Dell P4317Q User manual

Model No.: P4317Q
Regulatory model: P4317Qc
User’s Guide
Dell P4317Q

Notes, cautions, and warnings
NOTE: A NOTE indicates important information that helps you make better
use of your computer.
CAUTION: A CAUTION indicates potential damage to hardware or loss of
data if instructions are not followed.
WARNING: A WARNING indicates a potential for property damage, personal
injury or death.
_________________________
Information in this document is subject to change without notice.
© 2016 Dell Inc. All rights reserved.
Reproduction of these materials in any manner whatsoever without the written permission
of Dell Inc. is strictly forbidden.
Trademarks used in this text: Dell and the DELL logo are trademarks of Dell Inc.; Microsoft
and Windows are either trademarks or registered trademarks of Microsoft. Corporation in
the United States and/or other countries, Intel is a registered trademark of Intel Corporation
in the U.S. and other countries; and ATI is a trademark of Advanced Micro Devices, Inc.
ENERGY STAR is a registered trademark of the U.S. Environmental Protection Agency. As an
ENERGY STAR partner, Dell Inc. has determined that this product meets the ENERGY STAR
guidelines for energy efficiency.
Other trademarks and trade names may be used in this document to refer to either the
entities claiming the marks and names or their products. Dell Inc. disclaims any proprietary
interest in trademarks and trade names other than its own.
2016 - 03 Rev. A00

Contents | 3
Contents
About your monitor ................................................................ 5
Package contents.......................................................................................5
Product features.........................................................................................6
Monitor specifications............................................................................... 7
Universal Serial Bus (USB) Interface .....................................................16
Identifying parts and controls................................................................18
Plug and play capability ..........................................................................21
LCD monitor quality and pixel policy...................................................21
Maintenance guidelines.......................................................................... 21
Setting up the monitor .........................................................22
Attaching the stand..................................................................................22
Connecting your monitor ......................................................................23
Removing the monitor stand.................................................................27
Wall Mounting (Optional) .......................................................................27

4| Contents
Operating your monitor.......................................................28
Power on the monitor.............................................................................28
Using the front panel controls ..............................................................28
Using the on-screen display (OSD) menu ......................................... 30
Setting up your monitor..........................................................................45
Setting the maximum resolution ..........................................................45
Using tilt .................................................................................................... 46
Troubleshooting....................................................................47
Self-test ......................................................................................................47
Built-in diagnostics ................................................................................. 48
Common problems ................................................................................ 49
Product-specific problems .................................................................... 51
Universal Serial Bus (USB) specific problems .....................................52
Mobile high-definition link (MHL) specific problems .......................52
Appendix ....................................................................................................53
FCC notices (U.S. Only) and other regulatory information.............53
Contacting Dell.........................................................................................53

About your monitor | 5
About your monitor
Package contents
Your monitor ships with the components shown below. Ensure that you have
received all the components and Contacting Dell if something is missing.
NOTE: Some items may be optional and may not ship with your monitor. Some
features or media may not be available in certain countries.
NOTE: To set up with any other stand, please refer to the respective stand setup
guide for setup instructions.
∞ Monitor
∞ Stand riser
∞ Stand base
3
2
∞ VESA cover
∞ Power cable (varies by
countries)
∞ HDMI cable

6| About your monitor
∞ mDP to DP cable
∞ DP to DP cable
∞ USB 3.0 upstream cable
(enables the USB ports on
the monitor)
DellTM UltraSharp U2715H Monitor
∞ Drivers and
Documentation Guide
∞ Quick Setup Guide
∞ Safety and Regulatory
Information
Product features
The Dell P4317Q flat panel display has an active matrix, Thin-Film Transistor (TFT),
Liquid Crystal Display (LCD), and LED backlight. The monitor features include:
∞ 107.98 cm (42.51 inch) viewable area display (measured diagonally). 3840 x 2160
resolution, plus full-screen support for lower resolutions.
∞ Plug and play capability if supported by your system.
∞ VGA and HDMI (MHL) and DP and mDP connectivity makes it simple and easy to
connect with legacy and new system.
∞ Build-in Speaker (8W x 2).
∞ On-Screen Display (OSD) adjustments for ease of set-up and screen
optimization.
∞ Software and documentation media includes an Information File (INF), Image
Color Matching File (ICM), and product documentation.
∞ Dell Display Manager Software included (in the CD shipped with the monitor).
∞ Support PIP and PBP Function.

About your monitor | 7
Monitor specifications
Model P4317Q
Screen type Active matrix - TFT LCD
Panel type In-plane Switching
Viewable image
Bezel width
Diagonal
Horizontal, Active Area
Vertical, Active Area
Area
566.40 mm (22.30 in)
107.98 cm (42.51 in)
941.18 mm (37.05 in)
529.42 mm (20.84 in)
1274.79 cm2(197.59 inch2)
Pixel pitch 0.2451 x 0.2451 mm
Viewing angle (vertical
/ horizontal)
178° / 178° (typical)
Brightness 350 cd/m² (typical)
Contrast ratio 1000 to 1 (typical)
Aspect Ratio 16:9
Display screen coating Anti-Glare with 2H hardness
Backlight Technology white LED edgelight system
Response time 8 ms
Color depth 1.06 Billion colors
PIP / PBP Yes
Connectivity 1 x DP 1.2
1 x mDP 1.2
2 x HDMI 1.4 (MHL)
1 x VGA
1 x USB 3.0 port - Upstream
4 x USB 3.0 port
1 x Audio Input
1 x Headphone Output
1 x RS232
Audio output 8W x 2
Built in device - usb Upstream x 1
Downstream x 4 (including one Charging Port)

8| About your monitor
DDM compatibility Yes
Adjustability
Tilt -5° to 10°
Security Security lock slot (cable lock sold separately)
* 72% (CIE 1931), 82%(CIE 1976)
Resolution specifications
Model P4317Q
Horizontal scan range 30 kHz to 83 kHz (automatic)
Vertical scan range 56 Hz to 76 Hz (automatic)
Maximum preset
resolution
3840 x 2160 at 60 Hz (DP only)
Preset display modes
Display Mode Horizontal
Frequency
(kHz)
Vertical
Frequency
(Hz)
Pixel Clock
(MHz)
Sync Polarity
(Horizontal /
Vertical)
VESA, 720 x 400 31.5 70.1 28.3 -/+
VESA, 640 x 480 31.5 60.0 25.2 -/-
VESA, 640 x 480 37.5 75.0 31.5 -/-
VESA, 800 x 600 37.9 60.3 40.0 +/+
VESA, 800 x 600 46.9 75.0 49.5 +/+
VESA, 1024 x 768 48.4 60.0 65.0 -/-
VESA, 1024 x 768 60.0 75.0 78.8 +/+
VESA, 1280 x 1024 64.0 60.0 108.0 +/+
VESA, 1280 x 1024 80.0 75.0 135.0 +/+
VESA, 1440 x 900 55.5 60.0 88.8 +/-
VESA, 1440 x 900 70.1 75.0 136.8 -/+
**VESA, 1920 x 1080 67.5 60.0 148.5 +/+
VESA, 3840 x 2160 67.5 30.0 297.0 +/+
*VESA, 3840 x 2160 135.0 60.0 594.0 +/+
* Requires a graphics card that supports DisplayPort 1.2
** PBP mode maximum resolution support 1920x1080@60Hz

About your monitor | 9
Electrical specifications
Model P4317Q
Video input signals ∞ Analog RGB, 0.7 Volts +/-5%, positive polarity at 75
ohm input impedance
∞ HDMI1.4, 600 mV for each differential line, positive
polarity at 100 ohm input impedance
Synchronization input
signals
Separate horizontal and vertical synchronizations,
polarity-free TTL level, SOG (Composite SYNC on
green)
AC input voltage/frequency/
current
100 VAC to 240 VAC/50 Hz or 60 Hz ± 3 Hz/
2 A
Inrush current 120 V:30 A (Max.)
240 V:60 A (Max.)
Physical characteristics
Model P4317Q
Signal cable type ∞ Analog: detachable, D-Sub, 15 pins
∞ Digital: detachable, HDMI, 19 pins
∞ Digital: detachable, mDP, 20 pins
∞ Digital: detachable, DP, 20 pins
Dimensions (with stand)
Height 658.0 mm (25.90 in)
Width 973.1 mm (38.31 in)
Depth 250.0 mm (9.84 in)
Dimensions (without stand)
Height 566.4 mm (22.29 in)
Width 973.1 mm (38.31 in)
Depth 83.0 mm (3.27 in)
Stand dimensions
Height 488.6 mm (19.24 in)
Width 320.0 mm (12.60 in)
Depth 250.0 mm (9.84 in)
Weight
Weight with packaging 24.4 kg (53.78 lb)
Weight with stand
assembly and cables
17.93 kg (39.51 lb)

10 | About your monitor
Weight without stand
assembly
14.11 kg (31.09 lb)
Weight of stand
assembly
3.3 kg (7.26 lb)
Caution: Any third-party arm or pole purchased separately should support the weight
of the monitor as well as any external brackets and interface plates.
Environmental characteristics
Model P4317Q
Temperature
Operating 0°C to 40°C (32°F to 104°F)
Non-operating Storage ∞ -20°C to 60°C (-4°F to 140°F)
∞ -20°C to 60°C (-4°F to 140°F)
Shipping
Humidity
Operating 10% to 80% (non-condensing)
Non-operating ∞ Storage: 5% to 90% (non-condensing)
∞ Shipping: 5% to 90% (non-condensing)
Altitude
Operating (maximum) 5,000 m (16,400 ft)
Non-operating (maximum) 12,192 m (40,000 ft)
Thermal dissipation ∞ 494.9 BTU/hour (maximum)
∞ 238.9 BTU/hour (typical)
Power management modes
If you have VESA's DPM™ compliance display card or software installed in your PC,

About your monitor | 11
the monitor can automatically reduce its power consumption when not in use. This
is referred to as Power Save Mode*. If the computer detects input from the keyboard,
mouse or other input devices, the monitor automatically resumes functioning. The
following table shows the power consumption and signaling of this automatic power
saving feature.
* Zero power consumption in off mode can only be achieved by disconnecting the
main cable from the monitor.
VESA
Modes
Horizontal
Sync
Vertical
Sync
Video Power
Indicator
Power
Consumption
Normal
operation
Active Active Active White < 160 W (maximum)**
< 70 W (typical)
Active-off
mode
Inactive Inactive Blanked White
(Glowing )
Less than 0.3 W
Switch off - - - Off Less than 0.3 W
Speaker specifications
Model P4317Q
Speaker rated power 2 x 8 W
Frequency Response 200 Hz - 16 kHz
Impedance 6 ohm
The OSD functions only in the normal operation mode. When any button is pressed
in the Active-off mode, the following message will be displayed:
Dell P4317Q
No VGA signal from your device.
?
Press any key on the keyboard or move the mouse to wake it up.
the correct input source.
If there is no display, press the monitor button again to select
Activate the computer and the monitor to gain access to the OSD.

12 | About your monitor
Pin assignments
VGA connector
Pin Number 15-pin Side of the Connected Signal Cable
1 Video-Red
2 Video-Green
3 Video-Blue
4 GND
5 Self-test
6 GND-R
7 GND-G
8 GND-B
9 Computer 5V/3.3V
10 GND-sync
11 GND
12 DDC data
13 H-sync
14 V-sync
15 DDC clock

About your monitor | 13
HDMI connector
Pin Number 19-pin Side of the Connected Signal Cable
1 T.M.D.S. Data 2-
2 T.M.D.S. Data 2 Shield
3 T.M.D.S. Data 2+
4 T.M.D.S. Data 1+
5 T.M.D.S. Data 1 Shield
6 T.M.D.S. Data 1 -
7 T.M.D.S. Data 0+
8 T.M.D.S. Data 0 Shield
9 T.M.D.S. Data 0-
10 T.M.D.S. Clock +
11 T.M.D.S. Clock Shield
12 T.M.D.S. Clock -
13 CEC
14 Reserved (N.C. on device)
15 SCL
16 SDA
17 DDC/CEC Ground
18 +5V Power
19 Hot Plug Detect

14 | About your monitor
DP connector
119
220
Pin Number 20-pin Side of the Connected Signal Cable
1 ML0(p)
2 GND
3 ML0(n)
4 ML1(p)
5 GND
6 ML1(n)
7 ML2(p)
8 GND
9 ML2(n)
10 ML3(p)
11 GND
12 ML3(n)
13 GND
14 GND
15 AUX(p)
16 GND
17 AUX(n)
18 GND
19 Re-PWR
20 +3.3V DP_PWR

About your monitor | 15
Mini DP connector
119
2
20
Pin Number 20-pin Side of the Connected Signal Cable
1 GND
2 Hot Plug Detect
3 ML3(n)
4 GND
5 ML3(n)
6 GND
7 GND
8 GND
9 ML2(n)
10 ML0(n)
11 ML2(p)
12 ML0(p)
13 GND
14 GND
15 ML1(n)
16 AUX(P)
17 ML1(p)
18 AUX(N)
19 GND
20 +3.3V DP_PWR

16 | About your monitor
Universal Serial Bus (USB) Interface
This section gives you information about the USB ports that are available on the
monitor.
NOTE: This monitor is Super-Speed USB 3.0 compatible.
Transfer Speed Data Rate Power Consumption*
Super-speed 5 Gbps 4.5 W (Max, each port)
High speed 480 Mbps 4.5 W (Max, each port)
Full speed 12 Mbps 4.5 W (Max, each port)
* Up to 1.5A on USB downstream port (port with battery icon) with BC1.2
compliance devices or normal USB devices.
USB Upstream Connector
Pin Number 9-pin Side of the Connector
1 VCC
2 D-
3 D+
4 GND
5 SSTX-
6 SSTX+
7 GND
8 SSRX-
9 SSRX+

About your monitor | 17
USB Downstream Connector
Pin Number 9-pin Side of the Connector
1 VCC
2 D-
3 D+
4 GND
5 SSTX-
6 SSTX+
7 GND
8 SSRX-
9 SSRX+
USB Ports
∞ 1 upstream - blue
∞ 4 downstream - blue
∞ Power Charging Port- the port with battery icon; supports current
charging capability if the device is BC1.2 compatible.
NOTE: USB 3.0 functionality requires a USB 3.0-capable computer.
NOTE: The monitor’s USB interface works only when the monitor is on or in the
power save mode. If you turn off the monitor and then turn it on, the attached
peripherals may take a few seconds to resume normal functionality.

18 | About your monitor
Identifying parts and controls
Front View
Front panel controls
2
1
Label Description
1Function buttons (For more information, see Operating your monitor)
2Power on/off button (with LED indicator)
NOTE: For displays with glossy bezels the user should consider the placement of
the display as the bezel may cause disturbing reflections from surrounding light
and bright surfaces.

About your monitor | 19
Back view
45
2
3
Q40G043N-700-01A
䊂
XXXXXX-XX
XXXXXXXX
MSIP-REM-TPV-P4317Qc
㐔㷡㢬ڕTOPVICTORY
ELECTRONICS(FUJIAN)CO.,LTD.
㥐㦤㣄ڕTPVElectronics(Fujian)Co., Ltd.
080-200-3800
P4317Qc
CANICES-3(B)/NMB-3(B)
Удельнаямощностьрабочего режима - XXXВт/см²
Потребляемаямощностьизделием в режиме ожидания - XXX Вт
Потребляемаямощностьизделием в выключенном режиме - XXX Вт
MODELNO./ NUMÉRO DE MODÈLE /ൟোൟ㰳모델명:P4317Qc
MonitorPlanoPanel /Moniteur écran plat /⎆᱊乃⼎఼/⎆᱊ᰒ⼎఼
䔌ܹ䳏⑤:
Ѹ⌕䳏ວ100-240 ,0.75-0.3ᅝ෍, 50/60䌿㤆
:100-240V 50/60Hz,0.75-0.3A(1.6Afor Mexico)
Consumodeenergía: XXX Wh
Consumodeenergía en modo de espera: XXX Wh
MadeinChina /сделанный в Китай /FabriquéenChine /Ё೑ࠊ䗴/Ё೟㻑䗴
1
Back View with monitor stand
Label Description Use
1VESA mounting holes behind
attached VESA Cover:
1) 100 mm x 100 mm
2) 200 mm x 200 mm
Wall mount monitor using the
compatible wall-mount kits for the
specific VESA mounting holes.
2Regulatory label Lists the regulatory approvals.
3Security - lock slot Secures monitor with security lock
(security lock not included).
4Barcode serial number label Refer to this label if you need to
contact Dell for technical support.
5Cable management slot Use to organize cables by placing
them through the slot.
Side view
Back View without monitor stand

20 | About your monitor
Bottom view
2345 6 78910 11 12
1
Bottom view without monitor stand
Label Description Use
1AC power cord
connector
To connect the monitor power cable.
2RS232 port To connect your computer to the monitor using a
RS232 cable.
3HDMI/MHL 1 port
connector Connect your computer with HDMI/MHL cable.
4HDMI/MHL 2 port
connector
5mini DisplayPort To connect your computer to the monitor using a
mDP to DP cable.
6DisplayPort To connect your computer to the monitor using a DP
to DP cable.
7VGA port To connect your computer to the monitor using a
VGA cable.
8Audio Line In port Connects the audio cable (optional purchase) from
the source device to the monitor.
9Headphone Out port Connect to external headphone (optional purchase)
10 USB upstream port Connect the USB cable that comes with your monitor
to the computer. Once this cable is connected, you
can use the USB connectors on the monitor.
11
12
USB downstream
port
Connect your USB device. You can only use this
connector after you have connected the USB cable
to the computer and USB upstream connector on the
monitor. *
* It is use the port (12) support battery charging.
