Dell OptiPlex 3011 AIO Owner's manual

Dell OptiPlex 3011 AIO
Setup And Features Information
About Warnings
WARNING: A WARNING indicates a potential for property damage, personal injury,
or death.
Front View
1. camera status light
2. camera
3. microphone
NOTE: The location of
microphone varies in the
touch screen computer.
4. display
Regulatory Model: W07B
Regulatory Type: W07B001
2013 - 03

5. optical drive (optional)
6. optical-drive eject button
7. hard-drive activity light
8. power button
9. stand
Back View
1. serial port
2. security cable slot
3. back panel connectors
4. memory card reader
5. USB 3.0 connectors (2)
6. microphone connector
7. headphone connector
8. On Screen Display (OSD) buttons (3)
2

Back Panel View
1. power connector
2. network connector
3. USB 2.0 connectors (4)
Quick Setup
WARNING: Before you begin any of the procedures in this section, read the safety
information that shipped with your computer. For additional best practices
information, see www.dell.com/regulatory_compliance
NOTE: Some devices may not be included if you did not order.
1. Connect the USB keyboard or mouse. To connect a wireless keyboard and mouse,
see
Setting Up Your Dell Cordless Mouse, Keyboard, and USB Receiver tech sheet
that shipped with your wireless keyboard and mouse.
Figure 1. USB Connection
2. Connect the network cable (optional).
3

Figure 2. Network Connection
3. Connect the power cable(s).
Figure 3. Connecting Power
4. Press the power button on the computer.
Figure 4. Turning On Power
Specifications
NOTE: The following specifications are only those required by law to ship with your
computer. For a complete and current listing of the specifications for your
computer, go to www.dell.com/support.
Table 1. Power
Feature Specification
Coin-cell battery 3 V CR2032 lithium coin cell
Voltage 100 VAC to 240 VAC
4

Feature Specification
Wattage 180 W
Maximum heat dissipation 853 BTU/hr
Table 2. Physical
Feature Optiplex 3011 AIO (non-
touch)
Optiplex 3011 AIO (touch)
Height (without stand) 323 mm (12.71 inches) 323 mm (12.71 inches)
Height (with stand) 376.95 mm (14.82 inches) 376.95 mm (14.82 inches)
Width 506.8 mm (19.95 inches) 506.8 mm (19.95 inches)
Depth 63.2 mm (2.49 inches) 65.5 mm (2.58 inches)
Weight (Minimum) 6.95 kg - 7.44 kg (15.32 lb -
16.40 lb)
8.14 kg - 8.63 kg (17.94 lb -
19.02 lb)
Table 3. Environmental
Feature Specification
Operating temperature 10 °C to 35 °C (50 °F to 95 °F)
Information para NOM (únicamente para México)
The following information is provided on the device described in this document in
compliance with the requirements of the official Mexican standards (NOM).
Voltaje de alimentación 100 VAC – 240 VAC
Frecuencia 50 Hz – 60 Hz
Consumo eléctrico 2,9 A
Finding More Information and Resources
See the safety and regulatory documents that shipped with your computer and the
regulatory compliance website at www.dell.com/regulatory_compliance for more
information on:
• Safety best practices
• Regulatory certification
• Ergonomics
5

See www.dell.com for additional information on:
• Warranty
• Terms and Conditions (U.S. only)
• End User License Agreement
Additional information on your product is available at www.dell.com/support/manuals
