Delta CliQ II DRP024V480W3B Series Instruction Manual

TECHNICAL DATASHEET
CliQ II DIN Rail Power Supply
24V 480W 3 Phase / DRP024V480W3B
□
All parameters are specified at 25°C ambient and AC input unless otherwise indicated.
www.DeltaPSU.com (December 2018, Rev. 03)
1
Highlights & Features
•Universal AC input voltage: 3 x 320Vac – 600Vac (3-Phase)
or 2 x 360Vac – 600Vac (2-Phase)
•Power will not de-rate for the entire input voltage range
•Power Boost of 150% for 5 seconds and 200% for 2 seconds
•Full corrosion resistant aluminium chassis
•Conformal coating on PCBA to protect against chemical and
dust pollutants
•Hazardous Locations approval to ATEX and Class I, Div 2
(DRP024V480W3BA)
Safety Standards
CB Certified for worldwide use
Model Number: DRP024V480W3B☐
Unit Weight:1.35 kg (2.98 lb)
Dimensions (L x W x D): 121 x 140 x 117.3 mm
(4.76 x 5.51 x 4.62 inch)
General Description
The CliQ II 3-phase DIN rail power supply series offers output voltage of 24V. These products are encased in rugged yet lightweight full
aluminium body that can withstand shock and vibration according to IEC 60068-2 standard. The series of 3-phase products can
operate over a wide temperature range of -25°C to +80°C. These products also feature universal AC input voltage range for 3-phase
from 320Vac to 600Vac or 2-phase from 360Vac to 600Vac, and the power will not de-rate throughout the entire range. Another great
feature is the conformal coating on the PCBA which allows selected models to be certified to ATEX and Class I, Div 2 for use in
hazardous locations. The design conforms to harmonic current emission IEC/EN 61000-3-2, Class A.
Model Information
CliQ II DIN Rail Power Supply
Model
Number Input Voltage Range Rated Output V oltage Rated Output Curr ent
DRP024V480W3B☐ 3 x 320-600Vac (3-Phase) or
2 x 360-600Vac (2-Phase)
24Vdc 20.0A
Model Numbering
DR P024V
480W
3
B
□
DIN Rail Power Supply Output Voltage Output Power Three Phase CliQ II Series A - Metal Case,
with Class I, Div 2
N - Metal Case,
without Class I, Div 2

TECHNICAL DATASHEET
CliQ II DIN Rail Power Supply
24V 480W 3 Phase / DRP024V480W3B
□
All parameters are specified at 25°C ambient and AC input unless otherwise indicated.
www.DeltaPSU.com (December 2018, Rev. 03)
2
Specifications
Input Ratings / Characteristics
Nominal Input Voltage 3 x 400-500Vac
Input Voltage Range 3 x 320-600Vac (3-Phase) or 2 x 360-600Vac (2-Phase)
Nominal Input Frequency 50-60Hz
Input Frequency Range 47-63Hz
DC Input Voltage Range* 450-800Vdc
Input Current < 1.00A @ 3 x 400Vac, < 0.75A @ 3 x 500Vac
Efficiency at 100% Load > 91.0% @ 3 x 400Vac & 3 x 500Vac
Max Inrush Current (Cold Start) < 50A @ 3 x 400Vac & 3 x 500Vac
Power Factor at 100% Load > 0.95 @ 3 x 400Vac, > 0.94 @ 3 x 500Vac
Leakage Current < 3.5mA @ 500Vac
*Safety approval according to IEC/EN/UL 60950-1.
Output Ratings / Characteristics
Nominal Output Voltage 24Vdc
Factory Set Point Tolerance ± 2% (initial set point tolerance from factory)
Output Voltage Adjustment Range 24-28Vdc
Output Current 20.0A (continuously operating at 24V)
30.0A (Power Boost for 5 seconds at 24V, refer to the details in
the Functions section)
40.0A (Power Boost for 2 seconds at 24V, refer to the details in
the Functions section)
Output Power 480W (continuously operating at 24V)
720W (Power Boost for 5 seconds at 24V, refer to the details in
the Functions section)
960W (Power
Boost for 2 seconds at 24V, refer to the details in
the Functions section)
Line Regulation < 0.5% typ. (@ 3 x 320-600Vac input, 100% load)
Load Regulation < 1% typ. (@ 3 x 320-600Vac input, 0-100% load)
PARD (20MHz) < 150mVpp
Rise Time
< 100ms @ nominal input (100% load)
Start-up Time < 1,000ms @ nominal input (100% load)
Hold-up Time > 20ms @ 3 x 400Vac & 3 x 500Vac (100% load)
Dynamic Response (Overshoot & Undershoot O/P Voltage) ± 5% @ 10-90% load
Start-up with Capacitive Loads 10,000µF Max

TECHNICAL DATASHEET
CliQ II DIN Rail Power Supply
24V 480W 3 Phase / DRP024V480W3B
□
All parameters are specified at 25°C ambient and AC input unless otherwise indicated.
www.DeltaPSU.com (December 2018, Rev. 03)
3
Mechanical
Case Cover / Chassis
Aluminium
Dimensions (L x W x D) 121 x 140 x 117.3 mm (4.76 x 5.51 x 4.62 inch)
Unit Weight 1.35 kg (2.98 lb)
Indicator Green LED (DC OK)
Cooling System Convection
Terminal Input 4 Pins (Rated 600V/35A)
Output 4 Pins (Rated 300V/30A)
Wire Input AWG 18-8
Output AWG 12-10
Mounting Rail Standard TS35 DIN Rail in accordance with EN 60715
Noise (1 Meter from power supply) Sound Pressure Level (SPL) < 40dBA
Environment
Surrounding Air Temperature Operating -25°C to +80°C (Cold Start at -40°C)
Storage -40°C to +85°C
Power De-rating Vertical Mounting > 50°C de-rate power by 2.5% / °C,
> 70°C de-rate power by 5% / °C
Operating Humidity 5 to 95% RH (Non-Condensing)
Operating Altitude 0 to 2,500 Meters (8,200 ft.) for ITE application (@ 50°C)
0 to 2,000 Meters (6,560 ft.) for Industrial application (@ 50°C)
Shock Test Non-Operating IEC 60068-2-27, 30G (300m/S²) for a duration of 18ms,
1 time per direction, 2 times in total
Vibration Non-Operating IEC 60068-2-6, 10Hz to 500Hz @ 30m/S² (3G peak);
60 min per axis for all X, Y, Z direction
Pollution Degree 2
Protections
Overvoltage 32V ±10%, SELV Output, Hiccup Mode,
Non-Latching (Auto-Recovery)
Overload / Overcurrent > 200% of rated load current, Hiccup Mode,
Non-Latching (Auto-Recovery)
Over Temperature < 80°C Surrounding Air Temperature @ 100% load,
Non-Latching (Auto-Recovery)
Short Circuit Hiccup Mode, Non-Latching
(Auto-Recovery when the fault is removed)
Degree of Protection IP20
Protection Against Shock Class I with PE* connection
*PE: Primary Earth

TECHNICAL DATASHEET
CliQ II DIN Rail Power Supply
24V 480W 3 Phase / DRP024V480W3B
□
All parameters are specified at 25°C ambient and AC input unless otherwise indicated.
www.DeltaPSU.com (December 2018, Rev. 03)
4
Reliability Data
MTBF > 500,000 hrs. as per Telcordia SR-332
I/P: 3 x 400Vac, O/P: 100% load, Ta: 25°C
Expected Cap Life Time 10 years (3 x 400Vac & 3x 500Vac, 50% load @ 40°C)
Safety Standards / Directives
Electrical Equipment in Power
Installations
EN 50178 / IEC 62103
Electrical Safety SIQ Bauart
EN 60950-1
UL/cUL recognized UL 60950-1 and CSA C22.2 No. 60950-1 (File No. E191395)
CB scheme IEC 60950-1
Industrial Control Equipment UL/cUL listed UL 508 and CSA C22.2 No. 107.1-01 (File No. E315355)
CSA CSA C22.2 No. 107.1-01 (File No. 181564)
Hazardous Location / ATEX cCSAus CSA C22.2 No. 213-M1987, ANSI / ISA 12.12.01:2007
[Class I, Division 2, Group A, B, C, D T4, Ta = -25°C to +80°C
(> +50°C derating)]
ATEX EN 60079-0:2012, EN 60079-15:2010
[ II 3G Ex nA IIC T4 Gc, Ta= -25°C to +80°C (> +50°C
derating)]
Certificate No. EPS 13 ATEX 1 575 X
CE In conformance with EMC Directive 2014/30/EU and
Low Voltage Directive 2014/35/EU
DRP024V480W3BA:
In conformance with Equipment for explosive atmospheres
(ATEX) directive 2014/34/EU
Material and Parts RoHS Directive 2011/65/EU Compliant
Galvanic Isolation Input to Output 4.0KVac
Input to Ground 2.0KVac
Output to Ground 1.5KVac

TECHNICAL DATASHEET
CliQ II DIN Rail Power Supply
24V 480W 3 Phase / DRP024V480W3B
□
All parameters are specified at 25°C ambient and AC input unless otherwise indicated.
www.DeltaPSU.com (December 2018, Rev. 03)
5
EMC
Emissions (CE & RE) CISPR 32, EN 55032, CISPR 11, EN 55011,
FCC Title 47: Class B
Component Power Supply for General Use EN 61204-3
Immunity EN 55024, EN 61000-6-2
Electrostatic Discharge IEC 61000-4-2 Level 4 Criteria A1)
Air Discharge: 15kV
Contact Discharge: 8kV
Radiated Field IEC 61000-4-3 Level 3 Criteria A1)
80MHz-1GHz, 10V/M, 80% modulation (1KHz)
1.4GHz-2GHz, 3V/M, 80% modulation (1KHz)
2GHz-2.7GHz, 1V/M, 80% modulation (1KHz)
Electrical Fast Transient / Burst IEC 61000-4-4 Level 3 Criteria A1)
2kV
Surge IEC 61000-4-5 Level 3 Criteria A1)
Common Mode2): 2kV
Differential Mode3): 1kV
Conducted IEC 61000-4-6 Level 3 Criteria A1)
150kHz-80MHz, 10Vrms
Power Frequency Magnetic Fields IEC 61000-4-8 Criteria A1)
30A/Meter
Voltage Dips IEC 61000-4-11 100% dip; 1 cycle (20ms); Self Recoverable
Low Energy Pulse Test (Ring Wave) IEC 61000-4-12 Level 3 Criteria A1)
Common Mode2): 2kV
Differential Mode3): 1kV
Harmonic Current Emission IEC/EN 61000-3-2, Class A
Voltage Fluctuation and Flicker IEC/EN 61000-3-3
1) Criteria A: Normal performance within the specification limits
2) Asymmetrical: Common mode (Line to earth)
3) Symmetrical: Differential mode (Line to line)

TECHNICAL DATASHEET
CliQ II DIN Rail Power Supply
24V 480W 3 Phase / DRP024V480W3B
□
All parameters are specified at 25°C ambient and AC input unless otherwise indicated.
www.DeltaPSU.com (December 2018, Rev. 03)
6
Block Diagram
Device Description
1) Input terminal block connector
2) Output terminal block connector
3) DC Voltage adjustment potentiometer
4) DC OK control LED (Green)
5) Universal mounting rail system

TECHNICAL DATASHEET
CliQ II DIN Rail Power Supply
24V 480W 3 Phase / DRP024V480W3B
□
All parameters are specified at 25°C ambient and AC input unless otherwise indicated.
www.DeltaPSU.com (December 2018, Rev. 03)
7
Dimensions
L x W x D: 121 x 140 x 117.3 mm (4.76 x 5.51 x 4.62 inch)
Engineering Data
Output Load De-rating VS Surrounding Air Temperature
Note
1. Power supply components may degrade, or
be damaged, when the power supply is
continuously used outside the shaded region,
refer to the graph shown in Fig. 1.
2. If the output capacity is not reduced when the
surrounding air temperature >50°C (Vertical),
the device may run into Over Temperature
Protection. When activated, the output
voltage will go into bouncing mode and will
recover when the surrounding air
temperature is lowered or the load is reduced
as far as necessary to keep the device in
working condition.
3. In order for the device to function in the
manner intended, it is also necessary to keep
a safety distance of 5mm (0.20 inch) for
Vertical Mounting with adjacent units while
the device is in operation.
4.
Depending on the surrounding air
temperature and output load delivered by the
power supply, the device can be very hot!
5. If the device has to be mounted in any other
orientation, please contact
[email protected]om for more details.
Fig. 1 De-rating for Vertical Mounting Orientation
> 50°C de-rate power by 2.5% / °C,
> 70°C de-rate power by 5% / °C

TECHNICAL DATASHEET
CliQ II DIN Rail Power Supply
24V 480W 3 Phase / DRP024V480W3B
□
All parameters are specified at 25°C ambient and AC input unless otherwise indicated.
www.DeltaPSU.com (December 2018, Rev. 03)
8
Output Load De-rating VS Input Voltage
Assembly & Installation
The power supply unit (PSU) can be mounted on 35mm DIN rails in accordance with EN 60715. For Vertical Mounting, the device
should be installed with input terminal block at the bottom.
Each device is delivered ready to install.
Mounting
No output power de-rating across the entire
input voltage range 3 x 320-600Vac
(3-Phase) or 2 x 360-600Vac (2-Phase)
Dismounting
Fig. 2.1 Mounting
Snap on the DIN rail as shown in Fig. 2.1:
1. Tilt the unit upwards and insert it onto the DIN rail.
2. Push downwards until stopped.
3. Press against the bottom front side for locking.
4. Shake the unit slightly to ensure that it is secured.
Fig. 2.2 Dismounting
To uninstall, pull or slide down the latch with screw driver as
shown in Fig. 2.2. Then slide the power supply unit (PSU) in
the opposite direction, release the latch and pull out the power
supply unit (PSU) from the rail.
In accordance to EN 60950 / UL 50950, flexible cables require ferrules.
Use appropriate copper cables designed to sustain operating temperature of:
1. 60°C, 60°C / 75°C for USA
2. At least 75°C for ambient not exceeding 50°C, and 90°C for ambient exceeding 50°C for Canada.

TECHNICAL DATASHEET
CliQ II DIN Rail Power Supply
24V 480W 3 Phase / DRP024V480W3B
□
All parameters are specified at 25°C ambient and AC input unless otherwise indicated.
www.DeltaPSU.com (December 2018, Rev. 03)
9
Safety Instructions
Vertical Mounting
•ALWAYS switch mains of input power OFF before connecting and disconnecting the input voltage to the unit. If mains are not
turned OFF, there is risk of explosion / severe damage.
•To guarantee sufficient convection cooling, keep a distance of 50mm (1.97 inch) above and below the device as well as a
lateral distance of 5mm (0.20 inch) to other units.
•Note that the enclosure of the device can become very hot depending on the surrounding air temperature and load of the power
supply. Risk of burns!
•Only plug in and unplug connectors when power is turned off!
•DO NOT insert any objects into the unit.
•Hazardous voltages may be present for up to 5 minutes after the input mains voltage is disconnected. Do not touch the unit during
this time.
•The power supplies unit should be installed in minimum IP54 rated enclosure.
•The power supplies are built in units and must be installed in a cabinet or room (condensation free environment and indoor
location) that is relatively free of conductive contaminants.
•CAUTION: “For use in a controlled environment”.
•It is NOT advised to install in horizontal mounting orientation, since it may cause damage to the PSU.
For DRP024V480W3BA:
•The power supplies unit must be installed in an IP54 enclosure or cabinet in the final installation. The enclosure or cabinet must
comply with EN60079-0 or EN60079-15.
•Warning: Explosion Hazard - Substitution of components may impair suitability for Class I, Division 2.
•Warning: Explosion Hazard - Do not disconnect equipment or adjust potentiometer unless the power has been switched off or the
area is known to be non-hazardous.

TECHNICAL DATASHEET
CliQ II DIN Rail Power Supply
24V 480W 3 Phase / DRP024V480W3B
□
All parameters are specified at 25°C ambient and AC input unless otherwise indicated.
www.DeltaPSU.com (December 2018, Rev. 03)
10
Functions
Graph illustrating the Start-up Time, Rise Time, and Hold-up Time
Start-up Time
The time required for the output voltage to reach 90% of its final steady state set value, after the input voltage is applied.
Rise Time
The time required for the output voltage to change from 10% to 90% of its final steady state set value.
Hold-up Time
Time between the collapse of the AC input voltage, and the output falling to 95% of its steady state set value.
Inrush Current
Inrush current is the peak, instantaneous, input current measured
and, occurs when the input voltage is first applied. For AC input
voltages, the maximum peak value of inrush current will occur
during the first half cycle of the applied AC voltage. This peak
value decreases exponentially during subsequent cycles of AC
voltage.
Dynamic Response
The power supply output voltage will remains within ±5% of its
steady state value, when subjected to a dynamic load from 10%
to 90% of its rated current.
