Delta D1600e User manual

INSTRUCTIONMANUAL
PART NO. D27665 Rev. 0
Copyright © 2002 Delta Machinery
To learn more about DELTA MACHINERY
visit our website at: www.deltamachinery.com.
For Parts, Service, Warranty or other Assistance,
please call 1-866-422-4286
Electric Pressure
Washer with
2400 Cleaning Units
(Model D1600e)
ESPAÑOL: PÁGINA 15
FRANÇAIS: PAGE 29

2- ENG
D27665
indicates an imminently hazardous situation which, if not
avoided, will result in death or serious injury.
indicates a potentially hazardous situation which, if not
avoided, could result in death or serious injury.
indicates a potentially hazardous situation which, if not
avoided, may result in minor or moderate injury.
used without the safety alert symbol indicates potentially
hazardous situation which, if not avoided, may result in
property damage.
This manual contains
information that is
important for you to
know and understand.
This information re-
lates to protecting
YOUR SAFETY and
PREVENTING
EQUIPMENT PROB-
LEMS. To help you
recognize this infor-
mation, we use the
symbols to the right.
Please read the man-
ual and pay attention
to these sections.
SAFETY GUIDELINES / DEFINITIONS
Read Operator’s Manual. Do not operate equipment until you
have read Operator’s Manual for Safety, Assembly, Operation,
and Maintenance Instructions.
GENERAL INFORMATION
●Congratulations! You have purchased a high quality product from America’s
leading manufacturer of pressure washers. This pressure washer, when
properly used and maintained, will provide trouble free service. Please read
and follow these instructions for proper use and maintenance.
●All sales of pressure washers are final. Do not return this product to the
retailer. Call 1-866-422-4286.
●If you experience any problems and need assistance, please call us at our
toll free number 1-866-422-4286, Monday through Saturday, 8:00 a.m. To
6:00 p.m. C.S.T.
●If repair or service part purchase is required, our many Authorized Warranty
Service Centers are conveniently located and equipped to handle all in-
warranty and out-of-warranty service.
●For the location of the nearest Authorized Warranty Service Center call
1-866-422-4286, Ext. 2, 24 hours a day, 7 days a week.
●All pressure washers carry a manufacturer's one year warranty from date of
purchase for consumer use and a 90 day warranty for commercial use.
●Retain sales receipt as proof of purchase for warranty service.
●Do not operate this unit until you have read and understood this Owners
Manual for Safety, Operation, and Maintenance Instructions.

3- ENG D27665
IMPORTANT SAFETY INSTRUCTIONS
Improper operation or maintenance of this product could result in serious
injury and property damage. Read and understand all warnings and
operating instructions before using. Follow maintenance instructions specified in this
manual.
RISK OF
EXPLOSION
OR FIRE
HAZARD WHAT CAN HAPPEN HOW TO PREVENT IT
Do not use acids, gasoline, kerosene,
or any other flammable materials in this
product. Use only household
detergents, cleaners, and degreasers
recommended for use in Pressure
Washers. Work in a well ventilated area.
Use of acids, unapproved chemicals,
or flammable solvents with this
product could cause injury or death.
RISK TO
BREATHING
• Some cleaning fluids contain sub-
stances which could cause injury to
skin, eyes, or lungs.
•Use only cleaning fluids specifically
recommended for high pressure
washers. Follow manufacturers
recommendations. Do not use
chlorine bleach or any other
corrosive compound.
RISK TO FLUID
INJECTION
• Your washer operates at fluid
pressures and velocities high enough
to penetrate human and animal flesh,
which could result in amputation or
other serious injury. Leaks caused by
loose fittings or worn or damaged
hoses can result in injection injuries.
DO NOT TREAT FLUID INJECTION
AS A SIMPLE CUT! See a physician
immediately!
• Never place hands in front of nozzle.
• Do not direct discharge stream at
persons or animals.
• Make sure hose and fittings are
tightened and in good condition.
Never hold onto the hose or fittings
during operation.
• Do not operate pressure washer with
worn or abraded hose.
• Never attach or remove wand or hose
fittings while system is pressurized.
• Injuries can result if system pressure
is not reduced before attempting
maintenance or disassembly.
• To relieve system pressure, place
on/off switch in off position, turn off
water supply, and pull gun trigger
until water stops flowing.
• Use only hose and high pressure
accessories rated for pressure higher
than your pressure washer's p.s.i.
RISK OF
ELECTRICAL
SHOCK
• Water spray directed at electrical
outlets or switches, or objects con-
nected to an electrical circuit, could
result in a fatal electrical shock.
• Unplug any electrically operated
product before attempting to clean it.
Direct spray away from electric outlets
and switches.
• This product is powered by
electricity. It contains and sprays
water and other conductive liquids.
Improper operation could result in
electrocution.
•The Ground Fault Circuit
Interrupter (GFCI) will not function
properly unless connected to a fully
grounded electrical circuit!
• Extension cords can lead to electrical
shock.
•Always connect cordset to a
properly grounded and polarized
electrical circuit. Your cordset is
equipped with a Ground Fault Circuit
Interrupter (GFCI) for your personal
protection.
• If damaged, the entire cordset
assembly must be replaced by an
authorized service center. Refer to
Grounding Instructions.
• Do not use with extension cords.
Restricting any of the pressure
washer ventilation openings will
cause serious overheating and could
cause fire.
Never place objects against or on
top of pressure washer. Operate
pressure washer in an open area at
least 12 inches away from any wall
or obstruction that would restrict the
flow of fresh air to the ventilation
openings.

4- ENG
D27665
• Do not use acids, gasoline, kero-
sene, or any other flammable
materials in this product. Use only
household detergents, cleaners and
degreasers recommended for use in
pressure washers.
• Wear protective clothing to protect
eyes and skin from contact with
sprayed materials.
• Use of acids, toxic or corrosive
chemicals, poisons, insecticides, or
any kind of flammable solvent with
this product could result in serious
injury or death.
RISK OF
CHEMICAL
BURN
• Reactive force of spray will cause
gun/wand to move, and could
cause the operator to slip or fall, or
misdirect the spray. Improper
control of gun/wand can result in
injuries to self and others.
• Do not overreach or stand on an
unstable support. Grip gun/wand
firmly with both hands. Expect the
gun to kick when triggered.
HAZARD WHAT CAN HAPPEN HOW TO PREVENT IT
• The spray gun/wand is a powerful
cleaning tool that could look like a
toy to a child.
• Keep children away from the
pressure washer at all times.
RISK OF
UNSAFE
OPERATION
• Unsafe operation of your pressure
washer could lead to serious injury
or death to you or others.
• Do not use chlorine bleach or any
other corrosive compound.
• Become familiar with the operation
and controls of the pressure
washer.
• Keep operating area clear of all
persons, pets, and obstacles.
• Do not operate the product when
fatigued or under the influence of
alcohol or drugs. Stay alert at all
times.
• Never defeat the safety features of
this product.
• Never leave wand unattended while
unit is running.
• Know how to stop product and
bleed pressure quickly.
• Pressure washer pump contains
moving parts. Contact with moving
parts can cause serious injury.
• Never operate machine with pump
guard removed.
• Do not operate machine with
missing, broken, or unauthorized
parts.
• Contact with hot surfaces could
result in serious burn. • During operation, touch only the
control surfaces of the pressure
washer. Keep children away from the
pressure washer at all times. They
may not be able to recognize the
hazards of this product.
RISK OF
HOT
SURFACES
RISK OF INJURY
FROM SPRAY
• High velocity fluid spray can
cause objects to break,
propelling particles at high
speed.
• Light or unsecured objects can
become hazardous projectiles.
• Always wear ANSI approved Z87
safety glasses.Wear protective
clothing to protect against accidental
spraying.
• Never point wand at, or spray people
or animals.
• Always secure trigger lock when
wand is not in service to prevent
accidental operation.
• Never permanently secure trigger in
pull back (open) position.

5- ENG D27665
The powerful spray from your pressure washer is capable of causing
damage to surfaces such as wood, glass, automobile paint, auto striping
and trim, and delicate objects such as flowers and shrubs. Before spraying, check the item to
be cleaned to assure yourself that it is strong enough to resist damage from the force of the
spray. Avoid the use of the concentrated spray stream except for very strong surfaces like
concrete and steel.
SAVE THESE INSTRUCTIONS
GROUNDING INSTRUCTIONS
This product must be grounded. If it
should malfunction or breakdown,
grounding provides a path of least
resistance for electric current to reduce
the risk of electric shock. This product
is equipped with a cord having an
equipment-grounding conductor and a
grounding plug. The plug must be
plugged into an appropriate outlet that
is properly installed and grounded in
accordance with all local codes and
ordinances.
Improper connection
of the equipment-
grounding conductor can result in
risk of electrocution. Check with a
qualified electrician or service
personnel if you are in doubt as to
whether the outlet is properly
grounded. Do not modify the plug
provided with the product-if it will
not fit the outlet, have a proper
outlet installed by a qualified
electrician. Do not use any type of
adapter with this product.
EXTENSION CORDS
Use additional length of high pressure
hose instead of extension cords to
avoid voltage drop and power loss to
the motor, and to prevent overheating.
DO NOT USE EXTENSION CORDS.
NOTE: The use of additional length of
high pressure hose will lower the
pressure washer's PSI below 1600.
GROUND FAULT CIRCUIT
INTERRUPTER PROTECTION
This pressure washer is provided with
a ground fault circuit interrupter (GFCI)
built into the plug of the power supply
cord. This device provides additional
protection from the risk of electric
shock. Should replacement of the plug
or cord become necessary, use only
identical replacement parts that
include GFCI protection.
