Dell EMC Z9264F-ON User manual

Z9264F-ON
Setup Guide

Notes, cautions, and warnings
NOTE: A NOTE indicates important information that helps you make better use of
your product.
CAUTION: A CAUTION indicates either potential damage to hardware or loss of
data and tells you how to avoid the problem.
WARNING: A WARNING indicates a potential for property damage, personal injury,
or death.
Copyright © 2018 Dell Inc. or its subsidiaries. All rights reserved. Dell, EMC, and other trademarks
are trademarks of Dell Inc. or its subsidiaries. Other trademarks may be trademarks of their respective
owners.
2018- 06
Rev. A01

Contents
1 About this guide.............................................................................. 4
Regulatory................................................................................................. 4
Related documents.................................................................................. 5
Information Symbols................................................................................ 5
2 Site preparations............................................................................ 6
Site selection.............................................................................................6
Cabinet placement................................................................................... 7
Rack mounting.......................................................................................... 7
Switch ground...........................................................................................8
Fans and airow........................................................................................8
Power.........................................................................................................8
Storing components.................................................................................9
3 Z9264F-ON switch installation......................................................10
Unpack..................................................................................................... 10
Four-post rack assembly.........................................................................11
Four-post rack mount............................................................................. 11
Ground cable........................................................................................... 14
Optics installation....................................................................................15
Optics removal.................................................................................. 15
Switch power-up.....................................................................................15
Power up sequence.......................................................................... 16
After switch installation..........................................................................16
4 Specications................................................................................17
Chassis physical design.......................................................................... 17
5 Support........................................................................................ 20
Contents 3

About this guide
This guide provides site preparation recommendations, step-by-step procedures for rack
mounting and desk mounting, inserting modules, and connecting to a power source.
CAUTION: To avoid electrostatic discharge (ESD) damage, wear grounding wrist
straps when handling this equipment.
WARNING: Only trained and qualied personnel can install this equipment. Read
this guide before you install and power up this equipment. This equipment contains
two power cords. Disconnect both power cords before servicing.
WARNING: This equipment contains optical transceivers, which comply with the
limits of Class 1 laser radiation.
Figure 1. Class 1 laser product tag
WARNING: When no cable is connected, visible and invisible laser radiation may be
emitted from the aperture of the optical transceiver ports. Avoid exposure to laser
radiation and do not stare into open apertures.
Regulatory
Marketing model Z9264F-ON is represented by the regulatory model E23W and the
regulatory type E23W002.
1
4 About this guide

Topics:
• Related documents
• Information Symbols
Related documents
For more information about the Z9264F-ON switch, see the following documents.
•OS10 Enterprise Edition Release Notes
•OS10 Enterprise Edition User Guide
•Z9264F-ON Installation Guide
•Z9264F-ON Release Notes
•Open Networking Hardware Diagnostic Guide
NOTE: For the most recent documentation, visit the support site: www.dell.com/
support.
Information Symbols
This book uses the following information symbols:
NOTE: The Note icon signals important operational information.
CAUTION: The Caution icon signals information about situations that could result in
equipment damage or loss of data.
WARNING: The Warning icon signals information about hardware handling that
could result in injury.
WARNING: The ESD Warning icon requires that you take electrostatic precautions
when handling the device.
About this guide 5

Site preparations
The Z9264F-ON switch is suitable for installation as part of a common bond network
(CBN).
You can install the switch in:
• Network telecommunication facilities
• Data centers
• Other locations where the National Electric Code (NEC) applies
For more information about the Z9264F-ON switch specications, see Specications.
NOTE: Install the switch into a rack or cabinet before installing any optional
components.
Topics:
• Site selection
• Cabinet placement
• Rack mounting
• Switch ground
• Fans and airow
• Power
• Storing components
Site selection
Install your equipment in restricted access areas. A restricted access area is one where
service personnel can only gain access using a special tool, lock, key, or other means of
security. The authority responsible for the location controls access to the restricted area.
2
6 Site preparations

Ensure that the area where you install your switch meets the following safety requirements:
• Near an adequate power source. Connect the switch to the appropriate branch circuit
protection according to your local electrical codes.
• Environmental—switch location—continuous temperature range is from 0°C to 45°C
(32°F to 113°F).
• Operating humidity is from 5 to 90 percent non-condensing, continuous.
• In a dry, clean, well-ventilated, and temperature-controlled room, away from heat
sources such as hot cooling vents or direct sunlight.
• Away from sources of severe electromagnetic noise.
• Positioned in a rack or cabinet, or on a desktop with adequate space in the front, back,
and sides for proper ventilation and access.
• Install the switch in Information Technology Rooms in accordance with Article 645 of
the National Electrical Code and NFPA 75.
For more information about switch storage and environmental temperatures, see
Specications.
Cabinet placement
Install the Z9264F-ON switch only in indoor cabinets designed for use in a controlled
environment.
Do not install the switch in outside cabinets. For cabinet placement requirements, see Site
selection.
The cabinet must meet minimum size requirements. Airow must be in accordance with the
Electronic Industries Alliance (EIA) standard. Ensure that there is a minimum of 5 inches
(12.7 cm) between the intake and exhaust vents and the cabinet wall.
Rack mounting
When you prepare your equipment rack, ensure that the rack is grounded. Ground the
equipment rack to the same ground point the power service in your area uses. The ground
path must be permanent.
Site preparations 7

Switch ground
Dell EMC recommends grounding your switch. Use the Z9264F-ON switch in a CBN.
For more information, see Ground cable.
Fans and airow
Fan installation is done as part of the factory install based on stock keeping unit (SKU) type.
The Z9264F-ON switch has SKUs that support the following congurations:
• AC PSU with fan airow from the I/O to the PSU—normal
• AC PSU with fan airow from the PSU to the I/O—reverse
• DC fan unit with airow from the I/O to the PSU—normal
• DC fan unit with fan airow from the PSU to the I/O—reverse
Be sure to order the fans suitable to support your site’s ventilation. Use a single type of
airow fan in your switch. Do not mix reverse and normal airows in a single switch.
For proper ventilation, position the switch in an equipment rack or cabinet with a minimum
of 5 inches (12.7 cm) of clearance around the exhaust vents. The fan speed varies based on
internal temperature monitoring. The switch never intentionally turns o the fans.
Power
Connect the switch to the applicable power source using the appropriate power cable. An
AC power cable is included with the switch.
When installing AC or DC switches, follow the requirements of the National Electrical Code
ANSI/NFPA 70, where applicable.
The switch is powered-up when the power cable is connected between the switch and the
power source.
CAUTION: Always disconnect the power cable before you service the power supply
slots. The switch has multiple power cords. Before servicing, ensure all power cords
are disconnected.
8 Site preparations

CAUTION: On the AC switch, use the power supply cable as the main disconnect
device. Ensure that the socket-outlet is located/installed near the equipment and is
easily accessible.
NOTE: Module power is software controlled. You do not see module LEDs when the
switch powers up in ONIE.
Storing components
If you do not install your Z9264F-ON switch and components immediately, properly store
the switch and all optional components following these guidelines:
• Storage location temperature must remain constant. The storage range is from -40° to
70°C (-40° to 158°F).
• Store on a dry surface or oor, away from direct sunlight, heat, and air conditioning
ducts.
• Store in a dust-free environment.
NOTE: ESD damage can occur when components are mishandled. Always wear an
ESD-preventive wrist or heel ground strap when handling the switch and its
accessories. After you remove the original packaging, place the Z9264F-ON switch
and its components on an anti-static surface.
Site preparations 9

Z9264F-ON switch installation
To install the Z9264F-ON switch, complete the installation procedures in the order
presented in this section.
Always handle the switch and its components with care. Avoid dropping the switch or any
eld replaceable units (FRUs).
NOTE: ESD damage can occur if components are mishandled. Always wear an ESD-
preventive wrist or heel ground strap when handling the switch and its components.
As with all electrical devices of this type, take all the necessary safety precautions
to prevent injury when installing this switch.
Topics:
• Unpack
• Four-post rack assembly
• Four-post rack mount
• Ground cable
• Optics installation
• Switch power-up
• After switch installation
Unpack
NOTE: Before unpacking the switch, inspect the container and immediately report
any evidence of damage.
When unpacking the Z9264F-ON switch, make sure that the following items are included:
• One Z9264F-ON switch
• One RJ-45 to DB-9 female cable
3
10 Z9264F-ON switch installation

• Two sets of rail kits, no tools required
• Two PSUs
• Four fan units
• Two country- and region-specic AC power cords
•Z9264F-ON Set-up Guide
•Safety and Regulatory Information
•Warranty and Support Information
1 Place the container on a clean, at surface and cut all straps securing the container.
2 Open the container or remove the container top.
3 Carefully remove the switch from the container and place it on a secure and clean
surface.
4 Remove all packing material.
5 Inspect the product and accessories for damage.
Four-post rack assembly
Due to the chassis weight, the Z9264F-ON switch does not support a two-post rack
installation; you must install the switch in a four-post rack.
To install in a four-post rack, follow the instructions in your rack frame kit. In a four-post
rack, the maximum distance between the front and back vertical posts is 36 inches (91.44
cm); the minimum distance is 24 inches (60.96 cm).
Four-post rack mount
Rack mounting safety considerations
WARNING: To prevent bodily injury when mounting or servicing this unit in a rack,
take special precautions to ensure that the system remains stable. The following
guidelines are provided to ensure your safety:
• If your chassis is the only unit in the rack, mount it at the bottom of the rack.
• When mounting this unit in a partially lled rack, load the rack from the bottom to
the top with the heaviest component at the bottom of the rack.
• If the rack comes with stabilizing devices, install the stabilizers before mounting or
servicing the unit in the rack.
• If the chassis ships with blanks, remove the blanks from each slot before lifting the
chassis.
Z9264F-ON switch installation 11

WARNING: These instructions are a condensed reference. Read the safety
instructions in your Safety, Environmental, and Regulatory information booklet
before you begin.
NOTE: The illustrations in this document are not intended to represent a specic
switch.
Rack mount safety considerations
• Rack loading—Overloading or uneven loading of racks may result in shelf or rack failure,
possibly damaging the equipment and causing personal injury. Stabilize racks in a
permanent location before loading begins. Mount the components starting at the
bottom of the rack, then work to the top. Do not exceed your rack’s load rating.
• Power considerations—Connect only to the power source specied on the unit. When
you install multiple electrical components in a rack, ensure that the total component
power ratings do not exceed the circuit capabilities. Overloaded power sources and
extension cords present re and shock hazards.
• Elevated ambient temperature—If you install the switch in a closed rack assembly, the
operating temperature of the rack environment may be greater than the room ambient
temperature. Use care not to exceed the 45°C (113°F) maximum ambient temperature
of the switch.
• Reduced air ow—Do not compromise the amount of airow required for safe operation
of the equipment. Install the equipment in the rack so that the equipment constantly
has the correct amount of airow surrounding it.
• Reliable earthing—Maintain reliable earthing of rack-mounted equipment. Pay particular
attention to the supply connections other than the direct connections to the branch
circuit, for example: use of power strips.
• Do not mount the equipment with the fan panel facing in the downward position.
Switch installation and removal
1 Align the system with the rails and slide the system into the rack.
2 Tighten the screws on each side of the systems’s front panel, items 1 and 2.
3 To remove the system from the rack, loosen the screws and slide the system out of
the rack.
12 Z9264F-ON switch installation

Figure 2. Z9264F-ON installation
1Extra screws to restrict front-back
movement of the switch.
2 Main screw.
Z9264F-ON switch installation 13

Ground cable
Depending on the type of switch, to attach a ground cable to the switch, you need one of
the included M3 or M4 screws.
NOTE: For AC-powered switches, although the third conductor of the AC power
cord provides a ground path, Dell EMC recommends grounding your switch with a
dedicated ground wire.
NOTE: For DC-powered switches, the only way to safely ground your switch is to
attach a dedicated ground wire.
The switch ships with one of the following two congurations:
• One threaded hole using an included M3 screw.
• Two threaded holes using one of the two included M4 screws.
In both congurations, the ground cable is not included. To properly ground the switch, Dell
EMC recommends a one- or two-hole lug, M3 or M4 hole size. The grounding lugs must be
a UL-recognized, crimp-type lug.
CAUTION: Grounding conductors must be made of copper. Do not use aluminum
conductors.
NOTE: Coat the one-hole lug with an anti-oxidant compound before crimping. Also,
bring any unplated mating surfaces to a shiny nish and coat with an anti-oxidant
before mating. Plated mating surfaces must be clean and free from contamination.
NOTE: The rack installation ears are not suitable for grounding.
To connect the ground cable to the switch, follow these steps:
1 Cut your ground cable (not included) to the desired length. The cable length must
facilitate proper operation of the fault interrupt circuits. Use the shortest cable route
allowable.
2 To attach the ground cable, use one of the following:
• Using one threaded M3 hole, attached the ground cable to the lug using an M3
screw with a captive internal tooth lock washer, as shown. Torque the screw to
±4-5 in-lbs.
• Using one of the two M4 threaded holes, attach the ground cable to the lug. Use
an M4 screw with a captive internal tooth lock washer, as shown. Torque the screw
to ±5-6 in-lbs.
3 Attach the other end of the ground cable to a suitable ground point such as the rack or
cabinet.
14 Z9264F-ON switch installation

The rack installation ears are not a suitable grounding point.
Optics installation
WARNING: When working with optical bers, follow all warning labels and always
wear eye protection. Never look directly into the end of a terminated or
unterminated ber or connector as it may cause eye damage.
1 Position the optic so it is in the correct position.
The optic has a key that prevents it from being inserted incorrectly.
2 Insert the optic into the port until it gently snaps into place.
NOTE: When you cable the ports, be sure not to interfere with the airow from the
small vent holes above and below the ports.
Optics removal
Remove an optic by pushing the tab on the optic and sliding the optic from the port.
When removing optics with direct attach cables (DACs) from the port, pull the release tab
rmly and steadily. Before pulling the release tab, you may need to gently push the optic into
the port to ensure that it is seated properly. Do not jerk or tug repeatedly on the tab.
Switch power-up
Supply power to the Z9264F-ON switch after you mount it in a rack or cabinet.
Reinspect your switch before power up. Verify the following:
• The equipment is properly secured to the rack. Dell EMC recommends properly
grounding the switch.
• The ambient temperature around the unit, which may be higher than the room
temperature, is within the limits specied for the Z9264F-ON switch, see Specications.
• There is sucient airow around the unit.
• The input circuits are correctly sized for the loads and that you use sucient
overcurrent protection devices.
• All protective covers are in place.
• Blank panels are installed if you do not install optional modules.
Z9264F-ON switch installation 15

CAUTION: Do not power up the switch if you did not install a fan module.
NOTE: A US AC power cable is included for powering up an AC power supply. You
must order all other power cables separately.
NOTE: ESD damage can occur if components are mishandled. Always wear an ESD-
preventive wrist or heel ground strap when handling the switch and its components.
Power up sequence
When the switch powers up, the fans immediately come on at high speed. The fan speed
slows as the switch continues to boot up.
After switch installation
After you have securely installed and powered on the Z9264F-ON switch:
• If you are using Dell EMC software, see switch documentation at www.dell.com/
support.
• If you need ONIE information, see ONIE documentation at www.onie.org.
• If you are using third-party software, see your third-party documentation.
16 Z9264F-ON switch installation

Specications
This section lists the Z9264F-ON switch specications.
CAUTION: Operate the product at an ambient temperature not higher than 45°C
(113°F).
CAUTION: Lithium Battery Caution: There is a danger of explosion if the battery is
incorrectly replaced. Replace only with same or equivalent type of battery. Dispose
of the batteries according to the manufacturer's instructions.
NOTE: For RoHS information, see Restricted Material Compliance.
Chassis physical design
Table 1. Chassis physical design
Parameter Specications
Height 3.37 inches (85.6 mm)
Width 17.4 inches (442 mm)
Depth 20.0 inches (510 mm)
PSU/fan tray handle: 1.38 inches (35 mm)
Chassis weight with factory-installed
components
34.6 lbs (2 PSUs and 4 fans)
15.7 kg (2 PSUs and 4 fans)
Rack clearance required Front: 5 inches (12.7 cm)
Back: 5 inches (12.7 cm)
4
Specications 17

Table 2. Environmental parameters
Parameter Specications
Operating temperature 0°C to 45°C (32°F to 113°F) continuously
-5°C to 45°C (23°F to 113°F) short term
Short term is </= 1% of operational hours
per year.
NOTE: Reduce maximum
temperature by 1°C/125 meters
(1°F/228 feet) above 950 meters
(3,117 feet).
Operating humidity 5% to 90% (RH), non-condensing
Storage temperature -40°C to 70°C (-40°F to 158°F )
Storage humidity 5% to 90%, non-condensing
Maximum thermal output 470 W = 1603.7 BTU/Hr
Maximum operational altitude 10,000 feet (3,048 meters)
Maximum non-operational altitude 39,370 feet (12,000 meters)
Shock Dell EMC Spec SV0115
Table 3. AC power requirements
Parameter Specications
Power supply 100–240 VAC 50/60 Hz
Maximum current draw per system 4.7A/3.9A at 100/120V AC 2.35A/1.95A at
200/240V AC
Maximum power consumption 1104.37W (based on 4.5W QSFP28)
Typical power consumption 900W
18 Specications

Table 4. DC power requirements
Parameter Specications
Minimum and maximum input voltage range −40.5, –48V, –60V DC
Input current at full load with fan −40.5V/24.0A −48V/20.25A −60V/16.2A
Specications 19

Support
The support site provides documents and tools to help you eectively use your equipment
and mitigate network outages. Through the support site you can obtain technical
information, access software upgrades and patches, download available management
software, and manage your open cases. The support site provides integrated, secure access
to these services.
To access the support site, go to www.dell.com/support/. To display information in your
language, scroll down to the bottom of the web page and select your country from the
drop-down menu.
• To obtain product-specic information, enter the 7-character service tag, known as a
luggage tag, or 11-digit express service code of your switch and click Submit.
To view the chassis service tag or express service code, pull out the tag or enter the
show chassis command from the CLI.
• To receive more technical support, click Contact Us. On the Contact Information web
page, click Technical Support.
To access switch documentation, go to www.dell.com/manuals/.
To search for drivers and downloads, go to www.dell.com/drivers/.
To participate in community blogs and forums, go to www.dell.com/community.
5
20 Support
