www.deleld.com
Phone: [phone]
Fax: [phone]
Email: info@deleld.com
Approval _________________
Date____________________
MHPT2-GHSH
SPECIFICATIONS
Exterior: Cabinet front and shroud shall be 22-gauge
stainless steel. Exterior sides shall be aluminum. Facing
of shroud shall be easily removable without the use of
tools.
Cabinet interior shall be anodized aluminum. Bottom
& top of liner shall be die-stamped to provide
radius corners and a recessed bottom. Base shall be
fully insulated with high-density foamed in place
polyurethane.
Interior shall have three epoxy-coated wire shelves per
door section. Shelf support pilasters shall be heavy-duty
with shelves adjustable at 1.0” (2.5 cm) increments.
Units are mounted on 6” (15.24 cm) legs.
Doors: Solid doors shall have a 22-gauge stainless steel
exterior & anodized aluminum interior liner. Doors shall
be fully insulated with high density foamed in place
polyurethane. Each door shall have two self-closing,
cam-lift style hinges. Doors shall be easily removable
without use of tools. Door gaskets shall be magnetic snap-in
style to allow simple replacement. Door handles shall be
recessed.
Glass doors are constructed with a combination of extruded
aluminum & PVC, and are provided with magnetic gaskets.
Doors will have self-closing hinges and continuous handle
along vertical dimension of door(s).
• Please specify right or left hand hinging at time of order.
Mechanical controls shall be located behind a removable
shroud facing.
Dual Voltage Models Only: Electrical connections shall
be 115/208-240 volt, 60 hertz, single phase, and must be
hard-wired to the junction box located on top of the unit.
Heating Assembly: Cabinets to be designed to
maintain temperature up to 200ºF. Helical shaped,
tubular n heating element. High speed blower to
provide uniform airow in cabinet. Removable/
replaceable heating system. No exposed elements inside
cabinet. Fan and heating elements service accessible
without tools. Temperature to be controlled by an
adjustable electronic thermostat equipped with an analog
display. On/off switch in front.
MODELS:
 MHPT1-S Single section  MHPT2-S Two section
Solid full height door Solid full height doors
 MHPT1-GS Single section  MHPT2-GS Two section
Half glass/half solid door Half glass/half solid doors
 MHPT1-G Single section  MHPT2-G Two section
Full height glass door Full height glass doors
STANDARD FEATURES
• Shroud removes without tools, for easy condenser
maintenance
• Built in door locks
• Durable stainless steel doors and shroud, for lasting good
looks
• New high-density foam insulation cuts energy costs
• Big, easy grip handles are easy to nd, don’t intrude into
kitchen trafc
• Attractive aluminum side panels are easy to clean and
corrosion resistant
• Heavy-duty hinges with stay open feature
• Refrigeration system is located outside the food zone, more
space for product storage
• Mini watt door heaters eliminate condensation with
minimal energy cost
• Easy to read dial thermometer
• Tri seal door gaskets lower energy costs with a unique
insulating design
• Chrome shelves
• Aluminum interior stands up to food acids without
corroding
• Lots of interior storage space for the money
• Rugged metal legs, adjustable to compensate for
uneven oors
OPTIONS AND ACCESSORIES
 Stainless steel exterior sides
 Stainless steel interior
 Stainless steel kick plate
 Door and end laminate
 Stainless steel exterior back
 Digital thermometer
 TXV
 Chrome Shelves
 Tray Slides
 220/50/1 electrical
 Electronic control
 Stainless steel legs
 Casters

Meridian Series® Heated Pass-Throughs
Model #__________
CSI Section 11400
Printed in the USA.
08/03
DSMPTH
980 S. Isabella Road
Mt. Pleasant, MI 48858
www.deleld.com
Phone: [phone]
Fax: [phone]
Email: info@deleld.com
MECHANICAL DATA
SHELVES NO UNIT BTU/HR CAB BTU/HR SHIP NEMA
MODEL VOLTAGE AMPS STORAGE SQ. FT. SHELVES H.P. LOAD SYSTEM CAP WEIGHT PLUG
STAINLESS
MHPT1-S 120/208-240 9.0 26.64 12.81 3 NA NA NA 370 NA
MHPT2-S 120/208-240 16.0 55.42 27.54 6 NA NA NA 592 NA
GLASS/STAINLESS
MHPT1-GS 120/208-240 9.0 26.64 12.81 3 NA NA NA 380 NA
MHPT2-GS 120/208-240 16.0 55.42 27.54 6 NA NA NA 612 NA
GLASS
MHPT1-G 120/208-240 9.0 26.64 12.81 3 NA NA NA 390 NA
MHPT2-G 120/208-240 16.0 55.42 27.54 6 NA NA NA 622 NA
PLAN VIEW MHPT1-G PLAN VIEW MHPT2-G
ELEVATION VIEW MHPT2-GELEVATION VIEW MHPT1-G
DOOR CLEARANCE DETAIL
ALL MODELS
29”
73.7cm
56”
142.3cm
81”
205.7 cm
27.25”
69.21
cm
END SECTION VIEW
ALL MODELS
PERSPECTIVE VIEW
ALL MODELS
36.25”
92.1cm
36.25”
92.1cm
81”
205.7cm
6.00”
15.2cm
58”
147.3cm
25”
63.5cm 52”
132.1cm
12.14”
30.8cm
56.76”
144.2cm
36.25”
92.1cm
26.48”
67.3cm
3.80”
9.7cm
J-BOX LOCATED
75" AFF FOR ST'D BOXES
83" AFF FOR RI/RT'S
8" (1) door units
11" (2&3) door units
6" (1) door units
23" (2) door units
39" (3) door units
Front of unit
MECHANICAL DETAIL
