Delta Children 22408 User manual

www.DeltaChildren.com
DCP-IM-05222018-EN-F6
Customer Care Tel. [phone]
ADULT ASSEMBLY REQUIRED
INSTRUCTION MANUAL
Read all instructions BEFORE assembly and USE of product. KEEP INSTRUCTIONS FOR FUTURE USE.
STYLES AND COLORS MAY VARY
22408
CLASSIC WRANGLER
3-IN-1 ACTIVITY
WALKER
WARNING:
Adult assembly required because of
small parts. Keep assembly parts
out
of reach of children under 3 years.
CHOKING HAZARD
REQUIRED: (x2) “AA” Batteries (not Included)
Phillips Screwdriver (not included)

2www.DeltaChildren.com
Customer Service Tel. [phone]
• Wash using mild soap and warm water only. Wipe plastic components dry and air dry seat cover.
• Keep friction components clean to maintain stopping performance
Failure to follow these warnings and instructions could result in serious injury or death.
Read all instructions before assembling unit.
KEEP INSTRUCTIONS FOR FUTURE USE. DO NOT USE THIS UNIT IF THE INSTRUCTIONS
CANNOT BE STRICTLY FOLLOWED.
WARNING:
• NEVER LEAVE CHILD UNATTENDED!
• ALWAYS KEEP CHILD IN VIEW WHILE IN WALKER.
• NEVER use near stairs or thresholds.
• Before each use clean friction components to maintain stopping performance.
• Strings can cause strangulation! DO NOT place items with a string around child’s neck, such as hood
strings or pacifier cords. DO NOT suspend strings over product or attach string to toys.
• To avoid burn injuries, always keep child away from ranges, radiators, hot liquids, space heaters,
fireplaces, etc.
• To avoid drowning, never use near pools, bathtubs, etc.
• Always check that surfaces are flat and free of objects that may cause tipping over either indoors
or outdoors.
• To reduce chance of child slipping out of seat, always check that both feet of child touch floor.
• Use only for children who can sit upright unassisted and weigh no more than 25 lbs.
• NEVER carry walker or adjust height with child in it.
• Walk behind mode is only intended for use by children 9 months - 3 years.
• Not to be used as a ride-on toy when used in the floor toy car mode.
STAIR HAZARD
AVOID SERIOUS INJURY OR DEATH BLOCK STAIRS/STEPS SECURELY BEFORE USING WALKER.
• Maximum weight inside storage bin: 3lbs.
• Tubing frame should always remain in the downward position when walker top tray is removed.
• Tubing frame should remain in locked position when in walker mode.
CARE AND MAINTENANCE
WARNING

3www.DeltaChildren.com
Customer Service Tel. [phone]
EXTENDED WARRANTY
DON’T MISS YOUR CHANCE TO BE COVERED FOR ALL OF LIFES MISHAPS!
With Delta’s Extended Warranty, you’re covered for mechanical failure from normal use or if
your item stops working due to normal wear and tear, plus all those unexpected surprises.
2 YEARS OF PROTECTION
For Additional Information:
Simply visit our Website, register your product, and add the Extended Warranty
https://www.deltachildren.com/pages/product-registration
Extended Warranty only available in the following States: Arkansas, Colorado, Delaware, District of Columbia, Georgia, Idaho,
Illinois, Indiana, Iowa, Kansas, Kentucky, Louisiana, Maryland, Michigan, Mississippi, Missouri, Nebraska, Nevada, New Hampshire,
New York, North Carolina, North Dakota, Pennsylvania, Rhode Island, South Dakota, Tennessee, Utah, West Virginia
STOP
Please DO NOT return this product to the store.
If you experience any difficulty with assembly, missing parts or use, please
DO NOT return this item to the store. Retail stores are unable to properly
assist you. Contact our Customer Service Department directly for
assistance 1-800-377-3777.
www.DeltaChildren.com • [email protected]
©2018 Delta Children’s Products, Inc. New York, NY 10001

4www.DeltaChildren.com
Customer Service Tel. [phone]
Parts
IMPORTANT! Please remove all parts from the package and identify them before assembly.
Walker Top Tray
Front Wheels x2
Rear Wheels x2
Toy Tray
Front Bar
Walker Bottom Base Wheels x4
Storage Bin Storage Cap
Seat Pad
Part # 50331
Part # 50337
Part # 50333
Part # 50334 Part # 50335 Part # 50336
Part # 50332
Part # 50330
L
o
c
k
U
n
l
o
c
k
Part #
2030 (Exploration) - 50328
2031 (Orbit) - 50328

5www.DeltaChildren.com
Customer Service Tel. [phone]
Inserting Batteries
• Insert AA batteries (x2) as shown in the picture.
• Close battery cover. Use a Phillips head screw driver to fasten the
battery cover closed.
•Locate the toy tray.
• Locate toy tray lock tab on the bottom of the toy tray.
• Use a Phillips head screw driver to unfasten the battery cover.
• Lift cover to open battery compartment.
1 2
Bottom of Toy Tray
AA
AA
Inserting Batteries
Opening Battery Compartment
BATTERY SAFETY INFORMATION
In exceptional circumstances, batteries may
leak fluids that can cause a chemical burn
injury or ruin your product.
To avoid battery leakage:
• Do not mix old and new batteries or batteries
of different types: alkaline, standard (carbon
zinc) or rechargeable (nickel-cadmium).
• Insert batteries as indicated inside battery
compartment.
• Remove batteries during long periods of non-
use. Always remove exhausted batteries from
the product. Dispose of batteries safely. Do
not dispose of product in a fire. The batteries
inside may explode or leak.
• Never short-circuit the battery terminals.
• Use only batteries of the same or equivalent
type as recommended.
• Do not charge non-rechargeable batteries.
• Remove rechargeable batteries from the
product before charging.
• If removable, rechargeable batteries are used,
they are only to be charged under adult
supervision.
• When discarding batteries, be sure to dispose
of them in the proper manner, according to
your state and local regulations.
Battery Safety Information

6www.DeltaChildren.com
Customer Service Tel. [phone]
Walker Assembly
• Locate the walk behind bar.
• Press the two side buttons to adjust height up and down.
• For Walk Behind Mode, rotate handle into an upright position.
1
Walk Behind
Bar
CLICK
Walk Behind Bar (For Walk Behind Mode)
WARNING:
Walk Behind Mode is only intended for use by children 9 months - 3 years.
Walker Top
Tray
• Place the toy tray into the recess on the top tray, front side first
then push the back down you will hear a “click” when the
notches are engaged.
2
Attaching Toy Tray
• Pull upward on the toy tray to assure it is in a fully locked position.
• To release, press the notches in from underneath the tray.
*NOTE: On/Off switch is located on the underside of the toy tray
1
2
1
2
Toy Tray
Notches Notches
On/Off switch
Notches
FRONT

7www.DeltaChildren.com
Customer Service Tel. [phone]
Walker Assembly
• Insert the 4 tabs on the seat pad into the slots located around the seat
ring. Slide tabs through inserts. Turn tray upside down, pull tabs and
align into grooves.
NOTE: Push tabs from top of walker to securely fasten.
NOTE: Push down on the seating area of seat pad to ensure seat is securely
in place.
5
WARNING: DO NOT use walker if all tabs are not secured properly.
Seat Pad
Attaching Seat Pad
• Insert firstly three outer pins built-in at the fastening parts to the
round hole at the upper tray as illustrated.
• Move the plastic fastening panel downward to the lowest position
of holes to complete the assembly.
4
1
2
3
• Align the two bottom nubs of front bar to top tray recesses and press
down until it clicks.
•Pull upward on front bar to assure it is in a fully locked position.
3
Front Bar
Bottom
Nub
Walker Top
Tray
CLICK
Attaching Front Bar

8www.DeltaChildren.com
Customer Service Tel. [phone]
• Locate x4 wheels.
• Align wheels so plastic notches are facing outward of walker.
• Insert the wheel joint into the walker bottom housing and push down until the plastic notches engage.
• Pull upward on wheels to assure they are in a fully locked position.
7
6
• Completed assembly of wheels.
• Flip over entire walker top tray for next step.
Walker Top Tray Assembly
Flip Over
Plastic
Notches
Walker Bottom
Joint
Wheel
Wheel
Joint
Walker Top Tray
CLICK
Attaching Wheels to Walker Top Tray
2
3
1

9www.DeltaChildren.com
Customer Service Tel. [phone]
• Locate front wheels and walker bottom base.
• Place the walker bottom base on a solid flat surface with the bottom facing upwards.
• Insert the pins of the front wheels into their housings until they click into position.
• Pull upward on wheels to assure they are properly inserted, and in a fully locked position.
• Locate rear wheels and walker bottom base.
• Align rear wheel pin to bottom rear wheel groove and insert.
• Pull upward on wheels to assure they are properly inserted, and in a fully locked position.
• Locate both ends the tubing frame on the bottom base and pull upward
into a fully assembled position. Follow 1, 2 and 3 steps.
Hold both ends of tubing and pull
upward.
When pulling tubing, bottom slot joint
should fully extend to the back.
Release both ends of tubing to allow slot joint
to lock in place on hook. Push downward to
make sure it is in a fully locked position.
Walker Bottom Base Assembly
8
9
TOP VIEW
Align rear wheel pin to
bottom rear wheel groove.
Rear Wheel
Pin
Rear Wheel
Groove
Front Wheel
Walker
Bottom Base
Rear Wheel
Bottom Base
Tubing
End
Attaching Wheels to Walker Bottom Base
1 2 3
123
BACK
BACK
BACK
BACK

10 www.DeltaChildren.com
Customer Service Tel. [phone]
• Align bottom lock housings in between the 2 nubs of “X”Frame Tubing.
Make sure walker top tray is facing FRONT position, by aligning the front sticker located on the x frame tubings and the walker top tray.
• Pull both bottom lock housing tabs and clip lock housings on top of tubing.
• Once both lock housings are clipped on “X” frame tubing, release the lock housing tabs.
• To make sure top tray is locked, lock tab should be fully extended trapping the
tubing frame.
NOTE: Pull up top tray to ensure it is securely locked.
WARNING: DO NOT use walker if walker top tray is not fully locked.
• Completed Walker Assembly.
Walker Assembly
10
11 12
PULL
ALIGN ALIGN
PULL PULL
RELEASE
FRONT
LOCKED
BACK
LOCKED
RELEASE
Nub Nub
Bottom Lock
Housing Tab
Bottom Lock
Housing Tab Bottom Lock
Housing
Bottom Lock
Housing
“X” Frame
Tubings
1 1
22
3 3
1
2
3
Attaching Walker Top Tray
Locking Walker Top Tray
WARNING:
Walker Mode is only intended for use by children 6 months - 12 months.
FRONT
FRONT
BACK
BACK

11 www.DeltaChildren.com
Customer Service Tel. [phone]
• Locate Storage Bin and Storage Cap.
• Press side lock tabs inward and press down into walker seat hole until bottom side locks should catch on to bottom walker lip.
NOTE: To remove storage cap, locate side lock tabs and push inward to release.
NOTE: To remove mesh from storage bin, pull upwards until fully released.
• To unlock storage cap, twist center hub counter clockwise until center hub dash lines up with the unlock symbol.
• To lock storage cap, twist center hub clockwise until center hub dash lines up with the lock symbol
center hub dash lines up to unlock symbol.
Storage Bin Assembly
1
2
Storage Bin
with storage cap
attached
Center Hub
Side Lock
Tab
Walker Seat
Hole
Bottom Walker Lip
Attaching Storage Bin
Locking / Unlocking Storage Cap
L
o
c
k
U
n
l
o
c
k
L
o
c
k
U
n
l
o
c
k
1
3
2
WARNING:
Floor Toy Car Mode is not to be used as a ride-on toy.
