Dell™ST2010B Flat Panel Monitor User's Guide
Notes, Notices, and Cautions




Information in this document is subject to change without notice.
©2009DellInc.Allrightsreserved.
Reproduction of these materials in any manner whatsoever without the written permission of Dell Inc. is strictly forbidden.
Trademarks used in this text: Dell and the DELLlogoaretrademarksofDellInc;Microsoft and Windows are either trademarks or registered trademarks of
Microsoft Corporation in the United States and/or other countries. ENERGY STAR is a registered trademark of the U.S. Environmental Protection Agency. As an
ENERGY STAR partner, Dell Inc. has determined that this product meets the ENERGY STAR guidelines for energy efficiency.
Other trademarks and trade names may be used in this document to refer to either the entities claiming the marks and names or their products. Dell Inc.
disclaims any proprietary interest in trademarks and trade names other than its own.
Model ST2010f
November 2009 Rev. A00


About Your Monitor
Setting Up the Monitor
Operating the Monitor
Troubleshooting
Appendix

NOTE: A NOTE indicates important information that helps you make better use of your computer.
NOTICE: A NOTICE indicates either potential damage to hardware or loss of data and tells you how to avoid the problem.
CAUTION: A CAUTION indicates a potential for property damage, personal injury, or death.

Back to Contents Page

About Your Monitor
Dell™ST2010B Flat Panel Monitor User's Guide
Package Contents
Your monitor ships with the components shown below. Ensure that you have received all the components and contact Dell if something is missing.


Product Features
The ST2010B flat panel display has an active matrix, thin-film transistor (TFT), liquid crystal display (LCD). The monitor features include:
Package Contents
Product Features
Identifying Parts and Controls
Monitor Specifications
Plug and Play Capability
LCD Monitor Quality and Pixel Policy
Maintenance Guidelines
NOTE: Some items may be optional and may not ship with your Monitor. Some features or media may not
be available in certain countries.
lMonitor with stand
lPower Cable
lVGA Cable (attached to the monitor)
lDrivers and Documentation media
lQuick Setup Guide
lSafety Information

■20-inch ( 444.8*251.1 mm)viewable area display (Measured diagonally) .
■1600 x 900 resolution, plus full-screen support for lower resolutions.
■Tilt capability.
■Plug and play capability if supported by your system.
■On-Screen Display (OSD) adjustments for ease of set-up and screen optimization.
■Software and documentation media includes an information file (INF), Image color Matching File (ICM), and product documentation.
■Energy Saver feature for Energy Star compliance.
■Security lock slot.
Identifying Parts and Controls
Front View
Back View


Front View
On screen control and buttons on Mid Frame
Label
Description
1-2
Shortcut keys
*The default settings are Preset Modes select, Brightness/Contrast select1
1. Preset Modes Select
2. Brightness/Contrast Select
3
OSD menu select
4
EXIT
5
Power button (with power light indicator)
Back view with monitor stand

Side View

Bottom View


Label
Description
Use
1
Barcode serial number label
To contact Dell for technical support.
2
Security lock slot
To help secure your monitor.
3
Regulatory rating label
Lists the regulatory approvals.
4
Dell Soundbar mounting brackets
To attach the optional Dell Soundbar.
Right view
left view


Bottom view

Label
Description
1
AC power cord connector
2
HDMI connector
3
VGA connector
Monitor Specifications
Thefollowingsectionsgiveyouinformationaboutthevariouspowermanagementmodesandpinassignmentsforvariousconnectorsforyourmonitor.
Flat Panel Specifications
Screen type
Active matrix - TFT LCD
Panel type
TN

*[ST2010B] color gamut (typical) is based on CIE1976 (83%) and CIE1931 (72%) test standards.
Screen dimensions
20 inches (20-inch viewable image size)
Preset display area:
442.8 mm (W) X 249.1 mm (H)
Horizontal
442.8 mm (17.43 inches)
Vertical
249.1 mm (9.81 inches)
Pixel pitch
0.2768(H) X 0.2768(W)
Viewing angle
160°(vertical)typical,160°(horizontal)typical
Luminance output
250 cd/m²(typical)
Contrast ratio
1000 to 1 (typical)
Faceplate coating
Anti-Glare
Backlight
2-CCFL edgelight system
Response Time
5ms panel typical
Color depth
16.7 million colors
Color Gamut
83%*
Resolution Specifications
Supported Video Modes
Horizontal scan range
30 kHz to 83 kHz (automatic)
Vertical scan range
56Hzto76Hz(automatic)
Maximum preset resolution
1600x900 at 60 Hz
Video display capabilities (HDMI
playback)
480p, 576p, 720p, 1080p, 480i, 576i, 1080i.
Preset Display Modes
Display Mode
Horizontal Frequency (kHz)
Vertical Frequency (Hz)
Pixel Clock (MHz)
Sync Polarity
(Horizontal/Vertical)
VESA, 720 x 400
31.5
70.0
28.3
-/+
VESA, 640 x 480
31.5
60.0
25.2
-/-
VESA, 640 x 480
37.5
75.0
31.5
-/-
VESA, 800 x 600
37.9
60.7
40.0
+/+
VESA, 800 x 600
46.9
75.0
49.5
+/+
VESA, 1024 x 768
48.4
60.0
65.0
-/-
VESA, 1024 x 768
60.0
75.0
78.8
+/+
VESA, 1152 x 864
67.5
75.0
108.0
+/+
VESA, 1280 x 1024
64.0
60.0
108.0
+/+
VESA, 1280 x 1024
80.0
75.0
135.0
+/+
VESA, 1600 x 900
55.5
60.0
97.75
+/-
Electrical Specifications
Video input signals
Analog RGB, 0.707 Volts +/-5%, positive polarity at 75 ohm input impedance
HDMI, 600mV for each differential line, 100 ohm input impedance per differential pair
Synchronization input signals
Separate horizontal and vertical synchronizations, polarity-free TTL level, SOG (Composite SYNC on
green)
AC input voltage/frequency/current
100 to 240 VAC/50 or 60 Hz +3 Hz/1.5A (Max.)
Inrush current
120 V: 30 A (Max.)
240 V: 60 A (Max.)
Physical Characteristics

Connector type
15-pin D-subminiature, blue connector
19-pin HDMI ,black connector
Signal cable type
Analog: Detachable, D-Sub, 15pins, shipped attached
to the monitor
Dimensions (with stand)
Height
362.3 mm (14.27 inches)
Width
491.0 mm (19.33 inches)
Depth
193.5 mm (7.62 inches)
Dimensions (without stand)
Height
297.4 mm (11.70inches)
Width
491.02 mm (19.29 inches)
Depth
80.4 mm (3.17 inches)
Stand dimensions
Height
127.9 mm (5.01 inches)
Width
193.5 mm (7.62 inches)
Depth
193.5 mm (7.62 inches)
Weight
Weight with packaging
5.475kg ( 12.07 lb)
Weight with stand assembly and cables
4.598kg( 10.14 lb)
Weight without stand assembly
(For wall mount or VESA mount
considerations -no cables)
4.07 kg ( 8.97 lb)
Weight of stand assembly
0.308 kg (0.68 lb)
Environmental Characteristics
Temperature

Operating
0°to40°C
Non-operating
Storage: -20°to60°C
Shipping: -20°to60°C
Humidity
Operating
10% to 80% (non-condensing@5°to35°C)
Non-operating
Storage: 5% to 90% (non-condensing@-20°to60°C)
Shipping: 5% to 90% (non-condensing@-20°to60°C)
Altitude
Operating
3,657.60 m (12,000 ft) max
Non-operating
12,192 m (40,000 ft) max
Thermal dissipation
256.08 BTU/hour (maximum)
119.50 BTU/hour (typical)
Power Management Modes
IfyouhaveVESA'sDPM™compliancedisplaycardorsoftwareinstalledinyourmonitor,themonitorcanautomaticallyreduceitspowerconsumptionwhen
not in use. This is referred to as Power Save Mode*. If the computer detects input from keyboard, mouse, or other input devices, the monitor automatically
resumes functioning. The following table shows the power consumption and signaling of this automatic power saving feature:
Activate the computer and the monitor to gain access to the OSD.
VESA Modes
Horizontal Sync
Vertical Sync
Video
Power Indicator
Power Consumption
Normal operation
Active
Active
Active
White
20 W (typical)
Active-off mode
Inactive
Inactive
Blanked
Amber
Less than 0.5 W
Switch off
-
-
-
Off
Less than 0.5 W

* Zero power consumption in OFF mode can only be achieved by disconnecting the main cable from the monitor



NOTE: This monitor is ENERGY STAR®-compliant .

Back to Contents Page

Appendix
Dell™ST2010BFlatPanelMonitorUser'sGuide
Safety Instructions
FCC Notice (U.S. Only) and Other Regulatory Information
Contacting Dell


CAUTION: Safety Instructions
For information on safety instructions, see the Product Information Guide.
FCC Notices (U.S. Only) and Other Regulatory Information
For FCC notices and other regulatory information, see the regulatory compliance website located at www.dell.com\regulatory_compliance.
Contacting Dell
For customers in the United States, call 800-WWW-DELL (800-999-3355).
Dell provides several online and telephone-based support and service options. Availability varies by country and product, and some services may not be
available in your area. To contact Dell for sales, technical support, or customer service issues:

Back to Contents Page
CAUTION: Use of controls, adjustments, or procedures other than those specified in this documentation may result in exposure to shock,
electrical hazards, and/or mechanical hazards.
NOTE: If you do not have an active Internet connection, you can find contact information on your purchase invoice, packing slip, bill,
or Dell product catalog.
1.
Visit support.dell.com.
2.
Verify your country or region in the Choose A Country/Region drop-downmenuatthebottomofthepage.
3.
Click Contact Us on the left side of the page.
4.
Select the appropriate service or support link based on your need.
5.
Choose the method of contacting Dell that is convenient for you.

Back to Contents Page
Setting Up Your Monitor
Dell™ST2010BFlatPanelMonitor
IfyouhaveaDell™desktoporaDell™portablecomputerwithinternetaccess
1. Go to http://support.dell.com,enteryourservicetag,anddownloadthelatestdriverforyourgraphicscard.
2. After installing the drivers for your Graphics Adapter, attempt to set the resolution to 1600x900 again.
Back to Contents Page
NOTE:
Ifyouareunabletosettheresolutionto1600x900,pleasecontactDell™toinquireaboutaGraphicsAdapterthatsupportstheseresolutions.
