Reliability, Availability and Serviceability
The PowerEdge™ 2800 server features enterprise-level high availability features like optional hot-pluggable
redundant power, hot-pluggable redundant cooling and even hot-pluggable PCI slots which allow you to
replace components on the fly without taking your server offline. In addition, memory availability features
such as ECC, SDDC, memory mirroring and spare bank memory help to ensure high data integrity and
uptime.
Expandable Performance and Incredible Storage Capacity
The PowerEdge™ 2800 system delivers the latest in processor, memory and local I/O throughput
technologies. Plus, it includes as many as seven PCI/PCI-X® or PCI Express™ slots. The PowerEdge™ 2800
server’s combination of high performance and large storage capacities make it an ideal choice for server
and storage consolidation projects. And this flexible server can be deployed as either a tower or a 5U rack-
mountable unit. The ten hard drive bays not only provide scalable high performance, they also offer the
ability to store multiple terabytes of data to help you keep up with rapidly growing storage requirements.
Simple Manageability and Serviceability
Designed with built-in manageability with the standard Baseboard Management Controller (IPMI 1.5
compliant), administrators can manage their server with any standard management application that
supports IPMI. The optional DRAC4/I advanced remote management card provides even greater levels of
management with continuous video, virtual floppy/CD and Active Directory support. The Dell™ OpenManage™
IT Assistant and Dell™ OpenManage™ Server Administrator help reduce management costs and hassles. And
its easily accessible chassis makes service easy. The PowerEdge™ 2800 shares the same system board
drivers and BIOS with the PowerEdge™ 1850 and 2850, helping to reduce your Total Cost Of Ownership.
The PowerEdge™ 2800 server is a feature-optimised workgroup class server that offers new levels of
availability, performance, storage capacity and manageability.
The dual processor Dell™ PowerEdge™
2800 server delivers aggressive
performance, massive internal storage
capacity and outstanding reliability in
either a tower server or rack-mountable
chassis to handle your growing data
storage needs and keep your business
running.
Dell™ PowerEdge™
2800 Server
Dell™ PowerEdge™ 2800

1 With availability of the single ranked 2GB DIMMs scheduled for Q4 2004.
2 Availability scheduled for Q3 2004.
3 For hard drives, GB means 1 billion bytes; accessible capacity varies with operating environment.
4 Dell Services programs are subject to the service radius restrictions within the country. On-site service provided by independent third-party service provider
and many not be available in certain remote locations. Dell systems, which are not located within the four-hour or two-hour service coverage, will receive
the service levels on next business day basis or best effort basis and subject to service capabilities of the nominated Dell Service Provider. Except for 24X7
services, calls will only be accepted up to 5p.m. local time. Technician shall be dispatched if necessary following telephone technical support
5 On-site service provided by independent third-party service provider and may not be available in certain remote locations. Technician shall be dispatched
if necessary following telephone technical support.
DELL’S NORMAL TERMS AND CONDITIONS APPLY AND ARE AVAILABLE ONLINE OR UPON REQUEST. All efforts will be made to check for errors in typography
and photography; however inadvertent errors may occur for which Dell may not be responsible. Dell, the Dell logo, PowerEdge, PowerVault and OpenManage
are registered trademarks or trademarks of Dell Inc. Microsoft and Windows are either registered trademarks or trademarks of Microsoft Corporation in the
United States and/or other countries. Intel, the Intel Inside logo, Pentium and Xeon are either registered trademarks or trademarks of Intel Corporation or
its subsidiaries in the United States and/or other countries. Other trademarks and trade names may be used in this document to refer to either the entities
claiming marks and names or their products. Dell disclaims proprietary interest in the marks and names of others.
Copyright 2004 Dell Inc. All rights reserved.
Dell™ PowerEdge™ 2800 Server
DELL ENTERPRISE SERVICES
By leveraging the proven advantages of our direct model, including
tailored service and support, low cost and a single point of
accountability, Dell Services can provide you with fast, effective,
affordable service offerings at any point in your IT process. By doing
so, we offer a combination of bundled best practices and tailored
solutions that work together to provide maximum value to you.
Whether you need support, deployment, or training and certication
programs, individually or bundled as a total package, Dell promises to
be your single point of accountability at all times.
Dell Enterprise Deployment Services Can Help Improve IT
Efciency
We bring you deployment assistance that delivers true value
from beginning to end. Dell can tailor systems to our customers’
specications by customising the hardware and software conguration
during the initial system-build to reduce redundancy and time. We can
manage the delivery, installation and disposal of your assets with the
same eye for efciency.
Dell Training and Certication Can Help Your Staff Keep Up
with New Technology
Our approach to Training and Certication allows you to outsmart your
competitors – not outspend them – with industry standard learning
across Dell hardware and industry standard software. Dell can
assist you wherever you need us, whether on-site, or in a classroom
setting, to help your organisation take full advantage of information
technology.
Service
Ideal for
On-site Spares (customer owned)
On-site Engineer
On-site Troubleshooting
• Customer Traning
• Change Notication (Patch Fix,
FCO, OpenManage Subscription)
• Customer-Dened call priority
Seamless Support
• Technical Account Manager
(TAM)
• Remote Software Support
• On-site Hardware Support
• Technical Support
Lifetime Hardware Phone Support
4-Hour4
Development
Environments
Optional Resolution
Pack
7x24, hours response
Level 1
7x24
Next Business Day5
Testing for File/ Print
environments
Optional Resolution
Pack
Next Business Day
Response (upgrade
to standard warranty)
Level 1
7x24
For more information on the available services in your area, please visit www.dell.com/
ap/services
FEATURES DESCRIPTION
Form factor Tower or 5U rack-mount
Processors Up to two single-core 64-bit Intel® Xeon™ processors at up to 3.8GHz or
up to two dual-core 64-bit Intel Xeon processor at 2.8GHz
Front side bus 800MHz
Cache Up to 2MB L2 per processor core
Chipset Intel E7250
Memory 256MB/12GB DDR-2 400 SDRAM; 16GB with availability of dual rank
4GB DIMMS1
I/O channels Seven total: two PCI Express™ slots (1 x 4 lane and 1 x 8 lane);
four PCI-X™ slots (64-bit/133MHz); one PCI slot (32-bit/33MHz, 5v)
Drive controller Embedded dual channel Ultra320 SCSI
RAID controller Optional dual channel ROMB (PERC4/Di), PERC4/DC and PERC4e/DC2
Drive bays Eight 1” + Two 1” Ultra320 hot-plug SCSI drives with internal tape drive
support
Maximum internal storage Up to 1.46GB or up to 3TB with availability of 300GB hard drive
Hard drives 36GB, 73GB, 146GB and 300GB3 (10,000 rpm) Ultra320 SCSI 18GB, 36GB,
73GB and 146GB (15,000 rpm) Ultra320 SCSI
Internal storage 10K/15K RPM SCSI drives
External storage Dell PowerVault™ SCSI and Dell/EMC® fibre channel storage
Tape backup options Internal: PowerVault 100T and 110T
External: PowerVault 114T, 122T, 132T, 136T and 160T
Network interface card Dual embedded Intel 10/100/1000 Gigabit NIC, Intel PRO/1000 MT Gigabit
NIC (copper), Intel PRO/1000 MF Gigabit NIC (fibre)
Power supply 930W, optional hot-plug redundant power
Availability ECC memory, Hot-plug PCI Express slots, Single Device Data Correction
(SDDC), Spare Bank, Memory Mirroring; hot-plug SCSI hard drives; optional
hot-plug redundant power; hot-plug redundant cooling; tool-less chassis;
high availability fibre channel and SCSI cluster support; optional ROMB with
battery-backed cache; optional Split Backplane; LCD panel; Active ID
Video Embedded ATI Radeon 7000-M with 16MB SDRAM
Remote management Baseboard Management Controller with IPMI 1.5 compliance, accessible via
network or serial port; optional slot-free DRAC4/I
Systems management Dell OpenManage™
Rack support 4-post (Dell rack) and 3rd party
Operating systems Microsoft® Windows® Server 2003, Standard x64 Edition; Microsoft
Windows Server 2003; Enterprise x64 Edition, Microsoft Windows Server
2003, Standard Edition; Microsoft Windows Server 2003, Enterprise Edition;
Microsoft Windows Small Business Server 2003, Standard/Premium Red Hat®
Linux® Enterprise v2.1 AS and ES; Red Hat Linux Enterprise v3 AS and ES; Red
Hat Linux Enterprise v3 Advance Server EM64T; Novell® NetWare® 5.1 and
6.5
Visit www.dell.com/ap for more information.
