Demco PHOENIX ML44 User manual

Phoenix 44" Wide Format
Mounting Laminator
Instruction Manual

P HOENIX
TM
P HOENIX
TM
44 Laminator
Pouch / Roll Laminator
Operators
Manual
Model ML44
REV C

S
• OVERVIEW 3
• SAFETY INFORMATION 4
• SET-UP AND ELECTRICAL REQUIREMENTS 5
• STAND ASSEMBLY (OPTIONAL) 6
• ROLLER KIT INSTALLATION (OPTIONAL) 7
• ROLLER GAP CONTROL KNOB REAR PANEL 8
• OPERATIONAL CONTROL PANEL 9
• MOUNTING USING A HEAT ACTIVATED MOUNTING BOARD 10
• MOUNTING AND LAMINATING USING A POUCH BOARD 11
• ENCAPSULATING USING A FLEXIBLE POUCH 12
• USING ROLL FILMS IN A PHOENIX 13
• CLEANING YOUR PHOENIX LAMINATOR 14
• TROUBLESHOOTING GUIDE 15
• TECHNICAL SERVICE / REPAIR CENTERS 16
• MOUNTING AND LAMINATING TERMS 17
• TECHNICAL SPECIFICATIONS 18
• WIRING DIAGRAM 19
• PARTS LIST 20
• LIMITED WARRANTY 23
• PHOENIX SUPPLIES 24tor
TABLE OF CONTENT
PHOENIX 44 LAMINATOR

Thank you for purchasing a PHOENIX
laminator. We have designed the PHOENIX
Laminator to give you years of reliable
service. As you become familiar with the
PHOENIX laminator you will appreciate the
high quality of its production and the
excellence in its engineering design.
By following the guidelines for proper care
and use of the PHOENIX laminator you
can depend on many years of trouble-free
profitability from your investment.
The purpose of this manual is to outline
materials and processes. This manual will
show you how to use PHOENIX supplies
with your laminator to create signs
displays and flexible graphics with
professional results.
The manual includes instructions of
various laminating procedures which are
meant to give you comprehensive
information needed for the efficient use of
your laminator.
Please read and fully understand the
entire manual before proceeding to
use your laminator.
MOUNTING AND LAMINATING U E
Your Phoenix Laminator has been designed to
be used with pouch boards thermal laminat-
ing films and flexible pouches. When using
pouch boards and film pouches you are able
to laminate and encapsulate prints in one
step. You may also use roll film products and
the PHOENIX has been tested and laminates
well with polyester based films with low tem-
perature adhesives (I.e. adhesive which work
below 200 degrees). For other materials you
will have to test those films to determine the
best settings and applicability of those prod-
ucts.
WARNING! This laminator is designed
for mounting and laminating. Any use
other than the intended may cause
damage to the laminator or physical
harm to the user.
WARNING! Any unauthorized changes or
modifications to this unit without our prior
written approval will void the user’s warranty
and will transfer health and safety obligations
to the user.
LIABILITY TATEMENT
The details given in this manual are based on
the most recent information available to us.
They may be subject to change in the future.
We retain the right to make changes to the
construction or the design of our products
without accepting any responsibility for
modifying earlier versions.
CAUTION! Please pay attention to all pas-
sages marked this way. This information is
vital to preventing user injury and/or damage
to the unit. Failure to follow this information
could void the user's warranties and transfer
all safety obligations to the user.
Owner’s Manual Overview
PHOENIX 44 LAMINATOR 3

When using electrical appliances basic
precautions should always be taken to re-
duce the risk of electrical shock and injury
to persons including the following:
1. Read all instructions before connecting
or operating this unit.
2. Retain this Owners Manual for future
reference. For technical assistance
beyond what is covered in this manual
contact Technical Service.
3. Save your carton! PHOENIX laminators
are shipped in special cartons and should
be used in case your PHOENIX laminator
should ever require service or need to be
transported.
NOTICE! Failure to return machines
properly packed in original packaging
will impose a fifteen percent
restocking fee plus costs to repair
shipping damage. Contact Technical
ervice for a return authorization
(see WARRANTY AND AUTHORIZED
REPAIR CENTER ).
4. Do not use the laminator for other
than its intended use.
5. The Laminator case may be cleaned
with a lint-free cloth lightly
dampened with a mild soap and
water solution. Do not use spray-on
cleaners.
NOTE: Disconnect the laminator from
the main power supply before
cleaning!
6. Do not immerse any part of the
laminator in water or other liquids..
7. The laminator's location or position should
not interfere with its proper ventilation. Do
not install or place in a built-in enclosure
such as a bookcase.
8. Do not operate the laminator with a
damaged cord or plug or after the laminator
has been dropped or damaged in any
manner. If purchased in U.S./Canada
return the laminator to your ADEMCO reseller for
examination repair or adjustment.
8. Do not let the cord hang over the edge of a
counter/bench or touch hot surfaces.
9. Always unplug the laminator when it is not
in use for a long period.
10. This unit should only be connected to a
power supply outlet of the voltage
amperage and frequency marked on the
rear panel. The laminator has a grounded
plug (three prongs). To reduce the risk of
electrical shock this plug is intended to fit
only a grounded outlet of the proper
amperage and in only one way.
If the plug does not fit in the outlet, contact
a qualified electrician.
WARNING! Do not modify the plug in
any way.
AFETY I NFORMATION
PHOENIX 44 LAMINATOR
4

The PHOENIX 44 is a professional laminator
designed for ease of use. The process speed
and temperature have been preset to eliminate
operator guesswork. The factory setting will
facilitate good quality results using the
Flexible Pouches and Pouch Boards using low
temperature adhesives.
The PHOENIX 44 can handle Flexible Pouches
and Pouch Boards up to 44 inches (1120mm) wide.
Please familiarize yourself with machine
operation before installation operating the
Control Panel and the Nip Control Knob.
Installation of your PHOENIX Laminator
Please read and fully understand the entire manual
before proceeding to use your laminator.
Without the PHOENIX Stand your PHOENIX
laminator must be lifted and carried to the place
where it will be used. This should be done by at least
two people one on each side. Grasp the machine
8-10 inches (20cm-25cm) from the side. It should
only be placed on a sturdy clean flat level surface
able to support 150 lbs. (70kg). See Stand
instructions.
Keep the area around your laminator clear with
adequate space around it so you can feed receive
and trim mounted and/or laminated images.
Unpacking your Laminator
1. Open the box and lift the machine out (at least
two persons necessary!). Grasp the machine
8"-10" (200mm-250mm) from either side at
the bottom metal parts. Be careful! The
polyethylene bag is slippery!
2. Place the machine on the work area described
above.
3. Remove the protective molded foam.
4. Remove the polyethylene bag.
5. Inspect the machine for any physical damage
(if damage does exist report this to the Freight
Company on the BILL OF LADING. Contact
Your Dealer to determine if a replacement machine
should be shipped to you.
NOTICE! Retain original packaging.
Failure to return machines properly packed in
original packaging will impose a fifteen
percent restocking fee plus costs to repair
shipping damage. Contact Technical Service
for Return Authorization (see rear cover).
etting up your Laminator
The PHOENIX laminator should be installed
next to a power/main outlet. We do not
recommend using an extension cord but if
needed make sure the cord rating meets or
exceeds the machine rating.
The plug and the outlet must be easily
accessible. Please ensure that you plug your
laminator into a grounded three-prong
outlet. Please ensure that the total load of the
other items using the same circuit breaker do
not exceed its breaking value.
The US versions of the PHOENIX machines
are provided with a fixed power cable and
NEMA 5-20 plug.
Use 120Vac 20A grounded outlet
only.
110V 20 amp outlet
Using your PHOENIX 44
Plug the power cable into the grounded outlet
with appropriate service as described above.
Turn on power with main power switch. Roller
will turn continuously while power is on.
Depress the Heat switch and wait approxi-
mately 20 minutes for the unit to reach its
operating temperature. Also turn the Speed
on and set the Control Knob to zero so that
the roll heats uniformly. When Ready LED in-
dicator is constantly lit the PHOENIX lamina-
tor is ready for use.
CAUTION! et the Control Knob to the
“Open” position when not in use.
NOTE: The laminator may emit vapors the
first few times it is used. This is normal and
will cease after several minutes of use.
PHOENIX 44 LAMINATOR
ET - UP AND E LECTRICAL R EQUIREMENT
5

Tools Required
Philips head screwdriver
4mm Allen wrench
14mm wrench or adjustable wrench
tand Kit Contents (Figure 1)
(2) Side frames
(2) Cross straight supports
(8) 14mm Phillips screws & nuts
(4) 4mm Allen screws
Assemble cross supports (Figure 2)
Attach the cross supports to the
side frames. Position the nuts on
the inside of the stand. Leave
the bolts finger tight until all
of the stand has been assembled
in Figure 3. Then tighten all of the
screws securely.
Insure all of the bolts are
tightened before attaching the
stand to your Phoenix laminator.
Attach stand to Phoenix laminator
Place your Phoenix Laminator
on a flat secure surface. Rotate
the laminator gently onto the back
panel (do not pinch the power cord).
Having one person holding
the laminator remove the feet from
the bottom of the laminator and
attach the stand with
the 4mm screws supplied. The
angled side is the back. Tighten
securely. Then with 2 people lift
the Phoenix into position (Figure 4).
TAND A EMBY AND ET - UP (O PTIONAL )
6
Figure 1
Figure 2
Figure 3
Figure 4
PHOENIX 44 LAMINATOR
6

Tools Required
Philips head screwdriver
4mm Allen wrench
14mm wrench or adjustable wrench
Roll Kit Contents
(1) Dispensing Bar with tensioner
(2) Dispensing bar Support brackets
(1) Idler bar with 4mm allen screws
IMPORTANT! - Unplug you laminator
before installing the Phoenix Roll Kit
Remove the side panels
Lower the rollers to the closed or zero position.
Remove the roller gap control knob by taking off the
center cover of the Control Knob and unsrewing the
philips screw in the middle of the Control Knob (Figure 1)
and side panels gently and angle from the back
as the control panel will be attached to the circuit board
on the side frame (Figure 2).
Install Idler Bar (Figure 3)
Locate the pre-drilled holes in the sideframe in back of
the rollers. Attach the idler roll threading the 4mm
bolt through the hole in the side frame and tighten
with the corresponding nut. Repeat on the other side.
Install Roll holder (Figure 4)
Remove the upper back panel. Install roll
holder brackets with the 3 phillips screws.
Mount the roll holder in the bracket.
Replace the side panels and Control Knob.
Instructions for running cold films on Page 13
R OLL K IT A EMBLY (O PTIONAL )
PHOENIX 44 LAMINATOR 7
Figure 1
Figure 2
Figure 3
Figure 4

The Control Knob (see figure 1A) is located on
the right hand side of the laminator and should
be operated from this side. The control knob is
used to adjust the height of the rollers.
The Nip Settings are 1/4"(6mm) 3/16" (5mm)
1/8" (3mm) and 1/16" (1.5mm) correspond to
Pouch Board thickness. There is also a closed
position - 0" (0mm) for film and paperboard
applications. Select the setting that indicates
the thickness of the material you are using.
To Operate the Nip Control Knob
1. Grasp it with your right hand and push
in approximately 1/4" (6mm).
2. Once the knob has disengaged from the
stop it may be rotated forward or
backward (clockwise or counterclockwise as
viewed from the right hand side of the unit).
3. Once the indicator has reached the desired
nip setting release the knob or gently
pull the knob out to lock it in place. See
Figure 1A.
Figure 1A
Caution! et the Nip Control Knob to
the “Open” position when not in use.
Note: When the machine is warming
up, set the control to the zero or
closed position.
REAR PAN
R OLLER GAP CONTROL KNOB
R EAR P ANEL
Note: Always switch the power off when the
machine is not in use. The Control Panel is
always powered when the main power is
on.
In case of Emergency: Turn off the main
power breaker or unplug the machine
from the power outlet.
Caution! Turn off the main power
breaker and unplug the machine when
removing the side panels and performa-
ing maintenance on your Phoenix.
To turn the machine on and off use the
main breaker switch below in figure 1B.
“O” is off and “1” is on.
Figure 1B
PHOENIX 44 LAMINATOR
8

Figure 3
Location of Control Panel
Figure 2
O PERATIONAL CONTROL P ANEL
The Control Panel (see Figure 3) is lo-
cated on the top right of the machine. A
diagram of the Control Panel is shown
in Figure 2.
peed Control
The speed of the rollers is controlled in
the SPEED section of the Control Panel.
1. To turn the rollers on press the
‘On/Off’ pad once. The Green LED
light will turn on indicating the bot-
tom roller is turning. Note: the top
roller is free spinning as with all high
quality laminators. The PHOENIX will
automatically be set to the faster
‘Rabbit’ speed.
2. To adjust the speed of the rollers
press the ‘Rabbit’ for the faster speed
(approximately 1 foot per minute) or
the ‘Turtle’ (approximately 6 inches
per minute) for the slower speed. All
standard pouches and pouch boards
with inkjet paper up to 11 mils thick
should work on the faster speed. For
thicker materials.use the slow ‘Turtle’
speed. The LED light which is on is
the current speed of the PHOENIX.
Heat Control
The Heat of the rollers is controlled in the
HEAT section of the Control Panel. When you
turn the PHOENIX on the heat will be off and
the rollers cold. The LED Light above the
‘On/Off’ switch will be the color red.
1. To turn the heat on press the ‘On/Off’
pad once. The LED above the ‘On/Off’
the PHOENIX will automatically be set to
the ‘Pouch’ heat setting and the ‘Pouch’
LED will be lit. The LED above the ‘On/
Off’ switch will be Green indicating the
roller is heating. When that light be-
comes yellow the PHOENIX is ready to
process your pouch boards.
2. To adjust the heat of the rollers
press the ‘Pouch’ button when using
pouch boards mounting boards or flexi-
ble pouches. The ‘Pouch’ heat setting is
the higher setting and has a roll face
temperature of 150° Celsius. The Roll
temperature is a lower 90° Celsius (195°
Fahrenheit) for use with standard inkjet
laminating films.
In case of Emergency: Turn off the main
power switch or unplug the machine
from the power outlet. Open the Roller
Gap Control to its fully open position
and remove your work.
PHOENIX 44 LAMINATOR 9

PHOENIX 44 LAMINATOR
M OUNTING WITH H EAT A CTIVATED B OARD
Using a Heat Activated Mounting Board
Refer to the instruction sheet packed with
each box of Mounting Boards for specific
information on mounting with a heat acti-
vated Boards. All boards can not be thicker
than 1/4” inch and must use low tempera-
ture adhesive.
Also refer to the instruction sheet for
information on Compatible Media Process
Conditions and technical information.
Place the image to be mounted on the ad-
hesive-coated side of the mounting board
(dull side of the board).
Cover your print with the "cover sheet" as
marked (included with each box of
Mounting Boards or use a sheet of non-stick
silicon paper). If the release paper is
longer fold over the narrow end to make a
’pocket’ for the board to be inserted into.
Place your board with your print on it into
the fold of the cover sheet.
If you are overlaminating with roll film
while using Phoenix mount boards, do
not use any cover sheets but insure the
laminating film is equal to or wider
than your mount boards.
Set the Roller Gap Control knob to the cor-
rect setting that matches the Mounting
Board thickness.
Insert the board into the inlet opening. En-
sure the board will enter centered and
straight. A gentle push may be required to
start the board into the laminator.
Hold the edges of the board until it is en-
gaged in the unit and the laminator begins
pulling it on its own.
The board will feed through the lamina-
tor and automatically exit at the rear of
the unit.
CAUTION! The board will be hot! Al-
low it to lie flat while cooling.
CAUTION! USE ONLY WITH HEAT ACTI-
VATED MOUNTING BOARDS 1/4" (6mm)
THICK OR LESS.
DO NOT USE PLYWOOD METAL
CARDBOARD SHARP OR HARD BOARD
WITH RAGGED EDGES OR ANY TYPE OF
PLASTIC.
MAKE SURE THAT ALL MEDIA FED INTO
THE LAMINATOR IS FREE OF STAPLES
PAPER CLIPS OR OTHER HARD
OBJECTS.
Foam board may be cut or trimmed using
a sharp hobby knife such as an X-ACTO
Knife. Lightly score the paper first. Sev-
eral passes of the knife may be required.
We recommend a professional grade
trimmer with a standard utility knife
blade be used for professional and fast
results.
NOTE:
Ragged cuts or pulling of the foam
board indicates a dull blade.
10

L AMINATING WITH P OUCH B OARD
Refer to the instruction sheet packed with
each box of Pouch Boards for specific
information on mounting/laminating with a
Pouch Boards.
In addition refer to the instruction sheet for
information on Compatible Media Process
Conditions and technical information.
Carefully examine the board to determine
which edge is sealed. There is a 1/8" (3mm)
sealed edge where the laminate film is at-
tached to the board.
Starting at one of the corners opposite the
sealed edge gently lift and peel back the film.
Care should be taken not to break the sealed
hinge.
Center the image to be laminated on the
board and lay the film back over it.
Set the Control Knob to the correct setting
that matches the Pouch Board thickness.
Ensure that the PHOENIX rollers are turned on
and set either at the ‘Rabbit’ or ‘Turtle’ speed.
With the Heat is on set at the ‘Pouch’ setting
and the LED light is Yellow indicating the roll
temperature is ready to use.
Note: If your laminate appears cloudy or
your print is not fully adhered to the
board, adjust the speed to the ’Turtle’
setting and reprocess your pouch board.
Slowly insert the Pouch Board into the inlet
opening. Ensure that the Pouch Board will
enter centered and straight. A gentle push
may be required to start the board into the
laminator.
Hold the edges of the Pouch Board until it is
engaged and the laminator begins pulling it
on its own.
The Pouch Board will feed through the
laminator and automatically exit at the rear
of the unit.
CAUTION! The board will be hot! Allow
it to lie flat while cooling.
If there is any dirt or adhesive on the sur-
face of the board it can be removed by
dampening a lint free cloth with Isopropyl
Alcohol (IPA) and wiping the surface.
CAUTION! Always use care when using
Isopropyl Alcohol (IPA)! IPA is very
flammable. The flash point of IPA is 11ºC
(51.8ºF). The self-ignition temperature is
400ºF (752ºF).
PHOENIX 44 LAMINATOR 11

E NCAP ULATING WITH F LEXIBLE F ILM P OUCHE
Refer to the instruction sheet packed with
each box for specific information on encap-
sulating Flexible Film Pouches.
In addition refer to the instruction sheet for
information on Compatible Media Process
Conditions and technical information.
The Flexible Pouch consists of two
pieces of film that are hinged at one end
along a short side. Separate the two pieces
starting at the end opposite the hinge. Take
care not to break the hinged seal.
1. Insert the article to be laminated in the
pouch so there is at least a 1/8" (3.5mm)
board around each of the sides. This
ensures that moisture never reaches the
image.
2. Place the pouch with the image on the
sled included with the Flexible Pouches or
Purchase Sleds separately.
Note: The led is a non-stick board used
to assist in the handling of large Flexible
Pouches. It is made of materials that
will not damage or cause excessive
wear to your PHOENIX Laminator.
3. Smooth out any wrinkles with the side of
your hand or a soft flexible squeegee.
4. Tape the leading edge of the pouch to the
sled using masking tape.
5. Adjust the Control Knob to the
3/16" (5mm) setting for the Sled included
with your Dealers Flexible Pouches. (Or set
the thickness to the thickness of the non-
stick sled material you are using.)
6. Ensure that the PHOENIX rollers are
turned on and set either at the ‘Rabbit’ or
‘Turtle’ speed. Turn the Heat is on set at
the ‘Pouch’ setting and wait for the LED light
is Yellow indicating the roll temperature is
ready to use.
Note: If your laminate appears cloudy
or your print is not fully adhered to the
board, adjust the speed to the ’Turtle’
setting and reprocess your pouch
board.
7. Slowly insert the sled with the Flexible
Pouch on top into the inlet opening.
8. Ensure that the sled is centered and
straight. A gentle push may be required to
start the sled into the laminator.
9. Hold the edge of the sled until it is en-
gaged and the laminator begins pulling it
on its own.
10. The sled should feed through the lami-
nator and automatically exit at the rear of
the laminator.
CAUTION! The led will be hot! Allow it
to lie flat and cool before removing the
tape.
If there is any dirt or adhesive on the sur-
face of the board it can be removed by
dampening a lint free cloth with Isopropyl
Alcohol (IPA) and wiping the surface.
CAUTION! Always use care when using
Isopropyl Alcohol (IPA)! IPA is very flamma-
ble. The flash point of IPA is 11(51.8).The
self-ignition temperature is 400(752).
PHOENIX 44 LAMINATOR
12

L AMINATING WITH R OLL F ILM
PHOENIX 44 LAMINATOR
Refer to the instruction sheet packed with
each box for specific information on the roll
film you are using. We recommend
using low temperature adhesives on
either a 3 or 5 mil construction.
The Phoenix is designed for roll films to
laminate one side of a print over-laminate
a mounted print or simultaneously mount
and laminate using heat activated board.
If you are laminating one-side of a print
place your print on a sled or non-stick
board. Phoenix sleds are all 3/16” thick.
We recommend starting with the tempera-
ture to the ‘Roll’ setting and the Speed to
the ‘Rabbit’ setting.
If you are simultaneously mounting
and laminating using a heat activated
board, we recommend using boards
which use a low temperature
adhesive (i.e. below 160ºF). et the
temperature to ‘Pouch’ and the speed
to the ‘Rabbit’ setting.
1. Set the Control Knob to the 3/16”
thickness setting.
2. Mount you laminate roll on the top roll
dispensing bar/supply mandrel. Note:
The Roll should be mounted on the
Phoenix such that the film is being
pulled from the bottom of the roll so
that you are looking at the adhesive or
dull sized of the film.
3. Pull the film from the roll place it be-
hind the idler bar and drape the film over
the top roller and roller nip opening (the
adhesive on the film should begin to ’wet-
out’ or activate.
4. Using a Threading board (3/16” thick is
supplied with the Phoenix Roll Kit) push
the threading board into the nip of the roll-
ers. Turn the Motor control on and select
either the ‘Rabbit’ or ‘Turtle’ speeds. The
threading board will be automatically
pulled through the Phoenix with your roll
film.
5. Inspect the film on the top roll of the
Phoenix. It should be smooth and taught
against the roll. If it is not pull the thread-
ing board on the back of the Phoenix until
the film smooths out. Once smooth you
are ready to laminate.
6. Ensure that the PHOENIX rollers are
turned on and set either at the ‘Rabbit’
speed. With the Heat is on set at the ‘Roll’
setting and the LED light is Yellow indicating
the roll temperature is ready to use.
7. Set the Control Knob to match the thick-
ness of the board you will be using.
8. Insert your board (either the sled with
your print/mounted print/or heat activated
board. with your print into the nip of the
rollers. It will automatically be pulled
through the laminator and over-laminated.
9. If laminating more than one print insert
it after the first print is done. Check the
film on the roll face first. If it has some
wrinkles pull you first print unit they disap-
pear and adjust the tension on the dispens-
ing bar to maintain the film being smooth
on the roll face.
10. Trim your print after it exits the Phoe-
nix.
Note: If your laminate appears cloudy
or your print is not fully adhered to the
board, adjust the speed to the ’Turtle’
setting and reprocess your pouch
board.
Caution: Do not trim near the rollers.
Cuts and nicks in the roller can effect
the quality of your laminating and re-
quire maintenance. Cuts and nicks in
the roll face are not covered by the
Warranty.
13

PHOENIX 44 LAMINATOR
C LEANING YOUR PHOENIX L AMINATOR
Cleaning the Outside of the Laminator:
CAUTION! Disconnect the laminator
from the power supply before cleaning.
The laminator may be cleaned with a lint-
free cloth lightly dampened with a mild
soap and water solution. Do not use a
spray-on cleaner.
Do not immerse any part of the laminator in
water or other liquid.
Do not use an abrasive cleaner which can
damage the painted surfaces.
Do not allow water or liquids to enter the
electrical circuits which may cause personal
injury and/or damage the equipment when
power is applied.
Cleaning the Rollers
The laminating rollers of your PHOENIX should
be periodically cleaned of adhesive build up that
might occur during normal operation.
IMPORTANT! Clean the laminating rollers to
prevent adhesive build-up and to ensure quality
output. Adhesive build-up may eventually dam-
age the rollers.
When laminating a small amount of adhesive
will squeeze out between the laminate films and
onto the top and bottom rollers. This residue
accumulates through normal use and can be
easily cleaned off the rollers.
Use a Cleaning Board for regular cleaning:
A new sheet of 3/16” foam board may be
used to clean the rollers. Simply run the new
board through the machine to remove any
built up adhesive.
1. Turn on the unit. Once the machine has
reached process temperature set the
Control Knob to 3/16" (5mm).
2. Slowly insert the Cleaning Board into the
inlet opening. Ensure that the board enters
centered and straight. A gentle push may
be required to start the board into the
machine. Hold the edges of the board until
it is engaged in the unit and the laminator
begins pulling it on its own.
3. The board will feed through the laminator
and automatically exit at the rear of the
unit.
CAUTION! THE BOARD WILL BE HOT!
Allow the board to lie flat while cooling.
For heavier deposits of adhesive on the
rollers, turn your unit off and let it cool. Rub
the rollers with Isopropyl alcohol and a
Scotchbrite pad to remove the adhesive build-
up.
14

PROBLEM PO IBLE CAU E OLUTION
T ROUBLE - HOOTING / T ECHNICAL ERVICE
The Red LED Light above the
rollers does not come on in-
dicating the Main power
switch is turned on.
The Power cord is not
plugged in fully.
The main breaker is tripped.
The circuit breaker is tripped.
Check the Power cord.
Turn the breaker to the on.
Reset the circuit breaker.
Pouch Board is not being
pulled into the PHOENIX or
the motor is making a louder
humming noise or is stalling.
Only after pushing very hard
is the board pulled into the
PHOENIX.
The Pouch Board is too thick
for the setting on the Roller
gap control Knob.
The set screw on the roller
gear may be loose
Change the setting on the
Roller gap control to the next
thicker setting.
Contact Technical Service for
instructions how to tighten
set screw.
The Quality of the lamination
is poor. There are silvery ar-
eas on dark surfaces which
are visable or the edges of
the image are not sealed
well.
The roller temperature is too
low.
The Speed is too fast.
The Roller pressure is too
low.
Contact Technical Service for
instructions on how to adjust
temperature.
If using the ‘Rabbit’ speed
try the ‘Turtle’ speed. Other-
wise contact Technical Ser-
vice for instructions on how
to adjust speed.
Adjust the setting on the
Roller Gap Control to the
next narrower setting.
The quality of the lamination
shows bubbles or ripples.
The Roller temperature is too
high.
The Speed is too slow.
There is too much pressure.
Contact Technical Service for
instructions on how to adjust
temperature.
If using the ‘Turtle’ speed
try the ‘rabbit’ speed. Other-
wise contact Technical Ser-
vice for instructions on how
to adjust speed.
Adjust the setting on the
Roller Gap Control to the
next thicker setting.
There are wrinkles in either
the flexible pouch or pouch
board.
There is too much pressure.
The seal of the leading edge
is not smooth.
Adjust the setting on the
Roller Gap Control to the
next thicker setting.
Re-tape the entire leading
edge smoothly
PHOENIX 44 LAMINATOR 15

PARE P ART / T ECHNICAL ERVICE
Technical ervice
If the machine does not reach temperature
or you do not get the results you desire
please contact your Technical Service
Representative. When calling for Technical
Service please have the Laminator Serial
Number available.
Please contact your distributor or sales
person for replacement parts.
Your laminator is covered by a one-year
Warranty as described in this manual.
ervicing and replacement parts
Service and maintenance must be performed
fully in accordance with the instructions.
Servicing by any unauthorized technician
voids the warranty. A service technician
must use replacement parts specified by
Technical Service.
NOTE! Service Technicians must perform
safety checks after completing any service or
repairs to the laminator.
P HOENIX A UTHORIZED R EPAIR C ENTER
PHOENIX 44 LAMINATOR
North East
Stover Graphics
7A Railroad Avenue Ext.
Beacon Falls CT 06403
203-729-2846
Mid West
Film Source International
13878 Parks Steed drive
Earth City MO 63045
314-739-4400
West Coast
Film Source International
1487 North Main Street
Orange CA 92867
800.831.8947
Mid Atlantic
Film Source International
6601 S Laburum Avenue
Richmond VA 23231
804.226.0400
outh
Smooth Finish
2385 Black Rock Drive
Duluth GA
770.235.9374
16

M OUNTING & L AMINATING T ERM
Cleaning Board:
Board used to capture any adhesive that may be
clinging to the rollers.
Cold Mode:
Heat is off.
Cover heet:
Release paper to be placed on the surface of
mounting boards.
Roller Gap Control Knob:
Adjusts the space between the rollers on the
PHOENIX 44.
Flashing Temperature Light:
The machine has not reached temperature.
Film:
A synonym used for laminate. The material used
in the laminating and encapsulating process.
Flexible Pouch:
Plastic Film Pouch for laminating paper.
Heat-Activated Films:
Films with an adhesive activated when heat is
applied. Once applied to an image the adhesive
forms a strong bond between the laminate and
the image.
Hot Mode:
Heat is on.
Laminator:
A machine used to mount and laminate images.
LED:
Light Emitting Diode (light).
Mounting Board:
An adhesive coated board used for mounting
images.
Nip:
The spot where the top and bottom rollers
meet.
Out-Feed:
The back of the laminator where completed
images emerge.
Pouch Board:
An adhesive coated board with an over-
laminate attached.
Pre-Coating:
The process of coating a substrate with an
adhesive mounting film onto which an image
can be mounted.
Pressure- ensitive Films:
Films with an adhesive that is activated when
pressure is applied forming a bond between
the protective laminate and the surface of the
image. Used primarily for fast mounting
applications and recommended for heat-
sensitive thermal and photographic prints.
Release Liner:
The backing on a pressure-sensitive film or
mounting adhesive used to keep the film from
sticking to itself. After peeling the release liner
off the adhesive layer becomes exposed.
Roller Height:
The space between the rollers.
led:
A 3/16” (5mm) non-stick board used to place
flexible pouches to aide the laminating
process.
PHOENIX 44 LAMINATOR 17

PHOENIX 44 LAMINATOR
P HOENIX PECIFICATION
18
Dimensions
Height 15.25”
Width 17”
Length 56”
Roll Dimension 4”
Net Weight 145 pounds
Shipping weight 200 pounds
Operating tandards
Minimum Speed 6”/minute
Maximum Speed 12”/minute
Minimum temperature 195° Fahrenheit
Maximum temperature 300° Fahrenheit
Roll Core size 3” Inside Dimension (ID)
Maximum Roll size 6” Diameter
Roller Gap/Nip Settings
0 Closed (Rolls touch)
1/16”
1/8”
3/16”
1/4”
Stand Height 30”
Electrics
U.S. Version 110V/60Hz 17A
U.S. Plug Configuration AC Plug 3-Wire NEMA 5-20 Male
International 220V/50Hz 11A
Item Number ML44

1 2 3 4
4 3 2 1
Title
Number Revision Size
A4
Date: 21-Mar-2008 Sheet o
File:
C:\Documents and Settings\yg\ \




.DDB Drawn By:
L
N
1
2
AC110V
QA
C
speed setting plate
control panel
RT
heating tube
solid state relay

Phoenix
wiring diagram
Ademco


1
2
3
4
5
solid state relay
Q A switch
XB junction
SR
DZ47-32 25A
XB
2P
20A
SR
280V/50A
RT heat-sensitized resistance PT1000
M
motor
YN80-25/110V speed rate 1:500
6
7
8
heating tube
control panel
speed setting plate
115V/2000W
Kr
9
Temp.switch 150 degree, closed normally
20071212
L
N
Text
Text
7
11
13
N
3
4
8 2
1 7 5 6
20 18 16 14
5
N
t
