AVR-X3000

Integrated Network AV Receiver

So much to experience, Connected, Collected.

So easy to command:

Your IN-Command Series™ Integrated Network A/V Receiver is the heart

and brain of your networked home entertainment center.

Enjoy a wide variety of music and video entertainment in separate rooms.

The AVR-X3000 A/V receiver lets you enjoy both 3D video and immersive surround sound to your heart’s content. It is equipped with a powerful

7-channel amplier that delivers a rich, enveloping surround sound via Audyssey DSX or DTS Neo:X for height or wide channels in a 7.1-channel

conguration. The AVR-X3000 provides numerous features for enjoying entertainment, including AirPlay®for streaming music from an iTunes® library,

Spotify playback, internet radio broadcasts, playback of music stored on a networked PC or hard disk, and HD audio (up to 192 kHz) music sources.

The AVR-X3000 even has a multi-zone feature that lets other people enjoy music or video entertainment from a separate source in a different room

while you enjoy your own programs in the main room.

™

State-of-the-art Denon Solutions for Maximizing Content Quality

• Fully discrete, identical quality and power for all 7 channels (105 W x 7 ch)

• Audyssey DSX and DTS Neo:X for front height or front wide effects channels

for a more immersive surround experience

• 1080P & 4K Ultra HD (3840 x 2160) upconversion

• Analog to HDMI video conversion lets you run just one HDMI cable to your HDTV

• Audyssey MultEQ XT®automatically sets the speakers to suit the room’s listening environment

and the speakers’ characteristics

• Audyssey Dynamic EQ®improves surround effects at lower volume levels

• Audyssey Dynamic Volume® stabilizes volume levels for consistent sound

• Digitally transmitted play function for iPod® and iPhone® (via USB) for best sound quality

• High-performance 192kHz/24-bit D/A converters for all channels

• Denon’s proprietary Compressed Audio Restorer, to restore sound quality

from compressed music sources such as MP3 tracks

Connectivity

• Multi-room audio lets you enjoy 5.1 sound with separate stereo audio in a 2nd room

• Networking with AirPlay®, Pandora®, Spotify & SiriusXM Internet Radio

• Convenient front panel HDMI input for connecting a camcorder or game console

• 7 HDMI inputs (1 on the front panel)

• 2 HDMI outputs (1 for multi-room video)

• Supports HDMI with 4K Ultra HD (3840x2160), 3D, Audio Return Channel, Deep Color,

x.v.Color, Auto Lipsync and HDMI CEC (Consumer Electronics Control)

• Multi-room audio (2 zones, 2 sources)

• Power amplier assign function, for versatility in using the AVR-X3000 for different purposes

- 5.1 channel + Front height speakers (FHL + FHR)

- 5.1 channel + Front wide speakers (FWL + FWR)

- 5.1 channel + Zone 2 stereo speakers

- 5.1 channel + Bi-amp front main (L/R) speakers

- 5.1 channel + Front B speakers

• Convenient front USB input for quick and easy connection of your portable device

Ease-of-Use

• InstaPrevue Technology, provides live picture-in-picture preview of

of connected active

HDMI sources

• Supports new “Denon Remote App” to simplify operation by Android & iOS tablet/smartphone

• New, easy-to-connect speaker terminals in a horizontal layout

• Comes with color-coded labels to easily identify the correct speaker cables

• New Setup Assistant with rich GUI (Graphical User Interface) with easy-to- follow setup instructions

• Comes with simple, easy-to-use remote controller

• Auto power off

• Front panel display features easy-to-read characters

Others

• Audyssey Installer Pro Ready

• Lower power consumption at standby 0.1 W

• Supports web control functions via your PC's web browser

• Remote control input and output (IR)

• AMX, Control4, Crestron, RTI, Savant, URC third party control support

• RS-232C serial I/O control interface

• Trigger output (150 mA)

Main Specications

Power amplier section Preamplier section

Rated output

*THD gures are power amp stage values.

Input sensitivity/impedance

200 mV / 47 kΩ/kohms

Front L/R 105 W + 105 W Frequency response

10 Hz ~ 100 kHz — +1, –3 dB (DIRECT

mode)

(8 Ω/ohms, 20 Hz - 20 kHz, THD 0.08 %) S/N Ratio

100 dB (IHF-A weighted, DIRECT

mode)

135 W + 135 W

(6 Ω/ohms, 1 kHz, THD 0.7%) FM section

Center 105 W Tuning frequency range 87.5 - 107.9 MHz

(8 Ω/ohms, 20 Hz - 20 kHz, THD 0.08 %)

135 W AM section

(6 Ω/ohms, 1 kHz, THD 0.7%) Tuning frequency range 520 - 1710 kHz

Surround L/R 105 W + 105 W

(8 Ω/ohms, 20 Hz - 20 kHz, THD 0.08 %) General

135 W + 135 W Power supply AC 120 V , 60 Hz

(6 Ω/ohms, 1 kHz, THD 0.7%) Power consumption 600 W

Surround Back L/R 105 W + 105 W (Standby 0.1 W, CEC standby 0.5 W)

(8 Ω/ohms, 20 Hz - 20 kHz, THD 0.08 %) Dimensions (W x H x D) 17 3/32" x 6 67/64" x 14 59/64"

135 W + 135 W 434 x 167 x 379 mm

(6 Ω/ohms, 1 kHz, THD 0.7%) Weight 23 lbs 9 oz, 10.7 kg

D&M Holdings Inc.

D&M Building, 2-1 Nisshin-cho, Kawasaki-ku, Kawasaki-shi,

Kanagawa, 210-8569, Japan

www.denon.com

Denon Electronics (USA), LLC.

D&M Canada

100 Corporate Drive, Mahwah, New Jersey 07430 USA

TEL: 201-762-6500

usa.denon.com

ca.denon.com

*Design and specications are subject to change without notice. *“Dolby”, “Pro Logic” and the double-D symbol are trademarks of Dolby Laboratories. *DTS is a registered trademark and the DTS logos, Symbol and DTS-HD are trademarks of DTS, Inc. *The terms

HDMI and HDMI High-Denition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries. *Windows Media and the Windows logo are trademarks or registered trade-

marks of Microsoft Corporation in the United States and/or other countries. *NSV is a registered trademark of Analog Devices, Inc. *“Made for iPod,” and “Made for iPhone,” mean that an electronic accessory has been designed to connect specically to iPod,

or iPhone, respectively, and has been certied by the developer to meet Apple performance standards. Apple is not responsible for the operation of this device or its compliance with safety and regulatory standards. Please note that the use of this acces-

sory with iPod, iPhone, or iPad may affect wireless performance. AirPlay, iPad, iPhone, iPod, iPod touch, and iTunes are trademarks of Apple Inc., registered in the U.S. and other countries.

New intuitive GUI (Graphical User Interface) Multi-room video and audio (2 zones, 2 sources)

New Denon Remote App for iOS and Android devicesConvenient HDMI input on the front panel AirPlay lets you wirelessly stream music from your iPod touch, iPhone

or iPad

4K Ultra HD (3840x2160) support (Video pass-through, video upscaling)

Our Integration Partners:

Ports

In HDMI (incl. Front 1) 7

Video (component) 2

Video (composite) 3

Analog audio 5

Digital audio (optical) 2

Digital audio (coaxial) 2

Out HDMI monitor 2 (1 Zone2)

Audio preout (Zone2 L/R) 1
