Dell Latitude 5320 Operation and maintenance manual

Vostro 5320
Setup and Specifications
Regulatory Model: P156G
Regulatory Type: P156G001
March 2022
Rev. A01

Notes, cautions, and warnings
NOTE: A NOTE indicates important information that helps you make better use of your product.
CAUTION: A CAUTION indicates either potential damage to hardware or loss of data and tells you how to avoid
the problem.
WARNING: A WARNING indicates a potential for property damage, personal injury, or death.
© 2022 Dell Inc. or its subsidiaries. All rights reserved. Dell, EMC, and other trademarks are trademarks of Dell Inc. or its subsidiaries. Other
trademarks may be trademarks of their respective owners.

Chapter 1: Set up your Vostro 5320............................................................................................... 4
Chapter 2: Views of Vostro 5320................................................................................................... 6
Front....................................................................................................................................................................................... 6
Right........................................................................................................................................................................................7
Left..........................................................................................................................................................................................7
Top.......................................................................................................................................................................................... 8
Bottom................................................................................................................................................................................... 9
Battery charge and status light ...................................................................................................................................... 9
Chapter 3: Specifications of Vostro 5320..................................................................................... 11
Dimensions and weight......................................................................................................................................................11
Processor..............................................................................................................................................................................11
Chipset..................................................................................................................................................................................12
Operating system...............................................................................................................................................................12
Memory.................................................................................................................................................................................12
External ports......................................................................................................................................................................13
Internal slots........................................................................................................................................................................13
Wireless module..................................................................................................................................................................13
Audio..................................................................................................................................................................................... 14
Storage................................................................................................................................................................................. 14
Keyboard.............................................................................................................................................................................. 15
Camera................................................................................................................................................................................. 15
Touchpad............................................................................................................................................................................. 16
Power adapter.................................................................................................................................................................... 16
Battery.................................................................................................................................................................................. 17
Display...................................................................................................................................................................................18
Fingerprint reader (optional)...........................................................................................................................................18
GPU—Integrated...............................................................................................................................................................19
Operating and storage environment..............................................................................................................................19
Chapter 4: Dell ComfortView....................................................................................................... 20
Chapter 5: Keyboard shortcuts.................................................................................................... 21
Chapter 6: Getting help and contacting Dell................................................................................ 23
Contents
Contents 3

Set up your Vostro 5320
NOTE: The images in this document may differ from your computer depending on the configuration you ordered.
1. Connect the power adapter and press the power button.
NOTE: To conserve battery power, the battery might enter power saving mode. Connect the power adapter and press
the power button to turn on the computer.
2. Finish operating system setup.
Follow the on-screen instructions to complete the setup. When setting up, Dell recommends that you:
●Connect to a network for Windows updates.
NOTE: If connecting to a secured wireless network, enter the password for the wireless network access when
prompted.
●If connected to the internet, sign-in with or create a Microsoft account. If not connected to the internet, create an
offline account.
●On the Support and Protection screen, enter your contact details.
3. Locate and use Dell apps from the Windows Start menu—Recommended.
Table 1. Locate Dell apps
Resources Description
Dell Product Registration
Register your computer with Dell.
Dell Help & Support
Access help and support for your computer.
1
4 Set up your Vostro 5320

Table 1. Locate Dell apps (continued)
Resources Description
My Dell
Centralized location for key Dell applications, help articles, and other important information about
your computer. It also notifies you about the warranty status, recommended accessories, and
software updates if available.
SupportAssist
SupportAssist is the smart technology that keeps your computer running at its best by optimizing
settings, detecting issues, removing viruses and notifies when you need to make system
updates. SupportAssist proactively checks the health of your system's hardware and software.
When an issue is detected, the necessary system state information is sent to Dell to begin
troubleshooting. SupportAssist is preinstalled on most of the Dell devices running Windows
operating system. For more information, see SupportAssist for Home PCs User's Guide on
www.dell.com/serviceabilitytools.
NOTE: In SupportAssist, click the warranty expiry date to renew or upgrade your warranty.
Dell Update
Updates your computer with critical fixes and latest device drivers as they become available. For
more information on using Dell Update, search in the Knowledge Base Resource at www.dell.com/
support.
Dell Digital Delivery
Download software applications, which are purchased but not preinstalled on your computer.
For more information on using Dell Digital Delivery, search in the Knowledge Base Resource at
www.dell.com/support.
Set up your Vostro 5320 5

Views of Vostro 5320
Front
1. Left microphone
Provides digital sound input for audio recording and voice calls.
2. Privacy shutter
Slide the privacy shutter to cover the camera lens and protect your privacy when the camera is not in use.
3. Camera
Enables you to video chat, capture photos, and record videos.
4. Camera-status light
Turns on when the camera is in use.
5. Right microphone
Provides digital sound input for audio recording and voice calls.
2
6 Views of Vostro 5320

Right
1. USB 3.2 Gen 1 port
Connect devices such as external storage devices and printers. Provides data transfer speeds up to 5 Gbps.
2. Headset port
Connect headphones or a headset (headphone and microphone combo).
Left
1. HDMI port
Connect to a TV, external display or another HDMI-in enabled device. Provides video and audio output.
2. Thunderbolt 4.0 port with Power Delivery and DisplayPort (2)
Supports USB4, DisplayPort 1.4, Thunderbolt 4 and also enables you to connect to an external display using a display adapter.
Provides data transfer rates of up to 40 Gbps for USB4 and Thunderbolt 4.
NOTE: You can connect a Dell Docking Station to the Thunderbolt 4 ports. For more information, see the knowledge
base article 000124295 at www.dell.com/support.
NOTE: A USB Type-C to DisplayPort adapter (sold separately) is required to connect a DisplayPort device.
NOTE: USB4 is backward compatible with USB 3.2, USB 2.0, and Thunderbolt 3.
NOTE: Thunderbolt 4 supports two 4K displays or one 8K display.
3. Battery-status light
Indicates the battery-charge status.
Solid white—Power adapter is connected and the battery has more than 5% charge.
Amber—Computer is running on battery and the battery has less than 5% charge.
Off—Power adapter is disconnected or the battery is fully charged.
Views of Vostro 5320 7

Top
1. Left-click area
Press to left-click.
2. Touchpad
Move your finger on the touchpad to move the mouse pointer. Tap to left-click and two fingers tap to right-click.
3. Right-click area
Press to right-click.
4. Power button with optional fingerprint reader
Press to turn on the computer if it is turned off, in sleep state, or in hibernate state.
When the computer is turned on, press the power button to put the computer into sleep state; press and hold the power
button for four seconds to force shut-down the computer.
If the power button has a fingerprint reader, place your finger on the power button to log in.
NOTE: You can customize power-button behavior in Windows. For more information, see Me and My Dell at
www.dell.com/support/manuals.
8 Views of Vostro 5320

Bottom
1. Left speaker
Provides audio output.
2. Right speaker
Provides audio output.
3. Service Tag label
The Service Tag is a unique alphanumeric identifier that enables Dell service technicians to identify the hardware
components in your computer and access warranty information.
Battery charge and status light
The following table lists the battery charge and status light behavior of your Vostro 5320.
Table 2. Battery charge and status light behavior
Power Source LED Behavior System Power State Battery Charge Level
AC Adapter Off S0 - S5 Fully Charged
AC Adapter Solid White S0 - S5 < Fully Charged
Battery Off S0 - S5 > Low to Fully Charged
Battery Solid Amber (590+/-3 nm) S0 - S3 <= Low/Critical
●S0 (ON) - The computer is turned on.
●S3 (Sleep) - The computer is in sleep mode.
Views of Vostro 5320 9

●S4 (Hibernate) - The computer consumes the least power compared to all other sleep states. The computer is almost at an
OFF state, except for a trickle power. The context data is written to hard drive.
●S5 (OFF) - The computer is in a shutdown state.
10 Views of Vostro 5320

Specifications of Vostro 5320
Dimensions and weight
The following table lists the height, width, depth, and weight of your Vostro 5320.
Table 3. Dimensions and weight
Description Values
Height:
Front height 14.35 mm (0.56 in.)
Rear height 15.65 mm (0.62 in.)
Width 296.68 mm (11.68 in.)
Depth 213.50 mm (8.40 in.)
Weight
NOTE: The weight of your computer depends on the
configuration ordered and manufacturing variability.
1.30 kg (2.86 lb) - maximum
Processor
The following table lists the details of the processors supported by your Vostro 5320.
Table 4. Processor
Description Option one Option two Option three Option four
Processor type 12th Generation Intel
Core i5-1240P
12th Generation Intel
Core i7-1260P
12th Generation Intel
Core i5-1235U
12th Generation Intel Core
i3-1215U
Processor wattage 28 W 28 W 15 W 15 W
Processor core count 12 12 10 6
Processor thread
count 8 8 12 8
Processor speed Up to 4.40 GHz Up to 4.70 GHz Up to 4.40 GHz Up to 4.40 GHz
Processor cache 12 MB 18 MB 12 MB 10 MB
Integrated graphics Intel Iris XeGraphics Intel Iris XeGraphics Intel Iris XeGraphics Intel UHD Graphics
3
Specifications of Vostro 5320 11

Chipset
The following table lists the details of the chipset supported by your Vostro 5320.
Table 5. Chipset
Description Values
Chipset Intel 600 Series Chipset
Processor 12th Generation Intel Core i3/i5/i7
DRAM bus width 32-bit
Flash EPROM 32 MB
PCIe bus Up to Gen3.0
Operating system
Your Vostro 5320 supports the following operating systems:
●Windows 11 Pro, 64-bit
●Windows 11 Pro National Academic, 64-bit
●Windows 11 Home, 64-bit
Memory
The following table lists the memory specifications of your Vostro 5320.
Table 6. Memory specifications
Description Values
Memory slots Onboard memory
Memory type LPDDR5
Memory speed 4800 MHz
Maximum memory configuration 32 GB
Minimum memory configuration 8 GB
Memory configurations supported ●8 GB, 2 x 4 GB, LPDDR5, 4800 MHz, dual-channel,
integrated
●16 GB, 2 x 8 GB, LPDDR5, 4800 MHz, dual-channel,
integrated
●32 GB, 2 x 16 GB, LPDDR5, 4800 MHz, dual-channel,
integrated
12 Specifications of Vostro 5320

External ports
The following table lists the external ports on your Vostro 5320.
Table 7. External ports
Description Values
USB ports ●Two USB Type-C Thunderbolt 4 ports with DisplayPort
and Power Delivery
●One USB 3.2 Gen 1 port
Audio port One Universal audio jack
Video port/ports One HDMI 1.4 port
Media-card reader Not supported
Power-adapter port Two USB Type-C Thunderbolt 4 ports with DisplayPort and
Power Delivery
Security-cable slot Not supported
Internal slots
The following table lists the internal slots of your Vostro 5320.
Table 8. Internal slots
Description Values
M.2 ●One M.2 2230 slot for WiFi and Bluetooth combo card
●One M.2 2230/2280 slot for solid-state drive
NOTE: To learn more about the features of different
types of M.2 cards, search in the Knowledge Base
Resource at www.dell.com/support.
Wireless module
The following table lists the Wireless Local Area Network (WLAN) modules supported on your Vostro 5320.
Table 9. Wireless module specifications
Description Option one Option two
Model number Intel AX211 Intel AX201
Transfer rate Up to 2400 Mbps Up to 2400 Mbps
Frequency bands supported 2.4 GHz/5 GHz/6 GHz 2.4 GHz/5 GHz
Wireless standards ●WiFi 802.11a/b/g
●Wi-Fi 4 (WiFi 802.11n)
●Wi-Fi 5 (WiFi 802.11ac)
●Wi-Fi 6E (WiFi 802.11ax)
●WiFi 802.11a/b/g
●Wi-Fi 4 (WiFi 802.11n)
●Wi-Fi 5 (WiFi 802.11ac)
●Wi-Fi 6 (WiFi 802.11ax)
Encryption ●64-bit WEP ●64-bit WEP
Specifications of Vostro 5320 13

Table 9. Wireless module specifications (continued)
Description Option one Option two
●128-bit WEP
●AES-CCMP
●TKIP
●128-bit WEP
●AES-CCMP
●TKIP
Bluetooth Bluetooth 5.2 Bluetooth 5.2
Audio
The following table lists the audio specifications of your Vostro 5320.
Table 10. Audio specifications
Description Values
Audio controller Realtek ALC3204
Stereo conversion Supported
Internal audio interface High definition audio interface
External audio interface ●Universal audio jack
●HDMI 1.4b port
Number of speakers 2
Internal-speaker amplifier Supported
External volume controls Keyboard shortcut controls
Speaker output:
Average speaker output 2 W
Peak speaker output 2.5 W
Subwoofer output Not supported
Microphone Digital-array microphones
Storage
This section lists the storage options on your Vostro 5320.
Your Vostro 5320 supports one of the following storage configurations:
●One M.2 2230 solid-state drive
●One M.2 2280 solid-state drive
Table 11. Storage specifications
Storage type Interface type Capacity
M.2 2280, Class 40 solid-state drive PCIe NVMe Gen4 x4, up to 64 Gbps Up to 2 TB
M.2 2230, Class 35 solid-state drive PCIe NVMe Gen4 x4, up to 64 Gbps Up to 1 TB
14 Specifications of Vostro 5320

Keyboard
The following table lists the keyboard specifications of your Vostro 5320.
Table 12. Keyboard specifications
Description Values
Keyboard type ●Standard keyboard
●Standard backlit keyboard
Keyboard layout QWERTY
Number of keys ●United States and Canada: 79 keys
●United Kingdom: 80 keys
●Japan: 83 keys
Keyboard size X=19.05 mm key pitch
Y=18.05 mm key pitch
Keyboard shortcuts Some keys on your keyboard have two symbols on them.
These keys can be used to type alternate characters or to
perform secondary functions. To type the alternate character,
press Shift and the desired key. To perform secondary
functions, press Fn and the desired key.
NOTE: You can define the primary behavior of the
function keys (F1–F12) changing Function Key Behavior
in BIOS setup program.
For more information, see Keyboard shortcuts.
Camera
The following table lists the camera specifications of your Vostro 5320.
Table 13. Camera specifications
Description Values
Number of cameras One
Camera type FHD Camera
Camera location Front camera
Camera sensor type CMOS sensor technology
Camera resolution:
Still image 2.07 megapixel
Video 1920 x 1080 (HD) at 30 fps
Diagonal viewing angle: 82 degrees
Specifications of Vostro 5320 15

Touchpad
The following table lists the touchpad specifications of your Vostro 5320.
Table 14. Touchpad specifications
Description Values
Touchpad resolution: >300 DPI
Touchpad dimensions:
Horizontal 105 mm (4.13 in.)
Vertical 65 mm (2.56 in.)
Touchpad gestures For more information about touchpad gestures available
on Windows, see the Microsoft knowledge base article at
support.microsoft.com.
Power adapter
The following table lists the power adapter specifications of your Vostro 5320.
Table 15. Power adapter specifications
Description Values
Type 65 W USB Type-C
Power-adapter dimensions:
Height 28 mm (1.10 in.)
Width 51 mm (2.01 in.)
Depth 112 mm (4.40 in.)
Input voltage 100 VAC–240 VAC
Input frequency 50 Hz–60 Hz
Input current (maximum) 1.70 A
Output current (continuous) ●20 V/3.25 A (continuous)
●15 V/3 A (continuous)
●9 V/3 A (continuous)
●5 V/3 A (continuous)
Rated output voltage ●20 VDC
●15 VDC
●9 VDC
●5 VDC
Temperature range:
Operating 0°C to 40°C (32°F to 104°F)
Storage -40°C to 70°C (-40°F to 158°F)
16 Specifications of Vostro 5320

Table 15. Power adapter specifications (continued)
Description Values
CAUTION: Operating and storage temperature ranges may differ among components, so operating or storing
the device outside these ranges may impact the performance of specific components.
Battery
The following table lists the battery specifications of your Vostro 5320.
Table 16. Battery specifications
Description Option one Option two
Battery type 4-cell "polymer" lithium-ion (54 Wh) 4-cell "polymer" lithium-ion (64 Wh)
Battery voltage 15 VDC (Nominal) 15.20 VDC (Nominal)
Battery weight (maximum) 0.24 kg (0.53 lb) 0.26 kg (0.57 lb)
Battery dimensions:
Height 271.90 mm (10.70 in.) 271.90 mm (10.70 in.)
Width 82 mm (3.23 in.) 82 mm (3.23 in.)
Depth 5.75 mm (0.23 in.) 5.75 mm (0.23 in.)
Temperature range:
Operating 0°C to 50°C (32°F to 122°F) 0°C to 50°C (32°F to 122°F)
Storage -20°C to 60°C (-4°F to 140°F) -20°C to 60°C (-4°F to 140°F)
Battery operating time Varies depending on operating
conditions and can significantly
reduce under certain power-intensive
conditions.
Varies depending on operating conditions
and can significantly reduce under certain
power-intensive conditions.
Battery charging time (approximate)
NOTE: Control the charging time,
duration, start and end time, and so
on using the Dell Power Manager
application. For more information on
the Dell Power Manager see, Me and
My Dell on www.dell.com.
2 hours (Express charge ), 3 hours
(Standard charge)
2 hours (Express charge ), 3 hours
(Standard charge)
Coin-cell battery CR2032 CR2032
CAUTION: Operating and storage temperature ranges may differ among components, so operating or storing
the device outside these ranges may impact the performance of specific components.
CAUTION: Dell recommends that you charge the battery regularly for optimal power consumption. If your
battery charge is completely depleted, connect the power adapter, turn on your computer, and then restart
your computer to reduce the power consumption.
Specifications of Vostro 5320 17

Display
The following table lists the display specifications of your Vostro 5320.
Table 17. Display specifications
Description Option one Option two
Display type Full High Definition Plus (FHD+) Quad-High Definition Plus (QHD+)
Display-panel technology Wide-Viewing Angle (WVA) Wide-Viewing Angle (WVA)
Display-panel dimensions (active area):
Height 178.80 mm (7.04 in.) 178.80 mm (7.04 in.)
Width 286.08 mm (11.26 in.) 286.08 mm (11.26 in.)
Diagonal 337.36 mm (13.28 in.) 337.36 mm (13.28 in.)
Display-panel native resolution 1920 x 1200 2560 x 1600
Luminance (typical) 300 nits 300 nits
Megapixels 2.30 3.07
Color gamut 100% (sRGB) - typical 100% (sRGB) - typical
Pixels Per Inch (PPI) 170 227
Contrast ratio (min.) 1000:1 1200:1
Response time (max.) 35 ms 35 ms
Refresh rate 60 Hz 60 Hz
Horizontal view angle +/- 80 degrees +/- 80 degrees
Vertical view angle +/- 80 degrees +/- 80 degrees
Pixel pitch 0.149 mm x 0.149 mm 0.11175 mm x 0.11175 mm
Power consumption (maximum) 4.30 W 4.40 W
Anti-glare vs glossy finish Anti-glare Anti-glare
Touch options Not supported Not supported
Fingerprint reader (optional)
The following table lists the specifications of the optional fingerprint-reader of your Vostro 5320.
Table 18. Fingerprint reader specifications
Description Values
Fingerprint-reader sensor technology Capacitive
Fingerprint-reader sensor resolution 500 dpi
18 Specifications of Vostro 5320

Table 18. Fingerprint reader specifications (continued)
Description Values
Fingerprint-reader sensor pixel size 108 x 88
GPU—Integrated
The following table lists the specifications of the integrated Graphics Processing Unit (GPU) supported by your Vostro 5320.
Table 19. GPU—Integrated
Controller Memory size Processor
Intel Iris XeGraphics Shared system memory 12th Generation Intel Core i5/i7
Intel UHD Graphics Shared system memory 12th Generation Intel Core i3
Operating and storage environment
This table lists the operating and storage specifications of your Vostro 5320.
Airborne contaminant level: G1 as defined by ISA-S71.04-1985
Table 20. Computer environment
Description Operating Storage
Temperature range 0°C to 40°C (32°F to 104°F) -40°C to 65°C (-40°F to 149°F)
Relative humidity (maximum) 90% (non-condensing) 95% (non-condensing)
Vibration (maximum)*0.66 GRMS Not applicable
Shock (maximum) 140 G† Not applicable
Altitude range Not applicable Not applicable
CAUTION: Operating and storage temperature ranges may differ among components, so operating or storing
the device outside these ranges may impact the performance of specific components.
* Measured using a random vibration spectrum that simulates user environment.
† Measured using a 2 ms half-sine pulse.
Specifications of Vostro 5320 19

Dell ComfortView
CAUTION: Prolonged exposure to blue light, particularly from digital sources, may disrupt sleep patterns and
cause long-term effects such as eye strain, eye fatigue, or damage to the eyes.
Blue light is a color in the white light spectrum which has a short wavelength and high frequency. Chronic exposure to blue light,
particularly from digital sources, may disrupt sleep patterns and change our body's Circadian rhythm. Using the computer for an
extended period may also cause fatigue in other body parts such as the neck, arm, back, and shoulder.
Dell low blue light displays optimize eye comfort with a flicker-free screen. The ComfortView feature reduces the amount of
blue light emitted from the monitor to optimize eye comfort. ComfortView mode can be enabled and configured using the Dell
CinemaColor (DCC) application. Dell ComfortView has been certified by TÜV Rheinland as a low blue light software solution.
Dell CinemaColor
Dell CinemaColor (DCC) combines the hardware and software to deliver clear visuals that appear every bit as vibrant as the
world around you. The DCC has four color profiles that optimize these settings depending on the content and your surroundings.
When you open DCC, you can choose Movie (default), ComfortView, Sports, or Animation from the list. The ComfortView
Profile optimizes eye comfort with a Low Blue Light software solution that meets TÜV standards to reduce harmful blue light
emissions to make extended screen time easy on your eyes compared to standard digital panels while still retaining the vibrant
colors.
ComfortView mode is certified by TÜV for the effective reduction of hazardous blue light by adjusting display parameters. You
can adjust the Saturation, Temperature, and Contrast values to create your custom setting in the ComfortView mode.
NOTE: For more information on DellCinema components see KB article 000178241 at https://www.dell.com/support.
ComfortView Plus
ComfortView Plus is a built-in, always-on, and virtually unnoticeable low blue light solution for Dell displays. ComfortView Plus
employs a hardware-based design that allows for a wider blue spectrum, with a much lower peak and reduced intensity. Dell
ComfortView Plus has been certified by TÜV Rheinland as a low blue light hardware solution. This feature is enabled at the
factory.
NOTE: ComfortView Plus is an optional hardware feature to be configured at the point of sale.
To reduce the risk of eye strain, it is also recommended that you:
●Position the display at a comfortable viewing distance between 20 in. to 28 in. (50 cm and 70 cm) from your eyes.
●Blink frequently to moisten your eyes, wet your eyes with water, or apply suitable eye drops.
●Look away from your display, and gaze at a distant object at 20 ft (609.60 cm) away for at least 20 seconds during each
break.
●Take an extended break for 20 minutes every two hours.
4
20 Dell ComfortView
