Delta Electronics SMT Power Inductor HAH1365 Installation instructions

DELTA ELECTRONICS, INC.
(TAOYUAN PLANT CPBG)
o
At 25 C: 100KHz, 1V
SMT Power Inductor
HAH1365 Type
RoHS compliant.
Low profile (6.5mm max. height) SMD type.
Magnetically shielded, suitable for high density mounting.
High energy storage and low DCR.
Provided with embossed carrier tape packing.
Ideal for power source circuits, DC-DC converter,
DC-AC inverters inductor application.
In addition to the standard versions shown here,
customized inductors are available to meet your exact requirements.
Features
97
Electrical Characteristics:
Mechanical Dimension:
252, SAN YING ROAD, KUEISAN INDUSTRIAL ZONE, TAOYUAN SHIEN, 333, TAIWAN, R.O.C.
TEL: [phone]; FAX: [phone]
http://www.deltaww.com
UNIT : mm / inch
A = 13.0 0.5 / 0.512 0.020
B = 12.7 0.4 / 0.500 0.016
C = 4.00 / 0.157
D = 6.50 / 0.256 Max.
E = 0.03 / 0.001
F = 3.00 / 0.118
1
4.90
14.50
B
A
F
C
4.8
5.0
D
E
2
1. Lo is the initial inductance.
2. Isat is the DC current which cause the inductance drop to Li.
OO
3. Operating temperature : -20 C to 105 C ( including self-temperature rise ).
RECOMMENDED PAD PATTERNS
PART NO. Lo Li DCR Isat
(uH) (uH) 20% (m ) MAX (Adc)
HAH1365-0R2 0.20 0.20 0.50 50
HAH1365-0R4 0.50 0.40 1.00 45
HAH1365-1R0 1.00 0.80 1.80 30
