Delta EOC-110KIT User manual

User Manual
Code: EOC-110KIT
UTP / COAXIAL TRANSMITTER EOC-110KIT 2 PCS SET
DELTA-OPTI Monika Matysiak; https://www.delta.poznan.pl
POL; 60-713 Poznań; Graniczna 10
e-mail: [email protected]; tel: +(48) 61 864 69 60
2022-03-17 EOC-110KIT 1/2
Warning!
Please read the user manual included in this work as it contains important information related with safety of installation and use of
the device.
Only persons who read the user manual may use the device.
The user manual must be kept because it may be required in the future. The device is to be used exclusively for purposes specified
in this user manual.
The device must be unpacked prior to starting-up. After removing the packaging make sure the device is in working order.
If the product has defects, it should not be used until it is repaired.
The product is intended for use at home and commercial use and may not be used for other than intended use.
The manufacturer is not liable for damages resulting from not adhering to the rules contained in the user manual, therefore, we
recommend to follow the aforementioned safety rules for operation and maintenance of the device. In this way you will ensure
yourself safety and avoid causing damage to the device.
The manufacturer and the supplier are not liable for losses or damages arising out of the product, including financial or intangible
losses, loss of profits, income, data, pleasure from use of the product or other products related with it - indirect, incidental or
consequential loss or damage. The above provisions apply whether the loss or damage concerns:
1. Deterioration of quality or the lack of operation of the products or products related with it due to damage as well as the lack of
access to the product when it is undergoing repair, which results in stoppage the loss of user's time or a break in business activity;
2. Improper results of operation of the product or products related with it;
3. It applies to losses and damages according to any legal category, including negligence and other losses, termination of a
contract, expressed or implied guarantee and strict liability (even if the manufacturer or the supplier was notified about the
possibility of occurrence of such damages).
Safety measures:
Particular attention at designing was directed to quality standards of the device where ensuring safety of operation is the most
important factor.
The device must be secured against contact with caustic, staining and viscous fluids.
The EOC-110KIT kit for Ethernet transmission via coaxial cable.
Note! Patchcord connecting end devices (switches, IP cameras,
computers) to the transmitter should be shorter than 1m.
LAN ports: 1 pcs RJ45
1 pcs BNC socket
Transmission speed: 10 / 100 Mbps Half Duplex
Transmission range: 200 m @ RG6
Main features:
• Plug & Play
• Support for IP cameras and network devices
• Full transparency for networks
Weight: 0.055 kg (single element)
Dimensions: 72 x 25 x 25 mm (single element)

User Manual
Code: EOC-110KIT
UTP / COAXIAL TRANSMITTER EOC-110KIT 2 PCS SET
DELTA-OPTI Monika Matysiak; https://www.delta.poznan.pl
POL; 60-713 Poznań; Graniczna 10
e-mail: [email protected]; tel: +(48) 61 864 69 60
2022-03-17 EOC-110KIT 2/2
Guarantee: 2 years
Transmission schematic diagram:
1. IP Camera
2. Twisted-pair cable
3. Coaxial cable max. 200 m
4. IP DVR
