Delta Electronics AHB1748EH Manual

Operating
Voltage
Range
MODEL Rated
Voltage
Maximum
Air Flow
Speed
Maximum
Air Pressure Noise
PART FUNCTION VDC VDC Amp Watt R.P.M. /min CFM mmH
2O IN H2
O dB-A
172 x 25.4 MM SERIES
AHB
Bearing Type
Ball Bearings
Material
Impeller : Plastic(UL 94V-0)
Frame : Die-CastAluminum
Lead Wires :
UL 1007 AWG #24 OR Equivalent
Red Wire Positive(+)
Black Wire Negative(-)
Weight : 450g (15.87 oz)
*
*
*
*
* Function type is optional.
The max. air flow and the speed are measured in free air ; max. air pressure is measured at zero air flow.
Noise is measured in anechoic chamber in free air, one meter from intake side.
All readings are typical values at rated voltage.
Specifications are subject to change without notice.
*
*
*
*
m3
AHB1748VH -R00 / -F00 48 32.0 to 80.0 0.37 17.76 3400 6.408 226.31 13.62 0.536 56.0
AHB1748SH -R00 / -F00 48 32.0 to 80.0 0.43 20.64 3700 7.059 249.27 16.10 0.634 59.0
AHB1748EH -R00 / -F00 48 32.0 to 80.0 0.52 24.96 4000 7.675 271.05 18.69 0.736 61.0
PART
DIMENSIONS DRAWING
P & Q CURVE (AT RATED VOLTAGE) MOUNTING PANEL CUTOUT
UNIT: (INCH)
mm
OUTLET SIDE INLET SIDE
UNIT: (INCH)
mm
40
O.O.
OO
OO
OO
OO
http://www.deltaww.com
Input
Power
Input
Current
