DellTM UltraSharpTM 2007FP 20-inch Flat Panel Display
Displays
The Dell™ UltraSharp™ 2007FP 20-inch flat panel display redefines the
performance of LCD displays with its stylish new black design and advanced
functionality. This improved version of the former Dell UltraSharp 2001FP
demonstrates Dell’s continuous commitments to provide customers with some
of the latest flat-panel technology at excellent prices. Ideal for home users,
small businesses and corporate customers alike.
Outstanding Screen Performance
•Fast response time with less smearing and ghosting than traditional flat
panel displays.
- 16ms typical
•High contrast ratio resulting in excellent color accuracy and uniformity.
- 800:1 typical
•High Resolution can provide excellent entertainment and multimedia
experience.
-1600 x 1200 resolution: About 46% more content compared to Dell
UltraSharp 1907FP Display.
2
Excellent Multimedia, Video and Graphics Experience
•DVI (Digital Video Interface) Connector
- DVI helps to ensure high quality image (no jitter), and stupendous color
uniformity.
•S-Video and Composite Connector
- Allows connection to other video devices such as game consoles and cable
boxes.
• Easy attachment of optional Dell 10W multimedia soundbar AS501.
Designed for Comfort and Convenience
•4 USB 2.0 high speed ports for easy access to connect peripheral devices
such as cameras, USB keys or mouse.
•Comprehensive flexibility of height adjustability (130mm / 5.118 inches up
or down), swivel (45
o
left and right) and tilt (4
o
forward and 21
o
backward).
•Dell-Designed Display Enhancements
- Slim black bezel designed to fit into most working environments and on
most desktops.
- Easy display detachment from stand can enable panel to be wall-mounted
(VESA standard 100mm, wall mount sold separately.)
- Stand lock down mechanism allows locking of monitor into place at the
lowest height which can allow easy transportation of display.
Quality
Dell-branded monitors are
designed to our exacting quality
standards and manufactured by the
world’s foremost suppliers, who
must pass Dell’s stringent quality
audit. All Dell monitors meet or
exceed relevant industry
standards.
Reliability
Dell-branded monitors undergo
exhaustive testing for performance,
reliability, durability and
compatibility with Dell systems.
Under our H.A.L.T (Highly
Accelerated Life Cycle Testing)
regimen, Dell engineers push our
monitors well past specified
tolerance limits for heat, cold,
vibration, shocks and drops, to
ensure that they can withstand
real-world conditions.
Price-Performance Value
Dell’s enormous buying power and
direct business model allows us to
offer high quality monitors at low
prices. Dealing with Dell, the
world’s largest Flat Panel
provider
1
, means a single point of
contact and accountability, and the
peace of mind of purchasing from
a stable and reliable technology
partner.
See Important Information on Page 3

DETAILED SPECIFICATIONS
75.0 kHz Horizontal, 60.0 Hz Vertical, 162 MHzVESA, 1600 x 1200
60.0 kHz Horizontal, 75.0 Hz Vertical, 78.8 MHzVESA, 1024 x 768
67.5 kHz Horizontal, 75.0 Hz Vertical, 108 MHzVESA, 1152 x 864
64.0 kHz Horizontal, 60.0 Hz Vertical, 108 MHzVESA, 1280 x 1024
37.5 kHz Horizontal, 75.0 Hz Vertical, 31.5 MHzVESA, 640 x 480
37.9 kHz Horizontal, 60.3 Hz Vertical, 40.0 MHzVESA, 800 x 600
46.9 kHz Horizontal, 75.0 Hz Vertical, 49.5 MHzVESA, 800 x 600
48.4 kHz Horizontal, 60.0 Hz Vertical, 65.0 MHzVESA, 1024 x 768
80.0 kHz Horizontal, 75.0 Hz Vertical, 135 MHzVESA, 1280 x 1024
Tilt, Swivel, Height AdjustableStand
S-Video, Composite, 4 Universal Serial Bus (USB) 2.0 Ports, Kensington security portOther Connectors / Features
100 to 240 VAC / 50 or 60 Hz + 3 Hz / 2.0A (Max.)AC input voltage
Operating (Typical Maximum)
Less than 2W- Active Off
31.5 kHz Horizontal, 70.1 Hz Vertical, 28.3 MHzVESA, 720 x 400
31.5 kHz Horizontal, 59.9 Hz Vertical, 25.2 MHzVESA, 640 x 480
408mm (16.1 inches)Horizontal
306mm (12.1 inches)Vertical
YES (100mm)VESA Mounting Support
Analog, DVI-D (Digital)Connector Type
Less than 1W (at 230 V)- Switched Off
Preset Display Area:
0.255mmPixel Pitch
+/- 89 degrees (vertical), +/- 89 degrees (horizontal)Viewing Angle (Typical)
9.6 Kg (21.2 Ib)Weight (with packaging)
6.9 Kg (15.2 Ib)Weight (Monitor only)
547.6 (extended/portrait) x 367 (compressed/landscape) x 445.3 x 193.5Dimensions (Height x Height x Width x Depth) mm
21.6 (extended/portrait) x 14.5 (compressed/landscape) x 17.5 x 7.6Dimensions (Height x Height x Width x Depth) Inch
Preset Display Modes:
1600 x 1200 at 60 HzOptimal Resolution
56 Hz to 76 Hz (automatic), exception 1600 x 1200 at 60 Hz onlyVertical Scan Frequency Hz
30 kHz to 81 kHz (automatic)Horizontal Scan Frequency kHz
800:1Contrast Ratio (Typical)
300cd/m
2
TypicalLuminance (Brightness)
16msResponse Type (Typical)
20.1 inches (20.1-inch viewable image size)Monitor Size (Viewable Image Screen)
2007FPModel Name and Number
Flat Panel DisplayProduct Category
Recycling: Dell recommends that customers dispose of their used computer hardware, including monitors, in
an environmentally sound manner. Potential methods include reuse of parts or whole products and recycling of
product, components and/or materials. For more information, please visit http://dell.com/recycling_programs
and www.dell.com/environment.

Important Information
Dell cannot be held responsible for typography and photography.
1. DisplaySearch Q3 Quarterly Desktop Monitor Report, “ Top 10 WW LCD PFD Vendors”,
December 2005.
2. Content area determined by total pixel count per given area. Dell UltraSharp 2007FP, 20”
Flat Panel Display’s content area of 1,920,000 pixels (at 1600x1200 resolution) versus the
Dell UltraSharp 1907FP, 19” Flat Panel Display content area of 1,310,720 pixels (at
1280x1024 resolution).
