MAKERSPACE –ROVER TABLE
ASSEMBLY INSTRUCTIONS
Find Haskell Education Rover Table @demco.com,
search haskell education rover table
Call 800.962.4463 or email custs[email protected]

Components
A. Frame Assembly (1)
Black Sticker Dot
referencing “FRONT”
B. Table Top (1)
C. Outside Panel (1)
D. Outside Panel for Power (1)
E. Inside Panel (2)
F. Latch Assembly (2)
F1 - Latch
F2 - Paddle
G. Bin Module (2)
H. 6” Bin (1)
I. 4” Bin (4)
J. Magnetic Catch (2)
K. Table Top Stop (2)
L. Snap-in Grommet (1)
M. Power Unit Box &
Instructions
ABCDE
FGHI
JKLM
Right Hand Facing
Left Hand Facing
F1
F2

NBB1 PQ
RS
Components
N. Panhead Wood Screws
-#10x1” (6)
BB. Button Head Screw
BB.1 –M6x1x16mm (24)
BB.2 –M6x1x19mm (8)
P. Caster (4)
Q. Foot (4)
R. Cord Clip (2)
S. Panhead Self-Tapping Screw
(Gold) - #6x3/8x10mm (24)
T. Outside Panel Plug (1)
U. Panhead Plug Screw
- M4x.7x19 (3)
V. Cord Wrap (1)
TUV
BB2

Tools Required for Assembly
(C)
(A)
(A)
()
(C)
(D)
(E)
(F)
(C)
(D
(
(
IMPORTANT: Assemble of the
Rover Table requires (2) people
capable of lifting 75 lbs each.
(Table Top weighs 150 lbs)
X. #2 Phillips Screwdriver
W. 4mm Allen Key
Y. ¾” Combination Wrench
Z. Medium Strength Loctite
WX
YZ
X
AA. Box Cutter Knife
AA

Step 1: While frame is upside down. Gather Caster (4) (R), a ¾” Combination Wrench (Y)
and Loctite (Z) . Lock the caster by pressing the lever. Apply Loctite (Z) to the threaded stem
of the Caster (R). Insert caster stem into the hole in the bottom frame. Hand thread the nut
onto the threaded stem and tighten with the ¾” Combination Wrench (Y).
Press lever to lock Caster Apply Loctite
R

Step 2: Flipping the frame right-side up, set the frame assembly onto its casters. Double
check the tightening of the casters with the ¾” combination wrench (Y), to make sure they
are fully tightened.
NOTE: Failure to do so will lead to
product failure

Step 3: Insert Foot (G) into open end of Bottom Frame (F). Firmly push into place by
hand until fully seated. Repeat process for each corner x3.
F
G

Step 4: Locate the Table Top (B) and the front of the Frame Assembly (A)(Familiarize
yourself with the front and back – Black Sticker references the “FRONT” of the frame). Make
sure the bracket mechanisms are flat (Aligned with the top edge of the frame). With two
people, set the Table Top (B) onto the Frame Assembly (A).
B
A
NOTE: Front of the Table Top (A)
has the holes for the Table Stops
(K)

Step 5: Using the 4mm Allen Key (W) and the Button Head Screw (BB1)(Using all 22
screws), attach the Table Top (B) to the Frame Assembly (A).
O
A
B

Step 6: With a box cutter knife (AA), cut the banding that holds the tilt mechanism in
place. Repeat on opposite side.
Cut Here
Banding

Table Top Component Locations Reference –Bottom View
Front
F1
F2
J
K
M

Step 7: Screw the Table Top Stop (K) into the threaded insert in the Table Top (B) in both
mounting locations.
2X
1x 1x
KFront

Step 8: Fasten the Magnetic Catch (J) using three Panhead Wood Screws (N) and a #2
Philips Screwdriver (X). Repeat for the second Magnetic Catch (J).
2X
1x 1x
J
N
Front
Warning: Overtightening
will risk failure of the
product

Step 9: Attach the Paddle (F2) to the Table Top (B) with four Wood Screws (N) and a #2
Phillips screwdriver (X). Do not overtighten. Repeat for second paddle (F2).
1x 1x
2X
Front
Warning: Overtightening
will risk failure of the
product
F2

Step 10: Fasten the Latch (F1) to the Table Top (B) using four Button Head Screws (BB2)
and the 4mm Allen Key (W). Repeat for second Latch (F1).
2X
1x 1x
Front
F1

Step 11: Locate the Power Unit Box & Instructions (M). Follow the manufacturer’s
instructions to properly install the Power Unit. Note: The cord end is to be directed toward
the right side facing the table.
Powered Units Only
M
Bottom View

Step 12: Affix the Cord Clips (R) to the underside of Table Top (B) 11” apart and 1” from
the Frame Assembly (A).
Powered Units Only
2X 11”11”
A

Cord has enough slack to allow
tabletop to close without putting
tension on cord.
Step 13: Provide enough slack in the power cord to allow the tabletop to close without
tension on the cord. Open Snap-in Grommet (L) and secure over cord. Close tightly, using
pliers if necessary. Push Snap-in Grommet (L) into hole in frame.
Powered Units Only
L

Step 14: Fit inside panel between the end of the frame with the notch in the panel
facing up. Secure the Inside Panel (E) with the five Self-tapping Screws (S) through the five
mounting holes into the Frame Assembly (A) using a #2 Phillips Screwdriver (X). Repeat this
process for the other side.
Notch
E
A
5X
*Mechanism and table top are hidden for clarity

Powered Units Only
Step 15: Locate the Cord Wrap (V), the Outside Panel Plug (T), three Panhead Plug
Screws (U), Outside Panel w/Power (D) and a #2 Philips Screwdriver (X). Install Outside Panel
Plug (T) through the Cord Wrap (V) and the hole in the Outside Panel w/Power (D), secure in
place with three Panhead Plug Screws (U).
T
V
D
U
