Dell Latitude 3190 2-in-1
Technical Guidebook
Regulatory Model: P26T
Regulatory Type: P26T003

Notes, cautions, and warnings
NOTE: A NOTE indicates important information that helps you make better use of your product.
CAUTION: A CAUTION indicates either potential damage to hardware or loss of data and tells you how to avoid the problem.
WARNING: A WARNING indicates a potential for property damage, personal injury, or death.
Copyright © 2017 Dell Inc. or its subsidiaries. All rights reserved. Dell, EMC, and other trademarks are trademarks of Dell Inc. or its subsidiaries. Other
trademarks may be trademarks of their respective owners.
2017 - 12
Rev. A00

Contents
1 Product View and Technical Specications.....................................................................................................4
Features of Latitude 3190 2-in-1.......................................................................................................................................4
Front and back view.................................................................................................................................................... 4
Technical Specications.................................................................................................................................................... 5
2 Marketing System Congurations..................................................................................................................7
Operating system congurations......................................................................................................................................7
Processor ........................................................................................................................................................................... 7
Memory .............................................................................................................................................................................. 7
Security options .................................................................................................................................................................7
3 Engineering specications............................................................................................................................. 9
System dimensions............................................................................................................................................................ 9
Operating Conditions.........................................................................................................................................................9
Adapter options.................................................................................................................................................................10
Graphics options............................................................................................................................................................... 10
Wireless communications ................................................................................................................................................ 11
Camera option ..................................................................................................................................................................12
World Facing Camera (optional)..................................................................................................................................... 13
Storage options.................................................................................................................................................................13
Ports and Connectors...................................................................................................................................................... 14
Battery specications.......................................................................................................................................................15
Keyboard............................................................................................................................................................................15
Keyboard Hot Key Denitions........................................................................................................................................ 16
Touchpad........................................................................................................................................................................... 16
Display specications........................................................................................................................................................17
4 Getting help................................................................................................................................................. 18
Contacting Dell..................................................................................................................................................................18
Contents 3

Product View and Technical Specications
This chapter consists of the product view features along with technical specications. The product view feature calls out the dierent
ports, connectors and components available in the computer.
Features of Latitude 3190 2-in-1
The features topics call out the dierent views of the computer along with the ports and components available in each view for the
Latitude 3190 2-in-1.
Front and back view
1
4 Product View and Technical Specications

1 Camera 2 Camera status light
3 Microphone 4 World-facing microphone (optional)
5 World-facing camera status light (optional) 6 World-facing camera (optional)
7 Noble Wedge lock slot 8 Volume control button
9 Power button 10 Battery status light
11 Universal audio jack 12 Speakers
13 Touchpad 14 USB 3.1 Gen 1 port
15 USB 3.1 Gen 1 port with PowerShare 16 HDMI port
17 Power connector port 18 Microphone status light
19 Service tag label
Technical Specications
This topics lists out the technical specications for the Latitude 3190 2-in-1.
Table 1. Specications
Type Feature
Model Number Latitude 3190 2-in-1
Processor family •
• Intel® Pentium® Processor N5000 (6W, 4M cache, up to 2.7 GHz)
• Intel® Celeron® Processor N4100 (6W, 4M cache, up to 2.4 GHz)
Operating System • Microsoft® Windows 10 64 bit RS2 or above
Memory • 4 GB DDR4 2400Mhz
• 8 GB DDR4 2400Mhz
Product View and Technical Specications 5

Chipset • Intel Gemini Lake (integrated with processor)
Graphics Intel® UHD Graphics 605/600
Display • 11.6” HD 16:9 (1366 x 768) Touch with Corning® Gorilla® Glass NBT
Storage options • 64 GB eMMC
• M.2 128 GB SATA Class 20 Solid State Drive
• M.2 256 GB SATA Class 20 Solid State Drive
Multimedia • High Quality Speakers
• Headphone/Headset/Microphone combo jack
• Integrated, noise reducing array microphones
• Optional Integrated HD video webcam
Battery options • 42 Whr (3 Cell) Prismatic with ExpressCharge
Power adapter • E4 65W - 65 Watt AC Adapter
• E5 65W Rugged (India only)
• E5 65W - 65 Watt AC Adapter
• E4 65W HF (BFR/PVC Free)
• Dell Portable Power Companion (12000 mAh) PW7015M (Power
Companion 45W (Dura Ace))
• Dell Portable Power Companion (18000 mAh) PW7015L (Power Companion
65W (Tesla))
Connectivity Intel Dual Band Wireless-Intel® Dual Band Wireless-AC 8265 802.11AC 2x2 Wi-
Fi + BT 4.2 LE Solder Down Card
Ports, Slots and Chassis One full size HDMI port, 2 USB 3.1 Gen 1 (1 w/ Power share); universal mic/
headset
Security Dell Data Protection|Encryption Software Upsell Options
Dell Data Protection|Protected Workspace UPsell
Intel FW TPM
Noble Wedge Lock
Input device Single Point Sealed non-backlit Keyboard
Multi-touch Sealed Touchpad
Docking Dell D3100 USB 3.0 Dock
6 Product View and Technical Specications

Marketing System Congurations
This chapter lists the operating system congurations supported in computer. It also lists the processor, memory, storage options available
for this system. It will help the team in identifying whether a specic conguration is supported by the system.
Operating system congurations
This topic lists the operating system supported by
Table 2. Operating systems
Windows Microsoft® Windows10 64 bit RS2 and above
Processor
Dell Latitude 3190 2-in-1 system is built with Intel Pentium and Celeron processors.
Table 3. Processor specications
Processors Support List UMA Graphics
Intel Pentium Processor N5000 (6W, 4M cache, up to 2.7 GHz) Intel HD Graphics 605
Intel Celeron Processor N4100 (6W, 4M cache, up to 2.4 GHz) Intel HD Graphics 600
Memory
Your computer supports a maximum of 8 GB of memory.
Table 4. Memory specications
Minimum Memory Conguration 4 GB
Maximum Memory Conguration 8 GB
Type DDR4 (on-board memory)
Speed 2400 MHz
Security options
This topic lists the security information.
Table 5. Security options
Intel Platform Trust Technology Intel FW TPM
Noble Wedge Lock Yes
Dell Data Protection | Protected Workspace Upsell Yes
2
Marketing System Congurations 7

Dell Data Protection | Encryption Software Upsell Options Yes
Table 6. Service and Support
1-Year Mail-In Service
NOTE: Service many be provided by third party.
Technician will be dispatched if necessary
following phone-based troubleshooting, subject
to parts availability, and other terms of service
contract.
Standard
ProSupport Optional
8 Marketing System Congurations

Engineering specications
This chapter lists out the specication of each and every component in a comprehensive format. Specic features/models/congurations/
options discussed in the document may or may not be available.
System dimensions
This topic lists out the dimensions of the computer in detail.
Table 7. System dimension
Touch
Weight (pounds/kilogram) Starts from 3.19 lb/1.45 kg
Dimensions inches
Height • Front – 21.25 mm (0.83 inch)
• Back – 21.25 mm (0.83 inch)
Width 303.8 mm (11.96 inches)
Depth 207.9 mm (8.18 inches)
NOTE: System weight and shipping weight is based on a typical conguration and may vary based on the actual conguration.
Operating Conditions
This topics lists the operating conditions of your system.
Table 8. Operating conditions
Temperature Range • Operating: 0 °C to 35 °C (32 °F to 95 °F)
• Storage: -40 °C to 65 °C (-40 °F to 149 °F
Relative humidity • Operating : 10 % to 90 % (non-condensing)
• Storage: 5% to 95% (non-condensing)
Altitude (maximum) • Operating : 3048 m (10,000 ft)
• Storage: 10668 m (35,000 ft)
Shock • Operating: 160 G with pulse duration of 2 ms (equivalent to 80
in/sec)
• Storage: 160 G with pulse duration of 2 ms (equivalent to 80 in/
sec)
Vibration • Operating: 0.66 Grms
• Storage: 1.33 Grms
3
Engineering specications 9

Adapter options
This topic lists the adapter specications for Latitude 3190 2-in-1:
Table 9. AC Adapter
Wattage E4 65W - 65 Watt AC Adapter E5 65W Rugged (India only) E4 65W HF (BFR/PVC Free)
Adapter Specications
Input voltage 100 to 240 VAC 100 to 240 VAC 100 to 240 VAC
Input current (max) 1.7 A 1.7 A 1.7 A
Input Frequency 50 Hz to 60 Hz 50 Hz to 60 Hz 50 Hz to 60 Hz
Output current 3.34 A (continuous) 3.34 A (continuous) 3.34 A (continuous)
Rated output voltage 19.5 VDC 19.5 VDC 19.5 VDC
Weight (kg) 0.29 0.23 0.29
Dimensions (HxWxD inches) 1.1 x 1.9 x 4.3 0.87 x 2.6 x 4.17 1.1 x 1.9 x 4.3
Temperature range: 0 °C to 40 °C 0 °C to 40 °C 0 °C to 40 °C
Operating 32 °F to 104 °F 32 °F to 104 °F 32 °C to 104 °F
Storage -40 °C to 70 °C
-40 °F to 158 °F
-40 °C to 70 °C
-40 °F to 158 °F
-40 °C to 70 °C
-40 °F to 158 °F
Graphics options
This topic lists the graphic specications.
Table 10. Graphics specication
Integrated Graphics Controller Intel HD Graphics
Model Latitude 3190 2-in-1
Bus Type Internal PCIe
Memory Interface N/A (unied memory architecture)
Clock Speeds Pentium N5000: 2.7 GHz
Celeron N4100: 2.4 GHz
Max Graphics dynamic frequency Pentium N5000: 750MHz
Celeron N4100: 650MHz
Graphics Level Pentium N5000: Intel UHD Graphics 605
Celeron N4100: Intel UHD Graphics 600
Estimated Maximum Power Consumption
(TDP)
6 W ( Total SOC power consumption)
10 Engineering specications

Display Support eDP (internal), HDMI
Maximum Color Depth 32-bit
Maximum Vertical Refresh Rate Up to 60 Hz depending on resolution
Operating Systems Graphics/ Video API
Support
DirectX 12, OpenGL 4.3
Supported Resolutions and Max Refresh Rates
(Hz) (Note: Analog and/or digital)
eDP: Panel 1366x768@60hz.
HDMI: V1.4 @1.65Gb/s
Numbers of Displays Supported 2 max
Wireless communications
Table 11. Intel Dual Band Wireless-AC 8265 802.11AC 2x2 Wi-Fi + BT 4.2 LE Solder Down Card
Attribute Specication
Host interface M.2 1216 solder down form factor (WiFi – PCIe, Bluetooth – USB)
Network standard IEEE 802.11a/b/g/n/ac
Wi-Fi Alliance Certications 802.11a/b/g/n/ac, WPA, WPA2, WMM, WPS, Wi-Fi Direct, 802.11ac
Operating Frequency Bands 2.4 GHz and 5 GHz
Dual Stream N Support for two transmit and receive antennas enable better
wireless at the same distance when compared to older 802.11a/b/g
solutions.
Data Rate Up to 867 Mbps
Power Consumption Optimized power modes (sleep states) reduce power consumption
during periods of inactivity
Authentication
Authentication Protocols
Encryption
Product Safety
WPA and WPA2, 802.1X (EAP-TLS, TTLS, PEAP, LEAP, EAP-FAST),
EAP-SIM, EAP-AKA
PAP, CHAP, TLS, GTC, MS-CHAP, MS-CHAPv2
64-bit and 128-bit WEP, 128-bit AES-CCMP
UL, C-UL, CB (IEC60950-1)
Management Capabilities Alerting Not Supported
Government Compliance FIPS (Windows® 7 only), FISMA
Client Utility Intel® PRO/Set Wireless Software v19.0 and later.
Software Support Microsoft WHQL certied for Windows 10
Radio On/O Supported
Engineering specications 11

Attribute Specication
LED output Supported
Roaming Supports seamless roaming between respective access points
(802.11b, 802.11g, 802.11a/b/g, and 802.11a/b/g/n/ac)
Wake On Wireless Windows® 8.1/10 without Intel AMT
Wireless Display Native Windows 10 Miracast support
Country Restrictions N/A
Wireless PAN Standard Dual Mode Bluetooth 4.2, BLE
Bluetooth Data rates Up to 3 Mbps
Bluetooth Operating Frequency Bands 2.4 GHz
Bluetooth Proles Supported For Windows 7, includes DID, HID, PAN, HCRP, SPP, HFP, HSP
DUN, OPP, FTP, BIP, BPP, SYNCH, A2DP(source/sink), AVRCP
(target/controller), HOGP (LE HID)
Support for Microsoft Inbox Bluetooth proles in Windows 8.1 and
future OS versions.
Bluetooth Data Encryption 128-bit encryption
Bluetooth Output Power Power class 1
Temperature Operating temperature 0 °C to +50 °C (Full performance at shield
temperatures up to 80 °C)
Storage temperature of –40 °C to +70 °C
Humidity Up to 90% RH non-condensing (at temperatures of 25 °C to
35 °C)
Camera option
This topics lists out the detailed camera specications.
Table 12. Camera specication
Camera type HD xed focus
Sensor type CMOS sensor technology
Resolution: Motion video Up to 1280 X 720 (1 MP)
Resolution: Still image Up to 1280 X 720 (1 MP)
Imaging rate Up to 30 frames per second
12 Engineering specications

World Facing Camera (optional)
This topics lists out the detailed camera specications.
Table 13. Camera specication
Camera type 5M Auto Focus
Sensor type CMOS Image Sensor
Image Resolution(Maximum) 2592 x 1944 pixels
Video Resolution(Maximum) 1920 x 1080 pixels
Imaging rate(Maximum) Up to 30 frames per second
Storage options
This topic lists out the detailed specications of the supported SSDs and eMMC storage.
Table 14. 64 GB eMMC
Capacity (GB) 64 GB
MMC Interface 5.0
Voltage 3.3 V
Table 15. 128 GB Mobile SSD (M.2)
Capacity (GB) 128 GB
Dimensions inches (W x D x H) 80.0 mm x 22.0 mm x 3.65 mm (W x D x H)
Interface type and Maximum speed SATA interface and Maximum speed 6.0Gb/s rates.
MTBF 1,500,000 hours
Logical Blocks 125,045,424
Power Source
Power Consumption (reference only) 2.5 W
Environmental Operating Conditions (Non-Condensing):
Temperature Range 0 °C to 70 °C
Relative Humidity Range 5% to 95%
Op Shock (@0.5ms) 1500 G
Environmental Non-Operating Conditions (Non-Condensing):
Temperature Range -40 °C to 85 °C
Relative Humidity Range 5% to 95%
Engineering specications 13

Table 16. 256 GB Mobile SSD (M.2)
Capacity (GB) 256 GB
Dimensions inches (W x D x H) 80.0 mm x 22.0 mm x 3.65 mm (W x D x H)
Interface type and Maximum speed SATA interface and Maximum speed 6.0Gb/s rates.
MTBF 1,500,000 hours
Logical Blocks 125,045,424
Power Source
Power Consumption (reference only) 2.5 W
Environmental Operating Conditions (Non-Condensing):
Temperature Range 0 °C to 70 °C
Relative Humidity Range 5% to 95%
Op Shock (@0.5ms) 1500 G
Environmental Non-Operating Conditions (Non-Condensing):
Temperature Range -40 °C to 85 °C
Relative Humidity Range 5% to 95%
Ports and Connectors
Table 17. Ports and Connectors
USB Two USB 3.1 Gen 1 (one with PowerShare)
Video Full Size HDMI
Modem NA
Audio Universal Audio JAck
Two channel high denition audio
Stereo conversion: 16/20/24-bit (analog-to-digital and digital-to-
analog)
Internal Interface - high-denition audio codec.
Speakers: Power / Peak Power: 2W Average/2.5W Peak
Internal speaker amplier: 2 watt per channel
Internal microphone: digital microphone (dual microphone with
camera)
Volume control buttons, supports hot-key keyboard button
14 Engineering specications

Expansion NA
Express Card NA
Battery specications
This topics lists out the detailed battery specications.
Table 18. Battery specications
42 Whr (3 Cell) Prismatic with ExpressCharge
Type Li-polymer
Dimension
Length 184 mm (7.24 inches)
Width 97 mm (3.82 inches)
Weight 185.00 g
Height 5.9 mm (0.232 inches)
Voltage 11.4 VDC
Typical Amp-hour capacity 3.5 Ahr
Typical Watt-hour capacity 42 Whr
Temperature
Operating • 0 °C to 35 °C (32 °F to 95 °F)
• Charge: 0 °C to 60 °C (32 °F to 140 °F)
• Discharge: 0 °C to 70 °C (32 °F to 158 °F)
Non-operating –40 °C to 65 °C (–40 °F to 149 °F)
Charging time
Express Charge mode • 0~15°C: 4 hours
• 16~45°C: 2 hours
• 46~60°C: 3 hours
Standard mode • 0~15°C: 4 hours
• 16~60°C: 3 hours
ExpressCharge capable Yes (non-LLC only)
BATTMAN capable Yes
Keyboard
Table 19. Keyboard Specications
Number of keys 82 (US), 83 (UK), 84 (BZ), 86 (JP)
Size X= 19.05 mm key pitch
Y= 18.05 mm key pitch
Backlit keyboard option NA
Engineering specications 15

Keyboard Hot Key Denitions
Table 20. Keyboard hot key denitions
Fn Key Combination Function
Fn+ESC Fn Toggle
Fn+ F1 Speaker Mute
Fn + F2 Volume Down
Fn + F3 Volume Up
Fn + F4 Mic Mute
Fn + F5 Num Lock
Fn + F6 Scroll Lock
Fn + F8 Display Toggle (Win + P)
Fn + F9 Search
Fn + F10 No function
Fn + F11 Print Screen
Fn + F12 Insert
Fn + Home Toggle Wireless On/O
Fn + End Sleep
Fn + Up arrow Brightness up
Fn + down arrow Brightness down
FnKey Mode:
Standard = The F1-F12 keys behave as function keys. Holding <Fn> is required to access their secondary functions.
Touchpad
Table 21. Touchpad
Dimensions
Width 100 mm
Height 55 mm
16 Engineering specications

Supported Gestures Windows 10
Cursor moving Supported
Clicking/ tapping Supported
Click and drag Supported
2-nger scroll Supported
2-nger pinch/zoom Supported
2-nger tapping Supported
3-nger (Invoke Cortana) Supported
3-nger (See all open windows) Supported
3-nger (Show the desktop) Supported
3-nger (Switch between open windows) Supported
4-nger (Invoke Action Center) Supported
4-nger (Switch virtual desktops) Supported
Display specications
This topics lists out the detailed display specications.
Table 22. Display specications
11.6–inch HD IPS Touch with Microsoft Pen support
Type HD Ultra Slim
Luminance/Brightness (typical) HD 200 nits
Diagonal 11.6 inches
Native Resolution HD 1366 x 768
Megapixels (millions of pixels) HD 1.04
Pixels per Inch (PPI) 135 for HD
Contrast Ratio (typical) 800:1 for HD
Refresh Rate 60 Hz
Horizontal Viewing Angle HD +80/- 80 degrees
Vertical Viewing Angle HD +80/-80 degrees
Pixel Pitch HD 0.1875 x 0.1875 mm
Power Consumption (max) HD 3. 425 W
Engineering specications 17

Getting help
Contacting Dell
NOTE: If you do not have an active Internet connection, you can nd contact information on your purchase invoice, packing slip,
bill, or Dell product catalog.
Dell provides several online and telephone-based support and service options. Availability varies by country and product, and some services
may not be available in your area. To contact Dell for sales, technical support, or customer service issues:
1 Go to Dell.com/support.
2 Select your support category.
3 Verify your country or region in the Choose a Country/Region drop-down list at the bottom of the page.
4 Select the appropriate service or support link based on your need.
4
18 Getting help
