F5 30” DEEP PASS THROUGH SELF-CONTAINED DROP IN REFRIGERATED DISPLAY
CASES
Project
__________________________
Item
____________________________
Quantity
_________________________
CSI Section 11400
F5 Serview Drop In
30” Deep Pass Through Self-Contained Refrigerated Display Cases
F5 Serview Drop In
30” Deep Pass Through Self-Contained Refrigerated Display Cases
F5 Serview Drop In
980 S. Isabella Road
Mt. Pleasant, MI 48858
www.delfi eld.com
Phone: [phone]
Fax: [phone]
Email: info@delfi eld.com
Approval
_________________
Date
____________________
F5MC48N
SPECIFICATIONS
Display section exterior sides are made of 18-
gauge stainless steel. Exterior display section top
to be 22-gauge galvanized metal. Interior sides
are made of .095” thick ABS plastic with molded
shelf supports. The interior bottom is constructed
with stainless steel for long lasting durability.
Display section is fully insulated with high density
polyurethane foam between the interior and exte-
rior. Four adjustable epoxy coated wire shelves
are provided for the display section. An on/off
switch for the display section light(s) is located at
the right end of the front facing, above the display
section doors.
Display case refrigeration system consists of a
full-length top mounted coil with multiple fans
circulating the air throughout the cabinet utilizing
a thermostatic control. An ABS plastic drip pan is
placed below the coil with a clear drain hose for running
the condensation to the lower base mechanical section.
Front of the display section is equipped with two sliding
and removable self-closing .50” thick argon fi lled,
low-e glass doors with a warm edge spacer. The vertical
outsides of each door tuck into an extruded channel
running vertically up each side. Front and rear nosing
to be 20-gauge stainless steel.
Self-contained models have a pre-wired condensing
unit housed in a 16-gauge cage hanging form the units
exterior bottom. Cage also is supplied with an 8’ cord
and plug and electrical junction box. Electrical connec-
tions are 115V-60H-1PH.
Refrigeration system components are HFC-404A. Dis-
play cabinet blower coil assembly shall have a coated
evaporator coil and fans. Interior refrigerated base
cabinet and display section to maintain 36 to 40
degree temperatures at 100-degree ambient room
temperature.
Back has (2) sliding and removable self-closing .50”
thick argon fi lled, low-e glass doors with a warm
edge spacer.
MODELS:
❑
F5PC48D
30” Deep Self-Contained Drop In
Display Section
❑
F5PC72D
30” Deep Self-Contained Drop In
Display Section
STANDARD FEATURES
• Display exterior sides are made of 18-gauge stainless
steel
• ABS plastic interior sides with molded shelf supports
• (4) adjustable epoxy coated wire shelves
• On/off switch for the display section light(s)
• Top mount coil with multiple fans circulating the air
throughout the cabinet
• Display section runs off a thermostatic control
• Sliding and removable self-closing .50” thick argon
filled, low-E, warm edge insert, thermopane glass doors
with left and right vertical gasket
• High density polyurethane foam throughout unit
• Single service display section with mirrored back
• Environmentally friendly HFC-404A refrigerant
• Door locks standard
OPTIONS AND ACCESSORIES
❑
48” shelf (48” long units only)
❑
72” shelf (72” long units only)
❑
Mirrored interior on pass-through doors (48”)
❑
Mirrored interior on pass-through doors (72”)
❑
220 volt/50 cycle - inclusion of this option will
alter specifi cations

F5 30” Deep Pass Through Self-Contained Refrigerated Display Cases
Model #__________
CSI Section 11400
Printed in the USA.
01/04
DSF5PCD
980 S. Isabella Road
Mt. Pleasant, MI 48858
www.delfi eld.com
Phone: [phone]
Fax: [phone]
Email: info@delfi eld.com
PLAN VIEW F5PC48DPLAN VIEW F5PC72D
ELEVATION VIEW F5PC48D
48”
121.9cm
31.9”
81.0cm
22.8”
57.9cm
72”
182.9cm
34.0”
86.4cm
CUTOUT DIMENSIONS:
• 48" LONG MODELS
23.62" x 18.62" (60.0cm x 47.3cm)
• 72" LONG MODELS
32.62" x 18.62" (82.9cm x 47.3cm)
J
MECHANICAL ACCESS
PLAN VIEW ALL MODELS
INSTALLATION NOTE:
Refrigeration system is designed so air will fl ow
front to rear on 48” models and right to left on 72”
models, using the supplied louvered panels. Louver
cut-out dimensions are 23.5” by 12” (59.7cm x
30.5cm). Unobstructed airfl ow must be maintained
to insure unit performance and maintain warranty.
34.0”
86.4cm
34.0”
6.5”
16.5cm
56.90”
144.5cm
42.0”
106.7cm
18”
45.7cm
30”
76.2cm
34.0”
86.4cm
16.5cm
56.90”
144.5cm
42.0”
106.7cm
18”
45.7cm
30”
76.2cm
14.9”
37.8cm
14.9”
37.8cm
RIGHT END VIEW
48” MODELS
ELEVATION VIEW F5PC72D
MODEL SHELF AREA STORAGE SYS. CAP CABINET LOAD VOLTS/HERTZ NEMA SHIPPING
NUMBER SQ. FT. CU. FT. H.P. BTU/HOUR BTU/HOUR PHASE AMPS PLUG WEIGHT
F5PC48D
28.2 19.0 1/2 3160 1945 115/60/1 12.0 5-15P 609/276
F5PC72D
44.0 29.4 3/4 5758 2884 115/60/1 16.0 5-20P 815/370
Mechanical Data–Standard Unit
MODEL SHELF AREA STORAGE SYS. CAP CABINET LOAD VOLTS/HERTZ NEMA SHIPPING
NUMBER SQ. FT. CU. FT. H.P. BTU/HOUR BTU/HOUR PHASE AMPS PLUG WEIGHT
28.2 19.0 1/2 3160 1945 115/60/1 12.0 5-15P 609/276
44.0 29.4 3/4 5758 2884 115/60/1 16.0 5-20P 815/370
MODEL SHELF AREA STORAGE SYS. CAP CABINET LOAD VOLTS/HERTZ NEMA SHIPPING
NUMBER SQ. FT. CU. FT. H.P. BTU/HOUR BTU/HOUR PHASE AMPS PLUG WEIGHT
28.2 19.0 1/2 3160 1945 115/60/1 12.0 5-15P 609/276
44.0 29.4 3/4 5758 2884 115/60/1 16.0 5-20P 815/370
MODEL SHELF AREA STORAGE SYS. CAP CABINET LOAD VOLTS/HERTZ NEMA SHIPPING
NUMBER SQ. FT. CU. FT. H.P. BTU/HOUR BTU/HOUR PHASE AMPS PLUG WEIGHT
28.2 19.0 1/2 3160 1945 115/60/1 12.0 5-15P 609/276
44.0 29.4 3/4 5758 2884 115/60/1 16.0 5-20P 815/370
MODEL SHELF AREA STORAGE SYS. CAP CABINET LOAD VOLTS/HERTZ NEMA SHIPPING
NUMBER SQ. FT. CU. FT. H.P. BTU/HOUR BTU/HOUR PHASE AMPS PLUG WEIGHT
28.2 19.0 1/2 3160 1945 115/60/1 12.0 5-15P 609/276
44.0 29.4 3/4 5758 2884 115/60/1 16.0 5-20P 815/370
MODEL SHELF AREA STORAGE SYS. CAP CABINET LOAD VOLTS/HERTZ NEMA SHIPPING
NUMBER SQ. FT. CU. FT. H.P. BTU/HOUR BTU/HOUR PHASE AMPS PLUG WEIGHT
28.2 19.0 1/2 3160 1945 115/60/1 12.0 5-15P 609/276
44.0 29.4 3/4 5758 2884 115/60/1 16.0 5-20P 815/370
MODEL SHELF AREA STORAGE SYS. CAP CABINET LOAD VOLTS/HERTZ NEMA SHIPPING
NUMBER SQ. FT. CU. FT. H.P. BTU/HOUR BTU/HOUR PHASE AMPS PLUG WEIGHT
28.2 19.0 1/2 3160 1945 115/60/1 12.0 5-15P 609/276
44.0 29.4 3/4 5758 2884 115/60/1 16.0 5-20P 815/370
MODEL SHELF AREA STORAGE SYS. CAP CABINET LOAD VOLTS/HERTZ NEMA SHIPPING
NUMBER SQ. FT. CU. FT. H.P. BTU/HOUR BTU/HOUR PHASE AMPS PLUG WEIGHT
28.2 19.0 1/2 3160 1945 115/60/1 12.0 5-15P 609/276
44.0 29.4 3/4 5758 2884 115/60/1 16.0 5-20P 815/370
MODEL SHELF AREA STORAGE SYS. CAP CABINET LOAD VOLTS/HERTZ NEMA SHIPPING
NUMBER SQ. FT. CU. FT. H.P. BTU/HOUR BTU/HOUR PHASE AMPS PLUG WEIGHT
28.2 19.0 1/2 3160 1945 115/60/1 12.0 5-15P 609/276
44.0 29.4 3/4 5758 2884 115/60/1 16.0 5-20P 815/370
MODEL SHELF AREA STORAGE SYS. CAP CABINET LOAD VOLTS/HERTZ NEMA SHIPPING
NUMBER SQ. FT. CU. FT. H.P. BTU/HOUR BTU/HOUR PHASE AMPS PLUG WEIGHT
28.2 19.0 1/2 3160 1945 115/60/1 12.0 5-15P 609/276
44.0 29.4 3/4 5758 2884 115/60/1 16.0 5-20P 815/370
RIGHT END VIEW
72” MODELS
