Delta HEC2010FFA User manual

Specification and Manual
Customer :
Description : Air Conditioner for Equipment
Customer Part No. : Rev.:
Delta Model No. : HEC2010FFA Rev : 07
Sample Date Code:
Sample Issue Date : JUNE.17 2020
DELTA ELECTRONICS, INC.
252, SHANG YING ROAD, KUEI SAN TEL : [phone]
TAOYUAN CITY 333, TAIWAN FAX : [phone]
Please send one copy of this specification back after
you signed approval for production pre-arrangement
Approved by :
Date :

Part no. :
Delta model no. : HEC2010FFA
Page 2
Table of content
Description.......................................................................................................................................... 3
Packing & Shipping ........................................................................................................................... 3
Safety Notes ....................................................................................................................................... 3
1. Product Instruction .................................................................................................................... 7
1-1. General Description .......................................................................................................... 7
1-2. Main Feature & Model Number ....................................................................................... 7
1-3. Dimension ........................................................................................................................... 9
1-4. Mounting Panel Cutout ................................................................................................... 10
1-5. Configuration & Maintenance ........................................................................................ 11
1-6. Thermal and Airflow ........................................................................................................ 12
2 Electrical Specification ........................................................................................................... 13
2-1. Indicator & Connector ..................................................................................................... 13
2-1-1 Power Supply & Alarm Connector ...................................................................... 13
2-2. Parametric Setup ............................................................................................................. 14
2-3. Self-Test ............................................................................................................................ 15
3. Environmental Condition ........................................................................................................ 18
3-1. Operating Temperature .................................................................................................. 18
3-2. Storage Temperature ...................................................................................................... 18
3-3. Operation Humidity ......................................................................................................... 18
3-4. Ingress Protection Rating ............................................................................................... 18
4. Reliability Table ........................................................................................................................ 18
5. Safety Certification .................................................................................................................. 19
6. Accessory ................................................................................................................................. 19
7. Installation Notice .................................................................................................................... 19
8. Reclaim ..................................................................................................................................... 20

Part no. :
Delta model no. : HEC2010FFA
Page 3
Description
This document is an installation and the characteristics of Delta HEC series. Before installing the unit,
please read this manual thoroughly, and following the instructions contained in it. The document is the
exclusive property of Delta Electronics, Inc. it should not be distributed, reproduced, or any other format
without prior permission of Delta. Specifications are subject to change without notice.
Packing & Shipping
During handling or transport, air conditioner must be upward placed, “NO” inverted, flat, excessive
tilt and collision. Air conditioner is a precision instrument, it should be handled or transported with care, do
not stand on the box, or place heavy objects on it. Please pay attention to the following icons on the package.
If air conditioner is toppled, over slanted or dropped unfortunately, please follow below steps: a. stand
for 12 hours to ensure refrigerant pressure stability, b. power on and execute self-test to make sure no alarm
happened, c. air conditioner keeps 1 hour operating and make sure there is no abnormal acoustic noise.
Safety Notes
Please read the safety notes carefully before installing air conditioning unit and be sure to install it
correctly. After completing the installation, make sure that the unit operates properly during the start-up
operation.
Meaning of WARNING and CAUTION notices:
Warning:
Failure to follow these instructions properly may result in personal injure or loss life.
Caution:
Failure to observe these instructions properly may result in property damage or personal injury, which
may be serious depending on the circumstance.

Part no. :
Delta model no. : HEC2010FFA
Page 4
Warning:
1. Installation work and electrical wiring must be done by qualified person(s) in accordance with all applicable
codes, standards and national wiring regulations.
2. Use this unit only in the manner intended by the manufacturer. If you have questions, please contact the
manufacturer.
3. Install the air conditioner in accordance with the instructions in this installation manual. Improper
installation may result in water leakage, electric shocks or fire.
4. Make sure that all wiring is secured, the specified wires are used, and there is no strain on the terminal
connections or wires.
5. If refrigerant gas leaks during installation, ventilate the area immediately. Do not directly touch refrigerant
that has leaked from refrigerant pipes or other areas, as there is a danger of frostbite.
6. Before serving or cleaning unit, switch power off and disconnect power supply.
7. When cutting or drilling into wall or ceiling, do not damage electrical wiring or hidden utilities.
8. Be sure to use only the specified accessories and parts for installation work.
9. Protective earth connection: The enclosure must be earthed at the protective earth terminal. Use 1.5 mm2
(16 AWG) wire and use spring washer to avoid loosening.
10. The air conditioner shall be not accessible to the general public.
11. The installation must contain a device to disconnect all poles of the air conditioner from the power supply.
The contact distance in all poles must be 3 mm minimum.
12. To reduce the risk of electrical shock. Means for disconnection must be incorporated in the fixed wiring in
accordance with the wiring rules.
13. This appliance is intended to be used by expert or trained users in shops, in light industry and on farms,
or for commercial use by lay persons”.
Caution :
1. Install the air conditioner on a wall/ door strong enough to withstand the weight of the unit.
2. Do not block air inlets or exits.
3. Do not install the air conditioner at any place where there is a danger or flammable gas leakage.
4. Arrange the drain to ensure complete drainage.

Part no. :
Delta model no. : HEC2010FFA
Page 5
5. To avoid injury, do not touch the air inlet or aluminum fins of unit.
6. Watch your steps at the time of fin cleaning or air conditioner inspection.
7. Do not topple the air conditioner while moving or storage.
8. The hole in the bottom of the air conditioner should be connected to a sealed container through a drainpipe.
9. The appliance is not to be used by persons (including children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction.
10. Children being supervised not to play with the appliance.

Part no. :
Delta model no. : HEC2010FFA
Page 6
Specification for Approval
Customer :
Description : Air conditioner for Equipment with 2000 W or 100W/K Rated Cooling Capacity
Customer P/N : Rev. :
Delta model no. : HEC2010FFA Rev. : 07
Sample revision. : Date Code :
Sample issue date : Quantity :
INTERNAL EXTERNAL

Part no. :
Delta model no. : HEC2010FFA
Page 7
1. Product Instruction
1-1. General Description
HEC2010FFA is a hybrid air conditioner with 48VDC & 230 VAC power input, it is designed for IP55
sealed outdoor telecom cabinet to provide stable and optimum internal conditions for equipment and avoid
hotspot inside the cabinet.
HEC X1 FF A XXX
(1) (2) (3) (4) (5)
No Item Digit Specification
(1) Product Message HEC Compressor Air Conditioner
(2) Cooling Capacity X1 2000W and 100W/K
(3) Operation Voltage FF 230VAC & 48VDC for door with
heater
(4) Product Version A N/A
(5) Customer ID XXX N/A
1-2. Main Feature & Model Number
Dimensions, Weight & Mounting method
Dimension (H x W x D) (without flange) Mm (inch) 945 x 505 x 250 (37.2 x 19.9 x 9.8)
Application Outdoor
Weight Kg (lbs) 40 (88)
Mounting Method Door/Side
Color (optional) RAL7035
Environmental Protection & Performance
Operating Temperature Range °C (°F) -40 ~ +55 (-40 ~ +131)
Operating Humidity External : 0~100% RH
Internal: 0~80% RH
Storage Temperature °C (°F) -40 ~ +70 (-40 ~ +158)
Storage Relative Humidity RH 5~95%
Refrigerant R134a
Protection for Dust ,Wind and Water
(External) IEC 60529 /GR487
IP55 / GR487
Noise (1.5m) dB-A 65
Operating Status N/A LED Indicator / Display Board
Cooling Capacity & Operational Data
Rated Cooling Capacity at L35/L35 W (Btu/hr) 2000(6824)
Heat Exchange Capacity W/K 100±10%
Cooling AC Current at L35/L35 A 3.5

Part no. :
Delta model no. : HEC2010FFA
Page 8
Cooling DC Current at L35/L35 A 3.3
Rated Internal Airflow (L35/L35) m3/h (CFM) 950 (560)
Rated External Airflow (L35/L35) m3/h (CFM) 600 (354)
Heating Capacity W 1000
Power & Range
Input Voltage (Control and Fan) VDC 48
Input Voltage (Compressor) VAC / Phase /
frequency 230 / 1 / 50-60
Locked Rotor Current (Compressor) A 20.2(50Hz)/ 18.9(60Hz)
Alarm N/A Dry Contact Output
Key Components
Controller Built-in Smart Controller
Fans Delta High Efficiency Fan
Compressor Rotary
Cooling Capacity curves

Part no. :
Delta model no. : HEC2010FFA
Page 9
1-3. Dimension
mm(inch)
(1) Material: Case SGCC Sheet.
(2) Finish: Powder coating 75~120 uM, Color RAL 7035.
(3) Dimensional Tolerance: ±1 mm.
Drain pipe

Part no. :
Delta model no. : HEC2010FFA
Page 10
1-4. Mounting Panel Cutout
mm[inch]
GASKET
INSIDE
OUTSIDE
DOOR

Part no. :
Delta model no. : HEC2010FFA
Page 11
1-5. Configuration & Maintenance
Make sure the air conditioner surface sealed with mounting flange to avoid water penetrates into shelter
through mounting interface. It is suggested to use gaskets sticking on the mounting flange and seal the gap
between flange and cabinet with silicone gel during installation. There should be NO any gap surround
gaskets to avoid water penetrates into enclosure.
The air conditioner is composed as the following key components: they are chassis, cover, controller,
heat exchanger, blowers and compressor etc. It is “not” recommended that the user replace the compressor,
evaporator, and the condenser by themselves; it may damage the system and getting injured.
In order to assure the air conditioner running at optimal condition, the condenser should be cleaned
once annually at least; user can clean the condenser with water directly. The external side fan blade can
also be cleaned with normal pressure water if there is dust accumulation. Please do not use strong water
jet to impact the center of fan and the surface of condenser.
The bottom hole of the air conditioner should be connected to a sealed container through a drainpipe,
please clear drain holes when the maintenance. Please also notice that:
1. Check wires are connected correctly, and the insulation is not cracking or broken.
2. Use Self-test to check the unit running correctly or not. And the supplied air of internal side should be as
cooled air.
3. Do not wipe the product with organic solvent, volatile substances like toluene or gasoline, it will destroy
the powder-coated surface.
4. Turn off the power before maintaining.
5. Please turn off power and remove dry contact connector while non-operating for a long time.
NO. Q'TY DESCRIPTION
1 1 Case Chassis
2 1 Condenser
3 1 Power Board
4 1 Control Board
5 1 Communication Board
6 1 Internal Fan
7 1 External Fan
8 1 Compressor
9 1 Evaporator
10 1 Case Cover
11 1 Heater

Part no. :
Delta model no. : HEC2010FFA
Page 12
6. If any abnormal acoustic noise from air conditioner happened, please turn off the product and contact with
customer services.
7. The refrigerant is environmental friendly product of R134a. Little refrigerant leakage (< 5 g/ year) is allowed
for application. If refrigerant leakage seriously, please turn off the power and wait for at least 2 hours to
make sure the refrigerant fully exhaust. Please also contact the services to replace spare parts.
8. The compressor electrical protecting cover is sealed with silicon for IP55 requirement. Please do not
dismantle the sealed cover or will lose the quality assurance of the compressor.
1-6. Thermal and Airflow
The internal and external air flow circulation is shown as the figure. Through separated mechanism
design, internal and external air flow won’t be mixed since the waste heat can be dissipated from the
cabinet to the ambience. Internal temperature sensor is placed at return air stream to provide reliable
temperature measurement and safety of operation.
The waste heat generated from the internal equipment will be absorbed by the refrigerant through the
evaporator and dissipate to the ambience by the condenser of external side.

Part no. :
Delta model no. : HEC2010FFA
Page 13
2 Electrical Specification
2-1. Indicator & Connector
2-1-1 Power Supply & Alarm Connector
• System Alarm Default Setup
• Specification: Contact rating: 30 VDC, 1A
• Normal: NC and COM dry contact output close
• Any alarms happening: NC and COM dry contact output open
(Dry Contact will trigger when alarm happen except E2.4,E3.2, E3.3 ,E3.4
and E6.1)
Pin Description Cable wire size
1 PE (16AWG)
2 N (18AWG)
3 L (18AWG)
4 N/A N/A
5 -48VDC (18AWG)
6 RTN (18AWG)

Part no. :
Delta model no. : HEC2010FFA
Page 14
 Panel operation
• A: DisA 7-Segment Display:
It will show the temperature inside the cabinet and system parametric setup.
• B: LED indicator:
Power:
 When the system power on and the LED will light in green.
 If any alarm happens, according to flashing times of red led to check the root cause.
 If the system gets into self-test mode and the LED will flash in green.
• C: Press Buttons:
 ↑: UP or increase
 ↓: DOWN or decrease
 SET: Parametric setup or into self-test function
2-2. Parametric Setup
Panel menu
Content Range
d1.01 Communication address setting 1~128，(Default) 21
d1.02 Communication speed
0 : 9600
1 : 19200
(Default) : 0
d1.03 Cooling start temperature setting
temperature 20~50，(Default)40
d1.04 Cooling hysteresis setting 1~10，(Default)5
d1.05 High temperature alarm point setting 20~80，(Default)65
d1.06 System self-test 0: (Not self-test)
1: (self-test) (Default) : 0

Part no. :
Delta model no. : HEC2010FFA
Page 15
d1.07 External fan enable set 0: Disable
1: Enable (Default) : 0
d1.08 Dry contact set
0: normal Open ,abnormal Close
1: normal Close ,abnormal Open
(Default) : 1
d1.09 Reset 0: (Not Reset)
1: Reset (Default) : 0
d1.10 Heat start temperature -5~15，(Default=0)
d1.11 Heat hysteresis setting 5~15，(Default=10)
d1.12 Password setting (Default): 0001
d2.01 Evaporator temperature Display
d2.02 Condenser temperature Display
d2.03 Ambient temperature Display
d2.04 Internal fan speed Display
d2.05 External fan speed Display
d2.06 DC input voltage Display
d2.07 AC input voltage Display
d2.08 Firmware version Display
2-3. Self-Test
1. Press the SET button into parametric setup mode.
2. Press UP button to choose d1.06 and then press SET button to choose “1”executing
auto self-test.
3. If the system gets into self-test mode and LED will flash in green.
4. Auto self-test running period about eighty seconds exclude compressors three minutes
protection.
5. The test process including EEPROM, NTC sensor, inner-fan, outer-fan, compressor
heater, emergency fan running correctly.
6. Recognizing that the implementation process without generating alarm or fault. If any
alarm happens, according to alarm code to check the root cause.

Part no. :
Delta model no. : HEC2010FFA
Page 16
2-4. Alarm Logs & Fault Processing
Alarm Items Type of alarm Alarm code
Temperature protection
alarm
Evaporator low temperature alarm E 2.1
Cabinet high temperature alarm E 2.2
System high pressure alarm E 2.4
System high pressure frequent alarm E 2.5
Temperature sensor
abnormality
Cabinet temperature sensor fault alarm E 3.1
Evaporator temperature sensor fault alarm E 3.2
Condenser temperature sensor fault alarm E 3.3
Ambient temperature sensor fault alarm E 3.4
Fan exception
Internal fan exception alarm E 4.1
External fan exception alarm E 4.2
Emergency fan exception alarm E 4.3
Voltage
exception
AC input over voltage alarm E 5.1
AC input under voltage alarm E5.2
AC power down alarm E5.3
AC communication alarm E5.4
DC input over voltage alarm E5.5

Part no. :
Delta model no. : HEC2010FFA
Page 17
Fault Analysis and Processing
Fault State Analysis of the Reasons Solutions
Power on, and the
cabinet temperature is
too high but the air
conditioner is not
working
•
Power failure or no power
•
The target temperature is
higher than inside
temperature
•
System failure
•
Check the power supply and
the electric circuit
•
Re-set the target
temperature according to the
system requirement
•
Please contact Delta or
authorized Delta service
agent.
The air conditioner is
running but the
cabinet temperature is
still high, no obvious
cooling effect.
•
The air conditioner
capacity is not match the
load of the system.
•
The ambient temperature
is too high.
•
Low efficiency of the
condenser.
•
Other system failure
•
Check the heating load of the
system.
•
Ensure the air conditioner is
operating in correct
temperature range.
•
Clean the condenser.
•
Please contact Delta or
authorized Delta service
agent.
DC input under voltage alarm E5.6
System exception
EEPROM abnormal alarm E 6.1
Compressor failure alarm E 6.2
Heater failure alarm E 6.3

Part no. :
Delta model no. : HEC2010FFA
Page 18
The air conditioner
stop operating, and
there is no alarm
signal.
•
The inside temperature is
lower than the target
temperature.
•
Other system failure.
•
Re-set the target
temperature according to the
system requirement.
•
Please contact Delta or
authorized Delta service
agent.
3. Environmental Condition
3-1. Operating Temperature
-40 °C ~ +55 °C (-40 °F ~ 131 °F)
3-2. Storage Temperature
-40 °C ~ +70 °C (-40 °F ~ 158 °F)
3-3. Operation Humidity
External air loop: 0 ~ 100 % RH
Internal air loop: 0 ~ 80 % RH,
3-4. Ingress Protection Rating
IP55 (IEC60529) on external side
GR487 on external side
4. Reliability Table
Test item Condition
High temperature IEC 60068-2-2
Low temperature IEC 60068-2-1
High temp. / High humidity IEC 60068-2-3
Temperature cycle IEC 60068-2-14 test Nb
Vibration ETSI 300 019-1-4 CLASS 4.1
Ingress protection (external side) IEC 60529 IP55 / GR487
Salt fog test (external side) IEC 60068-2-11 severity 4 , 6cycles
Package bump IEC 60068-2-29

Part no. :
Delta model no. : HEC2010FFA
Page 19
PIN1
PIN6
5. Safety Certification
TBD
6. Accessory
 Power Cable
Pin Description Cable wire size
1 PE (16AWG)
2 N (18AWG)
3 L (18AWG)
4 N/A N/A
5 -48VDC (18AWG)
6 RTN (18AWG)
7. Installation Notice
Check the surrounding obstacles to make sure the product get enough space for air circulate.

Part no. :
Delta model no. : HEC2010FFA
Page 20
8. Reclaim
At the end of the unit working life, the produce must not be disposed of as urban waste. It must be
taken to a special local authority differentiated waste collection center or to a dealer providing this service.
