1.25Gbps Upstream/1.25Gbps Downstream
GE-PON ONU Transceiver
FEATURES
 RoHS compliant
 IEEE802.3ah Gigabit Ethernet compliant

2x5 pin SFF package with SC Receptacle
 1310nm Burst Mode 1.25Gbps transmitter,
and 1490nm Continuous Mode 1.25Gbps
receiver
 Integrated with WDM filter to cut 1550nm and
1650nm optical signal off
 Single +3.3V power supply
 LVPECL electrical signal interface

LVTTL Bias Control input and Rx Signal
Detect output
 Laser Class 1 Product which comply with the
requirements of IEC 60825-1 and IEC 60825-2
Description
DELTA’s GE-PON ONU transceiver
OPEP-33-A4Q1R is designed for Gigabit Ethernet
Passive Optical Network transmission.
The module is contained in a 2x5 SFF
package with standard SC receptacle connector.
The module consists 1310nm FP laser,
InGaAs PIN, Preamplifier and WDM filter in a
high-integrated optical sub-assembly, and it
receives up to 1.25Gbps of continuous data at
1490nm, and transmits 1.25Gbps of burst-mode
data at 1310nm.
Application
 IEEE 802.3ah 1000BASE-PX10-U
 GE-PON ONU
 Burst Mode Application
 FTTx WDM Broadband Access
 OPEP-33-A4Q1R data link up to 10km in
9/125um single mode fiber.

OPEP-33-A4Q1R
DELTA ELECTRONICS, INC.
2 Revision: S2
02/02/2007
www.deltaww.com
1. Absolute Maximum Ratings
Parameter Symbol Min. Typ. Max. Unit Note
Storage Temperature Ts -40 85 ºC
Storage Ambient Humidity HA5 95 %
Power Supply Voltage VCC -0.3 4 V
Signal Input Voltage -0.3 Vcc+0.3 V
Receiver Damage Threshold +2 dBm
Lead Soldering Temperature/Time TSOLD 260/10 ºC/sec Note (1)
Lead Soldering Temperature/Time TSOLD 380/10 ºC/sec Note (2)
Note (1). Suitable for wave soldering
Note (2). Only for soldering by iron
2. Recommended Operating Conditions
Parameter Symbol Min. Typ. Max. Unit Note
Ambient Operating Temperature TA0 70 ºC
Without air flow
Ambient Humidity HA5 85 %
Non-condensing
Power Supply Voltage VCC 3.13 3.3 3.47 V
Power Supply Current ICC 300 mA
Power Supply Noise Rejection 100 mVp-p 100Hz to 1MHz
Data Rate 1.25
-100ppm 1.25 1.25 +100ppm Gbps
Transmission Distance 10 km
3. Specification of Transmitter
Parameter Symbol Min. Typ. Max. Unit Note
Average Launched Power PO-1 +4 dBm Note (1)
Launched power (Peak.) PP+7.5 dBm
Extinction Ratio ER 9 dB
Center Wavelength λC1260 1310 1360 nm FP Laser
Spectrum Width (RMS) σCompliant with IEEE 802.3ah nm Note (4)
Transmitter OFF Output Power POff -45 dBm
Laser Burst On Time Ton 32
Laser Burst Off Time Toff 32
Optical Rise/Fall Time tr/tf260 ps Note (2)
Total Jitter tJ128 ps Note (3)
Optical Return Loss Tolerance ORLT 15 dB
Relative Intensity Noise RIN15OMA -113 dB/Hz
Optical Transmitter Reflectance -6 dB
Transmitter and Dispersion Penalty TDP 2.8 dB
Output Eye Mask
{X1,X2,Y1,Y2,Y3}
Compliant with IEEE 802.3ah
{0.22,0.375,0.20,0.20,0.30} Note (5)
Note (1). Launched power (avg.) is power coupled into a single mode fiber with master connector.
Note (2). These are unfiltered 20-80% values.
Note (3). Measure at 27-1 NRZ PRBS pattern

OPEP-33-A4Q1R
DELTA ELECTRONICS, INC.
3 Revision: S2
02/02/2007
www.deltaww.com
Note (4). Transmitter spectral limits
Note (5). Transmitter eye mask definition
4. Specification of Receiver
Parameter Symbol Min. Typ. Max. Unit Note
Input Optical Wavelength λIN 1480 1490 1500 nm PIN-PD
Receiver Sensitivity PIN -26 dBm Note (1)
Input Saturation Power (Overload) PSAT -3 dBm
Signal Detect -Assert Power PA- -26 dBm
Signal Detect -Deassert Power PD-44 dBm Note (2)
Signal Detect Hysteresis PA-PD0.5 2 6 dB
Data Output Rise/Fall time tr/tf260 ps Note (3)
Receiver
Reflectance 1480 to 1500nm -12 dB Note (4)
1260 to 1360nm -43 dB
1550 to 1560nm -33 dB
Optical Isolation
from External
Source 1640 to 1665nm -33 dB
Center Wavelength
R
MS spectral width(max)
1000Base-PX10-U
nm nm
1260 2.09
1270 2.52
1280 3.13
1290
1295
1297
1329
1331
1340
3.50
1350 3.06
1360 2.58
Transmitter Spectral Limits
0
1
2
3
4
1240 1260 1280 1300 1320 1340 1360 1380
Center Wavelength (nm)
RMS (nm)
1
0
X1 X2 1-X2 1-X1
1+ Y 3
1
1-Y1
0.5
Y1
0
-Y2
N
ormalized Time
N
ormalized Amplitude

OPEP-33-A4Q1R
DELTA ELECTRONICS, INC.
4 Revision: S2
02/02/2007
www.deltaww.com
Note (1). Measured with Light source +1dBm, 1490nm, ER=9dB; BER =<10-12@PRBS=27-1 NRZ
This assurance should be met with asynchronous data flowing out of the optical transmitter of
the system under test. The output data pattern from the transmitter of the system under test is a
repetition of alternate 0/1 pattern as defined for this measurement.
Note (2). When SD deasserted, the data output is Low-level (fixed)
Note (3). These are 20%~80% values.
Note (4). Measured at wavelength of 1490nm.
5. Electrical Interface Characteristics
Parameter Symbol Min. Typ. Max. Unit Note
Transmitter
Total Supply Current ICC A mA Note (1)
Differential line input Impedance RIN 80 100 120 Ohm
Differential Data Input Swing VDT 400 1600 mVp-p
Data Input Voltage- High VIH-VCC -1.165 -0.880 V
Data Input Voltage- Low VIL-VCC -1.810 -1.475 V LVPECL
BiasCNT Input Voltage- High VBCH 2 Vcc V
BiasCNT Input Voltage- Low VBCL 0 0.8 V LVTTL
Receiver
Total Supply Current ICC B mA Note (1)
Differential Data Output Swing VDR 400 650 900 mVp-p Note (2)
Signal Detect Output Voltage-High VLOSH 2 Vcc+0.3 V
Signal Detect Output Voltage-Low VLOSL 0 0.8 V LVTTL
Note (1). A (TX)+ B (RX) = 300mA (Not include termination circuit)
Note (2). Internally AC coupled, but requires a 100Ohm differential termination at or internal to Serializer/
Deserializer.
6. Transmitter Burst Mode Timing Characteristics
Parameter Symbol Min. Typ. Max. Unit Note
BiasCNT Enable Duration 1 us
Interval of BiasCNT Signal 0.112 1000000 us
B
iasCN
T
Interval of BiasCNT Signal
BiasCNT Enable Duration

OPEP-33-A4Q1R
DELTA ELECTRONICS, INC.
5 Revision: S2
02/02/2007
www.deltaww.com
VccT BiasCNT Data Input Optical Output
VccT < 3.1V X X OFF
Low X OFF
No Other
VccT > 3.1V High
Yes Laser bias and modulation signal output
X = Don’t care
Other = Less than +7.5dBm (peak)
High = Logic high level, Low = logic low level
No = No Data Input, Yes = Data Input,
OFF = Optical Power is less than –45dBm
BiasCNT
Optical Output Within 15% of steady state
Ton Toff
Data Input
L
H
7. Pin Description
Tx/Rx Pin No. I/O Pin Name Description
1
VeeR Receiver Ground
2
VccR +3.3V Receiver Power Supply
3 O
SD Normal Optical Input indicated by logic “High”, and No Optical
Input indicated by logic “Low”. (LVTTL)
4 O
RD(n) Inverted Receiver Data Output (AC-Coupled CML output)
Rx
5 O
RD(p) Non-Inverted Receiver Data Output (AC-Coupled CML output)
6
VccT +3.3V Transmitter Power Supply
7
VeeT Transmitter Ground
8 I
BiasCNT Positive pulse which control the ONU burst mode operation
9 I
TD(p) Non-Inverted Transmitter Data Input
Tx
10 I
TD(n) Inverted Transmitter Data Input
MS Mounting studs/ connect this pin to Chassis ground
Note (1). EMI shielding lead must be connected to Signal ground
Bottom View
MS
MS

OPEP-33-A4Q1R
DELTA ELECTRONICS, INC.
6 Revision: S2
02/02/2007
www.deltaww.com
8. Recommended Interface Circuit
Transmitter
9. TD(p)
10. TD(n)
8. BiasCNT
6. VccT
7. VeeT
Receiver
100nF
100nF
1. VeeR
5. RD(p)
4. RD(n)
3. SD
2. VccR
100nF
10uF 100nF
10uF 100nF
1uH
1uH
3.3V
Protocol IC
SerDes IC
100ohm
BiasCNT
SD
DELTA GEPON ONU Module
Z0=50ohm
Z0=50ohm
RES
VccR
* RES is the internal 4.7K to 10K Ohms pull-up resistor.
Coupled
interface
82ohm
130ohm
3.3V
130ohm
3.3V
82ohm 100ohm
100nF
100nF
DELTA
ONU
Host
Board
DELTA
ONU
Host
Board
Z0=50ohm
Z0=50ohm
150ohm150ohm
Z0=50ohm
Z0=50ohm
DC - Coupled interface AC - Coupled interface
Coupled
interface

OPEP-33-A4Q1R
DELTA ELECTRONICS, INC.
7 Revision: S2
02/02/2007
www.deltaww.com
9. Outline Dimensions
Parameter Unit Description Note
Mechanical Dimensions mm 48.3x13.5x9.6
Connector Type - SC/UPC connector IEC-61754-4
Week (52Weeks/Year) : 1月2日=01

OPEP-33-A4Q1R
DELTA ELECTRONICS, INC.
8 Revision: S2
02/02/2007
www.deltaww.com
10. Regulatory Compliance
Feature Test Method Reference Performance
Human Body Model
(HBM)
MIL-STD-883E Method 3015.7
EIA-JESD22-A114
Electrostatic Discharge
(ESD) to the Electrical
Pins Machine Model (MM) EIA-JESD22-A115
Contact Discharge IEC/EN 61000-4-2Electrostatic Discharge
(ESD) to the Simplex
Receptacle Air Discharge IEC/EN 61000-4-2
Radio Frequency
Electromagnetic Field
Immunity
IEC/EN 61000-4-3
Electromagnetic
Interference (EMI)
FCC Part 15 Class B
EN 55022 Class B
(CISPR 22A)
(1) Satisfied with
electrical
characteristics of
product spec.
(2) No physical damage
Laser Eye Safety
FDA/CDRH
TUV
FDA 21CFR 1040.10, 1040.11
IEC/EN 60825-1
IEC/EN 60825-2
CDRH File # 0420993
TUV Certificate #
R50032471
Component Recognition
TUV
UL/CSA
IEC/EN 60950
UL 60950
UL File # E239394
Appendix A. Document Revision
Version No. Date Description
S0 2006-08-15 Preliminary datasheet
S1 2007-01-12 Add specification for Lead Soldering Temperature/Time by iron.
S2 2007-02-02 Update the Average Launched Power to “-1~+4dBm”.
