About Your Monitor
Dell™U2412MMonitorUser'sGuide
Package Contents
Your monitor ships with the components shown below. Ensure that you have received all the components and contact Dell if something is missing.

Package Contents
Product Features
Identifying Parts and Controls
Monitor Specifications
Plug and Play Capability
Universal Serial Bus (USB) Interface
LCD Monitor Quality and Pixel Policy
Maintenance Guidelines
NOTE: Some items may be optional and may not ship with your monitor. Some features or media may not be available in certain countries.
NOTE: To set up with anyother stand, please refer to the respective stand setup guide for setup instructions.
lMonitor
lStand
lPower Cable


Product Features
The U2412M flat panel display has an active matrix, Thin-Film Transistor (TFT), Liquid Crystal Display (LCD). The monitor features include:
■60.96 cm (24-inch) viewable area display (measured diagonally). 1920 x 1200 resolution, plus full-screen support for lower resolutions.
■Wide viewing angle to allow viewing from a sitting or standing position, or while moving from side-to-side.
■Tilt, swivel, vertical extension and rotate adjustment capability.
■Removable stand and Video Electronics Standards Association (VESA™) 100 mm mounting holes for flexible mounting solutions.
■Plug and play capability if supported by your system.
■On-Screen Display (OSD) adjustments for ease of set-up and screen optimization.
■Software and documentation media includes an information file (INF), Image Color Matching File (ICM), PowerNap software application and product
documentation.
■Energy Saver feature for Energy Star compliance.
■Security lock slot.
■Stand lock.
■Asset Management Capability.
■Capability to switch from wide aspect to standard aspect ratio while maintaining the image quality.
■EPEAT Gold Rating.
■Halogen Reduced.
■TCO Certified Displays.
■PowerNap Software included (comes in the CD shipped with the monitor).
Identifying Parts and Controls
Front View
lVGA Cable
lDVI Cable
lUSB upstream cable (enables the USB ports on the
monitor)

lDrivers and Documentation media
lQuick Setup Guide
lProduct and Safety Information Guide

Back View
Front view
Front panel controls
Label
Description
1
Preset Modes (default, but configurable)
2
Brightness & Contrast (default, but configurable)
3
Menu
4
Exit
5
Power (with power light indicator)
Back view
Back view with monitor stand
Label
Description
Use
1
VESA mounting holes (100 mm x 100 mm -
behind attached VESA Plate)
Wall mount monitor using VESA-compatible wall mount kit (100 mm x 100 mm)
2
Regulatory label
Lists the regulatory approvals
3
Stand release button
Release stand from monitor
4
Barcode serial number label
Refer to this label if you need to contact Dell for technical support
5
Security lock slot
Secures monitor with security cable lock
6
Dell Soundbar mounting brackets
Attaches the optional Dell Soundbar
7
USB downstream ports
Connect your USB devices
8
Cable management slot
Use to organize cables by placing them through the slot

Side View
Bottom View
Left view
Right view
Bottom view
Bottom view with monitor stand
Label
Description
Use
1
AC power cord connector
Connect the power cable
2
DC power connector for Dell Soundbar
Connect the power cord for the soundbar (optional)
3
DisplayPort connector
Connect your computer DP cable
4
DVI connector
Connect your computer DVI cable
5
VGA connector
Connect your computer VGA cable
6
USB upstream port
Connect the USB cable that came with your monitor to the monitor and the
computer. Once this cable is connected,you can use the USB connectors on
the side and bottom of the monitor
7
USB downstream ports
Connect your USB devices. You can only use this connector after you have
connected the USB cable to the computer and USB upstream connector on
the monitor
8
Stand lock feature
To lock the stand to the monitor using M3 x 6 mm screw (screw is not
provided)

Monitor Specifications
Flat Panel Specifications
*[U2412M] color gamut (typical) is based on CIE1976 (82%) and CIE1931 (72%) test standards.
Resolution Specifications
Supported Video Modes
Preset Display Modes
U2412M
Model
U2412M
Screen type
Active matrix - TFT LCD
Panel type
IPS
Screen dimensions
60.96 cm (24-inches viewable image size)
Preset display area
518.4 (H) X 324.0 (V) mm
Horizontal
518.4 mm (20.3 inches)
Vertical
324.0 mm (12.7 inches)
Pixel pitch
0.27 mm
Viewing angle
178°(vertical)typical
178°(horizontal)typical
Luminance output
300 cd/m²(typical)
Contrast ratio
1000 to 1 (typical), 2M to 1 (typical Dynamic Contrast On)
Faceplate coating
Antiglare with hard-coating 3H
Backlight
LED edgelight system
Response time
8 ms gray-to-gray (typical)
Color depth
16.7 million colors
Color gamut
82%*
Model
U2412M
Horizontal scan range
30 kHz to 83 kHz (automatic)
Vertical scan range
50Hzto61Hz(automatic)
Maximum preset resolution
1920 x 1200 at 60 Hz
Model
U2412M
Video display capabilities (DVI & DP playback)
480p, 576p, 720p, 1080p,
576i, 1080i
Display Mode
Horizontal Frequency
(kHz)
Vertical Frequency (Hz)
Pixel Clock (MHz)
Sync Polarity (Horizontal/Vertical)
VESA, 720 x 400
31.5
70.0
28.3
-/+
VESA, 640 x 480
31.5
59.9
25.2
-/-
VESA, 800 x 600
37.9
60.3
40.0
+/+
VESA, 1024 x 768
48.4
60.0
65.0
-/-
VESA, 1280 x 1024
64.0
60.0
108.0
+/+
VESA, 1600 x 1200
75.0
60.0
162.0
+/+

Electrical Specifications
Physical Characteristics
Environmental Characteristics
VESA, 1680 x 1050
64.7
59.9
119.0
+/-
VESA, 1920 x 1080
66.6
59.9
138.5
+/-
VESA, 1920 x 1200
74.0
60.0
154.0
-/+
Model
U2412M
Video input signals
Analog RGB, 0.7 Volts +/-5%, positive polarity at 75 ohm input
impedance
Digital DVI-D TMDS, 600mV for each differential line, positive polarity at
50 ohm input impedance
DP 1.1a signal input support
Synchronization input signals
TTL levels required and separate syncs (including Trigger points), SOG
(Composite SYNC on green)
AC input
voltage/frequency/current
100 to 240 VAC / 50 or 60 Hz +3 Hz / 1.2 A (typical)
Inrush current
120 V : 30 A (Max)
240 V : 60 A (Max)
Model
U2412M
Connector type
15-pin D-subminiature, blue connector; DVI-D, white
connector; DP, black connector.
Signal cable type
Digital: detachable, DVI-D, solid pins, shipped detached from the monitor
Analog: attachable, D-Sub, 15pins, shipped detached from the monitor
Dimensions (with stand)
Height (extended)
513.5 mm (20.22 inches)
Height (compressed)
398.5 mm (15.69 inches)
Width
556.0 mm (21.89 inches)
Depth
180.3 mm (7.10 inches)
Dimensions (without stand)
Height
361.6 mm (14.24 inches)
Width
556.0 mm (21.89 inches)
Depth
64.9 mm (2.56 inches)
Stand dimensions
Height (extended)
400.7 mm (15.78 inches)
Height (compressed)
285.7 mm (11.25 inches)
Width
279.8 mm (11.02 inches)
Depth
180.3 mm (7.10 inches)
Weight
Weight with packaging
16.48 lbs (7.49 kg)
Weight with stand assembly and cables
13.73 lbs (6.24 kg)
Weight without stand assembly
(For wall mount or VESA mount considerations -
no cables)
8.73 lbs (3.97 kg)
Weight of stand assembly
3.87 lbs (1.76 kg)
Front frame gloss
5.0 gloss unit (max.) (Black Frame)
20.0 gloss unit (max.) (Silver Frame)
Model
U2412M
Temperature
Operating
0°Cto40°C

Power Management Modes
IfyouhaveVESA'sDPM™compliancedisplaycardorsoftwareinstalledinyourPC,themonitorcanautomaticallyreduceitspowerconsumptionwhennotin
use. This is referred to as Power Save Mode*. If the computer detects input from the keyboard, mouse, or other input devices, the monitor automatically
resumes functioning. The following table shows the power consumption and signaling of this automatic power saving feature:
U2412M
The OSD will only function in the normal operation mode. When any button is pressed in Active-off mode, one of the following messages will be displayed:
Activate the computer and the monitor to gain access to the OSD.
* Zero power consumption in OFF mode can only be achieved by disconnecting the main cable from the monitor.
** Maximum power consumption with max luminance, Dell Soundbar, and USB active.
Pin Assignments
VGA Connector
Non-operating
Storage: -20°Cto60°C(-4°Fto140°F)
Shipping: -20°Cto60°C(-4°Fto140°F)
Humidity
Operating
10% to 80% (non-condensing)
Non-operating
Storage: 5% to 90% (non-condensing)
Shipping: 5% to 90% (non-condensing)
Altitude
Operating
3,048 m (10,000 ft) max
Non-operating
10,668 m (35,000 ft) max
Thermal dissipation
245.66 BTU/hour (maximum)
129.66 BTU/hour (typical)
VESA Modes
Horizontal Sync
VerticalSync
Video
Power Indicator
Power Consumption

Normal
operation
Active
Active
Active
Blue
72 W (maximum) **
29 W (typical)
Active-off mode
Inactive
Inactive
Blanked
Amber
Less than 0.5 W
Switch off
-
-
-
Off
Less than 0.5 W
NOTE: This monitor is ENERGY STAR®-compliant.
Pin
Number
15-pin Side of the Connected Signal Cable
1
Video-Red
2
Video-Green

DVIConnector
DisplayPort Connector
3
Video-Blue
4
GND
5
Self-test
6
GND-R
7
GND-G
8
GND-B
9
Computer 5V/3.3V
10
GND-sync
11
GND
12
DDC data
13
H-sync
14
V-sync
15
DDC clock
Pin
Number
24-pin Side of the Connected Signal Cable
1
TMDS RX2-
2
TMDS RX2+
3
TMDS Ground
4
Floating
5
Floating
6
DDC Clock
7
DDC Data
8
Floating
9
TMDS RX1-
10
TMDS RX1+
11
TMDS Ground
12
Floating
13
Floating
14
+5V/+3.3V power
15
Selftest
16
Hot Plug Detect
17
TMDS RX0-
18
TMDS RX0+
19
TMDS Ground
20
Floating
21
Floating
22
TMDS Ground
23
TMDS Clock+
24
TMDS Clock-

Plug and Play Capability
You can install the monitor in any Plug and Play-compatible system. The monitor automatically provides the computer system with its Extended Display
Identification Data (EDID) using Display Data Channel (DDC) protocols so the system can configure itself and optimize the monitor settings. Most monitor
installations are automatic; you can select different settings if desired. For more information about changing the monitor settings, see Operating the Monitor.
Universal Serial Bus (USB) Interface
This section gives you information about the USB ports that are available on the left side of your monitor.
USB Upstream Connector
Pin
Number
20-pin Side of the Connected Signal Cable
1
ML0(p)
2
GND
3
ML0(n)
4
ML1(p)
5
GND
6
ML1(n)
7
ML2(p)
8
GND
9
ML2(n)
10
ML3(p)
11
GND
12
ML3(n)
13
GND
14
GND
15
AUX(p)
16
GND
17
AUX(n)
18
HPD
19
DP_PWR Return
20
+3.3V DP_PWR
NOTE: This monitor supports High-Speed Certified USB 2.0 interface.
Transfer Speed
Data Rate
Power Consumption
High speed
480 Mbps
2.5W(Max,eachport)
Full speed
12 Mbps
2.5W(Max,eachport)
Low speed
1.5 Mbps
2.5W(Max,eachport)

USB Downstream Connector
USB Ports
l1 upstream -back
l4 downstream -2 on the back; 2 on the left side
LCD Monitor Quality and Pixel Policy
During the LCD Monitor manufacturing process, it is not uncommon for one or more pixels to become fixed in an unchanging state which are hard to see and
do not affect the display quality or usability. For more information on Dell Monitor Quality and Pixel Policy, see Dell Support site at: support.dell.com.
Maintenance Guidelines
Cleaning Your Monitor
For best practices, follow the instructions in the list below while unpacking, cleaning, or handling your monitor:
lTo clean your antistatic screen, lightly dampen a soft, clean cloth with water. If possible, use a special screen-cleaning tissue or solution suitable for the
antistatic coating. Do not use benzene, thinner, ammonia, abrasive cleaners, or compressed air.
lUse a lightly-dampened,warmclothtocleanthemonitor.Avoidusingdetergentofanykindassomedetergentsleaveamilkyfilmonthemonitor.
lIf you notice white powder when you unpack your monitor, wipe it off with a cloth.
lHandleyourmonitorwithcareasadarker-colored monitor may scratch and show white scuff marks more than a lighter-coloredmonitor.
lTo help maintain the best image quality on your monitor, use a dynamically changing screen saver and turn off your monitor when not in use.


Back to Contents Page
Pin Number
4-pin Side of the Connector
1
DMU
2
VCC
3
DPU
4
GND
Pin Number
4-Pin Side of the Signal Cable
1
VCC
2
DMD
3
DPD
4
GND
NOTE:USB2.0functionalityrequiresaUSB2.0-
capablecomputer.
NOTE:
The monitor's USB interface works only when the monitor is on or in power save mode. If you turn off the monitor and then turn it on, the attached peripherals may
take a few seconds to resume normal functionality.
WARNING: Read and follow the safety instructionsbeforecleaningthemonitor.
WARNING:Beforecleaningthemonitor,unplugthemonitorpowercablefromtheelectricaloutlet.

Back to Contents Page

Appendix
Dell™U2412MMonitorUser'sGuide
Safety Instructions
FCC Notice (U.S. Only) and Other Regulatory Information
Contacting Dell

WARNING: Safety Instructions
For information on safety instructions, see the Product Information Guide.
FCC Notices (U.S. Only) and Other Regulatory Information
For FCC notices and other regulatory information, see the regulatory compliance website located at www.dell.com\regulatory_compliance.
Contacting Dell
For customers in the United States, call 800-WWW-DELL (800-999-3355).
Dell provides several online and telephone-based support and service options. Availability varies by country and product, and some services may not be
available in your area. To contact Dell for sales, technical support, or customer service issues:

Back to Contents Page
WARNING: Use of controls, adjustments, or procedures other than those specified in this documentation may result in exposure to shock,
electrical hazards, and/or mechanical hazards.
NOTE:
If you do not have an active Internet connection, you can find contact information on your purchase invoice, packing slip, bill, or Dell product catalog.
1.
Visit support.dell.com.
2.
Verify your country or region in the Choose A Country/Region drop-downmenuatthebottomofthepage.
3.
Click Contact Us on the left side of the page.
4.
Select the appropriate service or support link based on your need.
5.
Choose the method of contacting Dell that is convenient for you.

Back to Contents Page
Help on PowerNap Installation
To install PowerNap succesfully, follow these steps:-
Back to Contents Page
1.CheckOperatingSystemRequirements
Windows XP, Windows Vista®, Windows®7
2. Install Entech API
Install
3.InstallPowerNapSoftware
Install

Back to Contents Page
Setting Up Your Monitor
Dell™U2412MMonitor
IfyouhaveaDell™desktoporaDell™portablecomputerwithinternetaccess
1. Go to http://support.dell.com,enteryourservicetag,anddownloadthelatestdriverforyourgraphicscard.
2. After installing the drivers for your Graphics Adapter, attempt to set the resolution to 1920 x 1200 again.
Back to Contents Page
NOTE:
Ifyouareunabletosettheresolutionto1920x1200,pleasecontactDell™toinquireaboutaGraphicsAdapterthatsupportstheseresolutions.

Back to Contents Page
Setting Up Your Monitor
Dell™U2412MMonitor
IfyouhaveanonDell™desktop,portablecomputer,orgraphicscard
In Windows XP:
1. Right-click on the desktop and click Properties.
2. Select the Settings tab.
3. Select Advanced.
4. Identify your graphics controller supplier from the description at the top of the window (e.g. NVIDIA, ATI, Intel etc.).
5. Refer to the graphic card provider website for updated driver (for example, http://www.ATI.com OR http://www.NVIDIA.com ).
6. After installing the drivers for your Graphics Adapter, attempt to set the resolution to 1920 x 1200 again.
In Windows Vista®or Windows®7:
1. Right-click on the desktop and click Personalization.
2. Click Change Display Settings.
3. Click Advanced Settings.
4. Identify your graphics controller supplier from the description at the top of the window (e.g. NVIDIA, ATI, Intel etc.).
5. Refer to the graphic card provider website for updated driver (for example, http://www.ATI.com OR http://www.NVIDIA.com ).
6. After installing the drivers for your Graphics Adapter, attempt to set the resolution to 1920 x 1200 again.
Back to Contents Page
NOTE: If you are unable to set the resolution to 1920 x 1200, please contact the manufacturer of your computer or consider purchasing a graphics
adapter that will support the video resolution of 1920 x 1200.

Back to Contents Page

Operating the Monitor

Dell™U2412MMonitorUser'sGuide
Using the Front Panel Controls
Using the On-Screen Display (OSD) Menu
PowerNap Software
Setting the Maximum Resolution
Using the Dell Soundbar (Optional)
Using the Tilt, Swivel, and Vertical Extension
Rotating the monitor
Adjusting the Rotation Display Settings of Your System
Using the Front Panel
Use the control buttons on the front of the monitor to adjust the characteristics of the image being displayed. As you use these buttons to adjust the controls,
an OSD shows the numeric values of the characteristics as they change.
The following table describes the front panel buttons:
Front Panel Button
Description
1
Shortcut
key/
Preset
Modes
Use this button to choose from a list of preset color modes.
2
Shortcut key /
Brightness/Contrast
Use this button to directly access the "Brightness/Contrast" menu.
3
Menu
Use the MENU button to launch the on-screen display (OSD) and select the OSD Menu. See Accessing the Menu
System.
4
Use this button to go back to the main menu or exit the OSD main menu.

Using the On-Screen Display (OSD) Menu

Accessing the Menu System
1. Push the button to launch the OSD menu and display the main menu.
Main Menu for analog (VGA) input
or
Main Menu for digital (DVI) input
Exit
5
Power
(withpowerlight
indicator)
Use the Power button to turn the monitor on and off.
The blue LED indicates the monitor is on and fully functional. An amber LED indicates power save mode.

NOTE: IfyouchangethesettingsandtheneitherproceedtoanothermenuorexittheOSDmenu,themonitorautomaticallysavesthosechanges.The
changes are also saved if you change the settings and then wait for the OSD menu to disappear.

or
Main Menu for display (DP) input
2.Push the and buttons to move between the setting options. As you move from one icon to another, the option name is highlighted. See the
followingtableforacompletelistofalltheoptionsavailableforthemonitor.
3.Push the buttononcetoactivatethehighlightedoption.
4.Push and button to select the desired parameter.
5. Push to enter the slide bar and then use the and buttons, according to the indicators on the menu, to make your changes.
NOTE: Auto Adjust is only available when you use the analog (VGA) connector.

6.Select the button to return to the main menu.
Icon
Menu and
Submenus
Description


Brightness/Contrast
Use this menu to activate Brightness/Contrast adjustment.

Brightness
Brightness adjusts the luminance of the backlight.
Push the button to increase brightness and push the button to decrease brightness (min 0 ~ max 100).
NOTE: Manual adjustment of Brightness is disabled when Energy Smart or Dynamic Contrast is switched on.
Contrast
Adjust Brightness first, and then adjust Contrast only if further adjustment is necessary.
Push the button to increase contrast and push the button to decrease contrast (min 0 ~ max 100).
The Contrast function adjusts the degree of difference between darkness and lightness on the monitor screen.


Auto Adjust
Even though your computer recognizes your monitor on startup, the Auto Adjustment
function optimizes the display settings for use
with your particular setup.
Auto Adjustment allows the monitor to self-
adjust to the incoming video signal. After using Auto Adjustment, you can further tune your
monitor by using the Pixel Clock (Coarse) and Phase (Fine) controls under Display Settings.

NOTE: Inmostcases,AutoAdjustproducesthebestimageforyourconfiguration.
NOTE: Auto Adjust option is only available when you are using the analog (VGA) connector.

Input Source
Use the Input Source menu to select between different video signals that may be connected to your monitor.


Auto Select
Push to select Auto Select, the monitor will auto detect either VGA input or DVI-D input or DislpayPort input.
VGA
Select VGA input when you are using the analog (VGA) connector. Push to select the VGA input source.
DVI-D
Select DVI-D input when you are using the Digital (DVI) connector. Push to select the DVI input source.
DisplayPort
Select DisplayPort input when you are using the DisplayPort (DP) connector. Push
to select the DisplayPort input source.

Color Settings
Use Color Settings to adjust the color setting mode and color temperature.
There are different color setting sub-menus for VGA/DVI-D and Video input.

Input Color Format
Choose the RGB option if monitor is connected to a computer or a DVD using a VGA or DVI cable. Choose the YPbPr option if monitor is
connected to a DVD by a YPbPr to VGA or YPbPr to DVI cable or if the DVD color output setting is not RGB.
