Delfield F18RR44 User manual

Short Form Specifications
Exterior top is one-piece, 16-gauge stainless steel, with integral 2.12”
(5.4cm) high square nosing on front. Top has a mechanically cooled refrigerat-
ed raised rail at rear with openings to accommodate 1/6 size pans. Pans and
adapter bars are provided by others. Pans are recessed 3” (7.6cm) or 2”
(5.1cm) and set on adjustable stainless steel pan supports. Rail interior is 22-
gauge stainless steel. Raised rail openings have 20-gauge stainless steel remov-
able lids. Unit is equipped with separate expansion valve and on/off switch for
refrigerated rail. Temperature in top opening to maintain 33°F (1°C) to 41°F
(5°C), with pans recessed 3” (7.6cm), at 86°F ambient room temperature,
meeting NSF7 requirements.
Exterior Back and Bottom are 24-gauge galvanized steel. Exterior ends are
finished with 18-gauge galvanized steel.
Base Interior is 22-gauge stainless steel back and bottom. Base interior ends
and door frames are thermoformed ABS plastic. Base is insulated with 1.5”
(3.8cm) high density foamed in place polyurethane.
Door(s) have a 22-gauge stainless steel exterior front, with thermoformed
ABS plastic interior liner, black recessed handle and snap in magnetic gasket
which is easily replaceable. Each interior door section has (1) removable
epoxy coated wire shelf.
Base has a blower coil assembly with expansion valve located behind door
mullion. Base is equipped with independently controlled thermostat and sole-
noid valve. On/off switch for unit is located behind the hinged panel.
Unit is mounted on 6.13” (15.6cm) high adjustable stainless steel legs.
Electrical connections are 115 volt, 60 Hertz, single phase. Unit must be
hard wired.
Refrigeration System Components — HFC-404A
Optional Accessories & Modifications
906A Stainless steel end
505H Stainless steel back
505F Laminate facing (full front)
906E Laminate end
905A Laminate back
1030A Cutting board (Sanalite or composite)
109 Condensate evaporator (1 per coil) for base
107F Tray rack
102 Drawers
A-(2) 19” in lieu of one door
B-(2) 27” in lieu of one door
C-(2) 32” in lieu of one door
108 Locks
120F Cold pan drain
213 *220V/50 cycle
*Inclusion of this option will alter the
electrical specifications of the unit
Model F18RR79
31.5”(80cm)DeepRemoteReducedHeightRail
The Delfield Company, P.O. Box 470, Mt Pleasant, MI 48804-0470, U.S.A. • [phone] • Fax [phone] • www.delfield.com
Delfield reserves the right to make changes in design or specifications without prior notice. ©2001 The Delfield Company. All rights reserved. Printed in U.S.A.
PROJECT
ITEM #
QUANTITY DATE
APPROVAL
F18RR
®

6" [15.2cm]
6" [15.2cm]
6" [15.2cm] 6" [15.2cm]
6" [15.2cm]
6" [15.2cm]
19" (48.3cm)
REF'G 19" (48.3cm) REF'G 19" (48.3cm) REF'G 27" (68.6cm)
REF'G
32" (81.3cm)
REF'G 32" (81.3cm) REF'G
27" (68.6cm)
REF'G
27" (68.6cm)
REF'G
27" (68.6cm)
REF'G
27" (68.6cm)
REF'G
27" (68.6cm)
REF'G
27" (68.6cm)
REF'G
27" (68.6cm)
REF'G
19" (48.3cm)
REF'G
ELEVATION VIEW
F18RR44 ELEVATION VIEW F18RR52
ELEVATION VIEW
F18RR60 ELEVATION VIEW F18RR70
ELEVATION VIEW
F18RR79 ELEVATION VIEW F18RR87
F18RR
The Delfield Company, P.O. Box 470, Mt Pleasant, MI 48804-0470, U.S.A. • [phone] • Fax [phone] • www.delfield.com
Delfield reserves the right to make changes in design or specifications without prior notice. ©2001 The Delfield Company. All rights reserved. Printed in U.S.A.
31.5”(80cm)DeepRemoteReducedHeightRail

44" [111.8cm]
31.5"
[80cm] 31.5" [80cm]
52" [132.1cm]
60" [152.4cm] 70" [177.8cm]
79" [200.7cm] 87" [221cm]
44" LG. MECH. COOLED NSF-7
STYLE RAISED RAIL WITH (1) 13.62"
X 34.87" TOP OPENING TO ACCOMMODATE
(10) 1/6 SIZE PANS 6" DP. PROVIDED WITH
HINGED REMOVABLE COVER AND
ADJUSTABLE PAN CLIPS. (PANS AND
ADAPTER BARS BY OTHERS)
52" LG. MECH. COOLED NSF-7
STYLE RAISED RAIL WITH (1) 13.62"
X 41.87" TOP OPENING TO ACCOMMODATE
(12) 1/6 SIZE PANS 6" DP. PROVIDED WITH
HINGED REMOVABLE COVER AND
ADJUSTABLE PAN CLIPS. (PANS AND
ADAPTER BARS BY OTHERS)
31.5"
[80cm]
60" LG. MECH. COOLED NSF-7
STYLE RAISED RAIL WITH (1) 13.62"
X 20.87" TOP OPENING TO ACCOMMODATE
(6) 1/6 SIZE PANS 6" DP. AND (1) 13.62"
X 27.87" TOP OPENING TO ACCOMMODATE
(8) 1/6 SIZE PANS 6" DP. PROVIDED WITH
HINGED REMOVABLE COVER AND
ADJUSTABLE PAN CLIPS. (PANS AND
ADAPTER BARS BY OTHERS)
31.5"
[80cm]
70" LG. MECH. COOLED NSF-7
STYLE RAISED RAIL WITH (2) 13.62"
X 27.87" TOP OPENINGS TO ACCOMMODATE
(8) 1/6 SIZE PANS 6" DP. PROVIDED WITH
HINGED REMOVABLE COVER AND
ADJUSTABLE PAN CLIPS. (PANS AND
ADAPTER BARS BY OTHERS)
31.5"
[80cm]
79" LG. MECH. COOLED NSF-7
STYLE RAISED RAIL WITH (2) 13.62"
X 34.87" TOP OPENING TO ACCOMMODATE
(10) 1/6 SIZE PANS 6" DP. PROVIDED WITH
HINGED REMOVABLE COVER AND
ADJUSTABLE PAN CLIPS. (PANS AND
ADAPTER BARS BY OTHERS)
31.5"
[80cm]
87" LG. MECH. COOLED NSF-7
STYLE RAISED RAIL WITH (1) 13.62"
X 41.87" TOP OPENING TO ACCOMMODATE
(12) 1/6 SIZE PANS 6" DP. AND (1) 13.62"
X 34.87" TOP OPENING TO ACCOMMODATE
(10) 1/6 SIZE PANS 6" DP. PROVIDED WITH
HINGED REMOVABLE COVER AND
ADJUSTABLE PAN CLIPS. (PANS AND
ADAPTER BARS BY OTHERS)
PLAN VIEW
F18RR44 PLAN VIEW F18RR52
PLAN VIEW
F18RR60 PLAN VIEW F18RR70
PLAN VIEW
F18RR79 PLAN VIEW
F18RR87
F18RR
The Delfield Company, P.O. Box 470, Mt Pleasant, MI 48804-0470, U.S.A. • [phone] • Fax [phone] • www.delfield.com
Delfield reserves the right to make changes in design or specifications without prior notice. ©2001 The Delfield Company. All rights reserved. Printed in U.S.A.
31.5”(80cm)DeepRemoteReducedHeightRail

MODEL NUMBER OF NUMBER 0F STORAGE SHELF AREA SHIP WEIGHT BTU DESIGN LOAD EVAP. CAP.
NUMBER DOORS PANS CU. FT. SQ. FT. H.P.* AMPS LBS/KG BASE/RAIL BTU /°TD
F18RR44
(2) 19” 10 9.49 5.12 1/4 3.0 485/220 547/441 120/19
F18RR52
19” & 27 12 11.81 6.51 1/3 3.0 540/245 625/529 120/23
F18RR60 (2) 27” 14 14.14 7.90 1/3 5.0 620/281 703/617 120/26
F18RR70
(2) 32” 16 17.05 9.64 1/2 5.0 700/317 800/794 120/32
F18RR79
(2) 27” & 19” 20 18.68 10.29 1/2 5.0 735 /333 962/882 240/36
F18RR87 (3) 27” 22 21.30 11.85 3/4 5.0 765/347 1032/970 240/39
*Recommended horsepower
Mechanical Data–Standard Unit
44" (111.8cm)
52" (132.1cm)
60" (152.4cm)
70" (177.8cm)
79" (201cm)
87" (221cm)
31.5"
(80 cm) 31.5" (80 cm)
J = JUNCTION BOX
R = REFRIGERATION LINES 1/4" LIQUID, 38" SUCTION
D = DRAIN 1/2"
MECHANICAL DETAIL
J
J
R D R D
6" (15.2cm) 6" (15.2cm)
NOTE; UNOBSTRUCTED AIRFLOW MUST BE MAINTAINED TO
INSURE UNIT PERFORMANCE AND MAINTAIN WARRANTY.
17"
[43.1cm]
CLEARANCE
25"
[63.5cm]
CLEARANCE
30"
[76.2cm]
CLEARANCE
19" [48.3cm]
DOOR 27" [68.6cm] DOOR 32" [81.3cm] DOOR END VIEW ALL MODELS
6.13"
[15.6cm]
7.62"
[19.4cm]
36"
[91.4cm]
26.31"
[66.8cm] 24"
[61cm]
42"
[106.7cm]
6"
[15.2cm] 14.29"
[36.3cm]
PAN COVER, WHEN OPEN, EXTENDS
TO A HEIGHT OF 12" [30.5cm]
F18RR
The Delfield Company, P.O. Box 470, Mt Pleasant, MI 48804-0470, U.S.A. • [phone] • Fax [phone] • www.delfield.com
Delfield reserves the right to make changes in design or specifications without prior notice. ©2001 The Delfield Company. All rights reserved. Printed in U.S.A.
DS18RR 03/01
31.5”(80cm)DeepRemoteReducedHeightRail
