Delta Electronics AFB0605HC Manual

Operating
Voltage
Range
MODEL Rated
Voltage
Maximum
Air Flow
Speed
Maximum
Air Pressure
Noise
PART NO. FUNCTION VDC VDC Amp Watt R.P.M. CFM mmH O IN H O dB-A
22
60 x 60 x 13 MM SERIES
AFB
DIMENSIONS DRAWING
*
*
*
*
*
mm
(INCH)
UNIT:
AFB0605LC -R00 / -F00 5 4.5 to 5.5 0.12 0.60
AFB0612LC -R00 / -F00 12 7.0 to 13.8 0.08 0.96 3000 0.436 15.40 2.11 0.083 24.0
AFB0624LC -R00 / -F00 24 14.0 to 27.6 0.05 1.20
AFB0605MC -R00 / -F00 5 4.5 to 5.5 0.18 0.90
AFB0612MC -R00 / -F00 12 7.0 to 13.8 0.11 1.32 3600 0.514 18.15 3.02 0.119 28.0
AFB0624MC -R00 / -F00 24 14.0 to 27.6 0.06 1.44
AFB0605HC -R00 / -F00 5 4.5 to 5.5 0.29 1.45
AFB0612HC -R00 / -F00 12 7.0 to 13.8 0.14 1.68 4200 0.601 21.22 4.15 0.163 31.5
AFB0624HC -R00 / -F00 24 14.0 to 27.6 0.07 1.68
AFB0612HHC -R00 / -F00 12 7.0 to 13.8 0.20 2.40 4800 0.698 24.65 5.19 0.204 35.0
AFB0624HHC -R00 / -F00 24 14.0 to 27.6 0.09 2.16
AFB0612VHC -R00 / -F00 12 7.0 to 13.8 0.24 2.88 5400 0.785 27.72 6.41 0.252 38.0
AFB0624VHC -R00 / -F00 24 14.0 to 27.6 0.12 2.88
P & Q CURVE (AT RATED VOLTAGE) MOUNTING PANEL CUTOUT
mm
(INCH)
UNIT:
OUTLET SIDE INLET SIDE
Bearing Type
Ball Bearings
Material
Impeller & Frame : Plastic(UL 94V-0)
Lead Wires :
UL 2468 AWG #28 O Equivalent
Red Wire Positive(+)
Black Wire Negative(-)
Weight : 33.5g (1.18 OZ)
Rib Type Only
:
:
R
0.40.2
0
0
8.0
0.80.6
16.0 24.0
1.0
32.0
6.0
3.0
4.5
1.5
0.12
0.06
0 0
0.18
0.24
9.0
7.5
0.30
0.36
Air Pressure
(mm H O)
2
2
(IN H O)
(CFM)
Air Flow
3
(M /MIN)
AFB0605/12/24XC
L
M
H
HH
VH
* Function type is optional.
* The max. air flow and the speed are measured in free air ; max. air pressure is measured at zero air flow.
* Noise is measured in anechoic chamber in free air, one meter from intake side.
* All readings are typical values at rated voltage.
* Specifications are subject to change without notice.
* Both of the ball bearing and the 1 ball + 1 Sleeve type are available.
10
