Denon AVR-1712 User manual

AVR-1712
AV Surround Receiver
New model information
Features
Surround Your 3D Video with Powerful, Realistic Sound
Connect the AVR-1712 7.1 HD-Audio receiver to a TV and Blu-ray disc player supporting 3D video and you’ll
be able to experience an exciting 3D theatre with powerful surround sound. The AVR-1712 lets you enjoy a
program source in the Main Zone (the room where the AVR-1712 is located) and in Zone 2 (another room).
Setup is extremely easy as the AVR-1712’s Setup Wizard guides you through the procedures for setting
the language, speakers connections and other items on your TV screen.
New Features
• Setup Wizard, providing easy-to-follow setup instructions
• Easy operation, Graphical User Interface
• GUI overlay on HD source
• 6-HDMI inputs and 1-output
State-of-the-art Denon Solutions for Maximizing Content Quality
• Fully discrete, identical quality and power for all 7 channels (125 W x 7ch)
• Stable power supply for high-quality sound and picture playback
• Featuring 3D pass-through technology
• High denition audio support, Dolby TrueHD and DTS-HD Master Audio
• Supports Dolby Pro Logic IIz processing
Connectivity & Future-ready Expandability
• Supports HDMI (V.1.4a with 3D, Audio Return Channel) Deep Color,
“x.v.Color”, Auto Lipsync and HDMI control function
• Power Amp Assign function, for versatility in using the AVR-1712 for different
purpose (Surround Back, Front Height, Zone 2, Bi-Amp, Front Speaker B)
Ease-of-Use
• Audyssey Dynamic Volume®, for real-time volume adjustment
• Audyssey MultEQ® XT and Auto Setup
- Tower type microphone for more accurate measuring
- Up to six measurement points
- High level resolution lters for satellite speakers and also subwoofer
Others
• Lower power consumption at stand-by 0.1 W (Standby)

D&M Holdings Inc.
D&M Building, 2-1 Nisshin-cho, Kawasaki-ku, Kawasaki-shi,
Kanagawa, 210-8569, Japan
www.denon.com
Denon Electronics (USA), LLC.
100 Corporate Drive, Mahwah, New Jersey 07430 USA
TEL: [phone]
usa.denon.com
18150411 A
State-of-the-art Denon Solutions for
Maximizing Content Quality
• Fully discrete, identical quality and power for all
7 channels (125 W x 7ch)
To faithfully reproduce the original surround sound, each
of the AVR-1712’s 7 channels is equipped with the same
power amp of equal power. Since these power amps also use
discrete circuits congured with parts strictly selected for their
contribution to high sound quality, rather than with low-cost
integrated circuits (ICs), the surround sound playback is of
impeccably high quality.
• Featuring 3D pass-through technology
By connecting a 3D-compliant Blu-ray disc player and
3D-compliant TV to the AVR-1712, you will have a 3D
home theater where you can enjoy high-definition sound
and video on a level you’ve never experienced before.
• High-denition audio support
The AVR-1712 has a decoder that supports Dolby TrueHD,
the audio format of Blu-ray disc players, and DTS-HD Master
Audio, another high-grade digital audio format.
• Dolby Pro Logic IIz
To let you enjoy an even richer spatial expression, the
AVR-1712 is equipped with a Dolby Pro Logic IIz processor.
By connecting Front Height speakers and using Dolby Pro
Logic IIz playback, you will be able to enjoy surround sound in
the vertical as well as horizontal direction.
• Minimum Signal Path for clear audio and video
signal
The “simple and straight” design concept has been thoroughly
implemented in the signal paths to contribute to immaculately
clean audio and video playback. Signal paths are as short as
possible to keep signal degradation in the audio and video
circuitry to an absolute minimum.
• Direct Mechanical Ground Construction, embody-
ing concepts for thorough vibration resistance
Vibration-resistant construction has been reviewed to thor-
oughly suppress the adverse inuences of vibration on sound
quality. The power transformers, a source of vibration, have
been securely mounted on the highly rigid bottom chassis.
Direct mounting of feet to the radiator in near proximity to each
other serves to suppress mutual vibration with the power
transformers and other sources of vibration.
• Compressed Audio Restorer to enhance
digital music files
Compressed Audio Restorer is Denon technology that
restores compressed music sources to their original pre-
compressed quality to give you a lively sonic ambience with
greater detail and depth.
Connectivity & Future-ready Expandability
• Dock connectivity for iPod
and network streaming
Network music can be enjoyed via
the Denon Networked Control Dock.
(Requires separately-sold ASD-3N,
ASD-51W or ASD-51N.)
• Supports HDMI (V.1.4a with 3D, Audio Return
Channel) Deep Color, “x.v.Color”, Auto Lipsync
and HDMI control function
•Power Amp Assign function, for versatility in
using the AVR-1712 for different purposes
The AVR-1712 supports up to 7.1 channels (FL/ FR/ C/ SL/
SR/ SBL/ SBR/ SW) for surround playback dened by the
Blu-ray disc format. To enjoy surround playback with the
AVR-1712’s Dolby Pro Logic IIz, you can reassign the power
amp from the two surround back channels (SBL/SBR) to the
two front height channels (FHL/FHR). Or by assigning the
SBL/SBR power amp to Zone 2, you can enjoy multi-room
audio playback, or to achieve higher-quality sound for 2-channel
stereo playback, you can configure the AVR-1712 for front
bi-amp operation. These are just some of the ways you can
arrange the AVR-1712’s amps to suit various listening styles.
Ease-of-use
• Setup Wizard, providing easy-to-follow setup
instructions
First select the language when prompted. Then simply
follow the instructions displayed on the TV screen to set up
the speakers, and so on.
• Easy operation via icon displays
The AVR-1712 includes one-touch Quick Selection buttons
that let you instantly select frequently-used video/music sourc-
es and surround modes. Icon displays on the buttons make it
easy to recognize the buttons’ functions.
• GUI overlay on HD source
You can easily make settings for your home theatre system
while viewing menus on the TV screen. These menu displays
can also be output to the monitor over HDMI.
• Pre memory remote control handset with Glow-Key
• Remote Setup Guidance
• Auto surround mode
• Sleep timer function
• Audio Delay function (0 to 200 msec)
• Muting level settings (Full/-40dB/-20dB)
• Audio level memory, capable of correcting dif-
ferent signal levels for each input device
• Variable subwoofer crossover switching
*Design and specications are subject to change without notice.
*“Dolby”, “Pro Logic” and the double-D symbol are trademarks of Dolby
Laboratories.
*DTS is a registered trademark and the DTS logos, Symbol, DTS-HD
and DTS-HD Master Audio are trademarks of DTS, Inc.
*HDMI, the HDMI logo and High-Definition Multimedia Interface are
trademarks or registered trademarks of HDMI Licensing LLC.
*Audyssey MultEQ® XT is a registered trademark of Audyssey Laboratories.
Audyssey Dynamic EQ®is a trademark of Audyssey Laboratories.
Audyssey Dynamic Volume®is a trademark of Audyssey Laboratories.
*iPod is a trademark of Apple Inc., registered in the U.S. and other countries.
Main Specications
Power amplier section Preamplier section
Rated output *THD gures are power amp stage values.
Input sensitivity/impedance 200 mV / 47 kohms
Front L/R 90 W + 90 W Frequency response
10 Hz ~ 100 kHz — +1, –3 dB (DIRECT mode)
(8 ohms, 20 Hz - 20 kHz, THD 0.08 %) S/N Ratio 100 dB (IHF-A weighted, DIRECT mode)
125 W + 125 W
(6 ohms, 1 kHz, THD 0.7%) FM section
Center 90 W Tuning frequency range 87.5 - 107.9 MHz
(8 ohms, 20 Hz - 20 kHz, THD 0.08 %)
125 W AM section
(6 ohms, 1 kHz, THD 0.7%) Tuning frequency range 520 - 1710 kHz
Surround L/R 90 W + 90 W
(8 ohms, 20 Hz - 20 kHz, THD 0.08 %) General
125 W + 125 W Power supply AC 120 V, 60 Hz
(6 ohms, 1 kHz, THD 0.7%) Power consumption
460 W (Standby 0.1 W, CEC standby 3 W)
Surround Back L/R 90 W + 90 W Dimensions (W x H x D) 17-1/8” x 6-3/8” x 15-3/64”
(8 ohms, 20 Hz - 20 kHz, THD 0.08 %) 434 x 162 x 382 mm
125 W + 125 W Weight 22 lbs 7.8 oz, 10.2 kg
(6 ohms, 1 kHz, THD 0.7%)
Ports
In HDMI x 6
Component x 2
S-Video x 1
Composite (video) (included front 1) x 3
Analog Audio (included front 1) x 6
Digital Optical x 1
Digital Coaxial x 1
Out HDMI Monitor x 1
Composite Monitor x 1
Audio Preout (SW) x 1
Phones x 1
Other Remote Control In/Out In 1 / Out 1
Microphone Port x 1
Dock Control Port x 1
FM Tuner Antenna x 1
AM Tuner Antenna x 1
