DVD-2930CI
DVD Audio-VIdeo / Super Audio CD Player
DVD-Audio/Video & Super Audio CD Player
with Full 10bit HD Video Circuit
Video Section
■ Latest I/P converter from Silicon Optix, Inc.
The DVD-2930CI uses the latest 10-bit I/P converter “REON-VX” developed
through a joint development effort that merged image processing algorithms of
Silicon Optix, Inc., and Denon video technology on the foundation of an image
processing device. This 10-bit processing offers high conversion performance
and dramatically improves motion detection capability.
Multi-Directional Diagonal Filter (MDDF) technology, used
for the first time in the DVD-2930CI, which accurately
detects and corrects the directionality of lines on a per-
pixel level to avoid "jaggies" that easily appear when video
sources are I/P converted, ensuring smooth picture play-
back.
■ Denon Pixel Image Correction, for more natural contour correction
The Denon Pixel Image Correction feature that incorporates original Denon
enhancement technology and makes high-definition video correction possible,
has been advanced to even greater heights in the DVD-2930CI. Denon Pixel
Image Correction performs detection and correction through 10-bit processing to
significantly improve contour correction. This new contour correction circuit uses
enhancement processing technology that also considers the influence of pixels
surrounding the target pixels. It uses new algorithms to sample and analyze a
total of 9 pixels of video data around, and including, each target pixel. Video
images are detected and processed in vertical, horizontal, and diagonal directions
at a highly detailed per-pixel level to produce contours that are visually more nat-
ural and processed to suppress ringing noise and other artifacts that easily occur
during enhancement. By performing the type of processing that is most effective
for the current video image, the picture is free of degradation and appears more
natural.
■ High-performance video scaler capable of 1080p output for HDMI
“REON-VX”also works as the high-performance video scaler in the DVD2930CI.
This high-precision 10-bit scaler works with HDMI digital video output signals. This
scaler executes optimum conversion to suit the output to the independent HDMI
transmitters. Users can enjoy the best picture quality for their particular applica-
tions. Also this scaler can output PC resolution VGA/XGA/WXGA and SXGA.
■ Dual Discrete Video Circuit (DDVC)
The DVD-2930CI's video circuit features Denon's own DDVC technology
designed to enhance the quality of video signals. The use of dedicated circuits
–one independent block for composite and S-video signals, another block for
component signals, and a dual DAC configuration with built-in video encoder –
has made it possible to reproduce detailed video images with greater precision. In
order to bring out the maximum quality from both video and audio signals, the
DVD-2930CI has a discrete configuration in which the video, audio, and digital
blocks that comprise this universal player are all completely isolated from each
another in terms of their circuit configuration, boards, and power supplies. Denon
engineers have used the expertise gained from their development of earlier universal
players to design a configuration that thoroughly suppresses mutual interference
among the circuits and prevents noise from affecting the video and audio signals.
■ High-speed, high-precision 12-bit 216-MHz video DAC
To ensure that high-grade video signals from the latest high-performance I/P con-
verter are reproduced with utmost fidelity to the original images, the DVD-2930CI
has an extremely fast and accurate 12-bit, 216-MHz video DAC. Oversampling of
8x for Progressive and 16x for Interlaced signals results in sharp, detailed pic-
tures. Composite, S-video and component signals each have their own dedicated
video DAC, a design that enhances the reproduction of low-level video signals
and reproduces high-definition images that are faithful to the original. In addition,
Noise Shaped Video (NSV) technology is used to improve the S/N of video signals
and further boost their linearity.
■ Supports fine picture quality adjustments
Besides the DPIC feature, a total of 15 picture quality adjustments are possible,
including contrast, sharpness, white level, chroma level, noise reduction settings,
and gamma. Up to five combinations of settings can also be stored in memory,
giving the user freedom to adjust picture quality in considerable detail according
to individual preferences.
■ Custom Integrated
• RS232C serial command control
• Remote in/out IR command control
• Discrete Power on/off command
• 480i output capable for HDMI
*1) Version 1.1 compliant. HDMI audio output capacity is dependent on the monitor being used.
*2) HDMI output is HDCP compliant. Video cannot be viewed if connected to a monitor that does not support HDCP;
video can be viewed only on HDCP-compliant monitors.
*3) HDMI 1080p output is 50/60 Hz refresh rate only.
DVD2930CI_E3.qxd 06.8.28 18:59 Page 1

■ Others
•Simultaneous output possible for all video signals
•Supports PAL and NTSC
Audio Section
■AL24 processing plus, original DENON technology for high-quality audio
The DVD-2930CI employs Advanced AL24 Processing, the ultimate analog wave-
form reproduction technology developed by Denon, for use during PCM signal
input (during stereo signal processing). In addition to the data expansion of exist-
ing AL24 Processing Plus technology, algorithms developed by Denon for use in
large-capacity calculation processors such as DSPs and FPGAs are used to
interpolate data along the time axis and up-converted sampling is used to achieve
natural interpolation without losing original data. Greater optimization in digital fil-
tering has also been achieved for ringing-free pulse response and for pulsive
music data and attack sounds. This results in more natural reproduction of spa-
tial information such as the delicate nuances in the music, the locations of the
performers, and the breadth, height and depth of the concert hall.
For multi-channel linear PCM audio playback, AL24 Processing Plus technology
works to faithfully reproduce the original sound of recordings.
■All channel equal 24-bit, 192kHz Audio D/A Converter
The DVD-2910 uses a 24-bit, 192-kHz audio D/A converter that is well pro-
tected from noise caused by fluctuations in current from the power supply.
Since the level of quantization noise within the frequency range is uniform for
all frequencies, this D/A converter ensures that all the sound you hear is as
clear and noise-free as possible.
■Pure Direct mode, for greater purity in the audio signal
■DENON Link 3rd, for high-grade audio transmission
■HDMI output, for multi-channel audio
■Bass management function tailored for home theater environments
Construction
■Construction designed to thoroughly suppress vibration and mutual
interference among circuit blocks
•Three-box layout to isolate circuits and minimize mutual interference
•Thorough vibration-resistant construction
■DENON original high-accuracy drive mechanism
Other Features
■Supports playback of a wide variety of discs
■Playback frequency ranges of Super Audio CDs are switchable
(50 kHz / 100 kHz)
■ Independent bass management for analog audio output and HDMI audio signals
■Remote controller with backlight keys
■Wide pitch pin terminal
Output Terminals For Every A/V System
Video outputs
HDMI: 1
Component: 1 set
Composite: 1
S-Video: 1
Audio outputs
Optical digital: 1
Coaxial digital: 1
DENON Link: 1
Analog (L/R): 1 set
5.1-channel (FL/FR/C/SL/SR/SW): 1 set
Specifications
Video Section
Signal system
NTSC
Disc played
DVD Audio/Video, Music CD, SuperAudioCD, CD-R/RW(audio/MP3/WMA/JPEG),
Video CD, DVD-R/RW(Video mode/VR mode), DVD+R/RW/Picture CD
Video outputs
Composite Video Output
1.0 Vp-p (with 75 ohms load)
S-Video Output
Y; 1.0 Vp-p (with 75 ohms load),
C; 0.286 Vp-p
Component Video Output Y, Pb/Cb, Pr/Cr:
Y; 1.0 Vp-p (with 75 ohms load),
Pb/Cb; 0.648 Vp-p (with 75 ohms load),
Pr/Cr; 0.648 Vp-p (with 75 ohms load)
Audio Section
Frequency response
DVD
2 Hz - 88 kHz (192 kHz sampling),
2 Hz - 44 kHz (96 kHz sampling),
2 Hz - 22 kHz (48 kHz sampling)
Super Audio CD
2 Hz - 100 kHz
CD, VCD
2 Hz - 20 kHz
Signal-to-noise ratio
118 dB
Dynamic range
106 dB
Total harmonic distortion
0.001%
General
Power supply
AC 120 V, 60 Hz
Power Consumption
45 W
Dimensions
17.1”(W) x 4.0”(H) x 15.2”(D),
434 (W) x 102 (H) x 386 (D) mm
Weight
16.8 lbs, 7.6 kg
Denon Canada Inc.
505 Apple Creek Blvd, Unit 5, Markham, Ontario, Canada L3R 5B1
TEL: [phone] ca.denon.com
Denon Electronics (USA), LLC.
100 Corporate Drive Mahwah, New Jersey 07430 USA
TEL: [phone] www.usa.denon.com
Denon Brand Company
D&M Building, 2-1 Nisshin-cho, Kawasaki-ku, Kawasaki-shi,
Kanagawa, 210-8569, Japan
www.denon.com
16760806 A
DVD-2930CI
* Design and specifications are subject to change without notice.
