Delta Electronics FFB1012EHE Manual

60
http://www.deltaww.com
Operating
Voltage
Range
MODEL Rated
Voltage
Maximum
Air Flow
Speed
Maximum
Air Pressure
Noise
PART NO. FUNCTION VDC VDC Amp Watt R.P.M. CFM mmH
2O IN H2
O dB-A
100 x 100 x 38 MM SERIES
FFB
DIMENSIONS DRAWING
*
*
*
*
Bearing Type
Ball Bearings
Material
Impeller & Frame : Plastic (UL 94V-0)
Lead Wires :
Red Wire Positive (+)
Black Wire Negative (-)
Weight : 350g (12.34 oz)
UL1007AWG#24 OR Equivalent
P & Q CURVE (AT RATED VOLTAGE) MOUNTING PANEL CUTOUT
mm
(INCH)
UNIT:
OUTLET SIDE INLET SIDE
FFB1012EHE -R00 / -F00 12 7.0 to 12.6 2.20 26.40 5000 4.052 143.09 21.19 0.835 62.0
* Function type is optional.
* The max. air flow and the speed are measured in free air ; max. air pressure is measured at zero air flow.
* Noise is measured in anechoic chamber in free air, one meter from intake side.
* All readings are typical values at rated voltage.
* Specifications are subject to change without notice.
0.80
Air Pressure
(mm H O)
(IN H O)
Air Flow
35.0
4.0
0
2
0
2
0.16
0
0 0.9
20.0
16.0
8.0
12.0
0.32
0.48
0.64
105.070.0
1.8 2.7
140.0
3.6 4.5 (M /MIN)
(CFM)
3
FFB1012EHE
24.0
0.96
EH
mm
(INCH)
UNIT:
Input
Power
Input
Current
