Delta HEC1000AFR User manual

Specification and Manual
Customer:
Description: Air Conditioner for Equipment
Customer Part No.: Rev.:
Delta Model No.: HEC1000A R Rev.: X00
Sample Date Code:
Sample Issue Date:
DELTA ELECTRONICS, INC.
252, SHANG YING ROAD, KUEI SAN TEL: [phone]
TAOYUAN CITY 333, TAIWAN AX: 886-(0)3-3591991
Please send one copy of this specification back after
you signed approval for production pre-arrangement
Approved by:
Date:

Part no.:
Delta model no.: HEC1000A R
Page 2
Table of content
Description .......................................................................................................................................... 3
Packing & Shipping ........................................................................................................................... 3
Safety Notes ....................................................................................................................................... 3
1. Product Instruction .................................................................................................................... 7
1-1. General Description .......................................................................................................... 7
1-2. Main eature & Model Number ....................................................................................... 7
1-3. Dimension ........................................................................................................................... 9
1-4. Mounting plane Cutout ................................................................................................... 10
1-5. Configuration & Maintenance ........................................................................................ 11
1-6. Thermal and Airflow ........................................................................................................ 12
2. Electrical Specification ............................................................................................................ 13
3. Environmental Condition ........................................................................................................ 16
4. Reliability Table ........................................................................................................................ 16
5. Safety Certification .................................................................................................................. 16
6. Accessory ................................................................................................................................. 16
7. Parameters .................................................................................................................................. 17
7-1 Parametric Setup .............................................................................................................. 17
7.2 Self-Test ............................................................................................................................. 18
7.3 Alarm Logs & ault Processing ...................................................................................... 18
8. Installation Notice .................................................................................................................... 21
9. Warranty ................................................................................................................................... 21
10. Reclaim ..................................................................................................................................... 23
11. Versions .................................................................................................................................... 24

Part no.:
Delta model no.: HEC1000A R
Page 3
Description
This document is an installation and the characteristics of Delta HEC series. Before
installing the unit, please read this manual thoroughly, and following the instructions
contained in it. The document is the exclusive property of Delta Electronics, Inc. it should
not be distributed, reproduced, or any other format without prior permission of Delta.
Specifications are subject to change without notice.
Packing & Shipping
During handling or transport, air conditioner must be kept in upward position, “NOT”
inverted, flat, or subject to excessive tilt and collision. The air conditioner is a precision
instrument; it should be handled and transported with care. Do not stand on the box,
or place heavy objects on top of the box. Pay attention to the below icons on the package.
If air conditioner is toppled, slanted or dropped, follow these steps: a. stand unit up for
12 hours to ensure refrigerant pressure stability, b. power on the unit and execute self-
test to make sure no alarm condition, c. keep the air conditioner running for 1 hour to
make sure there is no abnormal acoustic noise.
Safety Notes
Please read the safety notes carefully before installing the air conditioner, and be sure
to install it correctly. After completing installation, check that the unit operates properly
during start-up operation.
Meaning of WARNING and CAUTION notices:
Warning:
ailure to follow these instructions properly may result in personal injury or loss of
life.
Caution:
ailure to observe these instructions properly may result in property damage or
personal injury, which may be serious depending on the circumstance.

Part no.:
Delta model no.: HEC1000A R
Page 4
Warning:
1. Installation work and electrical wiring should be done only by qualified personnel in
accordance with all applicable codes, standards and national wiring regulations.
2. Use this unit only in the manner intended by the manufacturer. If you have questions,
please contact the manufacturer.
3. Install the air conditioner in accordance with the instructions in this installation manual.
Improper installation may result in water leakage, electric shock or fire.
4. Make sure that all wiring is secured, that specified wires are used, and there is no strain
on the terminal connections or wires.
5. If refrigerant gas leaks during installation, ventilate the area immediately. Do not directly
touch refrigerant that has leaked from refrigerant pipes or other areas, as there is a
danger of frostbite.
6. Before serving or cleaning unit, switch power off and disconnect power supply.
7. When cutting or drilling into wall or ceiling, do not damage electrical wiring or hidden
utilities.
8. Be sure to use only the specified accessories and parts to complete installation.
9. Protective grounding connection: The enclosure must be grounded at the protective
ground terminal. Use 1.5 mm
2
(18AWG) wire and use spring washer to avoid loosening.
10. The air conditioner should not be accessible to the general public.
11. The installation must contain a device to disconnect all poles of the air conditioner from
the power supply. The contact distance in all poles must be 3 mm minimum.
12. To reduce the risk of electrical shock: Means for disconnection must be incorporated in
the fixed wiring in accordance with the wiring rules.
13. This appliance is intended for use only by qualified personnel.

Part no.:
Delta model no.: HEC1000A R
Page 5
Caution :
1. Install the air conditioner on a wall or door strong enough to withstand the weight of the
unit.
2. Do not allow a child to mount onto the outdoor unit. Avoid placing any object on it.
3. Do not block the air inlets or exits.
4. Do not install the air conditioner at any place where there is a danger or flammable gas
leakage.
5. Arrange the drain to ensure complete drainage.
6. To avoid injury, do not touch the air inlet or aluminum fins of the unit.
7. Watch your step at the time of fin cleaning or air conditioner inspection.
8. Do not topple the air conditioner while moving or in storage.
9. The hole in the bottom of the air conditioner should be connected to a sealed container
through a drain pipe.
10. This appliance is not to be used by any persons with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they have been given proper
supervision or instruction.
11. Children should be prevented from playing with the appliance.

Part no.:
Delta model no.: HEC1000A R
Page 6
Specification for Approval
Customer :
Description : Air conditioner for Equipment with 1000 W Rated Cooling Capacity
Customer P/N : Rev. :
Delta model no. : HEC1000A R Rev. : 00
Sample revision. : Date Code :
Sample issue date : Quantity :1 pc
EXTERNAL INTERNAL

Part no.:
Delta model no.: HEC1000A R
Page 7
1. Product Instruction
1-1. General Description
HEC1000A R is a AC air conditioner with 115VAC power input, it is designed for NEMA4X
sealed outdoor telecom cabinet to provide stable and optimum internal conditions for
equipment and avoid hotspot inside the cabinet.
HEC X1 A R
(1) (2) (3) (4) (5)
No Item Digit Specification
(1) Product Message HEC Compressor Air Conditioner
(2) Cooling Capacity X1 X1=1000
(3) Operation Voltage A AC 115V for door
(4) Air condition type = ix speed
(5) Product Version R N/A
1-2. Main eature & Model Number
Dimensions, Weight & Mounting method
Dimension (H x W x D) (Body only) mm (inch) 810 x 299 x 240 (32” x 11.8” x 9.5”)
Application Indoor / Outdoor
Weight Kg (lbs) 27.0(50.7)
Mounting Method Side mount
Color (optional) NA
Environmental Protection & Performance
Operating Temperature Range °C (° ) -10 to +55 ( 14 to +131)
Operating Humidity External: 0~100% RH
Internal: 0~80% RH
Storage Temperature °C (° ) -40 to +70 (-40 to +158)
Storage Relative Humidity RH 5~95%
Refrigerant R134a, 280±10 g
Protection for Dust ,Wind and Water
(External) IEC 60529 /NEMA UL 50E TYPE4X
Noise (1.0m) dB-A 65
Operating Status N/A LED Indicator / Display Board
Cooling Capacity & Operational Data
Cooling Capacity at L35/L35 (50/60HZ) W (Btu/hr) 850(2672)/1000(3143)
Cooling Current at L35/L35(50/60Hz)* A 5.1/ 4.2
Power & Range
Input Voltage
VAC/Phase/ requency
110/50/1,115/60/1

Part no.:
Delta model no.: HEC1000A R
Page 8
Input Voltage Range VAC 103~121/50Hz,105~127/60Hz
Locked Rotor Current (60Hz) A 15.9
Rated Current A 6.4
Minimum circuit ampacity (MCA) A 7.0
Maximum rating of overcurrent protective
device (MOP) A 11.7
Alarm N/A Dry Contact Output
Key Components
Controller Built-in Smart Controller
ans Delta High Efficiency ans
Compressor Rotary
* ollowed thermal balancing test of DIN3168
Cooling Capacity with Varied Temperature
Power Consumption with Varied Temperature
0
200
400
600
800
1000
1200
1400
1600
25 30 35 40 45 50 55
Cooling Capacity (W)
External Ambient Temp (℃)
T in 55℃(60HZ)
T in 55℃(50HZ)
T in 45℃(50HZ)
T in 45℃(60HZ)
T in 35℃(60HZ)
T in 35℃(50HZ)
T in 25℃(60HZ)
T in 25℃(50HZ)
400.00
420.00
440.00
460.00
480.00
500.00
520.00
540.00
25 30 35 40 45 50 55
Input Power (W)
External Ambient Temp (℃)
T in 55℃(60HZ)
T in 55℃(50HZ)
T in 45℃(60HZ)
T in 45℃(50HZ)
T in 35℃(60HZ)
T in 35℃(50HZ)
T in 25℃(60HZ)
T in 25℃(50HZ)

Part no.:
Delta model no.: HEC1000A R
Page 9
1-3. Dimension
mm(inch)
(1) Material: SUS 304
(2) inish: N/A
(3) Color: N/A
(4) Dimension tolerance: ± 1.0mm

Part no.:
Delta model no.: HEC1000A R
Page 10
1-4. Mounting plane Cutout
mm (inch)

Part no.:
Delta model no.: HEC1000A R
Page 11
1-5. Configuration & Maintenance
Make sure the air conditioner surface sealed with mounting flange to avoid water
penetrates into shelter through mounting interface. It is suggested to use gaskets sticking
on the mounting flange and seal the gap between flange and cabinet with silicone gel
during installation. There should be NO any gap surround gaskets to avoid water
penetrates into enclosure.
The air conditioner is composed as the following key components: they are chassis,
cover, controller, heat exchanger, blowers and compressor etc. It is “not” recommended
that the user replace the compressor, evaporator, and the condenser by themselves; it
may damage the system and getting injured.
In order to assure the air conditioner running at optimal condition, the condenser should
be cleaned once annually at least; user can clean the condenser with water directly. The
external side fan blade can also be cleaned with normal pressure water if there is dust
accumulation. Please do not use strong water jet to impact the center of fan and the
surface of condenser.
The bottom hole of the air conditioner should be connected to a sealed container through
a drainpipe, please clear drain holes when the maintenance. Please also notice that:
1. Check wires are connected correctly, and the insulation is not cracking or broken.
2. Use Self-test to check the unit running correctly or not. And the supplied air of internal
side should be as cooled air.
3. Do not wipe the product with organic solvent, volatile substances like toluene or gasoline,
it will destroy the powder-coated surface.
NO. Q'TY DESCRIPTION
1 1 Case Chassis
2 1 Case Cover
3 1 Display Board
4 1 Driver Board
5 1 Remote Control Board
6 1 Compressor
7 1 Condenser
8 1 Evaporator
9 1 External an
10 1 Internal an

Part no.:
Delta model no.: HEC1000A R
Page 12
4. Turn off the power before maintaining.
5. Please turn off power and remove dry contact connector while non-operating for a long
time.
6. If any abnormal acoustic noise from air conditioner happened, please turn off the product
and contact with customer services.
7. The refrigerant is environmental friendly product of R134a. Little refrigerant leakage (< 5
g/ year) is allowed for application. If refrigerant leakage seriously, please turn off the
power and wait for at least 2 hours to make sure the refrigerant fully exhaust. Please
also contact the services to replace spare parts.
8. The compressor electrical protecting cover is sealed with silicon for IP54 requirement.
Please do not dismantle the sealed cover or will lose the quality assurance of the
compressor.
1-6. Thermal and Airflow
Internal and external air flow circulation is shown in below diagram. Counter flow design
prevents mixing of internal and external air flows, but waste heat can still be dissipated
from cabinet to the ambient outside air. An internal temperature sensor has been placed
in the return air stream to provide reliable temperature measurement, and for safe
operation.
The heated air inside the cabinet will be cooled by the evaporator. Waste heat absorbed
by the refrigerant will be dissipated through the condenser at the external side.

Part no.:
Delta model no.: HEC1000A R
Page 13
2. Electrical Specification
 Power Supply & Alarm Connector & Indicator
(1) AC Power Connect：
(2) RS485 and J1 Connect：
J1 Pin Name Description
RS485 + RS485 Communication
RS485 - RS485 Communication
NC Dry Output NC
COM Dry Output COM
NO Dry Output NO
1 Door open alarm input
2 Door open alarm input
 System Alarm Default Setup
• Specification: Contact rating: 2A@30 VDC / 2A@250 VAC
Pin Description Cable wire size
1 PE 16 AWG
2 N 16 AWG
3 L 16 AWG

Part no.:
Delta model no.: HEC1000A R
Page 14
• Normal: NC and COM dry contact output close
• Alarms happening: NC and COM dry contact output open
(Dry Contact will trigger when alarm happen except E2.6 and E5.1)
(3) Panel operation：
• A: Display:
It will show the temperature inside the cabinet and system parametric setup.
• B: LED indicator:
 When the system power on and the LED will light in green.
 If any alarm happens, according to flashing times of red led to check the
root cause.
 If the system gets into self-test mode and the LED will flash in green.
• C: Press Buttons:
 ↑: UP or increase
 ↓: DOWN or decrease
 SET: Parametric setup
A
B
C

Part no.:
Delta model no.: HEC1000A R
Page 15
(4) Panel Operation lowchart :
※ If no button is pressed, after 20 seconds, the panel will return to the Cabinet
Temperature screen.
※ The default value of Password is 0001.
 SD card & Ethernet (Optional function):
The controller used communication technology to remotely control, monitor, SD card 8
GB for logging data and alarm the cooling function of the ACU. This can be done using
a RJ45 or RS485 connected to an industrial network or a personal computer (PC)
connected to an Internal local area network.

Part no.:
Delta model no.: HEC1000A R
Page 16
3. Environmental Condition
 Operating Temperature
-10°C ~ +55 °C (14 ° ~ +131 ° )
 Storage Temperature
-40 °C ~ +70 °C (-40 ° ~ 158 ° )
 Operation Humidity
External air loop: 0 ~ 100 % RH
Internal air loop: 0 ~ 80 % RH, non-condensing
 Ingress Protection Rating
NEMA 4X
4. Reliability Table
Test item Condition
High temperature IEC 60068-2-2
Low temperature IEC 60068-2-1
High temp. / High humidity IEC 60068-2-3
Temperature cycle IEC 60068-2-14 test Nb
Vibration ETSI 300 019-1-4 CLASS 4.1
Ingress protection (external side) IEC 60529 IP54 / NEMA 4X
Salt fog test (external side) IEC 60068-2-52, 6cycles
Package bump IEC 60068-2-29
5. Safety Certification
TBD
6. Accessory
Power and Alarm Cable：
Pin Description Cable wire size
1 L 16AWG
2 N 16AWG
3 PE 16AWG

Part no.:
Delta model no.: HEC1000A R
Page 17
7. Parameters
7-1 Parametric Setup
Display Description Range
d01
d1.01 Communication Address 1~128, (Default=21)
d1.02 Communication speed
(Baud rate)
0 : 9600
1 : 19200
(Default=0)
d1.03 Compressor turn on
temperature setting 20~50, (Default=40)
d1.04 Compressor hysteresis set
point setting 1~10, (Default=5)
d1.05 Cabinet over temperature
point setting 20~80,(Default=65)
d1.06 System self-test
0: off
1: on
(Default=0)
d1.07 Door open alarm function
0: Disable
1: Enable
(Default=0)
d1.08 Dry contact setting
0: normal Open
1: normal Closed
(Default=1)
d1.09 System parameters
recovery
0: off
1: on
(Default=0)
d1.10 Heater turn on
temperature setting N/A
d1.11 Heater hysteresis set point
setting N/A
d1.12 Password setting Default= 0001
d02
d2.01 Evaporator temperature Display
d2.02 Condenser temperature Display

Part no.:
Delta model no.: HEC1000A R
Page 18
d2.03 Ambient temperature Display
d2.04 Internal fan speed Display
d2.05 External fan speed Display
d2.06 irmware version Display
※ d1.10 and d1.11 are option functions. Default is closed.
※ d2 layer is for system status information read only.
7.2 Self-Test
1. Press the SET button into parametric setup mode.
2. Press UP button to choose d1.06 and then press SET button to choose “1”executing
auto self-test.
3. If the system gets into self-test mode and LED will flash in green.
4. Auto self-test running period about eighty seconds exclude compressors three minutes
protection.
5. The test process including EEPROM, NTC sensor, inner-fan, outer-fan, compressor
heater, emergency fan running correctly.
6. Recognizing that the implementation process without generating alarm or fault. If any
alarm happens, according to alarm code to check the root cause.
7.3 Alarm Logs & ault Processing
Alarm Items Type of alarm Alarm code
Temperature protection
alarm
Evaporator low temperature alarm E 2.1
abinet high temperature alarm E 2.2
System high pressure alarm E 2.4
System high pressure frequent alarm E 2.5
abinet low temperature alarm E 2.6
Temperature sensor
abnormality abinet temperature sensor fault alarm E 3.1

Part no.:
Delta model no.: HEC1000A R
Page 19
Evaporator temperature sensor fault alarm E 3.2
ondenser temperature sensor fault alarm E 3.3
Ambient temperature sensor fault alarm E 3.4
Fan exception
Internal fan exception alarm(Only For D Fan Project) N/A
External fan exception alarm(Only For D Fan Project) N/A
ontrol board exception EEPROM abnormal alarm E 5.1
System exception
Power board abnormal alarm(Only For D Fan Project) N/A
ompressor failure alarm E 6.2
Door Open Alarm E 6.3

Part no.:
Delta model no.: HEC1000A R
Page 20
ault Analysis and Processing
ault State Analysis of the Reasons Solutions
Power on, and the
cabinet temperature is
too high but the air
conditioner is not
working
1. Power failure or no power.
2. The target temperature is
higher than inside
temperature.
3. System failure.
1. Check the power supply and
the electric circuit.
2. Re-set the target
temperature
according to the
system requirement.
3. Please contact the service
department.
The air conditioner is
running but the cabinet
temperature is still high,
no obvious cooling
effect.
1. The air conditioner capacity is
not match the load of the
system.
2. The ambient temperature is
too high.
3. Low efficiency of the
condenser.
4. Other system failure
1. Check the heating load of
the system.
2. Ensure the air conditioner
operates in correct
temperature range.
3. Clean the condenser.
4. Please contact the service
department.
The air conditioner stop
operating, and there is
no alarm signal.
1. The inside temperature is
lower than the target
temperature.
2. Other system failure.
1. Re-set the target
temperature according to the
system requirement.
2. Please contact the service
department.
