Demco Reef User manual

Installation Instructions
Panel Table
Recommended Tools
Page 1 of 3Reef
Package Contents
Step 1
Attach Stretcher Rails to End Panels
• Stand End Panels upright and attach Stretcher Rail
using 1/4 ”bolts. Do not tighten bolts firmly until both
Stretcher Rails are in place.
• After both Stretcher Rails are placed, tighten bolts firmly.
Hardware Used
1/4
x 1”Machine Bolts
#8 x 5/8 ”Flat Head Wood Screws
Top
End Panels
Stretcher Rails
Note: Two people are recommended for assembly.
Insert bolts; Keep bolts
loose until both Stretcher
Rails are in place
Tighten bolts
firmly once both
Stretcher Rails
are in place.
#8 x 5/8 ”Pan Head Wood Screws
#2 Phillips Head Bit
#2 Phillips Screw Driver
Screw Gun
Level
Socket
Wrench
7/16 ”
Socket 3/16 ”
Hex Wrench
1/4 - 20 x 3/4 ”
Socket Head Cap Screws
(Used with Foot Rail option)
Notice To Installers: Failure to comply with installation
instructions will compromise the safety, durability and
performance of this product, which may risk injury to the user
of this product and/or diminish the product life cycle. Jasper
Group assumes no liability in these instances.
Find Reef Tables @demco.com
Search:
Reef Tables
Call 800.962.4463 or email [email protected]

Installation Instructions
Page 2 of 3
Panel Table
(continued)
Reef
Step 2
Attach Worksurface to Frame
• Place worksurface onto frame. Align edges accordingly.
• Fasten top to frame using all under surface brackets.
Use #8 x 5/8 ”flat head screws on triangle brackets
and #8 x 5/8 ”pan head screws on L-brackets.
Step 3
Level Table
• Level table front-to-back and side-to-side
by rotating adjustable glides.
#8 x 5/8 ”Flat Head Screws
#8 x 5/8 ”Pan Head Screws
Notice To Installers: Failure to comply with installation
instructions will compromise the safety, durability and
performance of this product, which may risk injury to the user
of this product and/or diminish the product life cycle. Jasper
Group assumes no liability in these instances.
Find Reef Tables @demco.com
Search:
Reef Tables
Call 800.962.4463 or email [email protected]

Installation Instructions
Table Options
Page 3 of 3Reef
Coat Hook
Attach Coat Hooks to End Panels
• Pilot holes have been factory pre-drilled for the four
coat hook locations. Use these holes and #8 x 5/8 ”
flat head screws to attach hooks to end panels.
Coat Hook
Foot Rails
#8 x 5/8 ”
Flat Head
Wood Screws
Panel Table
(Options)
Coat Hook
Foot Rails
Foot Rail
Attach Foot Rails to End Panels
• Locate holes with threaded inserts towards bottom of end panels.
• Carefully slide Foot Rails into place between end panels.
Note: Bottom of End Panels may need to pulled out slightly as
not to scratch/mar inside surfaces.
• Fasten using 1/4 - 20 x 3/4 ”
Socket Head Cap Screws.
Pilot Holes
#8 x 5/8 ”
Flat Head Screws
Threaded
Metal Inserts
Flange points
down & inward
towards center
of table
Slightly pull bottom of end panels outward
in order to slide Foot Rails into place
without marring surfaces
Coat Hooks
1/4 - 20 x 3/4 ”
Socket Head
Cap Screws
3/16 ”
Hex Wrench
1/4 - 20 x 3/4 ”
Socket Head
Cap Screw
