The 1-socket Dell™ PowerEdge™T320 tower server delivers performance, scalability and
enterprise-class reliability, availability, and serviceability (RAS) capabilities, enabling users to grow
their businesses and organizations and become more productive. The T320’s balanced combination
of compute power, memory capacity, and I/O bandwidth make it an excellent fit for collaboration
and productivity applications, file and print serving, mail and messaging, and data coordination and
sharing. In addition, the T320’s robust design and innovative manageability make it a trustworthy
server for branch offices and remote sites that might not have technical IT skills onsite.
Featuring the extensive performance of the Intel®Xeon®processor E5-2400 product family, and
boasting up to six DIMM slots for memory and five PCIe slots for broad I/O bandwidth, the T320
delivers balanced performance and built-in room for growth. Capacity for up to eight 3.5-inch or
sixteen 2.5-inch hard drives accommodate storage as your business or organization expands. For
users not needing the Enterprise-class high performance of the Intel Xeon E5-2400 processors, the
T320 also supports the more price-sensitive Intel Xeon processor E5-1410 and Intel Pentium®
processor 1400 product family.
Users selecting the Intel Xeon processor E5-2400 product family can choose to implement
advanced memory protection capabilities (memory sparing and memory mirroring) previously not
seen in the 1-socket x86 server space. These capabilities are not possible with the Intel Xeon
processor E5-1410 and the Intel Pentiumprocessor 1400 product family. Regardless of the
processor type, you can take advantage of other high availability features offered on the T320. To
protect your virtualized workloads, the T320 offers redundant dual SD media cards making your
hypervisors failsafe. Other reliability and availability features that give you peace of mind include
hot-plug hard drives, both hardware and software RAID options, redundant fans and hot-plug power
supplies. Last, but not least, the T320’s quiet acoustical profile allows it to fit unobtrusively into quiet
office environments.
The PowerEdge family is engineered with the right combination of features and performance
scalability to handle tough workloads for businesses and organizations of all sizes.
The Dell OpenManage™ systems management portfolio includes the Integrated Dell Remote Access
Controller 7 (iDRAC7) with Lifecycle Controller. This embedded feature helps IT administrators
manage Dell servers in physical, virtual, local and remote environments, operating in-band or
out-of-band, with or without a systems management software agent. OpenManage integrates and
connects to third-party systems management solutions so you can maintain your single point of
control and capitalize on your existing investment. OpenManage simplifies the lifecycle of deploying,
updating, monitoring, and maintaining your Dell PowerEdge servers.

Table 1 summarizes the newest technologies used in the Dell PowerEdge T320 tower server.
New technologies
Detailed descriptions
New Intel processors
The new Intel Xeon processor E5-2400 product family, Intel Xeon processor
E5-1410, and Intel Pentiumprocessor 1400 product family offer new features such
as embedded PCIe lanes for improved I/O performance. See the Processor section
for details.
Intel C600 series chipset
The Intel Platform Controller Hub (PCH) chip is implemented on the T320 server.
1600MT/s DDR3
memory
Certain models of the Xeon Intel processor E5-2400 product family support
1600MT/s memory. The T320 supports two DIMMs per channel at 1600MT/s with
certain models. See the Memory section for details.
Next generation PERC
options
The T320 supports the new PERC controller cards with improved functionality and
faster performance. See the Storage section for details.
PERC S110 software
RAID Solution
This new software RAID solution supports RAID 0, 1, 5 and 10, and supports a
maximum of four hot-plug SATA hard drives or SATA solid-state drives. See the
Storage section for details.
iDRAC7 with Lifecycle
Controller
The new embedded system management solution for Dell servers features
hardware and firmware inventory and alerting, in-depth memory alerting, faster
performance, a dedicated gigabit port, and many more features. See the Dell
OpenManage systems management section for details.
Internal GPU support
The T320 supports internal graphics processing units (GPUs) for virtual desktop
infrastructure (VDI) and medical imaging. See the Processor section for details.
Advanced power
management
The T320 supports advanced power monitoring and power capping tools that can
help manage power consumption. See the Power, thermal, and acoustics section
for details.
Fresh Air cooling
Dell has tested and validated an integrated data center solution that enables you
to operate at higher temperatures or even chiller-less. See the Power, thermal, and
acoustics section for details.
Failsafe hypervisors
The internal dual SD module is a modular fail-safe design that is dedicated for an
embedded ESX hypervisor or other embedded operating system. See the
Supported virtualization for details.
Fan fault tolerance
Failure of one fan rotor is tolerated with degradation in performance through
active throttling and increased fan speeds. The feature helps reduce downtime by
allowing you to schedule a fan replacement within 360 hours of a fan failure.

Compared to the previous generation PowerEdge T310, the T320 supports up to 100% more
processor cores, up to 300% more internal storage capacity, PCIe 2.0 and 3.0 I/O slots, and
advanced, enterprise-class memory protection including memory sparing and memory mirroring
previously not found in 1-scoket servers. In addition, the T320 is Fresh Air compliant, offers optional
failsafe hypervisors and support for an optional, internal graphics processing unit (GPU), and the
improved acoustics make the T320 perfect for the quiet office environment.
The T320 is the new generation PowerEdge server replacing the T310. Table 2 compares some of
the T320 features to the T310 features.
Feature
PowerEdge T310
PowerEdge T320
Chassis
5U tower
5U rackable tower1
Processors
IntelXeonprocessors 3400 series
Intel Xeon processor E5-2400 product family,
Intel Xeon processor E5-1410, Intel Pentium
processor 1400 product family
Internal interconnect
Intel DMI
Intel DMI 2.0
Memory2
Up to 6 x DDR3 RDIMM or 4 x
DDR3 UDIMM
Up to 6 x DDR3 RDIMM and UDIMM up to
1600MT/s
Hard drive bays
Up to 4 x 3.5”or 2.5” hot-plug or
cabled
Up to 16 x 2.5“ or 8 x 2.5”/3.5“ hot-plug or
4 x 3.5”cabled
RAID controller
PERC 6/i, SAS 6/iR, PERC 6/E,
H200, H700, H800, S100, S300
PERC H310, H710, H710P, H810, S110
PCI slots
Up to 5 PCIe 2.0
Up to 3 PCIe 3.0 and 2 PCIe 2.0
Embedded NICs
2 x 1GbE Dual Port LOM with
optional TOE
2 x 1GbE Dual Port LOM with optional TOE
Power supplies
Non-redundant 375W
Redundant 400W
Non-redundant 350W
Hot-plug, redundant 495W, 750W
Dell OpenManage
Systems Management
Dell OpenManage
Dell Management Console (DMC)
Lifecycle Controller 1.x
iDRAC6 (Express or Enterprise) with
Lifecycle Controller
OpenManage Essentials
Dell Management Console
IT Assistant
OMSA Agent
OpenManage Power Center (requires iDRAC7
Enterprise with Lifecycle Controller)
OpenManage Integrations and Connections
Basic management (standard option)
Internal GPU
Not supported
1 single-width or 1 double-width (optional)
Power efficiency
Silver
Platinum
Availability
Hot-plug drives
Hot-plug, redundant power supply
units
Hot-plug drives
Hot-plug, redundant power supply units
Fan fault tolerance
Dell fault-resilient memory
Internal dual SD module
1Optional kit available for field conversion from tower to rackable unit.
2GB means 1 billion bytes and TB equals 1 trillion bytes; actual capacity varies with preloaded material and operating environment and will
be less.

Table 3 summarizes the specifications for each of the PowerEdge T320 features. For the latest
information on supported features for the PowerEdge T320, visit Dell.com.
Feature
PowerEdge T320 technical specification
Form factor
5U rackable tower1
Processors
IntelXeonprocessor E5-2400 product family
Intel Xeon processor E5-1410
Intel Pentiumprocessor 1400 product family
Processor socket
1 socket
Internal interconnect
Intel DMI 2.0
Cache
2.5MB per core with core options of 2, 4, 6, or 8
Chipset
Intel C600
Memory2
Up to 96GB (6 DIMM slots): 2GB/4GB/8GB/16GB DDR3 up to 1600MT/s
PCIe slots
5 PCIe slots
1x16 slot with x16 bandwidth, 3.0, full-height, full-length
1x8 slot with x4 bandwidth, 3.0, full-height, half-length
1x8 slot with x4 bandwidth, 2.0, full-height, half-length
1x8 slot with x4 bandwidth, 3.0, full-height, full-length
1x8 slot with x1 bandwidth, 2.0, full-height, full-length
RAID controller
Internal controllers:
PERC S110 (SW RAID)
PERC H310
PERC H710
PERC H710P
Internal HBAs (non-RAID):
Internal tape adapter
External HBAs (RAID):
PERC H810
External HBAs (non-RAID):
6Gbps SAS HBA
Hard drives
Drive bay options:
4 x 3.5” cabled drive bays or
8 x 3.5” or 2.5”hot-plug drive bays or
16 x 2.5” hot-plug drive bays
Hot-plug hard drive options:
2.5” SATA (7.2K), nearline SAS (7.2K), SAS (15K, 10K), SAS SSD, SATA SSD
3.5” SATA (7.2K), nearline SAS (7.2K), SAS (15K)
Self-encrypting drives available
Cabled hard drive options:
3.5” SATA or SAS
Embedded NIC
Broadcom®5720 GbE Dual Port Base-T
Power supply
Platinum efficiency 495W and 750W power supplies
Silver efficiency cabled 350W power supply
Auto-ranging power supplies

Feature
PowerEdge T320 technical specification
Availability
Optional high-efficiency, hot-plug, redundant power supplies; hot-plug hard drives;
TPM; dual internal SD support; redundant fans; optional bezel; information tag; ECC
memory; interactive LCD screen; extended power range; ENERGY STAR®compliant
Dell OpenManage
Systems Management
(Agent-free or with
OpenManage Server
Administrator [OMSA]
Agent)
OpenManage Essentials
Dell Management Console
IT Assistant
OMSA Agent
OpenManage Power Center (requires iDRAC7 Enterprise with Lifecycle
Controller)
OpenManage Integrations and Connections:
-OpenManage Integration Suite for Microsoft®System Center
-Dell Management Plug-in for VMware®vCenter™
-Connections for HP®Operations Manager, IBM®Tivoli®Netcool®and CA
Network and Systems Management
Basic management (standard option)
-Upgrade to iDRAC7 (Express or Enterprise) with Lifecycle Controller
-Upgrade to 8GB vFlash media or 16GB vFlash media for iDRAC7 Enterprise
with Lifecycle Controller
-Trial evaluations available for IDRAC7 (Express and Enterprise) with Lifecycle
Controller
Rack support
ReadyRails™II sliding rails for tool-less mounting in 4-post racks with square or
unthreaded round holes or tooled mounting in 4-post threaded hole racks, with
support for optional tool-less cable management arm
Operating systems
Microsoft Windows Server®2008 R2 SP1, x64 (includes Hyper-V®v2)
Microsoft Windows®Small Business Server 2011
SUSE®Linux®Enterprise Server
Red Hat®Enterprise Linux®
Optional embedded hypervisors:
Citrix®XenServer™
VMware vSphere™
For more information on the specific versions and additions, visit
Dell.com/OSsupport.
1Optional kit available for field conversion from tower to rackable unit.
2GB means 1 billion bytes and TB equals 1 trillion bytes; actual capacity varies with preloaded material and operating environment and
will be less.

The Dell PowerEdge T320 is a 5U, 2-socket, rackable tower server. For additional system views and
features, see the Dell PowerEdge T320 Systems Owner’s Manual on Support.Dell.com/Manuals.
Table 4 lists the possible chassis configurations available for the T320.
Number of
drive bays
Drive types
Controller
Front
control
panel
Power supply
Rack
option
4 cabled
drive bays
3.5” SATA and
SAS HHD
PERC S110, H310, H710*, H710P*
LED
Cabled 350W
No
8 hot-plug
drive bays
3.5” SATA and
SAS HHD
2.5” SAS SSD
PERC S110, H310, H710, H710P
LCD
Cabled 350W
or hot-plug
495W, 750W
Yes
16 hot-plug
drive bays
2.5” SATA and
SAS SSD/HHD
PERC H310, H710, H710P
LCD
Hot-plug
495W, 750W
Yes
*Available Q3 2012
Figure 1 shows the features on the front of the T320 16-drive bay chassis with the front control
panel, USB connectors, and many other components and features described in this guide.
Figure 2 shows the optional lockable bezel on the front of the T320 chassis.

Figure 3 shows the features on the back panel of the T320 including USB connectors, Ethernet
connectors, serial connector, video connector, PCIe slots, power supplies, iDRAC dedicated port
and many other components and features described in this guide.
The chassis design of the T320 is optimized for easy access to components and for airflow for
effective and efficient cooling. Figure 4 provides an internal view of the T320 including the DIMMs,
PCIe card slots, power supplies, fans, and processors.

Figure 5 shows the front view of the rackable T320 chassis without a bezel.

Table 5 lists the various features on the T320. For additional information, see the Dell PowerEdge
T320 Systems Owner’s Manual on Support.Dell.com/Manuals.
Feature
Description
Power button
ACPI-compliant power button with an integrated green power LED
Front bezel
Covers the system’s front-loading hard drives and locks for security
NMI button
Used to troubleshoot software and device driver errors; use only if directed
to do so by qualified support personnel or by the operating system's
documentation
System identification button
Buttons on the back and front of a system to help identify the unit in a data
center environment
Hard drives
Up to sixteen 2.5-inch drives
USB connectors
Connects USB devices to the server
Information tag
Slide-out label panel for recording system information
Video connector
Connects a monitor to the server; the tower chassis has one port on the
back of the chassis; the rack chassis has a port on both the front and back of
the chassis
LCD panel and buttons
Displays system ID, status information, and system error messages;
the hot-plug chassis has two navigation buttons to scroll through the menu
on the LCD and one select button
Optical drive
Optional half-height DVD or DVD+RW drive
Power supply units
Supplies power to the server
Power supply indicators
Indicates whether server has power
NIC indicators
Indicates network activity and status
PCIe slots
Connects PCIe expansion cards to the server
Ethernet connectors
Connects integrated 10/100/1000 NICs to the server
Serial connector
Connects a serial device to the server
iDRAC7 Enterprise port
Dedicated management port for optional iDRAC Ports card

The T320 control panel is located on the front of the chassis as shown in Figure 6. For more
information about the LCD control panel, see the Dell PowerEdge T320 Systems Owner’s Manual on
Support.Dell.com/Manuals.
A useful feature included with Dell PowerEdge 12th generation servers is the Quick Resource Locator
(QRL)—a model-specific Quick Response (QR) code that is located inside the T320 chassis cover
(see Figure 7). Use your smartphone to access the Dell QRL app to learn more about the server.
This QRL code allows you to:
View step-by-step videos, including overviews of system internals and externals, as well as
detailed, concise, task-oriented videos and installation wizards
Locate reference materials, including searchable owner’s manual content, LCD diagnostics, and
an electrical overview
Look up your service tag so you can quickly gain access to your specific hardware configuration
info and warranty information
Contact Dell directly (by link) to get in touch with technical support and sales teams and provide
feedback to Dell
These codes provide an easy way to retrieve the critical support information you need when you
need it, making you more efficient and effective in managing your hardware.

The latest generation of PowerEdge servers has the features listed in Table 6 to help ensure the
security of your data center.
Security feature
Description
Cover latch
A tooled latch is integrated on the chassis (top of rack chassis or side of tower
chassis) with a coin key lock to secure the system.
Bezel
An optional metal bezel is mounted to the chassis front to provide the Dell ID. A
lock on the bezel is used to protect un-authorized access to hard drives. System
status is viewable on the LCD screen when the bezel is installed.
TPM
The Trusted Platform Module (TPM) is used to generate/store keys,
protect/authenticate passwords, and create/store digital certificates. It also
supports the Intel Xeon TXT functionality. TPM can also be used to enable the
BitLocker™ hard drive encryption feature in Windows Server 2008. TPM 1.2 is
supported. No TPM version is available for China or Russia.
Power-off security
BIOS has the ability to disable the power button function.
Intrusion alert
An internal switch is used to detect chassis intrusion.
Secure mode
BIOS has the ability to enter a secure boot mode through system setup. This
mode includes the option to lock out the power and NMI switches on the
control panel or set up a system password.

The Dell PowerEdge T320 features a variety of Intel processor options. The Intel Xeon processor
E5-2400 product family offers an ideal combination of performance, dependability, and cost. These
processors provide substantial performance and capacity for entry and mainstream workloads. In
addition to providing raw performance gains, improved I/O is also made possible with Intel
Integrated I/O, which can reduce latency by adding more lanes and doubling bandwidth. This helps
to reduce network and storage bottlenecks, unleashing the processor’s performance capabilities.
In addition to the Intel Xeon processor E5-2400 product family, the T320 also supports the Intel
Xeon E5-1410, which provide a balance of performance, value, and advanced features, and the Intel
Pentium processor 1400 product family, which is cost-efficient and provides the basic features.
Some of the features of these new Intel processors include:
Up to 8 execution cores per processor
Intel Hyper-Threading technology enables up to 16 computational threads
Micro-architecture on 32nm process for greater performance per watt
Support for up to 6 DIMM slots, up to 16GB DIMMs for a total possible memory capacity of
96GB
Integrated memory controller with 3 channels of DDR3 and 46-bit physical addressing facilitate
greater memory capacity
Intel Integrated I/O has support for up to 24 lanes of PCIe 3.0 links
Faster connections throughout the system with support for DDR3 1600MT/s memory and
8.0GT/s QPI
Intel Data Direct I/O (DDIO) allows I/O traffic to skip the main system memory and be directed
straight to the processor cache, which can provide a significant reduction in latency as well as
allowing memory to remain in a low-power state
High bandwidth, low latency, bidirectional ring interconnect allows faster access to the 20MB
multi-banked last level cache
Intel Advanced Vector Extensions offer up to double the floating point operations per clock cycle
by doubling the length of registers, which can be useful for addressing very complex problems or
dealing with large-number calculations, which are integral to many technical, financial, and
scientific computing problems
Intel Turbo Boost Technology 2.0, which allows processor cores to run faster than the base
operating frequency if it's operating below power, current, and temperature specification limits,
delivers up to double the boost than the previous generation
Continued improvements to both Intel TXT and AES-NI help to better protect systems and data
Table 7 lists the Intel Xeon processors supported by the PowerEdge T320. For the latest information
on supported processors, visit Dell.com/PowerEdge.

Model
Speed
TDP
Cache
Cores/
threads
Max memory
speed
Turbo
Xeon E5-2470
2.3GHz
95W
20MB
8/16
1600 MT/s
Yes
Xeon E5-2440
2.4GHz
95W
15MB
6/12
1333 MT/s
Yes
Xeon E5-2430L
2.0GHz
60W
15MB
6/12
1333 MT/s
Yes
Xeon E5-2430
2.2GHz
95W
15MB
6/12
1333 MT/s
Yes
Xeon E5-2420
1.9GHz
95W
15MB
6/12
1333 MT/s
Yes
Xeon E5-1410
2.8GHz
80W
10MB
4/8
1333 MT/s
Yes
Xeon E5-2407
2.2GHz
80W
10MB
4/8
1066 MT/s
NA
Xeon E5-2403
1.8GHz
80W
10MB
4/8
1066 MT/s
NA
Pentium 1407
2.8GHz
80W
5MB
2/4
1066 MT/s
NA
Pentium 1403
2.6GHz
80W
5MB
2/4
1066 MT/s
NA
For more information supported Intel processors, visit Intel.com. For information on processor
installation and configuration, see the Dell PowerEdge T320 Systems Owner’s Manual on
Support.Dell.com/Manuals.
The T320 supports graphics processing unit (GPU) technology, providing accelerated performance
for a variety of applications including VDI and medical imaging.
The T320 supports one nVidia®Q4000 full-length, single-width or one nVidia Q6000 full-length,
double-width GPU. GPU cards are available through certified factory installation (CFI) or field
upgrade only.
Each GPU supports up to 6GB of dedicated GDDR5 memory and is actively cooled. Each GPU has
one or two power connectors to meet the high demand for power delivery. The power connectors
are located on the back of the card.
The GPUs from nVidia have PCIe 2.0 interfaces and can be installed in the T320 PCIe x16 3.0 slots.
The interface for the next generation GPU cards will be PCIe 3.0.
The following system configuration restrictions apply when a GPU is installed:
750W redundant power supply is recommended
System can support only one 5.25-inch device
Some operating systems have not been validated to support GPUs. See Table 20 for more
information on operating system support of GPUs.
The Intel C600 chipset is implemented on the PowerEdge T320. For more information, visit
Intel.com.

More options are available for the Dell PowerEdge 12th generation servers than in previous
generations—more capacity choices and more frequency choices. The PowerEdge T320 supports
up to 96GB of memory with speeds of up to 1600MT/s, providing high performance in a variety of
applications. The new reliability, availability, serviceability (RAS) features like memory mirroring and
sparing help you increase your uptime and reduce data loss. RAS aids in the rapid and accurate
diagnosis of faults that require service, increasing your memory reliability.
The T320 supports the memory technologies shown in Table 8.
Feature
UDIMM
RDIMM
Register
No
Yes
Buffer
No
No
Frequencies
800, 1066, or 1333 MT/s
800, 1066, 1333, or 1600 MT/s
Ranks supported
1 or 2
1, 2, or 4
Capacity per DIMM
2 or 4GB
2, 4, 8, or 16GB
Maximum DIMMS per channel
2
2
DRAM technology
x8
x4 or x8
Temperature sensor
Yes
Yes
ECC
Yes
Yes
SDDC
Yes (with advanced ECC mode)
Yes
Address parity
Yes
Yes

The T320 supports the DIMMs listed in Table 9. For the latest information on supported memory,
visit Dell.com.
Capacity
(GB)
Speed
(MT/s)
Type
Ranks per
DIMM
Data
width
SDDC support
Voltage
2
1333
RDIMM
1
x8
Advanced ECC
1.35
2
1333
UDIMM
1
x8
Advanced ECC
1.35
2
1600
RDIMM
1
x8
Advanced ECC
1.5
4
1333
RDIMM
2
x8
Advanced ECC
1.35
4
1333
RDIMM
1
x4
All modes
1.35
4
1333
UDIMM
2
x8
Advanced ECC
1.35
4
1600
RDIMM
2
x8
Advanced ECC
1.5
8
1333
RDIMM
2
x4
All modes
1.35
8
1600
RDIMM
2
x4
All modes
1.5
16
1333
RDIMM
2
x4
All modes
1.35
16
1600
RDIMM
2
x4
All modes
1.5
Flexible memory configurations are supported on the T320, ranging from capacities of 2GB to
96GB. The system supports up to 6 DIMMs. The T320 has 3 memory channels per processor, with
each channel supporting up to 2 DIMMs.
The T320 supports a flexible memory configuration according to these basic rules:
Speed: If DIMMs of different speeds are mixed, all channels across all processors operate at the
slowest DIMM’s common frequency.
DIMM type: Only one type of DIMM can be used in a system. UDIMMs and RDIMMs cannot be
mixed.
The following additional memory population guidelines apply to the T320:
Up to two quad-rank (QR), dual-rank (DR), or single-rank (SR) DIMMs may be populated per
channel.
DIMMs must be installed in each channel, starting with the DIMM farthest from the processor.
DIMMs should be installed with largest rank count to smallest. For example, if DR DIMMS are
mixed with SR DIMMs, DR DIMMS should be placed in the lowest DIMM slots, followed by the SR
DIMMs.
For more information on memory configuration, see the Dell PowerEdge T320 Systems Owner’s
Manual on Support.Dell.com/Manuals.
The T320 supports memory speeds of 1600MT/s, 1333MT/s, 1066MT/s, and 800MT/s depending on
the DIMM types installed and the configuration. All memory on all processors and channels run at
the same speed and voltage. By default, the systems run at the highest speed for the channel with
the lowest DIMM voltage and speed. The operating speed of the memory is also determined by the

maximum speed supported by the processor, the speed settings in the BIOS, and the operating
voltage of the system.
Table 10 lists memory configuration and performance details for the T320 based on the population
of the number and type of DIMMs per memory channel.
DIMM
type
DIMM 0
DIMM 1
Number
of
DIMMs
Speed (MT/s)
800
1066
1333
1600
UDIMM
SR
1
∞
∞
∞
DR
1
∞
∞
∞
SR
SR
2
∞
∞
∞
SR
DR
2
∞
∞
∞
DR
DR
2
∞
∞
∞
RDIMM
SR
1
∞
∞
∞
∞
DR
1
∞
∞
∞
∞
QR
1
∞
∞
SR
SR
2
∞
∞
∞
∞
SR
DR
2
∞
∞
∞
DR
DR
2
∞
∞
∞
∞
QR
SR
2
∞
QR
DR
2
∞
QR
QR
2
∞
RAS features help keep the system online and operational without significant impact to performance,
and can decrease data loss and crashing due to errors. RAS aids in rapid, accurate diagnosis of faults
that require service. Table 11 describes the RAS features supported on the T320.
Feature
Description
Dense configuration
optimized profile
Increased memory reliability can be a result from this selectable platform profile
that adjusts parameters to reduce faults regarding refresh rates, speed,
temperature and voltage
Memory demand and
patrol scrubbing
Demand scrubbing is the ability to write corrected data back to the memory once
a correctable error is detected on a read transaction.
Patrol scrubbing proactively searches the system memory, repairing correctable
errors.
Recovery from single
DRAM device failure
Recovery from Single DRAM Device Failure (SDDC) provides error checking and
correction that protects against any single memory chip failure as well as multi-bit
errors from any portion of a single memory chip.
