Denon DHT590BA - DHT Home Theater System User manual

DHT-590BA
Home Theater System
System Power of 650W 5.1 Home Theater System built for Blu-ray Disc Player High
Denition Audio and Video, featuring the Denon AVR-590 receiver and Boston
Acoustics MCS 90 speaker system.
Bullet points
™
®
Color : Black
New model information
AVR-590 Main Features
One Cable HD Solution for easy connection
• 3 HDMI audio/video inputs
• High Denition Audio Decoding, Dolby TrueHD and DTS-HD Master Audio format
support
• All sources are upconverted to HDMI
• 1080p, xvYCC, Deep Color HD video pass-through
No need to adjust volume between TV programs and commercials
• Audyssey Dynamic Volume technology dynamically monitors the input
audio signal and automatically adjusts volume level in real time.
• Audyssey Dynamic EQ technology monitors the volume level and
provides automatic tonal balance compensation to ensure natural sound
quality, even when listening at low volume levels.
Denon Design Solutions for Maximizing Content Quality
• Identical quality and power for all 5 channels, 110W x 5ch (6 ohms)
• Discrete devices for ultimate performance in each block
• New 32-bit oating point high precision DSP
• Dolby Pro Logic IIz 7.1 height channel processing support
Digital Media Connectivity
• iPod Audio/Photo and Video playback (optional ASD-11R)
• Network Audio/Photo Ready (optional ASD-3N/3W and new 51 series)
Boston Acoustics MCS 90 Features
Two way design satellite speakers
• 3” mid-bass drivers and 1/2”soft dome tweeter
• Reduced Bae Diraction Design for wider, smoother dispersion
• MagnaGuard video shielding for front and surround speakers
• Adjustable footings
• Built-in wall mount brackets
• Changeable grilles to match your enviroment (optional)
Center speaker
• Dual 3” mid-bass drivers
• 1/2” soft dome tweeter
• Reduced Bae Diraction Design for wider , smoother dispersion
• MagnaGuard video shielding
• Adjustable footings
• Built-in wall mount brackets
• Changeable grilles to match your enviroment (optional)
Matching Subwoofer
• 8” down-ring design
• 100 watt power amplier
• Deep Channel Design (DCD) for more bass from less amplier power

Other features
AVR-590 Input / Output Terminals:
IN HDMI x 3
Component x 2
S-Video x 1
Composite (Front x1) x 4
Analog Audio (Front x1) x 5
Digital OPTICAL x 2
Digital COAXIAL x 1
OUT HDMI Monitor x 1
Component Monitor x 1
Composite Monitor x 1
REC x 1
Analog Audio REC x 2
Audio PRE out (SBL/SBR/SW) x 3
Others Dock Control Port x 1
FM Tuner Antenna x 1
AM Tuner Antenna x 1
AVR-590 Main Specications:
Power amplier section
Rated output *THD gures are power amp stage values.
Front L/R 110 W + 110 W
(6 ohms, 1 kHz, THD 0.7%)
75 W + 75 W
(8 ohms, 20Hz - 20kHz, THD 0.08 %)
Center 110 W
(6 ohms, 1 kHz, THD 0.7%)
75 W
(8 ohms, 20Hz - 20kHz, THD 0.08 %)
Surround L/R 110 W + 110 W
(6 ohms, 1 kHz, THD 0.7%)
75 W + 75 W
(8 ohms, 20Hz - 20kHz, THD 0.08 %)
Preamplier section
Input sensitivity/impedance 200 mV / 47 kΩ/kohms
Frequency response
10 Hz ~ 100 kHz — +1, –3 dB (DIRECT mode)
S/N Ratio 98 dB (IHF-A weighted, DIRECT mode)
General
Power supply AC 120 V, 60 Hz
Dimensions (W x H x D) 434 x 171 x 377 mm
17-3/32” x 6-47/64” x 14-27/32”
Weight ( 10.8 kg )
( 23lbs 13oz )
MCS 90 Main Specications:
Satellite Speakers
Nominal Impedance 8 ohms.
Dimensions (WxHxD) 113 x 93 x 189 mm
4 3/8” x 4 11/16” x 7 3/8”
Weight 1.14 kg, 2.5 lbs / each
Center Speaker
Nominal Impedance 8 ohms
Dimensions (WxHxD) 321 x 95 x 145 mm
12 5/8” x 3 3/4” x 5 11/16”
Weight 2.1kg, 4.6 lbs
Subwoofer
Power supply AC 120 V, 60 Hz
Dimensions (WxHxD) 390 x 324 x 390 mm
15 3/8” x 12 3/4” x 15 3/8"
Weight 10.3kg, 22.7 lbs
A
A
HDMI
HD-TV
HDMI
HDMI
Blu-ray
Set Top Box
MCS 90 Sub Woofer
MCS 90 Speakers
17211207 A
Denon Brand Company
D&M Building, 2-1 Nisshin-cho, Kawasaki-ku, Kawasaki-shi,
Kanagawa, 210-8569, Japan
www.denon.com
Denon Electronics (USA), LLC.
100 Corporate Drive, Mahwah, New Jersey 07430 USA
TEL: [phone] usa.denon.com
Denon Canada Inc.
505 Apple Creek Blvd, Unit 5, Markham, Ontario, Canada L3R 5B1
TEL: [phone] ca.denon.com
*HDMI cables are not included
DHT-590BA Connections
