Dell™DX Object Storage Platform Interoperability
Guide
This document provides information about the supported hardware and software versions for Dell™DX Object
Storage Platform systems.
Supported Hardware
This section lists the hardware supported by DX Object Storage Platform. Where applicable, firmware and driver
versions are also listed.
BIOS Versions
Table 1 lists the BIOS version supported by the DX6000 system.
Platform
BIOS Version Supported
DX6000
2.0.13 or later
DX6012S
1.2.12 or later
DX6004S
1.0.0 or later
Table 1. Supported System BIOS
Hard Drives
The DX Object Storage Platform supports internal 3.5-inch hard drives only. Table 2 lists the supported hard drives
and RAID types.
Platform
Hot-swappable (Yes/No)
Raid Type
Drives
DX6000
Yes
Raid 5
3.5-inch SATA 250GB or 1TB and
3.5-inch NearLine SAS 500GB or 1TB
DX6012S
No1
No RAID
3.5-inch SATA 250GB, 500GB, 1TB, or 2TB and
3.5-inch NearLine SAS 500GB, 1TB, or 2TB
DX6004S
No1
No RAID
3.5-inch SATA 250GB, 500GB, 1TB, or 2TB and
3.5-inch NearLine SAS 500GB, 1TB, or 2TB
Table 2. Supported Hard drives
1Hot removal of drive is supported. Reinserting or adding a new hard drive requires reboot of the DX6012S and DX6004S.
Supported Controllers
Table 3 lists the supported RAID controllers, supported firmware, and driver versions.
Platform
Controller
Type
RAID
Controller
Number of
Controllers
Firmware Revision
BIOS Revision
Driver
Revision
DX6000
Internal
H700
1
12.0.1-00 or later
12.0.1-00 or later2
4.17-2 or later
DX6012S
Internal
H200
1
07.02.42.00 or later
07.11.01.00 or later2
N/A3
DX6004S
Internal
H200
1
07.02.42.00 or later
07.11.01.00 or later2
N/A3
Table 3. Supported RAID Controllers
2Dell DX Compatibility Manager and DX Storage Node Console report RAID controller BIOS Revisions. The corresponding RAID
controller firmware updates available at www.support.dell.com are referenced by Firmware Revision.

2׀DX Object Storage Platform Interoperability Guide
3The Drivers are applicable to DX6000 platform only as DX6012S and DX6004S run PXE bootable image from DX6000 that has
embedded OS, Drivers and Application.
Table 4 lists the supported network interface controllers (NICs), supported firmware and driver versions.
Platform
NIC
Firmware Revision
Driver Revision
DX6000; DX6012S; DX6004S
Broadcom®NetXtreme™II
5.2.0 or later
14.2.0 or later4
DX6000; DX6012S
Intel®PRO PCI-E Gigabit (2007)
N/A
11.2 or later4
Table 4. Supported Network Interface Controllers
4The Drivers are applicable to DX6000 platform only as DX6012S and DX6004S run PXE bootable image from DX6000 that has
embedded OS, Drivers and Application.
Table 5 lists supported remote access controllers (iDRAC) and corresponding firmware versions.
Platform
iDRAC
Firmware Revision
DX6000
iDRAC Express or iDRAC Enterprise (optional)
1.41 or later
DX6012S
iDRAC Express or iDRAC Enterprise (optional)
1.41 or later
DX6004S
iDRAC Express or iDRAC Enterprise (optional)
1.54 or later
Table 5. Supported Remote Access Controllers
Supported Software
This section lists the supported operating systems and applications on the DX Object Storage Platform. Dell DX
Object Storage Platform Compatibility Manager can be used to determine software component versions.
Supported Operating System
Table 6 lists the supported operating systems for the DX Object Storage Platform Software.
Platform
DX Platform Software
OS Support
DX6000
1.0
Red Hat®Enterprise Linux®5.3 64-bit
2.0.0
Red Hat®Enterprise Linux®5.5 64-bit
Table 6. Supported Operating Systems
Note: DX Object Storage Platform is not intended to be used as a web server or host any other services
other than those specified in this document.

Supported Dell Applications
Table 7 lists the supported applications for the DX Object Storage Platform Software.
Table 7. Supported Applications
Platform
Dell Applications
DX Platform Software 1.0
DX Platform Software
2.1.1
DX6000
Dell DX Object Storage Platform Compatibility Manager
A01
A03 or later
Dell OpenManage™ Server Administrator
6.2 or later
6.4 or later
Dell Management Console5
1.01 or later
1.01 or later
Dell DX Content Router Rules Configurator (CRRC)
N/A
A00 or later
Dell Unified Server Configurator –Lifecycle Controller
Enabled (USC-LCE)
A00 or later
A00 or later
DX6012S
Dell Unified Server Configurator –Lifecycle Controller
Enabled (USC-LCE)
A00 or later
A00 or later
DX6004S
Dell Unified Server Configurator –Lifecycle Controller
Enabled (USC-LCE)
A03 or later
A03 or later
5Dell Management Console is not installed on the DX Object Storage Platform but is a Management Application to remotely
monitor the platform status.
Supported DX Object Storage Platform Application Software Stack
Table 8 lists the application software stack supported on the DX Object Storage Platform.
Platform
Component
CSN 1.0
CSN 2.1.1
DX6000
DX Object Storage Software
4.0.0 to 4.0.3; 4.0.3
patch for DX6004S support
5.1.0 or later
DX Content Router Software
2.0 to 2.1.2
2.3.0 or later
DX Proxy
1.0 to 1.1
1.3.2 or later
DX SDK
1.0 to 1.1
1.3.2 or later
Table 8. Supported Object Storage Platform Software Stack
Browser Validation list for DX Object Storage Platform
The following list of browsers have been tested and validated with DX Object Storage Platform.
Browser
Linux
Windows®
Internet Explorer®v7
X
Internet Explorer® v8
X
Firefox v3.0
X
Firefox v 3.0.5
X
Table 9. Supported Browsers
Note: Other browsers, not tested in Dell Labs may also work with the Dell DX Object Storage Platform.
